GeoVision GV-POE0410-E Manual de usuario

GV-POE0410-E User's Manual

GV-PoE Switch

POE0410E-B

Before attempting to connect or operate this product,

please read these instructions carefully and save this manual for future use.

Under the copyright laws, this manual may not be copied, in whole or in part,

without the written consent of GeoVision.

Every effort has been made to ensure that the information in this manual is

accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind

and assumes no responsibility for errors or omissions. No liability is assumed

for incidental or consequential damages arising from the use of the information

or products contained herein. Features and specifications are subject to

change without notice.

GeoVision, Inc.

9F, No. 246, Sec. 1, Neihu Rd.,

Neihu District, Taipei, Taiwan

Tel: +886-2-8797-8377

Fax: +886-2-8797-8335

http://www.geovision.com.tw

Trademarks used in this manual: GeoVision, the GeoVision logo and GV

series products are trademarks of GeoVision, Inc. Windows is the registered

trademark of Microsoft Corporation.

July 2016





Contents

Contents.................................................................................................................... 2

1. Safety Precautions ................................................................................................ 1

2. Introduction ...........................................................................................................

2.1. Key Features ......................................................................................

2.2. Packing List ........................................................................................ 3

2.3. Option .................................................................................................

3. Hardware Description............................................................................................

4. DIN-Rail Mounting .................................................................................................

5. Hardware Installation.............................................................................................

5.1. Wiring the DC Power Inputs ................................................................

5.2. Wiring the Alarm Relay........................................................................

5.3. Wiring the Earth Grounding...............................................................

5.4. Enable the Event Alarm Function .......................................................

5.5. Cabling .............................................................................................

1. Safety Precautions

FCC Warning

This Equipment has been tested and found to comply with the limits for a Class-A

digital device, pursuant to Part 15 of the FCC rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy. It may cause harmful interference to radio communications if the equipment

is not installed and used in accordance with the instructions. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

yReorient or relocate the receiving antenna.

yIncrease the separation between the equipment and receiver.

yConnect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

yConsult the dealer or an experienced radio/TV technician for help.

1



2. Introduction

Figure 2-1



Product Overview

The GV-POE0410-E is a 4-port PoE Switch with 4 PoE+ 10/100/1000BaseT(X) port

and 1 Gigabit SFP. The switch supports IEEE 802.3at Power over Ethernet standard

with up to 30 W per port and maximum 130 W power consumption per system. No

special network cable is required for connecting your powered devices (PD), such as

IP cameras. The GV-POE0410-E is featured with a redundant power supply for

automatic power backup and supports alarms alerting for power and link failure.

The switch is designed for small network environment to strengthen its network

connection and efficiency.

Redundant Power Inputs

This switch provides two power inputs that can be connected simultaneously as

power supply. One of the power supplies provides backup power immediately if the

other fails.

Auto-Negotiation

Every port can automatically detect and adjust if the connected network devices are

running at 10Mbps, 100M, 1000Mbps and Half/Full-Duplex mode.

Auto-MDI/MDI-X

Every port can automatically detect your type of cable. There is no need for

crossover cables whether you are connecting this switch to another switch or to a

computer.

Rugged Design

This switch is designed for harsh environmental conditions. With its rigid aluminum

enclosure and 6kV surge protection design, the switch not only protects the surge

from the DC in port, but also the RJ-45 ports. By using this switch, it will make your

network more reliable regardless of the bad weather outside.

2

2.1. Key Features

•4-port PoE+ 10/100/1000BaseT(X), 1 Gigabit SFP

•IEEE 802.3at Compliant (4 Ports at Full 30W)

•Max. 130 W power consumption

•Extreme temperature support (40°C ~ 70°C /40°F ~ 158°F)

•Auto-MDI/MDI-X

•Auto-Negotiation

•Alarm control

•DIN-Rail Installation

•Redundant DC power

•6 kV surge protection

•Up to 4 GV-IP Cameras support

2.2. Packing List

1. GV-POE0410-E x 1

2. GV-POE0410-E Quick Start Guide x 1

2.3. Option

Optional devices can expand your GV-POE0410-E’s capabilities and versatility.

Contact your dealer for more information.

GV-LC and GV-LC10

The SFP Transceiver is designed to plug into the SFP

port of the GV-POE Switch and is the interface between

the switch and optical fiber cables. This product complies

with IEEE 802.3z 1000BaseSX/LX standards. The SFP

Transceiver is a hot swappable device; you can add or

remove the device without powering down.

3



3. Hardware Description

This section mainly describes the hardware of this switch and gives a physical and

functional overview on the switch.

Dimensions

The dimensions of this switch are 120 x 55 x 108 mm (4.72” x 2.16” x 4.25”).

Figure 3-1

4

Front Panel

4 PoE ports / LED

Gigabit SFP port / LED

Alarm Control / LED

Power 1 ~ 2

Figure 3-2

LED Status Description

Green on Power onPWR1

Off Power off

Green on Power onPWR2

Off Power off

Red on Port link down or power failureAlm

Off No event

Green On A network device is detected and links upPort 1~4

Yellow On A powered device is detected and links up

Port 5 (SFP) Green on The gigabit SFP port links up



Note: If the power LEDs go off when the power cord is plugged in, a power failure

might have occurred. Check the power output connection to see if there is any error

at the power source. If you still cannot solve the problem, contact your local dealer

for assistance.

5



Bottom Panel

Dip Switch for

Alarm Control

Removable

Terminal Block

Earth Ground Screw



Figure 3-3

The GV-POE0410-E is featured with a redundant power supply for automatic power

backup and supports alarms alerting for power and link failure.



Power Supply

With DC power cables wired to both PW1 and PW2 on the terminal block, one of the

power supplies provides backup power immediately if the other fails.

Alarm Control

With an alarm device wired to Alm on the terminal block, when any of the power

supplies fails or any of the port links fails, the alarm will be triggered. Use the dip

switch to enable or disable the alarm function.

Power 1 Connect to DC power input

Power 2 Connect to DC power input

Terminal

Block

Alarm control Connect to an alarm output

Switch 1 ~ 5 Switch up/down to turn on/off the alarm of

corresponding port links on the front panel.

Dip switch 1 ~ 4 corresponds to Port 1 ~ 4, and dip

switch 5 corresponds to Port 5 (SFP) on the front

panel.

Dip Switch

Switch 6 Switch up/down to enable/disable the alarm for

power failure.

6

4. DIN-Rail Mounting

A DIN-Rail clip is built in the rear body of the switch supporting EN 50022 standard

DIN Rail. The dimensions of EN 50022 DIN Rail are included in the following

diagram. Follow the steps below to mount the switch on a DIN-Rail track.

1. Insert the upper end of the DIN-Rail clip into the back of the DIN-Rail track

from its upper side

2. Lightly push the bottom of the DIN-Rail clip into the track.

3. Check if the DIN-Rail clip is tightly attached to the track.

4. To remove the switch from the track, reverse the steps above.

Figure 4-1 
