GE 610 Manual de usuario

MODEL 610

Liquid Nitrogen

Battery Operated Low Level Alarm

16380 13 Mile Rd. • Roseville, Michigan 48066 • (586) 778-0426 • Fax (586) 778-0479

www.gordinier.com Email: pat@gordinier.com

TABLE OF CONTENTS

Receiving and Unpacking 1

Features 2

Installing Bracket and Controller to Small Refrigerator 3

Low Level Probe Installation 4

Connect Probe to Controller 5

Connect Transformer to Controller 5

Option - Special Order 6

Testing the Controller 7

Charging the Battery 7

Calibrating Low Level Alarm 8

Care & Maintenance 9

MODEL 610

MODEL 610 RECEIVING & UNPACKING

Important!

Carefully examine the shipping carton and contents for damage. If carton or contents are

damaged, contact your Gordinier Electronics, Inc. distributor or Gordinier Electronics Inc. directly at

(586) 778-0426, immediately to file a claim. To preserve the right to claim shipping damages, the

packing, inspection and filing of the claim must take place promptly. Failure to inspect and file

promptly will release the shipper from liability.

Check the contents for apparent shipping damage such as broken knobs, switches or dented

cases. If there is any damage, IMMEDIATELY contact the carrier for corrective action.

If an operating problem has been detected once the instrument has been properly set up,

contact your Gordinier Electronics, Inc. distributor or Gordinier Electronics Inc. directly at

(586) 778-0426.

STOP! READ THIS ENTIRE INSTRUCTION MANUAL

If you do not understand these instructions, please contact us

for further explanation. Failure to comply may result

in damage to unit or poor equipment performance.

Gordinier Electronics, Inc.

16380 13 Mile Road

Roseville, MI 48066

Phone (586) 778-0426 Fax (586) 778-0479

www.gordinier.com Email: pat@gordinier.com

Model 610 1

Test Button

Audible Horn

Calibration

Setting

9 Volt Connection

Probe

Connection

On/Off Calibration

Toggle Switch

BATTERY OPERATED LOW LEVELALARM

Features:

This economical, battery operated nitrogen low level alarm, provides up to 5 days of alarm on one

charge.

This handy unit is also equipped with a built-in battery charger, a bracket designed to protect the unit

during fill. Model 610 Liquid Nitrogen Low Level Alarm, is a small self-contained unit with features

you would expect to find only in larger costly alarms, designed with a test circuit and probe protection.

MODEL 610

Model 610 2

♦Built-in battery charger

♦Continuous alarm (5 days on full battery charge)

♦Universal 9 volt AC Wall Transformer/OPTION 220 volt

♦Open or shorted probe protection

♦Push to test button (battery and alarm can both be

tested at the same time)

♦Easy Installation

♦Low battery indicator

♦Compact size (3 1/4” x 5 1/2” x 1 3/4”)

♦Complete with mounting bracket to fit on the unit handle

INSTALLING BRACKET AND

CONTROLLER TO SMALLREFRIGERATOR

WARNING

Do Not allow this controller to come in contact

with Liquid Nitrogen vapors

Model 610 3

MODEL 610

• Secure bracket to handle on storage unit with existing screw.

• Remove Velcro Film from strip (2 places) and position controller onto bracket.

Screw

Velcro Film

Bracket

Handle

Controller

LOW LEVELPROBE INSTALLATION

MODEL 610

WARNING

Do Not allow this controller to come in contact

with Liquid Nitrogen vapors

Model 610 4

Lower the Sensor Probe to bottom of tank and raise off the bottom to desired level. A minimum of

2 to 3 inches is suggested, this should allow for several days of safety margin. The sensor bulb is

approximately 1/4” from end of probe.

Note: Consult tank manufacturer for data on “Day of holding time per inch of liquid nitrogen

level”.

Sensor Probe

Liquid Nitrogen

Sensor Probe

Connector

Controller

End of Sensor

Probe

When proper depth is determined gently bend the probe wires at the neck of the dewar.

CONNECT PROBE AND TRANSFORMER

TO CONTROLLER

WARNING

Do Not allow this controller to come in contact

with Liquid Nitrogen vapors

MODEL 610

Model 610 5

Plug the 9 Volt AC Transformer into proper AC outlet. It is imperative, for safe and stable

operation, that the controller be connected to a properly grounded AC outlet. Unfortunately,

some of the three (3) prong outlets are not properly grounded. Check to make sure that the

outlet to be used is connected to a known ground BEFORE plugging in theAC power cord.

ProperAC Outlet

9 Volt

Transformer

9 Volts AC

Low Sensor Probe

9 Volt

Transmittor

Connector (B)

Plug the Probe (A) into the Controller (as shown above).

Plug the 9 Volt AC Transformer connector (B) into the Controller (as shown above).

The Power LED will light.

(B)

(A)

Horn

Refer to Page 5 for Probe

Connection to Controller Special Order Lid

inserts directly

into dewar.

Low Level

Alarm Probe

OPTION

Special Order Lid

WARNING

Do Not allow this controller to come in contact

with Liquid Nitrogen vapors

MODEL 610

Model 610 6

Special Order Lid

TESTINGTHE CONTROLLER &

CHARGINGTHE BATTERY

MODEL 610

Model 610 7

This unit comes complete with three (3) nickel cadium batteries and 9VAC power adapter for

battery charging, eliminating the need to ever buy, or replace batteries. Under normal operating

conditions, the batteries require charging once a month.

• The battery operated alarm is activated by turning the battery switch “On”.

• If the sensor probe is immersed in Liquid Nitrogen, there is no audible signal from the alarm unit.

When the sensor is removed from the liquid nitrogen, the audible signal will sound

in a few seconds (5 to 15 typically.)

• The audible signal can be tested when the sensor is immersed in liquid nitrogen by pushing the

“Push toTest” button. The audible signal will sound for 5 days contiuously depending on the

charge level of the batteries.

• The audible signal can be silenced by correcting the low liquid nitrogen level problem, or turning

the battery switch to “Off”.

• In the event that the single thermistor should open or break, a tone will alert the operators.

• The battery and alarm horn can be tested at any time.

• When the batteries begin to go low, the unit produces an audible sound.

Test Button

Battery “ON/OFF” Switch

CHARGING THE BATTERY

A battery charging circuit is built into the alarm unit, and a 120VAC to 9VAC power adapter (or

Optional 220V) is provided.

The unit needs to be periodically recharged to maintain the batteries at peak voltage.

It is recommended that you recharge every week-end, a minimum of once a month. Recharging

time is approximately 15 hours.

The battery charger light will indicate that the batteries are being charged.

CALIBRATING LOW LEVELALARM

MODEL 610

Model 610 8

• Submerge the Probe in liquid nitrogen (LN2) for 10 minutes.

• Press the battery “On/Off-Cal” toggle switch downward and hold.

• Use the screwdriver (supplied) turn the adjuster clockwise or counter-clockwise

until the tone begins to sound. Slowly turn the adjuster until the tone sound just disappears.

• Release the “Cal” toggle switch to its battery “Off” position.

• Press “Cal” toggle switch to its full upright position or battery “On”.

• Press the “Push to Test” button to assure the battery power is turned on and calibrated.

ADJUST WITH

SCREW-

DRIVER

“ON/OFF”-CAL

TOGGLE SWITCH

PROBE

TEST BUTTON
