GE GSD2000 series Manual de usuario

GE Appliances

GE Answer Center

800.626.2000

Dishwashers

Part No. 165D4700P203 Pub. No. 49-5877

2-00 JR

GSD2000 series

GSD2200 series

GSD2300 series

GSD2600 series

Owner’s Manual

Congratulations!

You Are Now Part of the GE Family.

Welcome to the GE family.

We’re proud of our quality

products and we are

committed to providing

dependable service. You’ll

see it in this easy-to-use

Owner’s Manual and you’ll

hear it in the friendly voices

of our customer service

department.

Best of all, you’ll experience

these values each time you

use your dishwasher. That’s

important, because your

new dishwasher will be part

of your family for many

years. And we hope you will

be part of ours for a long

time to come.

We thank you for buying

GE. We appreciate your

purchase, and hope you

will continue to rely on us

whenever you need quality

appliances for your home.

Important!

Fill out and return the Consumer Product

Ownership Registration card that is packed

with this product. If you cannot find it,

please send in the duplicate card printed in

the back of this manual.

Write the model and serial

numbers here.

You can find them on the tub wall just

inside the door.

Staple sales slip or cancelled check

here.

Proof of the original purchase date is

needed to obtain service under the

warranty.

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

GE & You,

A Service Partnership.

Inside you will find many

helpful hints on how to use and

maintain your dishwasher

properly. Just a little preventive

care on your part can save you a

great deal of time and money

over the life of your dishwasher.

Read this Manual

Ask any GE appliance owner and they will

tell you we stand behind our products with

unmatched quality service. However, did

you know that most questions result from

simple problems that you can easily fix

yourself in just a few minutes? This

Owner’s Manual can tell you how.

You’ll find many answers to

common problems here.

If you review our chart of

Troubleshooting Tips first,

you may not need to call for

service at all.

Review the Section on

Troubleshooting Tips

If you do need service, you can

relax knowing help is only a

phone call away. A list of toll-free

customer service numbers is

included in the back section.

Or you can always call the

GE Answer Center®at

800.626.2000, 24 hours a day,

7 days a week.

If You Need Service

Safety Information . . . . . . .4–7

Operating Instructions

Control Panels . . . . . . . . . . . .8, 9

Control Settings . . . . . . . . . . . . .9

Dial Cycles . . . . . . . . . . . . .10, 11

Using the Dishwasher . . . .12, 13

Loading the

Dishwasher Racks . . . . . . .14, 15

Care and Cleaning . . . . . . .16, 17

Optional Accessories . . . . . . .18

Troubleshooting Tips

Before You

Call For Service . . . . . . . . .19–24

Customer Service

Product Registration . . . . .25, 26

Warranty . . . . . . . . . . . . . . . .27

Service Telephone

Numbers . . . . . . . . . .Back Cover

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

For your safety, the information in this manual must be

followed to minimize the risk of fire, explosion, electric

shock, or to prevent property damage, personal injury,

or loss of life.

Under certain conditions hydrogen gas may be produced in

a water heater that has not been used for two weeks or

more. HYDROGEN GAS IS EXPLOSIVE.

If the hot water has not been used for two weeks or more, prevent

the possibility of damage or injury by turning on all hot water

faucets and allow them to run for several minutes. Do this before

using any electrical appliance which is connected to the hot water

system. This simple procedure will allow any built-up hydrogen gas

to escape. Since the gas is flammable, do not smoke or use an open

flame or appliance during this process.

WATER HEATER SAFETY

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

Use your dishwasher only for its intended purpose as

described in this Owner’s Manual.

This dishwasher must be properly installed and located in

accordance with the Installation Instructions before it is used.

If you did not receive an Installation Instructions sheet with

your dishwasher, you can receive one by calling us toll-free

at the GE Answer Center®

, 800.626.2000.

■Connect to a grounded

metal, permanent wiring

system; or run an equipment-

grounding conductor with

the circuit conductors and

connect to the equipment-

grounding terminal or lead

of the appliance.

■Improper connection of the

equipment-grounding

conductor can result in a risk

of electric shock. Check with

a qualified electrician or

service representative if you

are in doubt whether the

appliance is properly

grounded.

■Dispose of discarded

appliances and shipping or

packing material properly.

■Do not attempt to repair or

replace any part of your

dishwasher unless it is

specifically recommended in

this manual. All other

servicing should be referred

to a qualified technician.

■To minimize the possibility of

electric shock, disconnect

this appliance from the

power supply before

attempting any maintenance.

NOTE:

Turning the

dishwasher off does not

disconnect the appliance

from the power supply. We

recommend having a

qualified technician service

your appliance.

PROPER INSTALLATION

AND MAINTENANCE

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

DO NOT…

■Do not tamper with controls.

■Do not abuse, sit on, or stand

on the door or dish rack of

the dishwasher.

■Do not discard a dishwasher

without first removing the

door of the washing

compartment.

■Do not store or use

combustible materials,

gasoline or other flammable

vapors and liquids in the

vicinity of this or any other

appliance.

■Do not allow children to play

inside, on or with this

appliance or any discarded

appliance.

WARNING!

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

WHEN USING YOUR DISHWASHER

■Use only powder, tabs or

liquid detergents or wetting

agents recommended for

use in a dishwasher and

keep them out of the reach

of children. Cascade®

Automatic Dishwashing

Detergent has been approved

for use in all GE dishwashers.

■Locate sharp items so that

they are not likely to damage

the door seal.

■Load sharp knives with the

handles up to reduce the risk

of cut-type injuries.

■Do not wash plastic items

unless marked

dishwasher

safe

or the equivalent. For

plastic items not so marked,

check the manufacturer’s

recommendations.

■Non-Dishware Items: Do not

wash items such as electronic

air cleaner filters, furnace

filters and paint brushes in

your dishwasher. Damage to

dishwasher and discoloration

or staining of dishwasher

may result.

■Do not touch the heating

element during or

immediately after use.

■Do not operate your

dishwasher unless all

enclosure panels are properly

in place.

■Close supervision is necessary

if this appliance is used by or

near children.

■Load light plastic items so

they will not become

dislodged and drop to the

bottom of the dishwasher—

they might come into contact

with the heating element and

be damaged.

Read and follow this

Safety Information carefully.

SAVE THESE INSTRUCTIONS

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

About the dishwasher control panel.

You can locate your model number on the tub wall just inside the door.

Throughout this manual, features and appearance may vary from your model.

GSD2300 series models

GSD2000 series models

NORMAL WASH

SHORT WASH

RINSE ONLY

DRYING

(HEATED DRY OFF)

OFF

HOT START

OPTION

HEAVY WASH

HEATED

DRY OFF

HEATED

DRY ON

NORMAL WASH

RINSE ONLY

HI TEMP WASH

ON OFF

DRYING

(HEATED DRY OFF)

OFF

HOT START

OPTION

HEAVY WASH

HEATED

DRY OFF

HEATED

DRY ON

ENERGY OPTIONS

GSD2600 series models

SHORT WASH

RINSE ONLY

HEAVY

WASH

CYCLES

NORMAL

WASH

HI TEMP WASH

ON OFF

PLATE WARMER

(HEATED DRY ON)

(HEATED DRY OFF)

OFF

START

HOT START

OPTION

HEATED

DRY OFF

HEATED

DRY ON

ENERGY OPTIONS

GSD2200 series models

SHORT WASH

RINSE ONLY

POTS

& PANS

CYCLES

NORMAL

WASH

HEATED DRY

ON OFF

PLATE WARMER

(HEATED DRY ON)

(HEATED DRY OFF)

OFF

START

HOT START

OPTION

ENERGY OPTIONS

1212

Energy Options

HI TEMP Provides extra heat for the best performance. It is used best with

WASH heavily-soiled dishes.

HEATED DRY Turns the drying heater on for fast drying. This cycle will extend the time

ON to your wash cycle.

HEATED DRY Shuts off the drying heat options. Dishes air dry naturally and energy is saved.

OFF

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

Control Settings–

Make sure the Dial is at the OFF position

Cycles

POTS & PANS/ For heavily soiled dishes or cookware with dried-on or baked-on soils.

HEAVY WASH Everyday dishes may be included. This cycle will not remove burned-on foods.

NORMAL WASH For loads of everyday dishes, glasses and cookware with medium soils.

NOTE:

Many dishes have lighter soil than normal. Choosing a cycle other

than

NORMAL WASH

will save energy and water.

SHORT WASH For quickly washing loads of everyday dishes with medium soils that have not

dried on, such as loads consisting mostly of glasses.

RINSE ONLY For rinsing partial loads that will be washed later.

Do not use detergent.

PLATE WARMER For warming clean dishes and serving plates. This cycle will take

approximately 31 minutes.

HOT START Preheats wash water to correct temperature.

Start

On some models—

Latch the door and slowly turn the Dial to the

START

position.

Don’t turn it past the

START

position, or you could accidentally miss a rinse.

On some models—

Slowly turn Dial to the desired cycle and latch door to start.

Don’t turn it past the desired wash cycle, or you could accidentally miss a rinse.

There is a time delay between start-up and water fill so you will not hear any

wash action right away.

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

About the dial cycles.

Short Wash

For quickly washing loads of everyday dishes with

medium soils that have not dried on.

Select the

NORMAL WASH

cycle and any options.

Be sure the door is unlatched.

Slowly turn the Dial to

SHORT WASH

Latch the door to start the cycle.

SHORT WASH

RINSE ONLY

PLATE WARMER

(HEATED DRY ON)

(HEATED DRY OFF)

OFF

START

HOT START

OPTION

Rinse Only

For rinsing partial loads that will be washed later.

Do not

use detergent.

Make sure

HEATED DRY OFF

is selected.

Be sure the door is unlatched.

Slowly turn the Dial to

RINSE ONLY.

Latch the door to start the cycle.

SHORT WASH

RINSE ONLY

PLATE WARMER

(HEATED DRY ON)

(HEATED DRY OFF)

OFF

START

HOT START

OPTION

Plate Warmer

For warming clean dishes and serving plates. This cycle

will take approximately 31 minutes.

Load clean dishware to be warmed.

Select

HEATED DRY ON.

Be sure the door is unlatched.

Slowly turn the Dial to

PLATE WARMER.

Latch the door to start the cycle.

SHORT WASH

RINSE ONLY

PLATE WARMER

(HEATED DRY ON)

(HEATED DRY OFF)

OFF

START

HOT START

OPTION

Hot Start

Preheats wash water to correct temperature.

Be sure the door is unlatched.

Slowly turn the Dial to

HOT START.

Latch the door to start the cycle.

SHORT WASH

RINSE ONLY

PLATE WARMER

(HEATED DRY ON)

(HEATED DRY OFF)

OFF

HOT START

OPTION

Otros manuales para GSD2000 series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Lavavajillas de GE

GE CDWT980RSS - Cafe 24" Tall Tub Dishwasher Manual

GE HDA3500NCC - Dishwasher w/ 5 Wash Cycles Manual de usuario

GE GE Profile Triton GPF475 Instrucciones de uso

GE GSC3500D35WW Manual de usuario

GE PDW1800NBB - Profile 18-in Dishwasher Instrucciones de montaje

GE Triton XL GSD6900 Series Manual de usuario

GE Profile PDW9980LSS Manual

GE GSC700 Manual de usuario

GE HDA2030 Instrucciones de instalación

GE GSD830M Manual de usuario

GE GSD2100V65BB Manual de usuario

GE Stainless Steel Tub Dishwashers Manual de usuario

GE Monogram ZBD6800 Manual de usuario

GE GE Profile PDW8600J Instrucciones de uso

GE Tall Tub Dishwashers Manual de usuario

GE ZBD 5600 Manual de usuario

GE GE Triton GSD660G Instrucciones de uso

GE ADW1000 Series Manual de usuario

GE GSD3310 Manual de usuario

GE GBF 630 Series Manual de usuario

GE GSD700G Manual de usuario

GE GSC870M Manual de usuario

GE GSD2100VWW Manual

GE Potscrubber GSC462 Manual del propietario

Manuales populares de Lavavajillas de otras marcas

Electrolux

Electrolux ESI5211LOX Manual de usuario

KitchenAid

KitchenAid KUDB230B Manual de usuario

Brandt

Brandt BDJ424DB Manual de usuario

Asko

Asko DSD767UXXL.AU Manual de usuario

Beko

Beko DFN26210W Manual de usuario

NEFF

NEFF S153ITX00E Hoja de especificaciones

Midea

Midea SV 4.45 wi Manual de usuario

LG LDF7932 Manual de usuario

Gorenje

Gorenje GV63214 Manual de usuario

Hotpoint

Hotpoint HDA1100ZWH Manual de servicio

Blomberg

Blomberg LDFN2240W Manual de usuario

AEG

AEG FFB83836PM Manual de usuario

Cylinda

Cylinda DM3220RFD Manual de usuario

Atag

Atag DW8214MB Manual de usuario

Siemens

Siemens SN23HI02KE Hoja de especificaciones

Omega

Omega ODW717X Manual de usuario

BORETTI

BORETTI BVW-683 Manual de usuario

Siemens

Siemens SN 56N591 Manual de usuario
