Gefen DVI-422DL Manual de usuario

2x2 DVI DL

Switcher

USER MANUAL

www.gefen.com

Technical Support:

Telephone (818) 772-9100

(800) 545-6900

Fax (818) 772-9120

Technical Support Hours:

8:00 AM to 5:00 PM Monday through Friday.

Write To:

Gefen Inc.

c/o Customer Service

20600 Nordhoff St

Chatsworth, CA 91311

www.gefen.com

[email protected]

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and any

accompanying documentation without prior written notice.

The 2x2 DVI DL Switcher is a trademark of Gefen Inc.

ASKING FOR ASSISTANCE

TABLE OF CONTENTS

Introduction

Front Panel Descriptions

Back Panel Descriptions

How To Connect The 2x2 DVI Switcher

System Speciﬁcations

Warranty

INTRODUCTION

Thankyouforpurchasing Gefen’s2x2DVIDLSwitcher.The2x2DVIDLSwitcherswitches

DVI, USB 2.0 and Audio between any combination of two computers.

The 2x2 DVI DL DVI Switcher allows you to easily switch between two cross-platform

extended desktop dual link DVI computers using just two dual link DVI displays, USB 2.0

keyboard and mouse. Dual link DVI uses all 24 pins of the DVI connector to achieve ultra

high video resolutions up to 3840x2400. USB 2.0 is the next generation of USB, capable

of sending data signiﬁcantly quicker than before. Video and control signals are “switched”

foreachcomputer uponselectionusing DiscreteIR Remote andDiscrete ContactClosure

(RMT-2x2), providing you with an easy and effective method of accessing two computers

from one workstation without the hassle of networking.

You simply connect your Dual Link DVI displays and USB 2.0 keyboard/mouse to the

Switcher’soutputs.Then youconnectyour computers’DualLink DVIandUSB portstothe

Switcher’sinputs usingthe suppliedcables.From there,youselect thecomputer youwant

using the IR remote that comes with the unit. It allows you to switch seamlessly between

Macintosh or PC keyboard/video/mouse combinations.

CONTENTS

The 2x2 DVI DL Switcher package consists of:

(1) 2x2 DVI DL Switcher

(1) RMT-2IR

(1) 5V Power Supply

(4) 6ft Dual Link DVI cables

(2) 6ft USB 2.0 Cables

(1) User’s Manual

(1) Rack Ears

1-2 Indicator LED

Power LED

FRONT PANEL DESCRIPTIONS

1-2 Switch Buttons

IR eye

BACK PANEL DESCRIPTIONS

POWER INPUT

DVI IN 1.1 DVI IN 1.2 DVI IN 2.1 DVI IN 2.2 DVI OUT 2 USB

OUTS

USB INPUTS

REMOTE -

RJ-45 Connecter

For RMT-4 Wired

Remote

AUDIO IN 1 AUDIO IN 2 AUDIO OUT

DVI OUT 1

1- Connect the cables from your ﬁrst computer into the DVI 1.1, DVI 1.2, USB and

Audio inputs in the back of the 2x2 DVI DL Switcher.

2- Connect the cable from your second computer into the DVI 2.1, DVI 2.2, USB and

Audio inputs in the back of the 2x2 DVI DL Switcher.

3- Connect the monitors to the DVI Out 1 & 2 .

4- Plug the 5v power supply into the 2x2 DVI DL Switcher.

5- Plug the 5v wallmount power supply into the wall outlet.

6- Start your computers only after you’ve made all the connections.

7- Press select, to switch between Computer 1 or Computer 2. You can also switch

between sources using the RMT-2IR. Switch remotely using the optional RMT-2

contact closure remote control.

HOW TO CONNECT THE 2x2 DVI DL SWITCHER

Video Ampliﬁer Bandwidth............................................................................2 x 1.65 Gbps

Input Video Signal...........................................................................................1.2 volts p-p

Input DDC Signal......................................................................................5 volts p-p (TTL)

Dual Link Range..............................................................................................3840 x 2400

DVI Connector.................................................................DVI-I 29 pin female (digital only)

Audio Connector.........................................................................mini-phone stereo 3.5mm

USB 2.0 Input Connection.....................................................................................Type “B”

USB 2.0 Output Connection..................................................................................Type “A”

Power Supply...........................................................................................................5V DC

Power Consumption....................................................................................20 watts (max)

Dimensions..............................................................................17” W x 1.75” H x 4.375” D

Rackmountable..........................................................................................1U Rack Space

Shipping Weight.........................................................................................................8 lbs.

SPECIFICATIONS

Gefen Inc. warrants the equipment it manufactures to be free from defects in material

and workmanship.

If equipment fails because of such defects and Gefen Inc. is notiﬁed within two (2) year

from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment,

provided that the equipment has not been subjected to mechanical, electrical, or other

abuse or modiﬁcations.

Equipment that fails under conditions other than those covered will be repaired at the

current price of parts and labor in effect at the time of repair. Such repairs are warranted

for ninety (90) days from the day of reshipment to the Buyer.

This warranty is in lieu of all other warranties expressed or implied, including without

limitation, any implied warranty or merchantability or ﬁtness for any particular purpose, all

of which are expressly disclaimed.

1. Proof of sale may be required in order to claim warranty.

2. Customers outside the US are responsible for shipping charges to and from Gefen.

3. Copper cables are limited to a 30 day warranty and cable must be free from any

scratches, markings, and neatly coiled.

Theinformation inthis manualhas beencarefully checkedand isbelieved tobeaccurate.

However, GefenInc.assumes noresponsibility foranyinaccuracies thatmay becontained

in this manual. In no event will Gefen Inc., be liable for direct, indirect, special, incidental,

or consequential damages resulting from any defect or omission in this manual, even if

advised of the possibility of such damages. The technical information contained herein

regarding the 2x2 DVI Switcher features and speciﬁcations is subject to change without

notice.

WARRANTY
