Hearth & Home ASD-36 Manual de usuario

Hearth & Home Technologies • Outdoor Mesh Doors • 4136-918 Rev B • 04/23 1

Models:

ASD-36, ASD-42, LSD-36, LSD-42, VOFBSD-36 and VOFBSD-42

Mesh Door Kits

Installation

Instructions

These mesh door kits have been tested for use with specic Hearth & Home Technologies products. Check with your local

building code agency before you begin installation to ensure compliance with local codes, including the need for permits

and follow-up inspections. If you encounter any problems regarding code approvals, or if you need clarication of any of the

instructions contained here, contact your Hearth & Home Technologies Inc. dealer. For the dealer nearest you, please visit

www.hearthnhome.com.

WARNING

Hot screen/mesh and glass doors will cause burns.

• Do not touch screen/mesh or glass doors until cooled

• NEVER allow children to touch screen/mesh or glass

doors

• Keep children away

• CAREFULLY SUPERVISE children in same room as

replace.

• Alert children and adults to hazards of high

temperatures.

High temperatures may ignite clothing or other

ammable materials.

• Keep clothing, furniture, draperies and other ammable

materials away.

HOT SURFACES!

Screen/mesh, glass doors and

other surfaces are hot during

operation AND cool down.

NOTICE: All ngerprints and smudges must be wiped clean

from the viewable surfaces of the door kit prior to the initial

burning of the replace. If this is not done, these prints and

smudges will be cured into the nish and set for the life of

the replace. To keep the nish looking its best, gently wipe

with a soft cloth and if desired, soap and water. Never use

thinner or abrasive cleaners since these products will damage

the nish.

CAUTION! Risk of Cuts/Abrasions. Wear protective

gloves and safety glasses during installation. Sheet metal

edges are sharp.

Figure 1 Mesh Door Kit

Door Model Number For Use on Models

ASD-36 ACUF36-BD ACUF36-GD BUF36A BUF36-T BUF36-H

ASD-42 ACUF42-BD ACUF42-GD BUF42A BUF42-T BUF42-H

VOFBSD-36 VOBF36-T VOBF36-H

VOFBSD-42 VOBF42-T VOBF42-H

LSD-36 LCUF36CR-C LCUF36CR-BT LCUF36CR-GT LCUF36CR-GH

LSD-42 LCUF42CR-C LCUF42CR-BT LCUF42CR-GT LCUF42CR-GH

Hearth & Home Technologies • Outdoor Mesh Doors • 4136-918 Rev B • 04/23

CAUTION! The door kit is heavy. We recommend two

installers to put the front assembly in place.

Installation:

1. Remove the existing screens from the replace.

See Figure 2:

• Remove one screw in each of the screen rods

behind the upper screen cover

• Slide screen rods out of support holes.

• Rods and screen will come out as an assembly.

• Discard.

Figure 4 Frame Assembly

Hang Hooks

Figure 6 Completed Mesh Door Installation

Figure 2 Remove Existing Screens

Mesh Door Hang Holes

Screen Rod Screws

2. Install inner hood by using the (4) bend tabs to locate.

Pry up hand band tabls slightly to locate. See Figure

3. Use the (2) screws from the screen rods to secure

into place. See Figure 5. Leave original hood in place.

3. Hang door frame assembly into the (4) slots located

on the rebox (see Figure 2) with the corresponding

hooks on the door frame. See Figure 4. Be sure door

is all the way down on the hooks. Door frame will have

approximatley 1/2 inch gap on the bottom of frame.

See Figure 6.

Tabs

Figure 3 Bend Tabs

Figure 5 Frame Assembly

Screws
