FVC SPRINTER SP1123B Manual de usuario
01FLATLINE VAN CO • SUPPORT@FLATLINEVANCO.COM • 888-667-5576
INSTALLATION
GUIDE
SPRINTER PANEL STORAGE LOCKER
TOOLS REQUIRED
Additionalhelpissuggestedforafewoftheinstall
steps.
TIMETOINSTALLTHISPRODUCT:2HOURS
Pleaseinspecttheproductandpackagingupon
deliverytoensuretherearenoissuesandthatall
partsandhardwareareaccountedfor.
ContactusASAPifanythingismissingat:
support@flatlinevanco.com
INSTALL INFO
BEFORE YOU START
+ TAPEMEASURE
+ MARKER
+ POWERDRILL
+ 7/32”DRILLBIT
+ CENTERPUNCH
+ HAMMER
+ STEPBIT
+ METALFILE
+ MASKINGTAPE
+ PAINT
+ 10MMWrench
+ 8MMWrench
+ 3MMAllenWrench
+ 2.5MMAllenWrench
+ DIEGRINDER(optional)
+ ANGLEGRINDERorBODYSAW
+ METALCUTOFFWHEELorBLADE
SP1123B + SP1124B
(NOTINCLUDED)
02FLATLINE VAN CO • SUPPORT@FLATLINEVANCO.COM • 888-667-5576
BEFORE YOU START
AllFlatlineVanCoproductsmustbeproperlyassembledandsecuredbeforeattaching
toyourvehicle.Improperattachmentcouldresultinanautomobileaccident,andcould
causeseriousbodilyinjuryordeathtoyouortoothersinvolved.Youareresponsiblefor
assemblingandsecuringFlatlineVanCoproductstoyourvehicle,checkingthemounting
pointsandattachmentspriortouse,andregularlyinspectingtheproductsforwearand
ordamage.Wealwaysrecommendyouuseaprofessionaltoinstallanyaftermarket
accessoriestoyourvehicle.Ifyouhavenomechanicalexperienceandarenotthoroughly
familiarwiththeinstallationprocedures,youmusthavetheproductinstalledbya
professionalinstallerorotherqualifiedpersons.Theresponsibilityisyoursandmustbe
takenseriouslyforeveryone’ssafety.
03FLATLINE VAN CO • SUPPORT@FLATLINEVANCO.COM • 888-667-5576
PACKAGE CONTENTS
DOOR FRAME ASSEMBLY DOOR FRAME GASKET
QTY: 1
BACKING PLATE 1 BACKING PLATE 2 DRILL/CUT TEMPLATE
QTY: 1 QTY: 1 QTY: 1 QTY: 1
DOOR FRAME ASSEMBLY DOOR FRAME GASKET
QTY: 1
BACKING PLATE 1 BACKING PLATE 2 DRILL/CUT TEMPLATE
QTY: 1 QTY: 1 QTY: 1 QTY: 1
DRIVER SIDE
PASSENGER SIDE
04FLATLINE VAN CO • SUPPORT@FLATLINEVANCO.COM • 888-667-5576
HARDWARE
M5 SCREW X 15 O.D. FLAT
WASHER M5-0.8 NYLON LOCKNUT M5-0.8 X 20 BUTTON HEAD
HEX DRIVE SCREW
M5-0.8 X 12 BUTTON HEAD
HEX DRIVE SCREW THREADLOCKER
QTY: 20 QTY: 20 QTY: 20 QTY: 8 QTY: 2
05FLATLINE VAN CO • SUPPORT@FLATLINEVANCO.COM • 888-667-5576
TOOLS REQUIRED FOR THIS STEP:
05FLATLINE VAN CO • SUPPORT@FLATLINEVANCO.COM • 888-667-5576 05
STEP | 01 LAYOUT AND INSTALL PREP
1.1 Clean Up: Startbycleaningtherearpanelsofanydirtand
debris.
1.2 Marking Points: Measureandmarktwospots3/8”fromthe
seamoftheupperplasticpaneland1/2”fromtherearbumper
plastictothemetalbodypanel(FIG 1).Thesemarkswillhelp
toguidetemplateplacement.
1.3 Template Alignment: Usetapetolineupthetemplate
paralleltotheplasticbodypanelsalongthemarks.Visualize
howthelockerwillfitonthevanandmakeadjustmentsas
necessary(FIG 2).
1.4 Tape Perimeter: Tapetheperimeterofthetemplate,leaving
drillholesexposed.Markallholeswithasharpie(FIG 3).
1.5 Cutting Path: Tracearoundtheinsideofthetemplateto
markthecuttingpath.Ensurethetemplateisflatagainstthe
van.
1.6 Remove Template: Carefullyremovethetemplate.You
shouldbeleftwithmarkingsasshownin(FIG 4).
NOTE - All figures depict driver side installation. The passenger
side follows the same steps, just mirrored.
INSTALL + TAPEMEASURE
+ MARKER
+ MASKINGTAPE
1/2”
FIG 1
FIG 3
FIG 2
FIG 4
CORNER GUIDE
CUTTING LINE
MOUNT HOLES
UPPER PLASTIC
REAR BUMPER
3/8”
06FLATLINE VAN CO • SUPPORT@FLATLINEVANCO.COM • 888-667-5576
TOOLS REQUIRED FOR THIS STEP:
STEP | 02 DRILLING MOUNT HOLES
2.1 Center Punch: LightlycenterpunchholesusingaCenter
Punch (FIG 5,6).
2.2 Drilling: Drilloutholesusinga7/32” Drill Bit (FIG 7,8).
NOTE - When drilling the holes next to the wheel well, be sure to
only drill through one layer of sheet metal.
+ POWERDRILL
+ 7/32”DRILLBIT
+ CENTERPUNCH
+ HAMMER
FIG 5
FIG 7
FIG 6
FIG 8
07FLATLINE VAN CO • SUPPORT@FLATLINEVANCO.COM • 888-667-5576
TOOLS REQUIRED FOR THIS STEP:
FIG 9
FIG 11
STEP | 03 CUTTING PANEL
3.1 Corner Guides: Drilloutcornerguideholeswithastepbitto
1/2”usingthetracedarchofthecuttinglineasavisualguide
(FIG 9,10).Thiswillserveasyourcornerguidewhencutting
outthepanel.
3.2 Body Saw: Useabodysaworanglegrinderwithametal
cuttingwheeltocutthetopandbottomhorizontallinesofthe
panelfirst.Proceedtocuttheleftandrightsides.Carefully
holdtheoppositeendofmetalonthelastcuttostabilize(FIG
11,12).
NOTE - Be sure to only be cutting through one layer of sheet
metal during this process.
NOTE - We recommend using a pneumatic or electric saw for
this step. We like the Astro Pneumatic Tool 930 Air Body Saber
Saw, but most saws with metal-cutting blades will work.
FIG 10
FIG 12
+ POWERDRILL
+ STEPBIT(MARKEDAT1/2”)
+ BODYSAWORANGLEGRINDER
+ METALCUTOFFWHEELORBLADE
CORNER GUIDE
08FLATLINE VAN CO • SUPPORT@FLATLINEVANCO.COM • 888-667-5576
TOOLS REQUIRED FOR THIS STEP:
STEP | 04 DEBURR AND CLEANUP
4.1 Deburr and Cleanup: Deburrthenewlycutholeandclean
upshavingsinsidecompartment(FIG 13,14).
NOTE - If you find that the cut is uneven, you can clean up the
edge with a die grinder.
4.2 Mask Van Body: Remaskperimeterwithtape(FIG 15).
4.3 Rust Prevention: Paintrawedgesofdrillholesandcutlines
withrustpreventativepaint(FIG 16).
PRO-TIP: Optionally, wipe down and paint the inner
compartment in a well-ventilated area.
FIG 13
FIG 15
FIG 14
FIG 16
+ METALFILE
+ MASKINGTAPE
+ PAINT
09FLATLINE VAN CO • SUPPORT@FLATLINEVANCO.COM • 888-667-5576
TOOLS REQUIRED FOR THIS STEP: + 8MMWrench
+ 2.5MMAllenWrench
FIG 17
FIG 19
FACE PLATE
GASKET
BACKER PLATES
STEP | 05 LOCKER ASSEMBLY
5.1 Gather Components: Gatherthefaceplate,gasket,and
backerplates(FIG 17).
5.2 Mount Face Plate: InsertM5-0.8 X 20 Button Head Hex
Drive Screws inthelocationsshowninFIG 17 toholdthedoor
againstthevanbody(mirroredforpassengerside).
5.3 Gasket Placement: PlacetheGasketontoboltsfromthe
inside compartment (FIG 18).
5.4 Install Backer Plates: Looselyinstallbackerplateswith
Washers And Nuts (FIG 19).
5.5 Alignment: Ifthere’sanalignmentissue,drilloutholes
asneeded(avoidbackingplates).UseLoctite onscrewsthat
attachtopemnuts(FIG 20).
5.6 Assembly: Applypressuretoflextheassemblyintoplace
whentighteningscrews.Tightennutswithan8mm Wrench
and2.5mm Allen Wrench untilsnug.
FIG 18
FIG 20
BACKER PLATE
VAN BODY
CUT PANEL
LOCTITE
010FLATLINE VAN CO • SUPPORT@FLATLINEVANCO.COM • 888-667-5576
TOOLS REQUIRED FOR THIS STEP: + 10MMWrench
+ 3MMAllenWrench
STEP | 06 ADJUSTMENTS AND TUNING
6.1 Latch Compression: Usinga10MM Wrench,loosentheJam
Nut (FIG 21) toadjusttheCompression Bolt andretightenthe
nutwhenadjustmentiscomplete.
NOTE - Screw the bolt out to increase seal compression and
screw the bolt in to decrease seal compression.
6.2 Hinge Bolts: Thehingescanbeadjustedusinga10MM
Wrench and 3MM Allen Wrench.TightentheHinge Pivot Bolt
toincreasetorque,loosenHinge Pivot Bolt todecreasetorque
(FIG 21).
YourRearStorageLockerisnowreadyforaction!Happy
travels!
JAM NUT
COMPRESSION BOLT
HINGE PIVOT
BOLT
FIG 21
