Harman JBL QUANTUM ONE Manual de usuario

QUICK START GUIDE

ONE

Software requirements

PLATFORM: Windows 7 / Windows 10 (64 bit) only

500MB of free hard drive space for installation

*QuantumSURROUND / QuantumSPHERE 360 and DTS Headphone:X V2.0

available on Windows only. Software installation required.

Download JBL QuantumENGINE to gain full access to features on your JBL Quantum headsets - from

headset calibration to adjusting 3D audio to suit your hearing, from creating customized RGB lighting

effects to determining how the boom microphone side-tone works. jblquantum.com/engine

JBL QuantumENGINE

001 WHAT'S IN THE BOX

JBL QUANTUMOne headset

3.5MM AUDIO

CABLE

QSG | WARRANTY CARD |

WARNING CARD

Windshield foam

for microphone

Detachable

Boom Microphone

Calibration

Microphone

Type-C to A cable with

Game / Chat Balance Dial

002 Requirements

System compatibility

PC | Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR

PLATFORM: Windows 7 / Windows 10 (64 bit) only

500MB OF FREE HARD DRIVE SPACE FOR INSTALLATION

SOFTWARE REQUIREMENTS

JBL

003 OVERVIEW

01 ANC / TALKTHRU LED

02 ANC / TALKTHRU button

03 Re-centering button for head tracking

04 Flat-fold ear cup

05 Volume Control

06 RGB-Lit earcup

07 Microphone Mute/unMute

08 power status LED

09 USB-C port

10 3.5mm Audio Jack

11 Boom Microphone Jack

12 Detachable boom microphone

13 Game audio-chat balance dial

14 power status LED

15 Volume Control

16 MIC MUTE BUTTON

004 Calibration microphone

15-30 sec

Go to JBL for detailed setup instructions.

005 SETUP

* USB-C to USB-C cable is not included by-pack. Connectivity with USB-C may not

work with all models of said devices.

PC | Mobile | LAPTOP| Nintendo Switch™

006 BUTTON COMMAND

ANC on/off

>2S

TALKTHRU ON/OFF

INCREASE CHAT VOLUME

INCREASE GAME VOLUME

INCREASE MASTER VOLUME

Re-centering button for head tracking

DECREASE MASTER VOLUME

ON/OFF

>5S

Microphone Mute / unMute

007 First time setup

JBL QUANTUMOne

Game

JBL QUANTUMOne

Chat

7a Go to Sound Settings

7B UNDER "PLAYBACK" HIGHLIGHT JBL QUANTUMOne GAME AND SELECT

"SET DEFAULT DEVICE"

7C HIGHLIGHT JBL QUANTUMOne CHAT AND SELECT "SET DEFAULT

COMMUNICATION DEVICE"

7D UNDER "RECORDING" HIGHLIGHT JBL QUANTUMOne CHAT AND SELECT

"SET DEFAULT DEVICE"

7E IN YOUR CHAT APPLICATION SELECT JBL QUANTUMOne CHAT AS THE

DEFAULT AUDIO DEVICE

008 MICROPHONE

MIC MUTE

MIC UNMUTE
