GE GSD3310 Manual de usuario

GE Appliances

GE Answer Center

800.626.2000

Dishwashers

Part No. 165D4700P184 Pub. No. 49-5858

7-98 CG

GSD3310

GSD3320

GSD3330

GSD3410

GSD3420

GSD3430

GSD3610

GSD3620

GSD3630

GSD3810

GSD3820

GSD3830

GSD3910

GSD3920

GSD3930

Owner’s Manual

Congratulations!

You Are Now Part of the GE Family.

Welcome to the GE family.

We’re proud of our quality

products and we are

committed to providing

dependable service. You’ll

see it in this easy-to-use

Owner’s Manual and you’ll

hear it in the friendly voices

of our customer service

department.

Best of all, you’ll experience

these values each time you

use your dishwasher. That’s

important, because your

new dishwasher will be part

of your family for many

years. And we hope you will

be part of ours for a long

time to come.

We thank you for buying

GE. We appreciate your

purchase, and hope you

will continue to rely on us

whenever you need quality

appliances for your home.

Important!

Fill out and return the Consumer Product

Ownership Registration card that is packed

with this product. If you cannot find it,

please send in the duplicate card printed in

the back of this manual.

Write the model and serial

numbers here.

#You can find them on the tub wall just

inside the door.

Staple sales slip or cancelled check

here.

Proof of the original purchase date is

needed to obtain service under the

warranty.

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

GE&You,

AService Partnership.

Inside you will find many

helpful hints on how to use and

maintain your dishwasher

properly. Just a little preventive

care on your part can save you a

great deal of time and money

over the life of your dishwasher.

Read this Manual

Ask any GEappliance owner and they will

tell you we stand behind our products with

unmatched quality service. However, did

you know that most questions result from

simple problems that you can easily fix

yourself in just a few minutes? This

Owner’s Manual can tell you how.

You’ll find many answers to

common problems here.

If you review our chart of

Troubleshooting Tips first,

you may not need to call for

service at all.

Review the Section on

Troubleshooting Tips

If you do need service, you can

relax knowing help is only a

phone call away. A list of toll-free

customer service numbers is

included in the back section.

Or you can always call the

GE Answer Center®at

800.626.2000, 24 hours a day,

7 days a week.

If You Need Service

Safety Information . . . . . . .4–7

Operating Instructions

Control Panel . . . . . . . . . . . . . . .8

Control Settings . . . . . . . . . . . . .8

Dial Cycles . . . . . . . . . . . . .10–11

Using the Dishwasher . . . .12, 13

Loading the

Dishwasher Racks . . . . . . .14, 15

Care and Cleaning . . . . . . .16, 17

Optional Accessories . . . . . . . .18

Troubleshooting Tips

Before You

Call For Service . . . . . . . . . 19–24

Customer Service

Product Registration . . . . . . . .29

Warranty . . . . . . . . . . . . . . . . .31

Service Telephone

Numbers . . . . . . . . . .Back Cover

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

For your safety, the information in this manual must be

followed to minimize the risk of fire, explosion, electric

shock, or to prevent property damage, personal injury,

or loss of life.

Under certain conditions hydrogen gas may be produced in

a water heater that has not been used for two weeks or

more. HYDROGEN GAS IS EXPLOSIVE.

If the hot water has not been used for two weeks or more, prevent

the possibility of damage or injury by turning on all hot water

faucets and allow them to run for several minutes. Do this before

using any electrical appliance which is connected to the hot water

system. This simple procedure will allow any built-up hydrogen gas

to escape. Since the gas is flammable, do not smoke or use an open

flame or appliance during this process.

WATER HEATER SAFETY

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

Use your dishwasher only for its intended purpose as

described in this Owner’s Manual.

This dishwasher must be properly installed and located in

accordancewith theInstallation Instructionsbefore itis used.

If you did not receive an Installation Instructions sheet with

your dishwasher, you can receive one by calling us toll-free

at the GE Answer Center®

, 800.626.2000.

■Connect to a grounded

metal, permanent wiring

system; or run an equipment-

grounding conductor with

the circuit conductors and

connect to the equipment-

grounding terminal or lead

of the appliance.

■Improper connection of the

equipment-grounding

conductor can result in a risk

of electric shock. Check with

a qualified electrician or

service representative if you

are in doubt whether the

appliance is properly

grounded.

■Dispose of discarded

appliances and shipping or

packing material properly.

■Do not attempt to repair or

replace any part of your

dishwasher unless it is

specifically recommended in

this manual. All other

servicing should be referred

to a qualified technician.

■To minimize the possibility of

electric shock, disconnect

this appliance from the

power supply before

attempting any maintenance.

NOTE:

Turning the

dishwasher off does not

disconnect the appliance

from the power supply. We

recommend having a

qualified technician service

your appliance.

PROPER INSTALLATION

AND MAINTENANCE

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

DO NOT…

■Do not tamper with controls.

■Do not abuse, sit on, or stand

on the door or dish rack of

the dishwasher.

■Do not discard a dishwasher

without first removing the

door of the washing

compartment.

■Do not store or use

combustible materials,

gasoline or other flammable

vapors and liquids in the

vicinity of this or any other

appliance.

■Do not allow children to play

inside, on or with this

appliance or any discarded

appliance.

WARNING!

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

WHEN USINGYOUR DISHWASHER

■Use only powder, tabs or

liquid detergents or wetting

agents recommended for use

in a dishwasher and keep

them out of the reach of

children.

■Locate sharp items so that

they are not likely to damage

the door seal.

■Load sharp knives with the

handles up to reduce the risk

of cut-type injuries.

■Do not wash plastic items

unless marked

dishwasher

safe

or the equivalent. For

plastic items not so marked,

check the manufacturer’s

recommendations.

■Non-Dishware Items: Do not

wash items such as electronic

air cleaner filters, furnace

filters and paint brushes in

your dishwasher. Damage to

dishwasher and discoloration

or staining of dishwasher

may result.

■Do not touch the heating

element during or

immediately after use.

■Do not operate your

dishwasher unless all

enclosure panels are properly

in place.

■Close supervision is necessary

if this appliance is used by or

near children.

■Load light plastic items so

they will not become

dislodged and drop to the

bottom of the dishwasher—

they might come into contact

with the heating element and

be damaged.

Read and follow this

Safety Information carefully.

SAVE THESE INSTRUCTIONS

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

About the dishwasher control panel.

You can locate your model number on the tub wall just inside the door.

Throughout this manual, features and appearance may vary from your model.

Models GSD3810, GSD3820, GSD3830, GSD3910, GSD3920 and GSD3930

SHORT

WASH

START DELAY

(HRS)

PLATE WARMER

(HEATED DRY ON)

(HEATED DRY OFF)

START

RINSE & HOLD

OFF

STATUS

CYCLE

CYCLES

ENERGY OPTIONS

POT-

SCRUBBER

NORMAL

WASH LIGHT

WASH WATER

SAVER HI TEMP

WASH

HEATED

DRY ENERGY

SAVER

1 2

Models GSD3610, GSD3620 and GSD3630

Models GSD3410, GSD3420 and GSD3430

POT-

SCRUBBER

CYCLES

NORMAL

WASH LIGHT

WASH HI TEMP WASH

ON OFF HEATED DRY

ON OFF

ENERGY OPTIONS

START DELAY

OFF

RINSE & HOLD

PLATE WARMER

SHORT

WASH

(HEATED DRY OFF)

(HEATED DRY ON)

CYCLE

START

(HOURS)

54321

SHORT WASH

RINSE & HOLD

CYCLES

PLATE WARMER

(HEATED DRY ON)

(HEATED DRY OFF)

OFF START

ENERGY OPTIONS

POT-

SCRUBBER

NORMAL

WASH WATER

SAVER HI TEMP

WASH

HEATED

DRY ENERGY

SAVER

11 3

Models GSD3310, GSD3320 and GSD3330

POT-

SCRUBBER

CYCLES

NORMAL

WASH HI TEMP WASH

ON OFF HEATED DRY

ON OFF

ENERGY OPTIONS

START DELAY

OFF

RINSE & HOLD

PLATE WARMER

SHORT

WASH

(HEATED DRY OFF)

(HEATED DRY ON)

CYCLE

START

(HRS)

54321

Energy Options

HI TEMP Provides extra heat for best performance. It is used

WASH best with heavily-soiled dishes.

HEATED DRY ON/

Turns the drying heater on for fast drying. This

HEATED DRY cycle will extend the time to your wash cycle.

HEATED DRY OFF

Shuts off the drying heat option. Dishes air dry

naturally and energy is saved.

ENERGY SAVER Turns all

ENERGY OPTIONS

off.

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

Control Settings

Cycles

POTSCRUBBER For heavily soiled dishes or cookware with dried-on

or baked-on soils. Everyday dishes may be included.

This cycle will not remove burned-on foods.

NORMAL WASH For loads of everyday dishes, glasses and cookware

with medium soils.

NOTE:

Many dishes have lighter

soil than normal. Choosing a cycle other than

NORMAL WASH

will save energy and water.

LIGHT WASH/ For dishes with light soils.

WATER SAVER

SHORT WASH For quickly washing loads of everyday dishes with

medium soils that have not dried on, such as loads

consisting mostly of glasses.

RINSE & HOLD For rinsing partial loads that will be washed later.

Do not use detergent.

PLATE WARMER For warming clean dishes and serving plates. This

cycle will take approximately 32 minutes.

■Make sure the Dial is at the

OFF

position.

■Latch the door.

■

NOTE:

The lights over the pads come on when pressed,

to indicate the cycle/option that has been selected.

Press pad firmly until lights come on. These lights

remain on while the door is locked.

Start

Slowly turn the Dial to the

START

position. Don’t turn it

past the

START

position, or you could accidentally miss a

rinse. There is a time delay between start-up and water

fill so you will not hear any wash action right away.

Start Delay

(GSD3310, GSD3320, GSD3330, GSD3410, GSD3420, GSD3430,

GSD3810, GSD3820, GSD3830, GSD3910, GSD3920 and GSD3930 only)

The

START DELAY

will allow you to delay the start time of

any

cycle not on the Dial automatically for up to 6 hours.

SHORT

WASH

START DELAY

(HRS)

RINSE & HOLD

PLATE WARMER

(HEATED DRY ON)

(HEATED DRY OFF)

START

OFF

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

About the dial cycles.

Short Wash

For quickly washing loads of everyday dishes with medium

soils that have not dried on.

SHORT

WASH

START DELAY

(HRS)

RINSE & HOLD

PLATE WARMER

(HEATED DRY ON)

(HEATED DRY OFF)

START

OFF

Plate Warmer

For warming clean dishes and serving plates. This cycle will

take approximately 32 minutes.

SHORT

WASH

START DELAY

(HRS)

RINSE & HOLD

PLATE WARMER

(HEATED DRY ON)

(HEATED DRY OFF)

START

OFF

Rinse & Hold

For rinsing partial loads that will be washed later.

Do not use

detergent.

SHORT

WASH

START DELAY

(HRS)

RINSE & HOLD

PLATE WARMER

(HEATED DRY ON)

(HEATED DRY OFF)

START

OFF

Be sure the door is

unlatched.

Select the wash cycle and

option you want.

Slowly turn the Dial to

desired time. The

CYCLE

light will come on.

Latch the door to start

the cycle.

Load clean dishware

to be warmed.

Select

HEATED DRY.

Be sure the door is

unlatched.

Slowly turn the Dial

PLATE WARMER.

Latch the door to start

the cycle.

Make sure

HEATED DRY

is not selected.

Be sure the door is

unlatched.

Slowly turn the Dial to

RINSE & HOLD.

Latch the door to start

the cycle.

Select the

NORMAL WASH

cycle and any options.

Be sure the door is

unlatched.

Slowly turn the Dial to

SHORT WASH

Latch the door to start

the cycle.

Otros manuales para GSD3310

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Lavavajillas de GE

GE GSD1130 Manual de usuario

GE ADT521 Series Manual de usuario

GE GSC3500VWW Instrucciones de montaje

GE GSD6900J10BB Manual de usuario

GE GPS5CC Manual de usuario

GE GSD2100N Manual

GE GSD4210 Manual de usuario

GE GD 450 Series Manual de usuario

GE GSD1100M Manual de usuario

GE PD 715 Series Manual de usuario

GE GLD5900N Manual

GE Monogram ZBD 1800 Manual de usuario

GE GSC3200J Manual de usuario

GE CDWT980RSS - Cafe 24" Tall Tub Dishwasher Manual de usuario

GE 49-5215 Instrucciones de instalación

GE Appliances GSD4410 Manual de usuario

GE GLD6500LWW/CC/BB Manual de usuario

GE GSD1005 Manual de usuario

GE PDW7300N25BB Manual de usuario

GE Monogram ZBD3500 Manual de usuario

GE Monogram ZBD3500ZWW Instrucciones de uso

GE Profile PDW9880NSS Manual

GE Profile PDW8200 Series Manual de usuario

GE GLD2800T Manual de usuario

Manuales populares de Lavavajillas de otras marcas

Electrolux

Electrolux ESI5211LOX Manual de usuario

KitchenAid

KitchenAid KUDB230B Manual de usuario

Brandt

Brandt BDJ424DB Manual de usuario

Asko

Asko DSD767UXXL.AU Manual de usuario

Beko

Beko DFN26210W Manual de usuario

NEFF

NEFF S153ITX00E Hoja de especificaciones

Midea

Midea SV 4.45 wi Manual de usuario

LG LDF7932 Manual de usuario

Gorenje

Gorenje GV63214 Manual de usuario

Hotpoint

Hotpoint HDA1100ZWH Manual de servicio

Blomberg

Blomberg LDFN2240W Manual de usuario

AEG

AEG FFB83836PM Manual de usuario

Cylinda

Cylinda DM3220RFD Manual de usuario

Atag

Atag DW8214MB Manual de usuario

Siemens

Siemens SN23HI02KE Hoja de especificaciones

Omega

Omega ODW717X Manual de usuario

BORETTI

BORETTI BVW-683 Manual de usuario

Siemens

Siemens SN 56N591 Manual de usuario
