Hand Held Products 4230 Manual de usuario

™

Quick Start Guide

4230

Cordless Imager

Disclaimer

Hand Held Products, Inc. (“Hand Held Products”) reserves the right to make

changes in specifications and other information contained in this document

without prior notice, and the reader should in all cases consult Hand Held

Products to determine whether any such changes have been made. The

information in this publication does not represent a commitment on the part of

Hand Held Products.

Hand Held Products shall not be liable for technical or editorial errors or

omissions contained herein; nor for incidental or consequential damages

resulting from the furnishing, performance, or use of this material.

This document contains proprietary information which is protected by copyright.

All rights are reserved. No part of this document may be photocopied,

reproduced, or translated into another language without the prior written consent

of Hand Held Products.

Web Address: www.handheld.com

Microsoft Pocket PC 2002, Windows, Windows NT, Windows 2000, Windows ME,

Windows XP, ActiveSync, Outlook, and the Windows logo are trademarks or registered

trademarks of Microsoft Corporation.

The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc.

Table of Contents

Getting Started

4230 with Green LED Aimer

Imager Identification ............................................................. 1

Reading Techniques ................................................................ 2

4230 Models............................................................................. 3

Cordless System: Main Components ....................................... 3

About the Battery..................................................................... 3

Proper Disposal of the Battery .......................................... 4

Using the Imager with Bluetooth Devices ............................... 4

Tested Bluetooth Adapters ................................................ 5

Example of Connecting 4230 with a PC ........................... 5

Changing Bluetooth PIN Code.......................................... 6

Unlinking the Imager......................................................... 6

Out-of-Range Notification ....................................................... 6

Useful Menu Bar Codes........................................................... 6

Manual/Serial Trigger Mode.................................................... 6

Presentation Mode ................................................................... 7

Suffix Selections ...................................................................... 7

Resetting the Standard Product Defaults ................................. 7

To Add a Test Code I.D. Prefix to All Symbologies ............... 7

Reset Imager ........................................................................... 8

Show Software Revision.......................................................... 8

Programming Codes................................................................. 9

Beeper and LED Sequences and Meaning ............................ 10

Repairs ................................................................................... 10

Maintenance........................................................................... 10

Cleaning the Imager’s Window....................................... 10

Inspecting Cords and Connectors.................................... 11

Troubleshooting ..................................................................... 11

Obtaining Factory Service ..................................................... 12

Technical Support .................................................................. 13

Statement of Agency Compliance ........................................ 14

Patents ............................................................................. 15

Solids and Water Protection ............................................ 15

Limited Warranty................................................................... 16

4230 Quick Start Guide 1

Getting Started

4230 with Green LED Aimer

Imager Identification

2 4230 Quick Start Guide

Reading Techniques

The imager has a view finder that projects a bright green aiming beam that

corresponds to the imager’s horizontal field of view. The aiming beam should be

centered over the bar code, but it can be positioned in any direction for a good

read.

The aiming beam is smaller when the imager is closer to the code and larger

when it is farther from the code. Symbologies with smaller bars or elements (mil

size) should be read closer to the unit. Symbologies with larger bars or elements

(mil size) should be read farther from the unit. To read single or multiple symbols

(on a page or on an object), hold the imager at an appropriate distance from the

target, pull the trigger, and center the aiming beam on the symbol. If the code

being scanned is highly reflective (e.g., laminated), it may be necessary to tilt the

code up 15° to 18° to prevent unwanted reflection.

Linear bar code 2D Matrix symbol

4230 Quick Start Guide 3

4230 Models

Cordless System: Main Components

About the Battery

Use only the Li-ion battery packs provided by Hand Held Products. The

use of any battery pack not sold by Hand Held Products will void your

warranty and may result in damage to your unit.

Power is supplied to the cordless imager by a rechargeable battery that is

integrated in the imager handle. Each imager is shipped with a battery.

Charging Information

The battery is designed to charge using a wall adapter.

Only use the battery charger supplied with the imager. Using another

power supply may damage the imager.

• Plug the adapter into the bottom of the imager’s handle.

Models Description

423XXX Cordless Area Imager - Green aimer

Battery Contained in Handle

Battery Charge Jack

4 4230 Quick Start Guide

Battery Recommendations

• Batteries are shipped discharged and need to be fully charged prior to first

use.

• The battery is a lithium ion cell and can be used without a full charge. It also

can be re-charged without fully discharging, without impacting the battery life.

There is no need to perform any charge/discharge conditioning on this cell

type battery.

• Do not disassemble the battery. There are no user-serviceable parts in the

battery.

• Replace a defective battery immediately since it could damage the 4230.

• Don’t short-circuit a battery or throw it into a fire. It can explode and cause

severe personal injury.

• Although your battery can be recharged many times, it will eventually be

depleted. Replace it after the battery is unable to hold an adequate charge.

• If you are not sure if the battery or charger is working properly, send it to Hand

Held Products or an authorized Hand Held Products service center for

inspection.

Proper Disposal of the Battery

When the battery has reached the end of its useful life, the

battery should be disposed of by a qualified recycler or

hazardous materials handler. Do not incinerate the battery or

dispose of the battery with general waste materials. You may

send batteries to Hand Held Products (postage paid). The

shipper is responsible for complying with all federal, state, and

local laws and regulations related to the packing, labeling,

manifesting, and shipping of spent batteries. Contact the

Product Service Department (page 12) for recycling or disposal information.

Since you may find that your cost of returning the batteries significant, it may be

more cost effective to locate a local recycle/disposal company.

Using the Imager with Bluetooth Devices

The 4230 imager may be used with other Bluetooth devices. If the imager goes

out of and back within range of the Bluetooth device, it automatically reconnects

to the device.

4230 Quick Start Guide 5

Tested Bluetooth Adapters

The following Bluetooth adapters have been verified to operate with the 4230.

Note: Communication with other devices may be possible; however, only those

listed have been tested for compatibility with the 4230

• Billionton BT USB Adapter Class 1 (UBTCR3C1A-B)

• Belkin BT USB Adapter Class 1 (F8T001)

• Blaze BT USB Adapter Class 1 (BTU01B)

• EagleTec BT USB Adapter Class 1 (ET-BTHC1U-A)

Example of Connecting 4230 with a PC

Note: This example applies to a PC with Windows® 2000 only.

The Bluetooth Serial Port Service on a computer allows a remote device, the

4230 imager, to establish a wireless link with the computer. The wireless link can

then be used as though a physical serial cable connects the 4230 and the

computer. The link is initiated by the 4230 operating in server mode, but once

the link is established the 4230 and computer swap modes and the 4230

becomes the client.

At the time of manufacture the imager is configured to operate in server mode.

Also, whenever the "DEFAULT" menu bar code symbol is scanned, the 4230

reverts to server mode.

The process to establish a link between an 4230 and a computer equipped with

Bluetooth is as follows:

1. Configure the computer's Bluetooth "Local Services" serial port to start auto-

matically.

2. Pull and release the trigger on the 4230 to insure that the imager is powered

up.

3. Scan the "DEFAULT" menu symbol to insure that the imager is in server

mode.

4. Run "Discover Bluetooth Devices" on the computer.

5. If the computer is configured for a secure connection, the user will be

prompted for the 4230's pin code (See "Changing Bluetooth PIN Code" on

page 6.) If desired, the user can set the 4230's pin code with the bar code

menu prior to initiating this process. The default value for the pin code is

1234.

6. The 4230 and the computer then create a link and automatically swap

modes, with the imager becoming the client and the computer the server.

7. Open the computer application that is to receive data from the 4230, using

the COM port number indicated for the Bluetooth Serial Port in the

computer's list of "Local Services".

6 4230 Quick Start Guide

Changing Bluetooth PIN Code

Some devices require a PIN code as part of the Bluetooth security features. Your

imager’s default PIN is 1234, which you may need to enter the first time you

connect to your PDA or PC. To change the PIN, scan the bar code below and

then scan the appropriate numeric bar codes from the Programming Codes on

page 9. Scan Save to save your selection.

Unlinking the Imager

If the Bluetooth device (dongle) has an imager linked to it, that imager must be

unlinked before a new imager can be linked. Once the previous imager is

unlinked, it will no longer communicate with the dongle. To unlink an imager from

the Bluetooth device (dongle), scan the Unlink Imager bar code below.

Out-of-Range Notification

If you are out of range when you scan a bar code, you will receive an error beep.

You receive the error beep since the data could not be communicated to the host.

Useful Menu Bar Codes

Manual/Serial Trigger Mode

Bluetooth PIN

Unlink Imager

Manual/Serial Trigger

Otros manuales para 4230

Tabla de contenidos

Otros manuales de Lector de código de barras de Hand Held Products

Hand Held Products

Hand Held Products SCANTEAM 2070 Manual de usuario

Hand Held Products

Hand Held Products 4X00 Manual de usuario

Hand Held Products

Hand Held Products SV Series Manual de usuario

Hand Held Products

Hand Held Products 3800LR Manual de usuario

Hand Held Products

Hand Held Products QUICK CHECK 890 Manual de usuario

Hand Held Products

Hand Held Products QUICK CHECK 890 Manual de usuario

Hand Held Products

Hand Held Products 2020/5620 Guía del usuario

Hand Held Products

Hand Held Products Quick Check Bar Code Verifiers 800 Manual de usuario

Hand Held Products

Hand Held Products HandHeld 3800 Linear Series Manual de usuario

Hand Held Products

Hand Held Products IMAGETEAM 4620 Manual de usuario

Hand Held Products

Hand Held Products IMAGETEAM 3800i Manual de usuario

Hand Held Products

Hand Held Products 3800PDF Manual de usuario

Hand Held Products

Hand Held Products 4820 Manual de usuario

Hand Held Products

Hand Held Products 4600g Manual de usuario

Hand Held Products

Hand Held Products 4600g Manual de usuario

Hand Held Products

Hand Held Products Quick Check PC600 Manual de usuario

Hand Held Products

Hand Held Products 4230 Manual de usuario

Hand Held Products

Hand Held Products IMAGETEAM 3800i Instrucciones de instalación y funcionamiento

Hand Held Products

Hand Held Products 4X00 Guía de inicio rápido

Hand Held Products

Hand Held Products 2020 Manual de usuario

Hand Held Products

Hand Held Products SCANTEAM 2070 Guía del usuario

Hand Held Products

Hand Held Products Quick Check PC600 Manual de usuario

Hand Held Products

Hand Held Products IMAGETEAM 3800E Manual de usuario

Hand Held Products

Hand Held Products DOLPHIN RF Manual de usuario

Manuales populares de Lector de código de barras de otras marcas

POSMicro

POSMicro Datalogic PowerScan D7100 Manual de usuario

Marson

Marson MT780 Guía de configuración rápida

NCR

NCR RealPOS Manual de usuario

Motorola

Motorola SE3300 Guía de configuración rápida

Element

Element P130BT Manual de usuario

Motorola

Motorola Symbol LS3008 Manual de instalación y operación

Meec tools

Meec tools OBD-II / VAG Manual de usuario

SICK

SICK CLP 100 Manual de usuario

Royal Tag SA

Royal Tag SA I-Read Manual de usuario

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manual de usuario

Meteor

Meteor 8310 Manual de usuario

Denso

Denso BHT-500B Manual de usuario

Datalogic

Datalogic Heron HD3130 Manual de usuario

Motorola

Motorola MP6000 Instrucciones de montaje

Newland

Newland NLS-HR15-BT Manual de usuario

ARTDEV

ARTDEV AS-1310 Manual de usuario

Aopos

Aopos AS290 Manual de usuario

ENS

ENS 367-5455 Manual de usuario
