FUJITSU Storage

ETERNUS DX

Configuration Guide -Server Connection-

(Fibre Channel) for Oracle Solaris

P3AM-3702-16ENZ0

This page is intentionally left blank.

Preface

This manual briefly explains the operations that need to be performed by the user in order to connect an

ETERNUS DX to a server running Solaris OS via a Fibre Channel interface.

This manual should be used in conjunction with any other applicable user manuals, such as those for the

ETERNUS DX, server, OS, Fibre Channel cards, and drivers.

Refer to "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- Notations" for the notations

used in this manual such as product trademarks and product names. For storage systems that are supported

by the OS, refer to the Server Support Matrix of the ETERNUS DX.

16th Edition

June 2015

The Contents and Structure of this Manual

This manual is composed of the following eleven chapters.

•"Chapter 1 Workflow" (page 6)

This chapter describes the workflow required to connect a server running Solaris OS to an ETERNUS DX.

•"Chapter 2 Checking the Server Environment" (page 23)

This chapter describes which servers can be connected to ETERNUS DX storage systems.

•"Chapter 3 Notes" (page 26)

This chapter describes issues that should be noted when connecting the ETERNUS DX storage systems and

server.

•"Chapter 4 Installing and Setting Up ETERNUSmgr" (page 32)

This chapter describes how to install ETERNUSmgr.

•"Chapter 5 Setting Up the ETERNUS DX" (page 33)

This chapter describes how to use ETERNUS Web GUI or ETERNUSmgr to set up the ETERNUS DX storage

systems.

•"Chapter 6 Setting Up the Fibre Channel Switches" (page 34)

This chapter describes how to set up the Fibre Channel switches.

•"Chapter 7 Installing Drivers and Setting Up the Server" (page 36)

This chapter describes the installation of the Fibre Channel card driver and related server settings.

•"Chapter 8 Setting Up the Server to Recognize the Logical Units" (page 37)

This chapter describes how to make the server recognize the LUNs of the ETERNUS DX.

•"Chapter 9 Setting the Multipaths" (page 38)

This chapter describes how to set multipaths for multipath connection.

•"Chapter 10 Setting a File System" (page 39)

This chapter describes how to create a file system.

•"Chapter 11 SAN Boot" (page 42)

This chapter provides notes for SAN Boot.

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris

P3AM-3702-16ENZ0

Table of Contents

Chapter 1 Workflow 6

1.1 For Fujitsu Drivers........................................................................................................................... 6

1.2 For Oracle Drivers ......................................................................................................................... 10

1.3 For Emulex Drivers ....................................................................................................................... 13

1.4 For QLogic Drivers......................................................................................................................... 17

1.5 For Brocade Drivers ...................................................................................................................... 20

Chapter 2 Checking the Server Environment 23

2.1 Hardware ..................................................................................................................................... 23

2.2 OS (Operating System)................................................................................................................. 23

2.3 Fibre Channel Cards...................................................................................................................... 23

2.4 Multipath Driver ........................................................................................................................... 23

2.5 Symantec VxVM............................................................................................................................ 23

2.6 Oracle OEM VxVM ......................................................................................................................... 23

2.7 SVM.............................................................................................................................................. 24

2.8 Clusterware .................................................................................................................................. 24

2.9 Fibre Channel Cards that Require an Oracle-brand Driver............................................................. 24

Chapter 3 Notes 26

3.1 Server Startup and Power Supply Control Notes............................................................................ 26

3.2 Instance Management Table Notes.............................................................................................. 26

3.3 System Design Sheet Notes.......................................................................................................... 26

3.4 Fibre Channel Switch Notes.......................................................................................................... 27

3.5 VxVM Notes.................................................................................................................................. 28

3.5.1 Driver Notes........................................................................................................................................................28

3.5.2 Symantec VxVM ..................................................................................................................................................28

3.5.3 Oracle OEM VxVM................................................................................................................................................28

3.6 VERITAS Cluster Server (VCS) Notes............................................................................................... 29

3.7 MPxIO Notes................................................................................................................................. 29

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris

P3AM-3702-16ENZ0

3.8 Oracle Solaris Cluster Installation Notes ....................................................................................... 29

3.8.1 Supported Versions and Hardware......................................................................................................................29

3.8.2 Multipath Configuration .....................................................................................................................................29

3.8.3 Reset Group Setting ............................................................................................................................................29

3.8.4 Host Response Setting ........................................................................................................................................29

3.8.5 Installing VxVM...................................................................................................................................................29

3.8.6 Number of Nodes................................................................................................................................................30

3.8.7 Oracle Solaris Cluster Data Service for Oracle Application Server (RAC) ...............................................................30

3.9 hddv Driver Notes......................................................................................................................... 31

Chapter 4 Installing and Setting Up ETERNUSmgr 32

Chapter 5 Setting Up the ETERNUS DX 33

Chapter 6 Setting Up the Fibre Channel Switches 34

Chapter 7 Installing Drivers and Setting Up the Server 36

Chapter 8 Setting Up the Server to Recognize the Logical Units 37

Chapter 9 Setting the Multipaths 38

Chapter 10 Setting a File System 39

10.1 Creating a File System ................................................................................................................ 39

10.2 Setting Up Automatic Disk Mounting ......................................................................................... 40

Chapter 11 SAN Boot 42

Table of Contents

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris

P3AM-3702-16ENZ0

Chapter 1

Workflow

This chapter describes the procedure for connecting ETERNUS DX storage systems to a server running Solaris

OS.

Procedures may vary according to the Fibre Channel card driver type and connection method.

When a Fibre Channel switch is used to make the connection, refer to the "FUJITSU Storage ETERNUS DX

Configuration Guide -Server Connection- (Fibre Channel) Fibre Channel Switch Settings" and use the proce-

dure described.

1.1 For Fujitsu Drivers

The following documents may be relevant when using a Fujitsu driver.

Exactly which documents are required depends on the connection environment, see the "Workflow" section

that follows for details.

Required Documents

•"Server Support Matrix"

•"Server Support Matrix for FC-SWITCH"

•"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- Disk Storage System Settings" that

corresponds to the ETERNUS DX to be connected

•"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) Fibre Channel

Switch Settings"

•"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris

Driver Settings for Fujitsu Fibre Channel Cards"

•"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris

Multipath Driver Settings"

•"ETERNUS Web GUI User's Guide"

•"ETERNUSmgr Install Guide"

•"ETERNUSmgr User Guide"

•Manuals supplied with the Fibre Channel card, multipath driver, and VxVM

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris

P3AM-3702-16ENZ0

Workflow

Installing ETERNUSmgr and Setting Up the ETERNUS DX

If ETERNUSmgr is to be used, install it and set up the ETERNUS DX.

•"Chapter 4 Installing and Setting Up ETERNUSmgr" (page 32)

•"Chapter 5 Setting Up the ETERNUS DX" (page 33)

•Checking the setup and maintenance operations

-"ETERNUS Web GUI User's Guide"

-"ETERNUSmgr Install Guide"

-"ETERNUSmgr User Guide"

•Setting up the ETERNUS DX

-"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- Disk Storage System Set-

tings" that corresponds to the ETERNUS DX to be connected

Setting Up the Fibre Channel Switches

If a Fibre Channel switch is to be used, set it up now.

•"Chapter 6 Setting Up the Fibre Channel Switches" (page 34)

•Setting up the Fibre Channel switches

-"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) Fibre

Channel Switch Settings"

•Checking the Fibre Channel switch connection requirements

-"Server Support Matrix for FC-SWITCH"

Installing the Driver

Install the appropriate driver for the Fibre Channel card being used.

•"Chapter 7 Installing Drivers and Setting Up the Server" (page 36)

•Installing Fibre Channel cards and drivers

-"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle

Solaris Driver Settings for Fujitsu Fibre Channel Cards"

•Checking the Fibre Channel card driver versions

-"Server Support Matrix"

Chapter 1 Workflow

1.1 For Fujitsu Drivers

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris

P3AM-3702-16ENZ0

When the ETERNUS Multipath Driver or the GR

Multipath Driver is used

When the ETERNUS Multipath Driver or the GR

Multipath Driver is not used

Setting Up the Server

Edit the setup file (/kernel/drv/fjpfca.conf) to set

the parameters required for connection.

•"Chapter 7 Installing Drivers and Setting Up

the Server" (page 36)

•Setting up the server

-"FUJITSU Storage ETERNUS DX Configuration

Guide -Server Connection- (Fibre Channel)

for Oracle Solaris Driver Settings for Fujitsu

Fibre Channel Cards"

Setting Up the Server to Recognize the Logical

Units

The sd or hddv driver is used to recognize the

ETERNUS DX's logical units.

Label the LUNs using the "format" command.

•"Chapter 8 Setting Up the Server to Recognize

the Logical Units" (page 37)

•Have the server recognize the ETERNUS DX

LUNs.

-"FUJITSU Storage ETERNUS DX Configuration

Guide -Server Connection- (Fibre Channel)

for Oracle Solaris Driver Settings for Fujitsu

Fibre Channel Cards"

When VxVM is used When VxVM is not used

Jump to Step 7

Creating Volume

Chapter 1 Workflow

1.1 For Fujitsu Drivers

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris

P3AM-3702-16ENZ0

When the ETERNUS Multipath Driver or the GR

Multipath Driver is used

When VxVM is used

Setting the Multipaths

Install the multipath software and set up the mul-

tipath connections. Settings will depend on which

multipath software is being used.

•"Chapter 9 Setting the Multipaths" (page 38)

•"FUJITSU Storage ETERNUS DX Configuration

Guide -Server Connection- (Fibre Channel) for

Oracle Solaris Multipath Driver Settings"

•Installing and setting up the Multipath Driver

-Multipath Driver product manual

•Checking the corresponding Multipath Driver

-"Server Support Matrix"

Setting Up VxVM

Install and set up VxVM when VxVM is used.

•"3.5 VxVM Notes" (page 28)

•"Chapter 9 Setting the Multipaths" (page 38)

•Installing and setting up the VERITAS Volume

Manager

-VxVM product documentation

•Checking the supported version and use envi-

ronment

-"Server Support Matrix"

Creating the Volumes

Create slices, exactly the same as for a regular disk.

Creating a File System

Create a file system, exactly the same as for a regular disk.

•"Chapter 10 Setting a File System" (page 39)

Chapter 1 Workflow

1.1 For Fujitsu Drivers

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris

P3AM-3702-16ENZ0

1.2 For Oracle Drivers

The following documents may be relevant when using an Oracle driver.

Exactly which documents are required depends on the connection environment, see the "Workflow" section

that follows for details.

Required Documents

•"Server Support Matrix"

•"Server Support Matrix for FC-SWITCH"

•"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- Disk Storage System Settings" that

corresponds to the ETERNUS DX to be connected

•"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) Fibre Channel

Switch Settings"

•"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris

Driver Settings for Non-Fujitsu Fibre Channel Cards"

•"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris

Multipath Driver Settings"

•"ETERNUS Web GUI User's Guide"

•"ETERNUSmgr Install Guide"

•"ETERNUSmgr User Guide"

•Manuals supplied with the Fibre Channel card, MPxIO, and VxVM

Workflow

Installing ETERNUSmgr and Setting Up the ETERNUS DX

If ETERNUSmgr is to be used, install it and set up the ETERNUS DX.

•"Chapter 4 Installing and Setting Up ETERNUSmgr" (page 32)

•"Chapter 5 Setting Up the ETERNUS DX" (page 33)

•Checking the setup and maintenance operations

-"ETERNUS Web GUI User's Guide"

-"ETERNUSmgr Install Guide"

-"ETERNUSmgr User Guide"

•Setting up the ETERNUS DX

-"FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- Disk Storage System Set-

tings" that corresponds to the ETERNUS DX to be connected

Chapter 1 Workflow

1.2 For Oracle Drivers

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris

P3AM-3702-16ENZ0

Otros manuales para ETERNUS DX Disk

Tabla de contenidos

Otros manuales de Almacenamiento de Fujitsu

Fujitsu

Fujitsu MHE2043AT Manual de usuario

Fujitsu

Fujitsu ETERNUS LT260 Manual de usuario

Fujitsu

Fujitsu AIRSTAGE UTY-ASGXZ1 Manual de usuario

Fujitsu

Fujitsu ETERNUS DX60 S3 Manual de usuario

Fujitsu

Fujitsu ETERNUS LT140 Manual de usuario

Fujitsu

Fujitsu MHM2100AT - Mobile 10 GB Hard Drive Manual de usuario

Fujitsu

Fujitsu PRIMERGY SX910 S1 Manual de usuario

Fujitsu

Fujitsu ETERNUS DX Disk Manual de usuario

Fujitsu

Fujitsu ETERNUS DX S2, ETERNUS DX S3, ETERNUS DX S4, ETERNUS... Manual de usuario

Fujitsu

Fujitsu MPG3xxxAT Manual de usuario

Fujitsu

Fujitsu Eternus DX600 S3 Instrucciones de montaje

Fujitsu

Fujitsu ETERNUS DX60 Manual de usuario

Fujitsu

Fujitsu MAP3147NC - Enterprise - Hard Drive Manual de usuario

Fujitsu

Fujitsu MJA2500BH - Mobile 500 GB Hard Drive Manual de usuario

Fujitsu

Fujitsu PRIMERGY LTO4 Manual de usuario

Fujitsu

Fujitsu MHT2080BH Manual de usuario

Fujitsu

Fujitsu HARD DISK DRIVES MAW3073FC Manual de usuario

Fujitsu

Fujitsu MHV2060AT Manual de usuario

Fujitsu

Fujitsu MAW3073 SERIES Manual de usuario

Fujitsu

Fujitsu ETERNUS DX100 S4 Manual técnico

Fujitsu

Fujitsu Eternus DX80 S2 Manual de usuario

Fujitsu

Fujitsu MBA3073RC SERIES Manual de usuario

Fujitsu

Fujitsu ETERNUS DX60 Manual de usuario

Fujitsu

Fujitsu LTO-6 Manual de usuario

Manuales populares de Almacenamiento de otras marcas

QNAP

QNAP TS 32PXU Series Manual de usuario

LaCie

LaCie RUGGED RAID Manual de usuario

Freecom

Freecom CLS DOCK Manual de usuario

PNY

PNY Attache P-FD64MBATT3 Manual de usuario

HP StorageWorks MSL2024 Manual de usuario

OLT

OLT 6x6 Maximizer Manual de usuario

Transcend

Transcend JetFlash 160 Manual de usuario

LaCie

LaCie RUGGED MINI Manual de usuario

Thunderbolt

Thunderbolt 600 Manual de usuario

Panasonic

Panasonic LB-DH8 series Manual

Intel

Intel RAID High Availability Manual de usuario

LaCie

LaCie 12big Thunderbolt 3 Manual de usuario

Spectra Logic

Spectra Logic T-Series Spectra T50e Manual de usuario

Panasonic

Panasonic LKM-F931-1 Manual de usuario

Tabernus

Tabernus Enterprise Erase E2400 Manual de usuario

Rocstor

Rocstor COMMANDER 3F series Manual de usuario

HP P9000 Manual de usuario

Western Digital

Western Digital Ultrastar Data60 Manual de usuario
