HERO GLAMOUR PROGRAMMED FI Manual de usuario

PREFACE

Thank you for selecting a . Hero MotoCorp GLAMOUR PROGRAMMED FI

We wish you many miles of continued riding pleasure in the years ahead.

We at are committed to demonstrate excellence in our environment Hero MotoCorp,

performance on a continual basis, as an intrinsic element of our corporate philosophy. To

achieve this we commit ourselves to continue product innovations to improve environment

compatibility, comply with all applicable legislation including environment legislation and

strengthen the green supply chain.

Your vehicle is conforming to latest (Bharat stage-VI norms) regulation for emission, safety &

noise levels. We are also using non asbestos brake shoes/pads and engine gaskets which are

environment friendly in nature.

This vehicle is fitted with a lighting feature known as “Automatic Headlamp ON”. The feature

is mandated for all 2 Wheelers by Ministry of Road Transport & Highways (Government of

India) vide notification GSR 188 (E) dated 22nd February 2016. This feature helps in

conspicuity for improving rider safety. The headlamp of this vehicle will always be lit ON when

the engine gets ON.

This booklet is your guide to the basic operation and maintenance of your new

. Please take time to read it carefully. As Hero MotoCorp GLAMOUR PROGRAMMED FI

with any fine machine, proper care and maintenance are essential for trouble-free operation

and optimum performance.

Your Authorised dealer will be glad to provide further information or Hero MotoCorp

assistance and is equipped to handle your future service needs.

Let us make this world a safer, healthier and more environment friendly place.

ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,

SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S

MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION AVAILABLE

AT THE TIME OF ITS PRINTING APPROVAL, AND THE ACCURACY OR

CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR GUARANTEED.

Hero MotoCorp Ltd RESERVES THE RIGHT TO MAKE CHANGES IN ITS

CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR INCURRING ANY

OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO REPRODUCE ANY

PART OF THIS PUBLICATION WITHOUT OBTAINING PRIOR WRITTEN

PERMISSION FROM Hero MotoCorp Ltd.

NOTE

ACCESSORIES SHOWN MAY NOT BE THE PART OF STANDARD FITMENT. IT IS

OUR ENDEAVOUR TO CONSTANTLY IMPROVE OUR PRODUCTS. THIS COULD

LEAD TO CHANGE IN PRODUCT SPECIFICATIONS WITHOUT NOTICE. Hero

MotoCorp Ltd ‘GLAMOUR PROGRAMMED FI’ COMPLIES WITH THE LATEST

EMISSION NORMS.

Pg. No.Pg. No.

CONTENTS

Pg. No.

VEHICLE IDENTIFICATION 1

VEHICLE VIEWS 2

VEHICLE SPECIFICATION 5

ACCESSORIES & MODIFICATIONS 7

ANTI-THEFT TIPS 7

VEHICLE 8 SAFETY

ŸImportant safety information 8

ŸaProtective pparel 9

SAFE RIDING TIPS 10

TIPS FOR HEALTHY ENVIRONMENT 11

PARTS FUNCTION 12

ŸIgnition switch 12

ŸI an I 3nstruments d ndicators 1

FEATURES 16

HANDLEBAR SWITCHES CONTROL 17

i3s (IDLE STOP START SYSTEM) 18

SIDE STAND INDICATOR/SWITCH 20

FUEL TANK 21

SEAT LOCK 21

HELMET HOLDER 22

USB CHARGER (OPTIONAL) 22

PRE-RIDE INSPECTION 23

STARTING THE ENGINE 24

RIDING 26

BRAKING 27

PARKING 27

TOOL KIT/FIRST AID KIT 28

CLEANING AND WASHING OF VEHICLE 28

MAINTENANCE 29

SAFETY PRECAUTION 30

MAINTENANCE SCHEDULE 31

SPARK PLUG INSPECTION 34

ENGINE OIL 35

ENGINE OIL FILTER ELEMENT 36

OIL FILTER SCREEN 37

AIR CLEANER 38

VALVE CLEARANCE ADJUSTMENT 40

CLUTCH LEVER FREE PLAY 42

THROTTLE OPERATION 43

DRIVE CHAIN SLACKNESS 43

DRIVE CHAIN SLIDER INSPECTION 46

BRAKES 46

SUSPENSION 51

WHEEL 51

MAIN/SIDE STAND LUBRICATION 54

TUBELESS TYRES 55

NUTS, BOLTS & FASTENERS 58

BATTERY 58

FUSE REPLACEMENT 59

STOP LAMP SWITCH 60

HEADLAMP FOCUS ADJUSTMENT 61

CATALYTIC CONVERTER 61

EVAPORATIVE EMISSION CONTROL SYSTEM 62

POLISHING OF VEHICLE 62

BASIC TROUBLESHOOTING 63

ROAD SIGNS 65

WARRANTY

HERO GENUINE PARTS

ZONAL/REGIONAL/AREA OFFICES

VEHICLE IDENTIFICATION

Model: GLAMOUR PROGRAMMED FI

Engine No.

Location: Stamped on the lower side of the

left crankcase.

MBLJAW16#########

JA07AB#

#######

VIN and Engine No. may be required:

1. During registration of the vehicle.

2. For dealing with legal & insurance departments.

VIN: MBLJAW16#########

MBL JAW16 #

Manufacturer

code Vehicle

Description Model Year

Check

Digit

Engine No.: JA07AB########

JA07AB # #

Engine

Description Year of

Manufacturing Assembly Plant

## #####

Plant

Code Month of

Manufacturing Production

Serial Number

# #####

Month of

Manufacturing Serial Number

Vehicle Identification Number (VIN)

Location: Stamped on the right side of the

steering head tube.

VIN Engine

Variant JAW16 JA07AB

Electric start/Front disc/Cast wheel JAW15 JA07AB

Electric start/Front drum/Cast wheel

(1) Speedometer

(2) Neutral indicator

(3) USB charger #

(Optional)

(4) Dimmer switch

( ) Horn switch5

( )6 Turn signal switch

( ) Clutch lever7

(8) Passing switch

(9) Rear view mirror

( ) High beam indicator10

( 1)1 i3s indicator

(1 ) 2 Programmed FI malfunction

indicator lamp (MIL)

(13) Turn signal indicator

(14) Side stand indicator

(15) LCD panel

(16) Mode/Reset button

(17) Front brake master cylinder/Reservoir

(18) i3s switch

(19) Front brake lever

(20) Throttle grip

(21) Electric starter switch

(22) Ignition switch with steering lock

(23) Fuel tank cap

*Accessories and features shown may not be part of standard fitment.

#OE fitment, for Matt Vernier Grey color variant only.

TOP VIEW VEHICLE VIEWS

12 16

13 17

11 18

LEFT SIDE VIEW

(1) Fuel injector

(2) Gear shift pedal

(3) Rider footrest

(4) Main stand

(5) Side stand

(6) Pillion footrest

(7) Left side cover

(8) Seat lock

(9) Saree guard with women

pillion step

(10) Rear turn signal lamp

(11) Rear reflex reflector

(12) Licence plate lamp

(13) Tail/Stop lamp

(14) Rear grip

(15) Helmet holder (inside)

(16) Battery (inside)

(17) Side stand switch

(18) Leg guard (Optional)

(19) Side reflex reflector

12356 98

141516

*Accessories and features shown may not be part of standard fitment.

(8) Caliper assembly

(9) Front brake disc

(10) Front suspension

(11) Front turn signal lamp

(12) Headlamp

(13) Position lamp

(14) Front visor

(15) Throttle body/ECU (inside)

(16) Seat

(17) Rear fender

(18) Rear shock absorber

(19) Exhaust muffler

(1) CBS Actuator (inside)

(2) Brake fluid reservoir

(3) Kick starter pedal

(4) Oil level dipstick

(5) Brake pedal

(6) Starter motor

(7) Front fender

*Accessories and features shown may not be part of standard fitment.

RIGHT SIDE VIEW

# Disc variant

1 2 3 4 6 7 8 9

VEHICLE SPECIFICATION

Engine oil

Fuel tank capacity

Maximum power

Maximum torque

Bore and stroke

Compression ratio

Displacement

Spark plug gap

Valve clearance

Idle speed

0.95 litre at disassembly and 0.75 litre at draining

10 litres

8 kW @ 7500 r/min

10.6 N-m @ 6000 r/min

52.4x57.8 mm

9.9:1

124.7 cc

0.8-0.9 mm

0.08 mm

0.12 mm

1400±100 r/min

Capacities

Engine

Intake (cold)

Exhaust (cold)

Spark plug

SPECIFICATIONSITEM

Dimensions

Overall length

Overall width

Overall height

Wheelbase

Saddle height

Ground clearance

2051 mm

743 mm ) & 720 mm (Drum-Drum) (Disc-Drum

1074

1273.1 mm

798 mm

180 mm

Weight

NGK-CPR 7EA9, RG8YC (Federal Mogul)

Kerb weight 1 (Disc-Drum23 kg ) & 122 kg (Drum-Drum)

Payload 130 kg

Trail length 92 mm

Front suspension

Rear suspension

Caster angle

Telescopic hydraulic shock absorbers

Swingarm with 5 step adjustable hydraulic shock

absorbers

26°

Chassis and suspension

Front

Rear

Tyre size 80/100-18 47P (Tubeless tyre)

100/80-18 53P (Tubeless tyre)

VEHICLE SPECIFICATION SPECIFICATIONSITEM

Brakes Front (Drum type)

Front (Disc type)

Rear (Drum type)

Dia. 240 mm

Dia. 130 mm

Transmission

Primary reduction

Final reduction

Gear ratio, 1

4th

Transmission

3.214 (45/14)

3.35 (67/20)

3.17 (38/12)

1.83 (33/18)

1.04 (26/25)

0.923 (24/26)

31.272 (28/22)

Transmission 5 Speed transmission

Battery

Alternator

Starting system

Headlamp (High/Low)

Tail/Stop lamp

Turn signal lamp 12V-5/21W

Kick/Electric start

12V-35W/35W Halogen bulb-**MFR

12V-10Wx4 (Amber bulb) with clear lens-**MFR

*MF battery,12V-4Ah/ETZ5

125 W @ 5000 r/min

Electricals

Meter illumination

Neutral indicator LED

LED

*MF stands for Maintenance Free

**MFR stands for Multi-Focal Reflector

Turn signal indicator

Position lamp

Hi beam indicator

Programmed-Fi Malfunction indicator lamp (MIL)

Licence plate lamp

i3s indicator

Side stand indicator

LED

12V-5.0W

LED

12V-5.0W

LED

Fuse 15A, 10A, 10A, 10A

15A, 10A

Circuit fuse

Spare fuse

ACCESSORIES & MODIFICATIONS

Modifying your vehicle or using non-Hero

MotoCorp accessories can make your vehicle

unsafe. Before you consider making any

modifications or adding an accessory, be sure

to read the following information.

operation. Such changes could seriously

impair your vehicle's handling, stability and

braking, making it unsafe to ride. Removing or

modifying your lamps, mufflers, emission

control system or other equipment can also

make your vehicle illegal.

ANTI-THEFT TIPS

•Always lock the steering and never leave the

key in the ignition switch. This sounds

simple but people do forgets.

•Be sure the registration information for your

vehicle is accurate and correct.

•Park your vehicle in a locked garage

whenever possible.

•Use an additional anti-theft device of good

quality.

•Never park your vehicle in an isolated area.

Park as far as possible in a designated area.

•Enter your name, address and phone

number in this Owner's Manual and keep it

in your vehicle at all times. Many times

stolen vehicles are identified by information

in the Owner's Manuals that are still with

them.

NAME: _____________________________________________

ADDRESS: _______________________________________

_______________________________________________________

PHONE NO : _____________________________________

Accessories

•Make sure that the accessory does not

obscure any lamps, reduce ground

clearance, limit suspension travel or steering

travel, affect your riding position or interfere

with operating any controls.

•Be sure electrical equipment does not

exceed the 's electrical system vehicle

capacity (page 6). A blown fuse can cause a

loss of lights.

•Do not pull a trailer or sidecar with your

vehicle. This vehicle was not designed for

these attachments, and their use can

seriously impair your vehicle's handling.

Modifications

We strongly advise you not to remove any

original equipment or modify your vehicle in

any way that would change its design or

•Improper accessories or modifications can

cause a crash in which you can be seriously

hurt or killed.

•Follow all instructions in this owner's manual

regarding accessories and modifications.

WARNING

Otros manuales para GLAMOUR PROGRAMMED FI

Tabla de contenidos

Otros manuales de Motocicleta de HERO

HERO

HERO ECO DELUXE Manual de usuario

HERO

HERO SPLENDOR+ PROGRAMMED FI Manual de usuario

HERO

HERO Splendor iSmart 110 Manual de usuario

HERO

HERO MotoCorp Splendor iSmart 110 Manual de usuario

HERO

HERO Karizma ZMR Manual de usuario

HERO

HERO GLAMOUR PROGRAMMED FI Manual de usuario

HERO

HERO Achiever Manual de usuario

HERO

HERO MAESTRO EDGE 125 PROGRAMMED FI Manual de usuario

HERO

HERO HUNK Manual de usuario

HERO

HERO SPLENDOR PRO Manual de usuario

HERO

HERO IGNITOR Manual de usuario

HERO

HERO SUPER SPLENDOR PROGRAMMED FI Manual de usuario

HERO

HERO MAESTRO EDGE 125 PROGRAMMED FI Manual de usuario

HERO

HERO SPLENDOR NXG Manual de usuario

HERO

HERO PASSION PRO PROGRAMMED FI Manual de usuario

HERO

HERO ACHIEVER 150 Manual de usuario

HERO

HERO SPLENDOR+ Manual de usuario

HERO

HERO KARIZMA Manual de usuario

HERO

HERO HUNK 150R Manual de usuario

HERO

HERO IGNITOR Manual de usuario

HERO

HERO MAESTRO EDGE PROGRAMMED FI Manual de usuario

HERO

HERO XPULSE 200 PROGRAMMED FI Manual de usuario

HERO

HERO HF-Deluxe Manual de usuario

HERO

HERO Passion Xpro Manual de usuario

Manuales populares de Motocicleta de otras marcas

OHVALE

OHVALE GP-0 Manual de lista de piezas

Yamaha

Yamaha Star XV19CTSZ 2009 Manual de usuario

KTM

KTM 350 XCF-W USA Manual de usuario

HYOSUNG

HYOSUNG ST7 Manual de usuario

Husqvarna

Husqvarna FC 250 2016 Manual de usuario

Ducati

Ducati SCRAMBLER 800 Manual de instrucciones

MOTO GUZZI

MOTO GUZZI QUOTA 1100 ES Manual de usuario

APRILIA

APRILIA ETV MILLE CAPONORD - PART1 02-2001 Manual de usuario

Yamaha

Yamaha 2006 YZF-R1V Manual de usuario

KTM

KTM Freeride E-XC 2021 Manual de usuario

Fantic

Fantic Enduro 125 Manual de usuario

Ducati

Ducati Supersport 750 desmodue Manual de usuario

MV Agusta

MV Agusta 2008 F4 312RR 1078 Manual de instrucciones

Yamaha

Yamaha XVS650A Manual de usuario

Yamaha

Yamaha YZF-R6T(C) Manual

Ducati

Ducati 748 monoposto strada Manual de usuario

ATK

ATK 1988 250 Manual de usuario

Excelsior-HENDERSON

Excelsior-HENDERSON 1999 HCX Manual de usuario
