Heath Zenith DualBrite Manual de usuario

FEATURES

• Automatically comes on when motion is de-

tected.

• Automatically turns light o.

• Dusk Accent lighting.

• Photocell keeps the light o during daylight

hours.

is package includes:

• Coach Light

• Mounting Bracket and Screws

• Wire Connectors

• Owner’s Manual

REQUIREMENTS

• e light control requires 120 volts AC.

• If you want to use Manual Mode, the control

must be wired through a switch.

• Some electrical codes require installation by

a qualied electrician.Please check the codes

in your area.

Model 4167

Before installation, record the model num-

ber listed inside the xture. Attach receipt

in case of possible warranty issues.

Model Number:

Installation and

Operating Instructions

DualBrite®Motion

Sensing Coach Light

Coach Light

2200471-02

GND

WIRING

CAUTION: DO NOT connect the RED

wire unless you want to control other

lights from the motion sensor (see Op-

tional Wiring).

Note: All wiring must be run in accordance with

the National Electrical Code through conduit

or another acceptable means. Contact a quali-

ed electrician if there is any question as to the

suitability of the system.

WARNING: Turn power o at circuit

breaker or fuse.

One Motion Light

Two Motion Lights

Black

White

Green

or Bare

Light

Fixture

Black

White

Green

or Bare

Light

Fixture

Light

Fixture

Ground Screw

INSTALLATION

Bracket

Mounting

Screws

Junction

Box

Note:Werecommendhavinganassistanthelphold

the lantern assembly during the wiring process.

For best performance, mount the xture about 6

feet (1.8 m) above the ground.

1. Remove two decorative nuts.

2. Remove X-Bar.

3. Tighten mounting screws on X-Bar nger

tight.

4. Attach X-Bar to junction box.

WARNING: Turn power o at circuit

breaker or fuse.

X-Bar

Decorative Nut

Lantern Base

Lantern Mounting

Screw

X-Bar

200471-02

Black to black

White to white

Recommended Grounding Method

Use a green ground“pigtail”(not provided) and

twistoneendtogetherwiththebarexturewire

and the box ground wire. Secure with a wire

connector. Secure the other end of the “pigtail”

with the GND screw on the mounting plate.

Connect the xture wires to the wires in the junc-

tion box.Twist the wires together and secure with

wire connectors.

If you have metal junction box,you may not need

the green “pigtail”. If you are unsure about the

grounding method, consult your local building

code.

4200471-02

OPTIONAL WIRING

is xture is provided with a sensor rated for 360 Watts. Since the xture is only rated 100 Watts,

260 Watts of additional lighting may be controlled by this sensor.

When determining what a xture is rated for, do not simply look at the rating on the light bulb in

the xture. Look at the marking which species the maximum bulb wattage for which the xture

is suitable.

Once you have selected the xtures to be connected and determined their maximum ratings,add these

ratings up. For instance,if you have 3 xtures rated 100 Watts, 150 Watts, and 75 Watts respectively,

you have a total load of 325 Watts.

Wiring Diagram 1 – When wiring to control a standard light xture: Strip the motion sensor’s

red wire and connect to the standard light’s black wire.Connect all white wires together.Total xture

ratings must not exceed 360 Watts (3.0 A).

Wiring Diagram 2 – When wiring to control another motion sensing light xture (Master /

Slave): Strip the red wire in both light xtures. Connect the red wire of the controlling (master)

xture to the red and black wires of the controlled (slave) xture. Connect all white wires together.

Total xture ratings must not exceed 360 Watts (3.0 A).

Wiring Diagram 3 – When wiring so either motion light turns on the both motion lights

(Master / Master): Strip the red wire in both light xtures. Connect the red wire of one xture

to the red wire of the second xture. Note: In most installations, an additional wire (same gauge as

existing house wire) will have to be installed in the house to connect the two xtures as master /

master. Connect all white wires together and all black wires together. Total xture ratings must not

exceed 360 Watts (3.0 A).

Black

White

Green

or Bare

Light

Fixture

Light

Fixture

(Standard) Master Slave

Black

White

Green

or Bare

Light

Fixture

Light

Fixture

Red

Wiring Diagram 1 Wiring Diagram 2

Wiring Diagram 3

Master Master

Black

White

Red

Green

or Bare

Light

Fixture

Light

Fixture

200471-02

Junction

Box

FINAL ASSEMBLY

1. Push the wires into the junction box. Make

sure none of the wires get pinched.

Slide the xture assembly onto the mounting

screws.Tighten decorative nuts removed in step

1 of Installation section securely against xture

base.

Mounting Screw

Decorative Nut

3. Install one medium base light bulb (100 Watt

maximum).

4. Caulkaroundxturebasewithsiliconeweather

sealant after all

Testing and Adjustments

are

complete.

TESTING AND ADJUSTMENTS

1. Turn on the circuit breaker and light

switch.

Note: Sensor has a 1 1/2minute warm up period

before it will detect motion.When rst turned

on wait 1 1/2minutes.

2. Set:

• ON-TIME switch to TEST

• DB® switch to OFF

• SENSITIVITY dial to Midway

Walk through the coverage area noting where

you are when the lights turn on.InTEST mode,

light will stay on for 5 seconds after sensing

motion and then turn o.

TEST 1 5 10

MINUTE

OFF 3 6 DUSK TO

HOUR DAWN

–+

SEN

6200471-02

Note:Whenrstturnedonwaitabout11/2minutes

for the circuitry to calibrate.

* resets to Auto Mode at dawn.

OPERATION

MANUAL MODE

Adjust the SENSITIVITY to increase or

decrease the range as needed.Too much sen-

sitivity may cause false triggering due to heat

sources in the coverage area (see Adjustment

of Coverage Area or Troubleshooting section).

5. Set the amount of ON-TIME you want the

light to stay on after motion is detected (1, 5,

or 10 minutes).

6. Set the DB® switch to o,3 hours,6

hours, or dusk-to-dawn.

Mode: On-Time Works: Day Night

Test 5 Seconds x x

Auto 1, 5, or 10

Minutes x

Accent 3, 6 Hour,

To Dawn x

Manual To Dawn* x

... back on.

1 Second

OFF then...

Manual mode only works at

night because daylight returns

the sensor to AUTO.

Flip the light switch o for one

second then back on to toggle

betweenAUTOandMANUAL

MODE.

Manual mode works only with

the ON-TIME switch in the 1,

5, or 10 position.

30 ft.

(9.1 m)

6 ft.

(1.8 m)

180°

Maximum

Maximum Range Coverage Angle*

(Top View)

Least Sensitive Most Sensitive

e sensor is less sensitive to motion directly

towards it and more sensitive to motion across

coverage area.

Sensor

Motion Motion

200471-02

ADJUSTMENT OF COVERAGE AREA

e sensor on this light xture detects “motion”

by the movement of heat across the coverage

area. However, following are examples of objects

that also produce heat and can cause the sensor

to trigger:

• Pools of Water • Air Conditioners

• Dryer Vents • Animals

• Heating Vents • Automobile Trac

If you suspect that a heat source of this type is

triggering the sensor, reduce the sensitivity.

SPECIFICATIONS

Range .................................................Up to 30 ft. (9.1 m) [varies with surrounding temperature]

Sensing Angle.....................................Up to 180°

Electrical Load ...................................Up to 100 Watt Maximum Incandescent

Bulb Type ...........................................Medium Base,Type “A”, 100 Watt Maximum

Sensor Capacity..................................Up to 360 Watt (3.0 A) Maximum Tungsten

Power Requirements...........................120 VAC, 60 Hz

Operating Modes ...............................TEST, AUTO, and MANUAL MODE

ON-Timer..........................................1, 5, 10 minutes

DB® Timer...........................O, 3, 6 hours, dusk-to dawn

Test Timer..........................................5 Seconds

Manual Mode Timer..........................Dusk-to-Dawn

MANUAL MODE

AUTO

TEST

ON-TIME Switch at 1, 5,

or 10 minutes

MODE SWITCHING SUMMARY

Flip light switch

o for one second

then back on*

* If you get confused while switching modes, turn

the power o for one minute, then back on. After

thecalibrationtimethecontrolwillbeintheAUTO

mode.

DualBrite®Dimmer Control

Light comes on half bright for selected time after

dusk (O,3 hr.,6 hr.,until dawn).Selecting OFF

disables this feature.e motion sensing features

will continue to work as described in this manual.

If motion is sensed, the light turns on full bright

for the ON-TIME (1, 5, or 10 minutes) then

returns to dim mode.

8200471-02

SYMPTOM POSSIBLE CAUSE SOLUTION

Lights will not

come on. 1. Light switch is turned o.

2. Light bulb is loose or burned out.

3. Fuse is blown or circuit breaker is turned o.

4. Daylight turn-o is in eect.

5. Sensor not detecting movement.

6. Incorrect circuit wiring, if this is a new installation.

1. Turn light switch on.

2. Check bulb and replace if burned out.

3. Replace fuse or turn circuit breaker on.

4. Recheck after dark.

5. Re-aim the sensor to cover desired area.

6. Verify wiring is correct.

Lights come on in

daylight. 1. Light control may be installed in a relatively dark

location.

2. Light control is in TEST.

1. e xture is operating normally under these

conditions.

2. Set control switch to 1, 5, or 10 minutes.

Lights come on for

no apparent reason. 1. Lightcontrolmaybesensingsmallanimalsorautomobile

trac.

2. Sensitivity is set too high.

1. Re-aim sensor. Reduce sensitivity.

2. Reduce sensitivity.

Lights stay on

continuously. 1. e sensor may be picking up a heat source like an air

vent, dryer vent, or brightly painted, heat-reective

surface.

2. Light control is in Manual Mode.

3. Light control is in DB® mode.

4. Sensitivity is set too high.

1. Re-aim sensor. Reduce sensitivity.

2. Switch to Auto.

3. Slide DB® switch to OFF position.

4. Reduce sensitivity.

Lights ash on

and o. 1. Light control is in the TEST mode and warming up.

2. Heatbeingreectedfromotherobjectsmaybe aecting

the sensor.

1. Flashing is normal under these conditions.

2. Re-aim sensor. Reduce sensitivity.

TROUBLESHOOTING GUIDE

TECHNICAL SERVICE

Please call 1-800-858-8501 (English speaking only) for assistance before

returning product to store.

If you experience a problem, follow this guide. You may also want to visit our Web site at: www.

hzsupport.com. If the problem persists, call* for assistance at 1-800-858-8501 (English speaking

only), 8:00 AM to 5:00 PM CST (M-F). You may also write* to:

HeathCo LLC

P.O. Box 90045

Bowling Green, KY 42102-9045

ATTN: Technical Service

* If contacting Technical Service, please have the following information available: Model Number,

Date of Purchase, and Place of Purchase.

No Service Parts Available for this Product

Please keep your dated sales receipt, it is required for all warranty requests.

200471-02

TWO YEAR LIMITED WARRANTY

is is a “Limited Warranty”which gives you specic legal rights.You may also have other rights

which vary from state to state or province to province.

For a period of two years from the date of purchase,any malfunction caused by factory defective

parts or workmanship will be corrected at no charge to you.

Not Covered - Repair service, adjustment and calibration due to misuse, abuse or negligence,

light bulbs,batteries,and other expendable items are not covered by this warranty.Unauthorized

service or modication of the product or of any furnished component will void this warranty in

its entirety.is warranty does not include reimbursement for inconvenience,installation, setup

time, loss of use, unauthorized service, or return shipping charges.

is warranty covers only HeathCo LLC assembled products and is not extended to other equip-

ment and components that a customer uses in conjunction with our products.

THISWARRANTYISEXPRESSLYINLIEUOFALLOTHERWARRANTIES,EXPRESS

OR IMPLIED, INCLUDING ANY WARRANTY, REPRESENTATION OR CONDI-

TION OF MERCHANT ABILITY OR THAT THE PRODUCTS ARE FIT FOR ANY

PARTICULARPURPOSE OR USE,ANDSPECIFICALLY INLIEU OF ALLSPECIAL,

INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.

REPAIRORREPLACEMENTSHALLBETHESOLEREMEDYOFTHECUSTOMER

AND THERE SHALL BE NO LIABILITY ON THE PART OF HEATHCO LLC FOR

ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES,

INCLUDING BUT NOT LIMITED TO ANY LOSS OF BUSINESS OR PROFITS,

WHETHER OR NOT FORESEEABLE. Some states or provinces do not allow the exclu-

sion or limitation of incidental or consequential damages, so the above limitation or exclusion

may not apply to you.

Please keep your dated sales receipt, it is required for all warranty requests.

HeathCo LLC reserves the right to discontinue products and to change specications at any time

without incurring any obligation to incorporate new features in products previously sold.

10 200471-02

CARACTERÍSTICAS

• Se enciende automáticamente al detectar mo-

vimiento.

• Apaga la luz automáticamente.

• Iluminación ornamental de baja intensidad.

• La fotocélula mantiene la luz apagada durante

las horas diurnas.

Este paquete contiene:

• Luz de Coche

• Ménsula y tornillos para montaje

• Conectores de alambre

• Manual del propietario

REQUISITOS

• El control de luz requiere 120 VCA.

• Para usar el Modo Manual, conecte el control

con un interruptor.

• Algunoscódigosrequiereninstalaciónporun

electricistacalicado.Reviseloscódigosensu

área.

Modelo 4167

INSTRUCCIONES PARA SU

INSTALACIÓN Y FUNCIONAMIENTO

Antesdeinstalar,registreelnúmerodelmode-

lomostradodentrodelaparato.Fije elrecibo

en caso posibles reclamos por la garantía.

Número del modelo:

DualBrite®Luces de

Coches Detectores de

Movimiento

Luz de Coche

Otros manuales para DualBrite

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Accesorios de Heath Zenith

Heath Zenith

Heath Zenith Replacement Motion Sensor SL-5407 Manual de usuario

Heath Zenith

Heath Zenith Wireless Christmas Chime 598-1127-03 Manual de usuario

Heath Zenith

Heath Zenith Motion Sensor Entryway Light SL-5610/15 Manual de usuario

Heath Zenith

Heath Zenith 7797 Manual de usuario

Heath Zenith

Heath Zenith 6168 Manual de usuario

Heath Zenith

Heath Zenith DualBrite 5716 Manual de usuario

Heath Zenith

Heath Zenith DESA 6270 Manual de usuario

Heath Zenith

Heath Zenith Wireless Push Button Accessory SL-6190... Manual de usuario

Heath Zenith

Heath Zenith 598-1215-01 Manual de usuario

Heath Zenith

Heath Zenith Notifi Elite Manual de usuario

Heath Zenith

Heath Zenith Dual Brite SL-5597 Manual de usuario

Heath Zenith

Heath Zenith Wireless Push Button Accessory 598-1105-05 Manual de usuario

Heath Zenith

Heath Zenith 5210 Manual de usuario

Heath Zenith

Heath Zenith Wireless Push Button Accessory 598-1105-06 Manual de usuario

Heath Zenith

Heath Zenith SL-6168 Manual de usuario

Heath Zenith

Heath Zenith SL-6200 Manual de usuario

Heath Zenith

Heath Zenith 6106 Manual de usuario

Heath Zenith

Heath Zenith 598-1112-04 Manual de usuario

Heath Zenith

Heath Zenith Wireless Push Button Accessory 598-1151-02 Manual de usuario

Heath Zenith

Heath Zenith Hardwired Electronic Chime 598-1313-00 Manual de usuario

Heath Zenith

Heath Zenith SECUR360 9600 Manual de usuario

Heath Zenith

Heath Zenith Single Entrance Chime 23/M Manual de usuario

Heath Zenith

Heath Zenith Motion Sensing 3-Way Wall Switch 6107 Manual de usuario

Heath Zenith

Heath Zenith 121AC Manual de usuario

Manuales populares de Accesorios de otras marcas

Hillco

Hillco 2810 Manual de usuario

Siemens

Siemens QSA2700D Manual del operador

Contours

Contours ZY024 Manual de usuario

Saivod

Saivod VS621 Manual de usuario

Virtuox

Virtuox VirtuCLEAN 2.0 Manual de usuario

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manual de usuario

Z-Wave

Z-Wave HSD-200Z Manual de usuario

turck

turck FMX-IM-2UPLI63FX Manual de usuario

Decagon Devices

Decagon Devices 10HS Manual de usuario

UPPAbaby

UPPAbaby Cup Holder Manual de usuario

Elko

Elko SmartSensor Leakage Wireless Manual de usuario

Grizzly

Grizzly H8371 Manual de usuario

Panasonic

Panasonic HG-T Series Manual de usuario

IFM Electronic

IFM Electronic Efector 250 Series Guía de referencia

DigiDesign

DigiDesign 888/24 I/O Manual de usuario

PROZIS

PROZIS QUAY Manual de usuario

patagonia

patagonia PSI Vest Manual de usuario

SFC Energy

SFC Energy EFOY GO! Manual de usuario
