Specification Revised 4/03

TM

PDW8600/80J – GE Profile™Stainless Built-In Dishwasher

24

25-1/4

21-1/4

44 (Adjustable)

34" MIN.

adj.to 35"

27-1/2

22-1/2

Built-In Dishwasher Dimensions

(in inches)

Electrical Rating

Voltage AC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Hertz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Total connected load amperage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9.1

Calrod®heater watts max. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 875

For use on adequately wired 120-volt, 15-amp circuit having 2-wire

service with a separate ground wire. This appliance must be

grounded for safe operation.

For answers to your Monogram,

® GE Profile™or

GE appliance questions, visit our website at

GEAppliances.com or call

GE Answer Center®service, 800.626.2000.

R

Listed by

Underwriters

Laboratories

As an ENERGY STAR®partner,

GE has determined that this product

meets the ENERGY STAR®

guidelines for energy efficiency.

This wall area

must be free of

pipes or wires

Countertop

4

6

Hot

water

line on

left

44

2Plumbing and electrical

service must enter

inside shaded area

24" From wall

24" MIN.

90°

19" MIN. from wall

24"

MIN.

6

34-1/2±1/4"

Underside

of countertop

to floor

55

90°

Electrical

wiring on

right

Electrical

wiring is

3" from

cabinet

Specification Revised 4/03

TM

PDW8600/80J – GE Profile™Stainless Built-In Dishwasher

Features and Benefits

• Full Color Wrap Contour Door – Lends a rich and contemporary look to any kitchen.

• Bright Annealed Stainless Steel Interior – A lustrous finish and lasting beauty that resists

stains and corrosion.

• Four-Position Adjustable/Removable Upper Rack – Pulls out completely and moves up, down

and diagonally for maximum flexibility.

• Countdown Display with 1-9-hr. Delay Start – Instantly identifies time left in a cycle.

• Color-Matched Nylon Pearlescent Racks – Complement the radiance of stainless steel.

• QuietPower™V Sound Package – Ensures the kitchen stays incredibly quiet with an enhanced

sound deadening system.

• 100% Fold-Down Tines, Lower Rack –Provide maximum loading flexibility in the lower rack.

• Four Sets Fold-Down Tines, Four Sets StemSafe™

,Upper Rack – Provide loading flexibility for

odd-shaped items and safe washing for fine stemware.

• Model PDW8600JWW – White on white

• Model PDW8600JCC – Bisque on bisque

• Model PDW8600JBB – Black on black

• Model PDW8680JSS – Stainless steel (shown)
