16x16 DVI Matrix

EXT-DVI-16416

User Manual

ASKING FOR ASSISTANCE

Technical Support:

Telephone (818) 772-9100

(800) 545-6900

Fax (818) 772-9120

Technical Support Hours:

8:00 AM to 5:00 PM PST Monday thru Friday PST

Write To:

Gefen Inc.

c/o Customer Service

20600 Nordhoff St

Chatsworth, CA 91311

www.gefen.com

[email protected]

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and

any accompanying documentation without prior written notice.

16x16 DVI Matrix is a trademark of Gefen Inc.

All trademarks are the property of their respective owners

Rev C4

4.6

CONTENTS

1 Introduction

2 Operation Notes

3 Features

4 Panel Layout

5 Panel Descriptions

6 Connecting And Operating The 16x16 DVI Matrix

7 Front Panel Display

9 RMT-16416IR Remote Description

10 RMT-16416IR Remote Installation

11 RMT-16416IR Code Conﬁguration

12 EDID Management Feature

13 RS-232 Serial Control Interface

14 RS-232 Serial Control Commands

19 WEB Interface - Main Page

20 WEB Interface - Manage EDID

23 WEB Interface - Masking

24 WEB Interface - IP Conﬁguration

25 WEB Interface - Backup/Restore & Power Management

26 Peripheral Device Power

27 Firmware Update

29 Speciﬁcations

30 Warranty

Congratulations on your purchase of the 16x16 DVI Matrix. Your complete

satisfaction is very important to us.

Gefen

Gefen delivers innovative, progressive computer and electronics add-on solutions

that harness integration, extension, distribution and conversion technologies.

Gefen’s reliable, plug-and-play products supplement cross-platform computer

systems, professional audio/video environments and HDTV systems of all sizes

with hard-working solutions that are easy to implement and simple to operate.

The Gefen 16x16 DVI Matrix

Now you can easily combine sixteen cross-platform computers and sixteen digital

displays using the 16x16 DVI Crosspoint Matrix. The Matrix provides a simple,

reliable and highly effective method of routing multiple computer workstations.

Each computer is capable of displaying video on any one of the 16 monitors.

There are 4 methods of controlling the Matrix - by using the front panel buttons,

the IR remote, a built-in RS-232 interface, and IP control over a local area

network.

How It Works

The 16x16 Crosspoint Matrix has sixteen DVI inputs and sixteen DVI outputs.

Using the supplied DVI cables, connect your sixteen computers to the DVI input

ports on the Matrix’s input side. Connect the Matrix’s sixteen DVI outputs to

the displays. Plug in the power cord and power on the Matrix. The connected

displays will show video according to the selection.

Note: This device only supports DVI-D.

INTRODUCTION

READ THESE NOTES BEFORE INSTALLING OR

OPERATING THE 16X16 DVI MATRIX

• The 16x16 DVI Matrix is not HDCP compliant

• There is a LOCAL EDID storage bank for each of the 16 DVI inputs. By

default, the EDID from the display connected to DVI Output 1 will be copied

to all 16 banks for use by each source device upon powering of the unit.

Please ensure that a display is powered and connected to the ﬁrst output

port before applying power to the 16x16 DVI Matrix. If a display is not

detected, an internal default EDID (640x480) will be used. This feature can

be disabled by using the Secure Local EDID function via the RS-232 serial

controls. Please see page 17 for more information.

• There is no internal scaling in the 16x16 DVI Matrix. All of the attached

monitors must be able to display the resolutions output by the source

devices. For maximum compatibility it is recommended that only one

compatible/common resolution be used by all of the source devices.

• Advanced EDID features and IP conﬁguration features are accessible via the

RS-232 serial communications. Please see page 13 for more information.

• Routing and EDID features can be accessed via a web browser using the IP

control feature built into the 16x16 DVI Matrix

OPERATION NOTES

Features

• Increases productivity by providing access to 16 displays from any 16

computers.

• Web-based control switching

• Maintains beautiful, sharp resolutions up to 1080p, 2K, and 1920x1200.

• Serial RS-232 for remote control via a computer or control automation

devices

• Supports DDWG standards for DVI monitors

• Discrete IR remote control included

Package Includes

(1) 16x16 DVI Matrix

(16) 6-foot DVI cable (M-M)

(1) 6-foot serial DB9 cable (M-F)

(1) RMT-16416IR remote control

(1) 24V DC Power Supply

(1) Set of Rack Ears

(1) Users Manual

FEATURES

Front Panel

Back Panel

911

4 5

6 8

PANEL LAYOUT

1 Main LCD Display

This 2 line 16 character display will display status information and is also used to

manage the display/source routes.

2 Control Buttons

These buttons are used to navigate the functions of the 16x16 DVI Matrix. The

following buttons are available:

◄- Left

►- Right

Select - Select

For complete details on these controls and how they are utilized, please see

page 7 and 8.

3 Infrared (IR) Receiver

This IR receiver will accept commands form the included RMT-16 remote

control. Line-of-sight between this receiver and the remote controls needs to be

preserved for proper operation.

4 Power LED Indicator

This LED indicator will be active when the included 24V DC power supply is

properly connected to the unit.

5 Cancel Button

This button is used to return the user to the main status screen once a routing

change has been initiated and the user decides to not continue with the change.

6 RS-232 Serial Communications Interface

This interface was designed to accept commands from an external control

system. This port will allow switching commands as well as EDID management

and conﬁguration operations. Please see page 13 for more information.

7 DVI Output Ports 1-16

These outputs are used to connect up to 16 DVI capable displays.

8 24V DC Power Receptacle

The port will accept power from the included 24V DC power supply.

9 DIP Switch Conﬁguration Bank

These DIP switches are used to control the IR Code Conﬁguration. Please see

page 11 for more information.

10 DVI Input Ports 1-16

These inputs are used to connect up to 16 DVI capable sources.

11 10/100 Ethernet Control Interface

This port is used to connect the 16x16 DVI Matrix to a network for IP control.

Please see page 19 for more information.

PANEL DESCRIPTIONS

How to Connect the 16x16 DVI Matrix

1. Connect up to 16 DVI source devices to the DVI inputs on the rear panel of

the 16x16 DVI Matrix using the supplied DVI cables.

2. Connect up to 16 DVI capable display to the DVI outputs on the rear panel of

the 16x16 DVI Matrix using user supplied DVI cables.

3. Connect the included 24V DC power supply to the power input receptacle

on the rear panel of the 16x16 DVI Matrix. Connect the opposite end of the

cable into a open wall power socket.

How to Operate the 16x16 DVI Matrix

The 16x16 DVI Matrix offers a number of control options. The following options

can be used to control basic routing functions of the 16x16 DVI Matrix:

1. Front Panel Control Buttons - Page 7 and 8

2. RMT-16416IR Remote Control - Page 9 and 10

3. RS-232 Serial Control - Page 14 -18

4. IP Control - Page 19-25

CONNECTING AND OPERATING THE 16X16 DVI MATRIX

FRONT PANEL DISPLAY

MAIN DISPLAY

The Main Display of the 16x16 DVI Matrix is a 16 character 2 line display. This

display will show the standby screen and will also be used to aid in performing

routing commands. The following is the standby screen:

This screen will display the company and product name.

Pressing the ◄or ►will display the firmware screen:

This screen will display the current ﬁrmware revision.

FRONT PANEL SELECTION

To route sources to a display :

Starting at the standby screen, press the SELECT button. The display selection

screen will now be displayed:

On this screen use the ◄or ►buttons to select the desired display that will

have a source routed to it in the next step. Once selection is complete press the

SELECT button to confirm the selection. To cancel this operation at this time

press the CANCEL button.
