USB•100
USER MANUAL
www.gefen.com
ASKING FOR ASSISTANCE
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff St.
Chatsworth, CA 91311
www.gefen.com
© 2007 Gefen Inc., All Rights Reserved
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
USB•100 is a trademark of Gefen Inc.
ExtremeUSB is a trademark of Icron Inc.
Macintosh is a trademark of Apple
Computer Inc.
TABLE OF CONTENTS
Introduction
Operation Notes
USB Series Installation
USB•100 Panel Layout
USB•100 Function Description
Wiring Diagram
Link Cable Diagram
Check List
Troubleshooting Hints
Warranty
1
2
3
4
5
6
7
8
9
10
Thank you for purchasing the ex•tend•it USB•100 Series. The new USB•100
incorporates ExtremeUSB™ technology, which allows users the benefits of USB
technology beyond the desktop. Extending your USB peripherals (i.e. computer
keyboard, mouse or trackball) up to 330 feet away from the location of your Macintosh
or PC computer are done easily with the USB•100.
The USB•100 system consists of two units. The USB•100S sender resides next to
the host computer, and the USB•100R receiver is linked to the sender via Category-5
(CAT-5) cable and resides at the desired location away from the computer.
The USB•100 signal is sent between the sender and receiver controls USB
peripherals by buffering the USB signal through send and receive line drivers. The
signal is extended by using standard Category 5 (CAT-5) cabling.
You can connect additional USB•100 systems to the same computer, allowing you to
access the computer from multiple locations up to 330 feet apart.
INTRODUCTION
1
OPERATION NOTES
READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE USB•100 SYSTEM.
* The USB•100 send and receive were designed to operate on USB enabled computers.
DO NOT attempt to use this equipment with any other type of computer.
* Use the computer's USB port when using a local keyboard that is not extended with
the USB•100 sender unit.
* In order to operate properly, the USB•100 receiver unit must be connected, powered,
and the CAT-5 cable must be installed between the send and receive units.
* Only dedicated Category 5 UTP type cable (CAT-5) is recommended for this
application (pin to pin).
* The length of cable used to connect the USB•100S send unit to the USB•100R
receiver unit MUST NOT EXCEED 330 feet.
2
USB•100 SERIES INSTALLATION
3
1. Place the USB•100R unit close to the USB devices at the remote end.
2. Connect the USB devices to the USB•100R unit.
3. Connect the power adapter to a suitable DC source wall outlet.
4. Connect the power adapter to the USB•100R unit using the supplied cable.
5. Place the USB•100S unit close to the host computer.
6. Connect the USB•100S unit to the USB•100R unit using the desired length of CAT5
cable
7. Connect the USB•100S unit to the host computer using the USB cable supplied with
the unit. This connection should be made last.
USB•100 PANELS LAYOUT
USB•100S
USB•100R
USB•100R
Power
1 2 3 4 5 6
Link
USB In
Link
USB OUT
10987
Power
12
11
4
USB LED - Indicates if a USB connection is made properly
USB In - USB cable (A-B) cable from computer to sender
Link LED - Indicates if a link between the USB•100S send and the USB•100R
Receive units
Link - CAT-5 Modular Jack which connects to the USB•100S send and the
USB•100R Receive units
Power LED - Indicates the unit is plugged in and powered up.
DC IN - Power plug for 15VDC Wallmount power supply.
Link LED - Indicates if a link between the USB•100S send and the USB•100R
Receive units
Link - CAT-5 Modular Jack which connects to the USB•100S send and the
USB•100R receive units
Power LED - Indicates the unit is plugged in and powered up.
DC IN - Power plug for 15DAC Wallmount power supply.
USB Led - Indicates if a USB device is plugged in
USB input A - One USB A type connector
USB•100 FUNCTION DESCRIPTION
5
1
2
3
4
5
6
7
8
9
10
11
12
WIRING DIAGRAM
6
Up to 330 feet using CAT5 cable
USB•100R USB•100S
LINK CABLE - WIRING DIAGRAM
7
White/Orange
Orange
White/Green
Blue
White/Blue
Green
White/Brown
Brown
RJ-45 Jack RJ-45 Jack
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
1818
