Read Me First

FUJITSU Storage ETERNUS DX60 S2 Disk storage system

The information in this document is subject to change without notice for improvement and functionality expansion of the

ETERNUS DX Disk storage system.

The latest version of this document, the latest information about the ETERNUS DX Disk storage system, and important

service and support contacts (see “Contact Fujitsu”) for Fujitsu Customer Service for your country of purchase is available

at the following website:

http://www.fujitsu.com/global/services/computing/storage/eternus/products/diskstorage/dx-entry/

Fujitsu would like to thank you for purchasing our ETERNUS DX60 S2 Disk storage system (hereinafter referred to as

"ETERNUS DX Disk storage system").

Read this document and check the shipment package to conrm that no items are missing.

Check the workow to set up the ETERNUS DX Disk storage system by referring to "Setup Procedures". For details on

the procedures, refer to the manuals that are described with the mark.

Refer to the provided manuals or any related manuals for the ETERNUS DX Disk storage system as necessary.

The company names and product names mentioned in this document are either registered trademarks or trademarks of their respective companies.

Read and understand the "Safety Precautions" before use.

"Safety Precautions"

Table of Contents

P3AM-5542-07EN

Provided Manuals .......................................2

Related Materials.........................................2

Package Contents .......................................3

Setup Procedures .......................................6

Operation and Maintenance .....................13

*P 3 A M -5542 - 0 7E N *

FUJITSU Storage ETERNUS DX60 S2 Disk storage system Read Me First

Manual Title Manual Code Description

Overview P3AM-5482 Describes the specications, features, and functions of the

ETERNUS DX Disk storage system.

User's Guide -Site Planning- P3AM-5492 Describes the onsite requirements for installation of the

ETERNUS DX Disk storage system.

User's Guide -Installation- P3AM-5502 Describes all the procedures that are required to start operation

of the ETERNUS DX Disk storage system.

User's Guide -Operation- P3AM-5512 Describes the operation management and maintenance of the

ETERNUS DX Disk storage system.

Product List P3AM-5522 Provides lists of the optional products for the ETERNUS DX Disk

storage system and describes possible combinations.

Read Me First P3AM-5542 Describes how the manuals are organized, package contents,

setup procedures, and the terms of use for the ETERNUS DX

Disk storage system. A manual booklet is also provided.

Read Me First for Optional Products P3AM-5552

P3AM-5562

Describes the package contents of the optional products. Manual

booklets are also provided for optional products.

Safety Precautions P3AM-5062 Describes the safety precautions that must be taken for the

ETERNUS DX Disk storage system. A manual booklet is also

provided.

ETERNUS Web GUI User's Guide P2 X0 -112 0 Explains how to monitor and set the ETERNUS DX Disk storage

system via Graphical User Interface (GUI).

ETERNUS CLI User's Guide P2 X0 -1130 Explains how to monitor and set the ETERNUS DX Disk storage

system via Command Line Interface (CLI).

ETERNUS SMI-S User's Guide P3AM-5652 Explains how to use the SMI-S compliant general storage

management application to manage the ETERNUS DX Disk

storage system.

Other manuals for the ETERNUS DX Disk storage system are as follows:

Manual Title Manual Code Description

Conguration Guide

-Server Connection- (*1)

Explains how to connect the ETERNUS DX Disk storage system

to a server.

Conguration Guide

(Power Synchronized Unit)

P3AM-8012 Explains how to use a power synchronized unit.

The Documentation CD that is provided with the ETERNUS DX Disk storage system includes the following manuals:

*1: Download the necessary manuals for the customer operating environment (for server OS, host interface type, etc.) from the specied website.

For the URL of the download website, refer to the Documentation CD provided with the ETERNUS DX Disk storage system.

Provided Manuals

Related Materials

FUJITSU Storage ETERNUS DX60 S2 Disk storage system Read Me First

Check the list of package contents for the purchased product to conrm that no items are missing. Tick off the checkbox

of each conrmed item.

If there is a missing item, contact your sales representative.

●Store the package contents in a safe and secure location, as they may be needed again when making changes to the

system or reinstalling the software.

●Note that the package may sometimes also contain an Errata sheet and/or other such unlisted documentation.

Package Contents

*1: An alphanumerical character is used for ato indicate the ETERNUS DX Disk storage system model.

D: dual-controller type

S: single-controller type

An alphanumerical character is used for bto indicate the host interface type.

F: FC

L : iSCSI

S : SAS

An alphanumerical character may also be used for cdepending on the purchased product.

□Pin (x 1)

Used to adjust the Controller Enclosure's AUTO POWER

dip-switch.

□Controller enclosure (x 1)

Drives that are purchased at the same time as the ETERNUS DX

Disk storage system are preinstalled according to the installation

rules.

●2.5inch

●3.5inch

□Cover (x 1)

●2.5inch

Flange cover

●3.5inch

Front cover

□M5 screw (x 8)

for attaching the rack rails

□Screw holder (x 8)

Used when the rack pillars

have square holes.

□Rack rail kit

□Rack rail (x 1 set)

□Read Me First (this document) (x 1)

□Safety Precautions (x 1)

□Documentation CD (x 1)

□Network Settings label (x 1)

ETERNUS DX60 S2 (2.5inch) (Product ID: ET062 aCb c U(*1))

ETERNUS DX60 S2 (3.5inch) (Product ID: ET062 aDb c U(*1))

□AC200V cable (x 2) IEC60320-C13↔NEMA L6-15P (4m)

FUJITSU Storage ETERNUS DX60 S2 Disk storage system Read Me First

□Drive enclosure (x 1)

Drives that are purchased at the same time as the ETERNUS DX

Disk storage system are preinstalled according to the installation

rules.

□miniSAS cable SFF8088↔SFF8088 (0.75m)

One miniSAS cable is provided when a for the product ID is "1". Two

miniSAS cables are provided when a for the product ID is "2".

Drive Enclosure (Product ID: ETEED aDU, ETCED aDU(*1))

□M5 screw (x 8)

for attaching the rack rails

□Screw holder (x 8)

Used when the rack pillars

have square holes.

□Rack rail kit

□Rack rail (x 1 set)

□AC200V cable (x 2) IEC60320-C13↔NEMA L6-15P (4m)

□Front cover (x 1)

*1:

An alphanumerical character is used for ato indicate the number of expanders.

1: One expander

2: Two expanders

FUJITSU Storage ETERNUS DX60 S2 Disk storage system Read Me First

*1: An alphanumerical character is used for ato indicate the drive capacity.

3 : 300GB

4 : 450GB

6 : 600GB

9 : 900GB

1 : 1.2TB

An alphanumerical character is used for b to indicate the number of drives and the RAID type.

H: x1

: x2 (RAID1)

P : x6 (RAID5)

D : x6 (RAID6)

S : x6 (RAID1+0)

An alphanumerical character is used for cto indicate the drive size and the drive speed.

A : Disk Drive (3.5inch) 15krpm

B : Disk Drive (2.5inch) 10krpm

SAS Disk Drive (Product ID: ETED a b c , ETCD a b c (*1))

*1: An alphanumerical character is used for ato indicate the drive capacity.

1 : 1TB

2 : 2TB

3 : 3TB

4 : 4TB

An alphanumerical character is used for b to indicate the number of drives and the RAID type.

H: x1

: x2 (RAID1)

P : x6 (RAID5)

D : x6 (RAID6)

S : x6 (RAID1+0)

An alphanumerical character is used for cto indicate the drive size.

A : 3.5inch

B : 2.5inch

Nearline SAS Disk Drive (Product ID: ETEN a b c , ETCN a b c (*1))

□Disk Drive

Installed in the controller enclosure or the drive enclosure.

●2.5inch

●3.5inch

□Disk Drive

Installed in the controller enclosure or the drive enclosure.

●2.5inch

●3.5inch

FUJITSU Storage ETERNUS DX60 S2 Disk storage system Read Me First

An installation space and network environment must be prepared in advance.

Prepare the following manuals:

●Documentation CD

●Related manuals, such as manuals for the server or the networking equipment that is used

Setup Procedures

Installation Space

-Site Planning- "2.5 Outlet/Socket Specications"

Network Environment

-Installation- "1.1 Connection Preparation"

●-Site Planning- "2.1 Installation Specications"

●-Site Planning- "2.4 Installation Environment"

Installation space

Check that the installation area meets the space requirements of the rack in which the ETERNUS DX Disk

storage system is to be installed.

Environmental considerations for installation

Check if the installation area for the ETERNUS DX Disk storage system meets the environmental conditions

and installation environment conditions.

Power outlets

Check the type and the number of power outlets/sockets that are required to install the ETERNUS DX Disk

storage system.

Completing and attaching the Network Settings label

Write down the following information on the Network Settings label and attach it to the controller enclosure.

●IP address and subnet mask for the ETERNUS DX Disk storage system

●IP address for maintenance work

Preparation

STEP

-Installation- "1.2 Setup Preparation"

Settings for the PC terminal

●Setup Network Environment

ƪIP address: 192.168.1.2

ƪSubnet mask: 255.255.255.0

●Set the Web browser

ƪProxy server and Cache: Disable

ƪJava Script, style sheets, and cookies: Enable

FUJITSU Storage ETERNUS DX60 S2 Disk storage system Read Me First

1. Adjust the rack rail size to t the rack.

The rack rail needs to be attached to the rack and the controller enclosure or the drive enclosure needs to

be installed.

The M5 screw positions for the rack rails are determined by the controller enclosure or the drive

enclosure base line.

Insert the M5 screws in the 1st and 3rd holes on the front and rear rack pillars above the base lines to

fasten the rack rails.

2. Attach the rack rails to the rack.

The size of the controller enclosure and the drive enclosure is 2U.

Installation in a Rack

STEP

●A drive enclosure must be installed above a controller enclosure.

●The center of gravity must be taken into consideration to prevent a rack from toppling over.

The controller enclosure and the drive enclosure should generally be installed from bottom to top to

lower the center of gravity and to ensure the safe use of racks.

IMPORTANT

-Installation- "Chapter 3 Rack Installation"

M5 screws

Screw holders

Bracket L

Screw holders

M5 screws

Screw holders

Bracket R

(Rear rack pillars)

(Front rack pillars)

Screw holders

[Right]

(Front rack pillars)

[Left]

Rack rail (for right side)

"R" is stamped on the inner

side of the right rack rail.

Rack rail (for left side)

"L" is stamped on the inner

side of the left rack rail.

(Rear rack pillars)

Loosen the screws,

and adjust the rack rails to

the depth of the rack.

1st position

(M5 screws)

3rd position

(M5 screws)

1st position

(M5 screws)

3rd position

(M5 screws) 2U

[Left] [Right]

Rack rail

Base line

3. Install the controller enclosure or the drive enclosure in the rack.

Make sure to install or remove the controller enclosure or the drive enclosure to or from a rack with

two or more people.

IMPORTANT

FUJITSU Storage ETERNUS DX60 S2 Disk storage system Read Me First

4. Fasten the controller enclosure or the drive enclosure in the rack.

●2.5" Type Controller Enclosure

(1) Use the thumb screw to fasten the front right of the controller enclosure to the rack pillars.

(2) Attach the ange cover to the front left of the controller enclosure and use the thumb screw to

fasten it to the rack pillars.

(Rear rack pillars)

Thumb screw

(Rear rack pillars)

Thumb screw

(Rear rack pillars)

Thumb screw

●3.5" Type Controller Enclosure/3.5" Type Drive Enclosure

(1) Use the thumb screws at the front of the controller enclosure or the drive enclosure to fasten it to

the rack.

(2) Attach the front cover.

Do not touch the power switch ( ) when attaching the ange cover.

IMPORTANT

Do not touch the power switch ( ) when attaching the ange cover.

IMPORTANT

FUJITSU Storage ETERNUS DX60 S2 Disk storage system Read Me First

●FC

●SAS

Connect a host interface cable to each of these ports.

Various cables need to be connected to the rear of the ETERNUS DX Disk storage system.

Rear viewCable

Connect a LAN cable (for operation management) to each MNT port.

Cable Connection

STEP

Host Interface Cable

LAN Cable (For Operation Management)

●iSCSI

●To help with cable management and prevent incorrect connection, attach labels to the cables and

make a note of connection origins and destinations.

●This step describes dual controller type as an example. Note that there is only controller 0 (CM#0) for

single controller type.

Point

The cables should never be bent, twisted or pulled.

IMPORTANT

-Installation- "4.1 LAN Cable Connection (For Operation Management)"

-Installation- "4.2 Host Interface Connection"

Controller (CM#0) Controller (CM#1)

Controller

Enclosure

The MNT port is on the right side.

Controller

Enclosure

Controller

Enclosure

Controller

Enclosure

Port#0 (left), Port#1 (right)

FUJITSU Storage ETERNUS DX60 S2 Disk storage system Read Me First

●Underside of the DI (OUT)

side plug

●Underside of the DI (IN)

side plug

Rear viewCable

When the drive enclosure is installed, connect the DI (OUT) port of the controller enclosure to the DI (IN)

port of the drive enclosure with the miniSAS cable.

MiniSAS Cables

-Installation- "4.3 Drive Enclosure Connection"

Plug the connectors with the " " symbol indented on them

into the DI (OUT) ports of the controller enclosure.

Controller

Enclosure

Drive

Enclosure

DI (OUT) port

DI (IN) port

Controller

Enclosure

Drive

Enclosure

Connect the power cords to the inlets of the power supply unit.

Use release ties to hold the power cords in place.

Rear viewCable

Power Cords

-Installation- "4.5 Power Cord Connection"

Plug the connectors with the " " symbol indented on them

into the DI (IN) ports of the drive enclosure.

The " " symbol is

indented here.

The " " symbol is

indented here.

Otros manuales para ETERNUS DX60 S2

Tabla de contenidos

Otros manuales de Almacenamiento de Fujitsu

Fujitsu

Fujitsu PRIMERGY SX960 S1 Manual de usuario

Fujitsu

Fujitsu MHC2032AT Manual de usuario

Fujitsu

Fujitsu Eternus DX200F Manual de usuario

Fujitsu

Fujitsu ETERNUS DX Disk Manual de usuario

Fujitsu

Fujitsu MPC3045AH Manual de usuario

Fujitsu

Fujitsu MHR2010AT Manual de usuario

Fujitsu

Fujitsu MHZ2040BH - Mobile 40 GB Hard Drive Manual de usuario

Fujitsu

Fujitsu ETERNUS DX S5 Series Manual de usuario

Fujitsu

Fujitsu ETERNUS DX60 Manual de usuario

Fujitsu

Fujitsu MPG3xxxAT Manual de usuario

Fujitsu

Fujitsu MHW2040BS Manual de usuario

Fujitsu

Fujitsu ETERNUS DX100 S3 Manual de usuario

Fujitsu

Fujitsu MHE2043AT Manual de usuario

Fujitsu

Fujitsu ETERNUS LT140 Manual de usuario

Fujitsu

Fujitsu ETERNUS2000 100 Manual de usuario

Fujitsu

Fujitsu ETERNUS2000 model 100 Manual de usuario

Fujitsu

Fujitsu MHY2120BH - Mobile 120 GB Hard Drive Guía del usuario

Fujitsu

Fujitsu ETERNUS LT40 S2 Cómo utilizar

Fujitsu

Fujitsu MPF3102AT - Desktop 10.2 GB Hard Drive Manual de usuario

Fujitsu

Fujitsu ETERNUS LT160 Manual de usuario

Fujitsu

Fujitsu MAT3300FC Manual de usuario

Fujitsu

Fujitsu ETERNUS LT20 S2 Cómo utilizar

Fujitsu

Fujitsu ETERNUS2000 200 Guía

Fujitsu

Fujitsu MAW3073 SERIES Manual de usuario

Manuales populares de Almacenamiento de otras marcas

QNAP

QNAP TS 32PXU Series Manual de usuario

LaCie

LaCie RUGGED RAID Manual de usuario

Freecom

Freecom CLS DOCK Manual de usuario

PNY

PNY Attache P-FD64MBATT3 Manual de usuario

HP StorageWorks MSL2024 Manual de usuario

OLT

OLT 6x6 Maximizer Manual de usuario

Transcend

Transcend JetFlash 160 Manual de usuario

LaCie

LaCie RUGGED MINI Manual de usuario

Thunderbolt

Thunderbolt 600 Manual de usuario

Panasonic

Panasonic LB-DH8 series Manual

Intel

Intel RAID High Availability Manual de usuario

LaCie

LaCie 12big Thunderbolt 3 Manual de usuario

Spectra Logic

Spectra Logic T-Series Spectra T50e Manual de usuario

Panasonic

Panasonic LKM-F931-1 Manual de usuario

Tabernus

Tabernus Enterprise Erase E2400 Manual de usuario

Rocstor

Rocstor COMMANDER 3F series Manual de usuario

HP P9000 Manual de usuario

Western Digital

Western Digital Ultrastar Data60 Manual de usuario
