Geemarc CL330 Manual de usuario

2LMC59YY

MULTIFUNCTION TELEPHONE

User guide P2

Notice D'utilisation P38

CL330

CONTENTS 1

INTRODUCTION 3

Unpacking the Telephone 4

DESCRIPTION 5

General Description 5

LCD Screen Description 7

Menu Navigation 7

INSTALLATION 8

Setting Up 8

Wall Mounting 10

SETTINGS 11

Language Setting 11

Screen Contrast Setting 12

Time Setting 13

Voice Function Setting 14

Flash (Recall) Setting 15

Dialling Mode (Tone/Pulse) Setting 15

Ringer Volume Setting 16

Ringer Tone Setting 16

USING THE TELEPHONE 17

Making a Call 17

Receiving a Call 19

Last Number Redial 19

Mute Function 20

Handset Volume Setting 20

Speaker Volume Setting 20

Tone Control Setting 20

Call Timer 21

Hearing Aid Use 21

Headset use 21

CONTENTS

CALLER DISPLAY 22

View Caller Display List 23

Dial a Number from the Caller Display List 23

Delete an Entry from the Caller Display List 24

Delete all Entries from the Caller Display List 24

Copying a Number to the Phone Book 25

PHONE BOOK 26

Create a Phone Book Entry 26

Store/Change a Name Recording 28

Delete a Name Recording 29

View Phone Book Entries 29

Dialling using a Phone Book Entry 30

Modify a Phone Book Entry 30

Delete a Phone Book Entry 31

Delete all Phone Book Entries 31

QUICK DIAL

Storing a Quick Dial Number 32

Dialling a Quick Dial Number 32

TROUBLE SHOOTING 33

SAFETY INFORMATION 34

GUARANTEE 35

RECYCLING DIRECTIVES 37

CONTENTS

Congratulations on purchasing your Geemarc CL330 telephone.

This is a multifunction telephone which offers features such as hands

free use, phone book, caller display* and voice announcing.

Its is important that you read the instructions below in order to use

your Geemarc telephone to its full potential. Keep this user guide in

a safe place for future reference.

This guide explains how to use the following telephone:

CL330

*To use the caller display facility, you must subscribe to your network provider’s caller

display service.

INTRODUCTION

Unpacking the Telephone

When unpacking the telephone, you should find the following in the

box:

•1 CL330 unit

•1 CL330 handset with curly cord

•1

Mains power adaptor

•1

Telephone line cord

•1 User Guide

For product support and help visit our website at www.geemarc.com

Telephone 01707 384438

Or fax 01707 372529

INTRODUCTION

General Description

CALL#

CLIP

TONE VOLUME

CMENU

DESCRIPTION

1= LED (flashes when a new call has been received)

2= Delete

3= Call back, confirm

4= Tone slide control

5= Amplify LED

6= Caller ID mode button

7= Amplify button

8= Speakerphone volume slide control

9= Handset

10= Mute

11= Scroll left

12= Menu

13= Scroll right

14= Earpiece volume control

15= Quick Dial M1 (emergency call number 1)

16= Phone book

17= Quick Dial M2 (emergency call number 2)

18= Quick Dial M3 (emergency call number 3)

19= Quick Dial M4 (emergency call number 4)

20= LED handsfree mode

21= Handsfree

22 = LED headset mode

23 = Headset

24 = Redial, Insert a pause

25 = Recall

Only If you have subscribed to the "Caller Display" service

from your network provider

DESCRIPTION

LCD Screen Description

This LCD display shows the total number of calls and the number of

new calls ready to be reviewed. In this example you have a total of 4

calls which includes two new calls.

Menu Navigation

To access settings, press

To exit the menu, press . or

To skip back a level within the menu, press

The telephone will automatically return to standby mode from any

menu if no button is pressed for 20 seconds.

DESCRIPTION

9:52 9/12

TOTAL:04 NEW:02

Battery

Low

Icon

level

Time and Date

New Calls

Received

Calls Received

9:52 9/12

call#

01517222277

ROBERT JONES

Caller’s Number

Caller’s Name

Setting Up

Connect the handset to one end of the curly cord. The connector at

the end of the curly cord plugs into the socket on the left hand side of

the CL330 unit.

Open the battery compartment (push the small clip backwards and

then upwards). Insert 4 good quality alkaline batteries (AA size, 1.5V

type, not supplied) into the battery compartment located on the base

of the telephone. Replace the battery cover. If the batteries are

running low, the low battery icon will appear on the LCD display.

Ensure that the telephone is not connected to the telephone line

socket and/or mains power connection when the batteries are being

inserted or replaced.

Note : Do not use rechargeable batteries. Do not put batteries into

the household rubbish, pay attention to battery regulations regarding

battery disposal.

Connect the line cord to the socket located at rear of telephone then

connect the plug into the wall socket *.

Connect the power supply to the socket located at rear of the

telephone then plug into a 13amp wall socket. Please choose a

socket near your telephone to enable you to unplug the mains power

quickly in case of a problem.

(*) Classified “hazardous voltage” according to EN60950 standard

(**) Classified TNV-3 according to EN60950 standard.

INSTALLATION

Note:

Mains power is required to power the multifunction features

of the telephone. Fit 4 x AA sized batteries in order to save and

use stored numbers in case of mains power failure. Without mains

or battery power, the telephone can still be used to answer calls or

to manually dial out calls but all the multifunction features will not

be available. If no batteries are inserted, the low battery icon will

be displayed on the LCD display.

INSTALLATION
