Gefen EXT-HDKVM-ELR Manual de usuario
Release A7
EXT-HDKVM-ELR
User Manual
HD KVM
Extra Long Range Extender
Over One CAT5
*Preferred
Gefen warrants the equipment it manufactures to be free from defects in material and
workmanship.
If equipment fails because of such defects and Gefen is notied within two (2) years from
the date of shipment, Gefen will, at its option, repair or replace the equipment, provided
that the equipment has not been subjected to mechanical, electrical, or other abuse or
modications. Equipment that fails under conditions other than those covered will be
repaired at the current price of parts and labor in effect at the time of repair. Such repairs
are warranted for ninety (90) days from the day of reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including without
limitation, any implied warranty or merchantability or tness for any particular purpose, all of
which are expressly disclaimed.
1. Proof of sale may be required in order to claim warranty.
2. Customers outside the US are responsible for shipping charges to and from Gefen.
3. Copper cables are limited to a 30 day warranty and cables must be in their original
condition.
The information in this manual has been carefully checked and is believed to be accurate.
However, Gefen assumes no responsibility for any inaccuracies that may be contained
in this manual. In no event will Gefen be liable for direct, indirect, special, incidental, or
consequential damages resulting from any defect or omission in this manual, even if
advised of the possibility of such damages. The technical information contained herein
regarding the features and specications is subject to change without notice.
Warranty Information
• Shielded CAT-5e (or better) cables should not exceed 330 feet (100 meters) between
the Sender and Receiver unit.
• By default, the source device will use the EDID from the display (or other sink device)
which is connected the Receiver unit. See EDID Management (page 8) for more
information.
• If terminating network cables in the eld, please adhere to the TIA/EIA568B
specication. See the Network Cable Diagram (page 12)for details.
Operating Notes
Features and Packing List
Features
• Extends 4K Ultra HD (3840 x 2160 @ 60Hz, 4:2:0 or 30Hz, 4:4:4), and USB over
a single CAT-5e cable up to 330 feet/100 meters (8-bit color)
• Extends 4K Cinema (DCI) (4096 x 2160 @ 24 or 30Hz 4:4:4), and USB over
a single CAT-5e cable up to 330 feet/100 meters (8-bit color)
• Extends HDMI at 1080p Full HD, and USB over a single CAT-5e cable up to
330 feet/100 meters (up to 12-bit Deep Color)
• Supported HDMI features:
►HDMI 2.0
►HDCP 1.4 compliant
►12-bit Deep Color
► LPCM 7.1 audio, Dolby® TrueHD, Dolby Digital® Plus, and DTS-HD® Master
Audio™ pass-through
►3DTV pass-through
► CEC pass-through
► Lip Sync pass-through
• Supports up to 30 Mbps when using USB 2.0
• Backward-compatible with USB 1.1
• EDID management for rapid integration of source and display devices
• ELR and HDBaseT® technologies
• Locking power supplies
• 1U tall, half-rack width enclosures are rack-mountable using EXT-RACK-1U
®
®
™
™
1080P
60Hz, 4:2:0
HDCP
4K
CINEMA
DCI, 4096 x 2160, 30Hz
4K
CINEMA
DCI, 4096 x 2160, 30Hz
Packing List
The HD KVM Extra Long Range Extender Over One CAT5 ships with the items listed
below. The packing contents of the Sender and Receiver unit are listed below. If any of
these items are not present in the box when you rst open it, immediately contact your
dealer or Gefen.
• 1 x HDKVM ELR Extender over One CAT5 - Sender unit
• 1 x HDKVM ELR Extender over One CAT5 - Receiver unit
• 1 x 6 ft. HDMI cable, locking (M-M)
• 1 x 6 ft. USB Cable (A-B)
• 2 x 5V DC Locking Power Supplies
• 2 x AC Power Cord
• 1 x Quick-Start Guide
Features and Packing List
HD KVM
Extra Long Range Extender
Over One CAT5
Getting Started
Page Title
Sender Unit
ID Name Description
1 Power This LED glows solid blue when the unit is
connected to an AC outlet and the unit is
powered ON.
2 Link This LED glows solid blue when the Sender
unit and Receiver unit are connected and
passing video.
3USB This LED indicator glows solid blue when a
USB source is connected to the Sender unit.
4 Video This LED indicator ashes blue when a video
source is connected to the Sender unit.
VideoLink
USB
Power
HD KVM ELR Extender over one CAT-5 S
®
EXT-HDKVM-ELRS
Service
Link HDMI In USB 5V DC
Introduction
Getting Started
Getting Started
1 3
2 4
Page Title
ID Name Description
1 Link Connects the Sender unit to the Receiver
unit using shielded CAT-5e (or better) cable.
2Service Mini-USB port for factory use only.
3 HDMI In Connect the included HDMI cable from this
connector to the HD source.
4USB Connect the included USB cable from the
computer to this USB port.
5 5V DC Connect the included 5V DC locking power
supply to this power receptacle.
VideoLink
USB
Power
HD KVM ELR Extender over one CAT-5 S
®
EXT-HDKVM-ELRS
Service
Link HDMI In USB 5V DC
Introduction
Getting Started
43 51 2
Introduction
Getting Started
Getting Started
Receiver Unit
ID Name Description
1 Power This LED glows solid blue when the unit is
connected to an AC outlet and the unit is
powered ON.
2 Link This LED glows solid blue when the Sender
unit and Receiver unit are connected and
passing video.
3USB This LED indicator glows solid blue when
a USB device is connected to the Receiver
unit.
4 Video This LED indicator ashes blue when a
display is connected to the Receiver unit.
Link Video
USB
Power
HD KVM ELR Extender over one CAT-5 R
®
2 E
1 2
ON TD402
EXT-HDKVM-ELRR
Service
Link HDMI Out USB 5V DC
1 3
2 4
ID Name Description
1 Link Connects the Receiver unit to the Sender
unit using shielded CAT-5e (or better) cable.
2 HDMI Out Connect an HDMI cable from this connector
to the display.
3Service Mini-USB port for factory use only.
4USB Use these ports to connect up to three USB
devices.
5 5V DC Connect the included 5V DC locking power
supply to this power receptacle.
Link Video
USB
Power
HD KVM ELR Extender over one CAT-5 R
®
2 E
1 2
ON TD402
EXT-HDKVM-ELRR
Service
Link HDMI Out USB 5V DC
Introduction
Getting Started
432 51
