Harman JBL QUANTUM 350 WIRELESS Manual de usuario
350
WIRELESS
OWNER’S MANUAL
TABLE OF CONTENTS
INTRODUCTION ........................................................................................................... 1
WHAT’S IN THE BOX..................................................................................................... 2
PRODUCT OVERVIEW ................................................................................................. 3
Controls on headset.....................................................................................................................................3
Controls on 2.4G USB wireless dongle..............................................................................................4
GETTING STARTED....................................................................................................... 5
Charging your headset...............................................................................................................................5
Wearing your headset.................................................................................................................................6
Power on..............................................................................................................................................................7
First-time setup (for PC only)...................................................................................................................7
USING YOUR HEADSET............................................................................................... 9
PRODUCT SPECIFICATIONS..................................................................................... 11
TROUBLESHOOTING ................................................................................................. 12
- 1 -
Introduction
Congratulations on your purchase! This manual includes information on the
gaming headset. We encourage you to take a few minutes to
read this manual, which describes the product and includes step-by-step instructions
to help you to set up and get started. Read and understand all the safety instructions
before using your product.
If you have any questions about this product or its operation, please contact your
retailer or customer service, or visit us at www.JBLQuantum.com
- 2 -
What’s in the box
01 02 03 04 05
06
01 gaming headset
02 USB charging cable (USB-A to USB-C)
03 Removable microphone
04 2.4G USB wireless dongle
05 QSG, warranty card and safety sheet
06 Windshield foam for boom microphone
- 3 -
PRODUCT OVERVIEW
Controls on headset
03
04
05
06
07
08
01 Volume +/- dial
• Adjusts headset volume.
02 button
• Press to mute or unmute the microphone.
03 Charging LED
• Indicates the charging and battery status.
04 USB-C port
05 Jack for 2.5 mm boom microphone
06 Flat-fold ear cup
07 Status LED (Power / 2.4G)
08 slider
• Slide upwards / downwards to power on / off the headset.
- 4 -
Controls on 2.4G USB wireless dongle
09
10
01 button
• Hold for more than 5 seconds to enter 2.4G wireless pairing mode.
02 LED
• Indicates the status of 2.4G wireless connection.
- 5 -
Getting started
Charging your headset
2HR
Before use, fully charge your headset through the supplied USB-A to USB-C charging
cable.
TIPS:
• It takes approximately 2 hours to fully charge the headset.
• You can also charge your headset through a USB-C to USB-C charging cable
(not supplied).
- 6 -
Wearing your headset
1. Attach the detachable boom microphone.
1. Put the side marked Lonto your left ear and the side marked Ronto your right ear.
2. Adjust the earpads and headband for a comfortable fit.
3. Adjust the microphone as necessary.
- 7 -
Power on
• Slide the power switch upwards to power on the headset.
• Slide downwards to power off.
The status LED glows solid white upon powering on.
First-time setup (for PC only)
Download from jblquantum.com/engine to gain access to
3D audio technologies.
Software requirements
Platform: Windows 7 (64 bit) / Windows 10 (64 bit) only
500MB of free hard drive space for installation
TIP:
• available on Windows only.
Software installation required.
- 8 -
1. Connect the headset to your PC via 2.4G USB wireless connection (See “Using
your headset”).
2. Go to “Sound Settings” -> “Sound Control Panel”.
3. Under “Playback” highlight “ “ and select “Set
Default”.
4. Under “Recording” highlight “ “ and select “Set
Default” .
5. Follow the onscreen instructions to personalize your sound settings.
JBL Quantum350 WIRELESS JBL Quantum350 WIRELESS
