VACUUM CLEANER

VCH 9530

___________________________________________

ENGLISH

SAFETY ___________________________________

Please read this instruction man-

ual thoroughly prior to using this

appliance! Follow all safety in-

structions in order to avoid dam-

ages due to improper use!

Keep the instruction manual for

future reference. Should this ap-

pliance be given to a third party,

then this instruction manual must

also be handed over.

7 Always keep hair, clothing and

any other utensils away from

the appliance during operation

in order to prevent injury and

damages.

7 The appliance is designed for

domestic use only. Warranty

will be voided if the appliance is

used for industrial or commercial

purposes.

7 Observe these instructions in

order to prevent damage to the

appliance or danger arising

from improper use.

7 Do not use on wet surfaces and

do not attempt to use on wet

objects.

7 Do not use the appliance in wet

surroundings.

7 Do not use the appliance with

wet hands.

7 This appliance is designed for

vacuuming dirt and dust particles.

Do not attempt to use it on large

objects which could block and

damage the appliance.

7 Do not use to clean cigarette

stubs, ash from a fireplace or

matches. This could cause a fire.

7 This appliance is not designed

for cleaning people or animals.

7 Do not insert any foreign objects

into the suction intake. Always

keep the suction intake free of

all objects.

7 Never operate the appliance

without the filter.

7 Clean the filter when necessary.

7 Only use original GRUNDIG

accessories when replacing

parts.

7 Check if the mains voltage on

the rating label corresponds to

your local mains supply.

7 Always pull out the power cord

after the charging process,

before cleaning or carrying

out any maintenance on the

appliance or the charging unit.

7 Avoid using extension cables

or multipoint connectors. Plug

the appliance directly in a wall

socket if possible.

ENGLISH

SAFETY ___________________________________

7 For additional protection, this

appliance should be connected

to a household residual current

device with a maximum rating of

30 mA. Consult your electrician

for advice.

7 Do not disconnect the plug by

pulling on the cable.

7 Never use the appliance if it

or the power cord is visibly

damaged. This also applies if

the appliance has accidentally

become wet. Please contact a

service centre in this case.

7 Our GRUNDIG Household

Appliances meet all applicable

safety standards; thus if the

appliance or the power cord is

damaged, it must be replaced

by the dealer, a service centre

or a similarly qualified and

authorised service person to

avoid any danger arising. Faulty

or unqualified repair work may

cause danger and risk to the

user.

7 Keep the appliance away from

children.

7 This appliance can be used

by children aged from 8 years

and above and persons with

reduced physical, sensory or

mental capabilities or lack of

experience and knowledge if

they have been given supervision

or instruction concerning use

of the appliance in a safe way

and understand the hazards

involved. Children shall not play

with the appliance. Cleaning

and user maintenance shall not

be made by children without

supervision.

7 Do not dismantle the appliance

under any circumstances. No

warranty claims are accepted

for damage resulting from

improper handling.

7 Do not use the appliance if

the air duct and the ventilation

slot are blocked. Always keep

the air duct and ventilation slot

free of dirt, hair and any other

elements which could obstruct or

block the air flow.

7 Only use the power cord

provided.

ENGLISH

OVERVIEW ________________________________

Dear Customer,

Congratulations on the purchase of your new

GRUNDIG rechargeable stick vacuum cleaner

VCH 9530.

Please read the following user notes carefully to

ensure you can enjoy your quality GRUNDIG

product for many years to come.

A responsible approach!

GRUNDIG focuses on

contractually agreed social

working conditions with fair wages

for both internal employees and

suppliers, as well as on the efficient

use of raw materials with continual

waste reduction of several tonnes of plastic each

year – and availability of at least 5 years for all

accessories.

For a future worth living.

For a good reason. Grundig.

HEPA ﬁlter

HEPA stands for High Efficiency Particulate Air.

HEPA filters are particulate air filters, which filter

more than 99.9% of all dust particles larger than

0.1 to 0.3 micrometres out of the air. Viruses,

respirable dusts, mite eggs and mite excrement,

pollen, smoke particles, asbestos, bacteria,

diverse toxic dusts and aerosols are removed

from the air.

Controls and parts

See the ﬁgure on Page 3.

A Handle

B On/Oﬀ button

C Handle folding button

D Body

E Power indicator LEDs

F Brush removal button

G Brush

ENGLISH

PREPARATION _____________________________

Installing the parts

Lift the handle A and bring it to the vertical

position till it clicks.

Place the body D in a way to match with the slot

on the brush. Attach the brush till it clicks.

Press brush removal button to remove the body D

from the brush.

Charging the appliance

Note

7 For the first 3 uses, charge the appliance for

12 hours.

7 For the following uses, you can charge the ap-

pliance for 5 hours.

7 When the vacuum cleaner is in power shortage,

red light on the indicator board will be flashing.

Appliance needs to be charged promptly.

ENGLISH

PREPARATION _____________________________

OPERATION _______________________________

1 Attach the thin tip of the charging adapter to

the charging port on the body D and then

plug the charging adapter in the socket.

Charging

port

– Charge indicator LEDs E flash white.

– When the charge indicator LED E light

white constantly, charging is completed.

2 Remove the thin tip of the charging adapter

and unplug it from the socket.

Switching on and oﬀ your

appliance

Press On/Off button B to switch on and off the

appliance.

Note

7 During operation the LEDs E on the body light

up white, LED at the brush lights up blue.

Warning:

7 While charging, the appliance will not start to

operate even if you press On/Off button B.

7 When a big object is trapped by the brush, the

appliance is switched off automatically for your

safety.

ENGLISH

CLEANING AND MAINTENANCE _____________

Cleaning the dust container

Notes

7 It is recommended to clean the dust container

after every use.

Warning

7 Do not clean the appliance while it is running.

1 Press the dust container removal button to

remove the dust container.

2 Remove the ﬁlter from the dust container.

3 Empty the full dust container into a bin.

4 Separate HEPA ﬁlter, sponge ﬁlter and cyclone

element.

Sponge

filter

5 Clean the cyclonic ﬁlter, HEPA, sponge ﬁlter

and dust container under the running water.

6 Clean the body D of the appliance with a soft

damp cloth.

7 After all parts are dried, place the HEPA and

sponge ﬁlter into the cyclonic ﬁlter.

8 Place the cyclonic ﬁlter into the dust container.

9 Place the dust container into the body of the

appliance.

Cleaning the brush

1 Open the cover by using a screwdriver.

ENGLISH

2 Remove the cover, pull out the brush and clean

it.

Cover

Brush

roll

3 After cleaning and drying the brush roll, re-

attach it and secure the cover again with a

screwdriver.

CLEANING AND MAINTENANCE _____________

Storage

Store the appliance in a vertical position or with

its handle folded.

1 If you want to store the appliance with its

handle folded, press the handle folding button

C and fold the handle downwards.

INFORMATION ____________________________

Problem Possible reason/cause Solution

Appliance does not

work.

The battery may be ﬂat. Charge it.

Suction power is get-

ting weaker.

The dust container may be full. Empty the dust container.

HEPA ﬁlter may be blocked. Clean or replace HEPA ﬁlter.

Air vent or brush may be blocked. Clean the brush.

The appliance is not

charging.

The power cable may not be

plugged in.

Plug in the power cord to the socket.

You may have forgotten to attach the

thin tip of the charging adapter to the

charging port.

Attach the thin tip of the charging

adapter to the charging port.

The appliance stays

in operation for a

very short time after

being charged.

The appliance may not be charged

enough.

Charge the appliance for 5 hours.

Service life of the battery may be

reduced.

Contact your GRUNDIG authorised

service.

Troubleshooting
