Getting Started

fi-5950 Image Scanner

P3PC-3062-03EN

Thank you for purchasing the fi-5950 Duplex Color Scanner.

This document describes how to use fi-5950 and basic operation methods. Before you start using fi-5950 be sure to

thoroughly read this manual to ensure correct use.

The "fi-5950 Operator’s Guide" stored on the Setup DVD-ROM provides useful and detailed information on Opera-

tions when you would like to use advanced features, Daily Care for maintenance of the scanner, and Replacing Con-

sumables to maintain conditions for smooth scanning. Please also read the fi-5950 Operator’s Guide for further

information.

Microsoft, Windows, Windows Server, Windows Vista, and SharePoint are either registered trademarks or trademarks

of Microsoft Corporation in the United States and/or other countries.

ISIS is a registered trademark or trademark of EMC Corporation in the United States.

PaperStream is a registered trademark of PFU LIMITED in Japan.

Other company names and product names are the registered trademarks or trademarks of the respective companies.

July, 2013

How Trademarks Are Indicated In

This Manual

References to operating systems (OS) are

indicated as follows:

Product Indication

Windows®2000

Professional

(Service Pack 4 or later)

Windows

2000

Windows

(*1)

Windows®XP

Professional

(Service Pack 3 or later),

Windows®XP

Professional x64 Edition

(Service Pack 2 or later),

Windows®XP

Home Edition

(Service Pack 3 or later)

Windows

Windows Server®2003,

Standard Edition,

Windows Server®2003,

Standard x64 Edition,

Windows Server®2003

R2, Standard Edition

(Service Pack 2 or later),

Windows Server®2003

R2, Standard x64 Edition

(Service Pack 2 or later)

Windows

Server

2003

Windows Vista®Home

Basic (32/64-bit)

(Service Pack 1 or later),

Windows Vista®Home

Premium (32/64-bit)

(Service Pack 1 or later),

Windows Vista®Business

(32/64-bit)

(Service Pack 1 or later),

Windows Vista®

Enterprise (32/64-bit)

(Service Pack 1 or later),

Windows Vista®Ultimate

(32/64-bit)

(Service Pack 1 or later)

Windows

Vista

Windows

(*1)

Windows Server®2008

Standard (32/64-bit),

Windows Server®2008 R2

Standard

Windows

Server

2008

Windows®7 Home

Premium (32/64-bit),

Windows®7 Professional

(32/64-bit),

Windows®7 Enterprise

(32/64-bit),

Windows® 7 Ultimate

(32/64-bit)

Windows

Product Indication

*1:Where there is no distinction between the

different versions of the above operating

system, the general term "Windows" is used.

Safety Precautions

The attached "Safety Precautions" manual

describes important details for users to use this

product safely and correctly. Read the Safety

Precautions thoroughly before you start using this

product.

Warning Indications Used In This

Manual

Symbols Used In This Manual

Screen Examples In This Manual

The screen examples in this manual are subject to

change without notice in the interest of product

improvement. If the actual displayed screen

differs from the screen examples in this manual,

operate by following the actual displayed screen

while referring to the User's Manual of the

scanner application you are using.

The screen examples used in this manual are of

the TWAIN driver, ISIS driver, and ScandAll PRO

(image scanning application).

The Operator Panel Language

Display

Apart from English, the operator panel can also

display French, German, Italian, Spanish, and

Chinese (Simplified). In this manual, the language

display of the operator panel is shown in English.

Windows Server®2012

Standard (64-bit)

Windows

Server

2012

Windows

(*1)

Windows®8 (32/64-bit),

Windows®8 Pro (32/64-bit),

Windows®8 Enterprise

(32/64-bit)

Windows

WARNING

This indication alerts operators to an

operation that, if not strictly

observed, may result in severe injury

or death.

CAUTION

This indication alerts operators to an

operation that, if not strictly

observed, may result in safety

hazards to personnel or damage to

equipment.

ATTENTION

This symbol alerts operators to particularly

important information. Be sure to read this

information.

HINT

This symbol alerts operators to helpful

advice regarding operation.

Product Indication

Chapter1 PREPARING THE SCANNER

1.1 Checking the Contents of the Scanner Package

When you unpack the scanner package, make sure that all of the following parts are included in the package.

If any parts are missing or defective, contact your scanner dealer or an authorized FUJITSU scanner service provider.

Handle the scanner and accessories with care.

Scanner (x1)

Document smoother (x1)

AC cable

(The contents may vary depending on the country and the

model purchased.)

USB cable (x1)

Setup DVD-ROM (x1)

2D Barcode for PaperStream Setup CD-ROM (x1)

Safety Precautions (x1)

Operator panel overlay (x5)

fi-5950 Convenient Operation (x1)

Cleanning Guide (x1)

Chapter2

INSTALLATION OF THE SCANNER

2.1 Installing the Scanner

1. Place the scanner at its installation site.

For details on the scanner's dimensions and

required installation space, refer to the fi-5950

Operator’s Guide, chapter "10. Scanner Specifi-

cations".

2. Connect the AC cable to the Power inlet of the

scanner and plug it into an outlet.

2.2 Connecting the Scanner to

Your PC

Connect either using the USB or SCSI interface.

■Connecting the USB Interface

1. Connect the USB cable to the USB connector.

2. Connect the other end of the USB cable to your

PC.

ATTENTION

•The scanner weight is 50 kg (110 lb).

Make sure two persons are available

when moving the scanner.

•When carrying the scanner, only grip the

bottom side.

ATTENTION

Use only the power cable provided by the

manufacturer.

HINT

The Function Number Display and the LED

may flash for an instant when plugging the

AC cable into the outlet. This is not a mal-

function.

ATTENTION

This scanner is provided with two inter-

faces: Ultra SCSI and USB 2.0 /1.1. Con-

nect only one of the USB or SCSI cable.

ATTENTION

•Be sure to use the USB cable which

comes with this scanner. Correct opera-

tion with commercially available cables

is not guaranteed.

•When connecting to a USB hub, use the

first stage USB hub that is closest to the

computer. If you use the second or later

hub stages, the scanner may not oper-

ate correctly.

•If you connect the scanner with USB 2.0,

it is required that the USB port and Hub

are compliant with USB 2.0. The scan-

ning speed may slow down if it is con-

nected with USB1.1.

3. Press the "I" side of the main power switch to

turn on the scanner.

■Connecting the SCSI interface

When using the scanner with a SCSI interface, the fol-

lowing SCSI cable and SCSI card must be purchased.

•SCSI cable

Use a SCSI cable whose connector on the scan-

ner side is the 68-pin high-density shielded-type

and whose connector on the PC side fits the con-

nector of the SCSI card to use.

It is recommended to use a cable of length 1.5 m

or shorter.

•SCSI card

Find the recommended SCSI card information

on the Fujitsu web site (FAQ).

http://www.fujitsu.com/global/support/

computing/peripheral/scanners/scsi/

1. Insert the SCSI cable into the interface connec-

tor of the scanner until both sides click.

2. Connect the other end of the cable to your PC.

3. Set the SCSI ID using the SCSI ID switch on

the back of the scanner.

The SCSI ID is initially set to "5" at the factory.

If the SCSI ID of another SCSI device is set to the

same ID, either change the scanner's SCSI ID or

SCSI ID of the other SCSI device.

When the scanner is turned on, the SCSI ID set is

enabled.

4. Press the "I" side of the main power switch to

turn on the scanner.

ATTENTION

•When connecting the SCSI cable, turn

the scanner off. Be sure to connect the

SCSI cable first, and then turn on the

power of the scanner and PC.

•In a SCSI daisy chain configuration,

connect the scanner so that it is the ter-

minated device.

ONOFF

ATTENTION

Be careful not to bend the pins of the SCSI

cable when connecting to the scanner.

ID No. Description

0 to 7 Can be set as the ID

8, 9 Works with the factory default value

(SCSI ID = 5).

ONOFF

2.3 Installing the Software

■Bundled Software

The following software are bundled with the scanner:

•PaperStream IP (TWAIN) Driver

Conforms to the TWAIN standard. Used when

you operate the scanner using TWAIN-compli-

ant applications.

•PaperStream IP (ISIS) Driver

Conforms to the ISIS standard. Used when you

operate the scanner using ISIS-compliant appli-

cations.

•2D Barcode for PaperStream

This option can recognize two dimensional

codes.

Can be used with the PaperStream IP (TWAIN)

driver, the PaperStream IP (ISIS) driver, or

PaperStream Capture.

For details about the installation, refer to readme

in the 2D Barcode for PaperStream Setup CD-

ROM.

•Software Operation Panel

Configure various settings such as the operation

of the scanner and managing the consumables.

Installed together with the PaperStream IP

(TWAIN) driver and PaperStream IP (ISIS)

driver.

•Error Recovery Guide

Shows the error status and countermeasures

when an error occurs. Installed together with the

PaperStream IP (TWAIN) driver and Paper-

Stream IP (ISIS) driver.

•PaperStream Capture

An image scanning application that supports the

PaperStream IP (TWAIN) driver and Paper-

Stream IP (ISIS) driver. By defining scan set-

tings as document profiles, you can customize

the settings according to your preference.

•Manual

Includes Safety Precautions, Getting Started and

Operator's Guide.

•Scanner Central Admin Agent

Used to centralize the management of multiple

scanners, by allowing you to apply firmware

updates simultaneously, monitor the operating

status, and check the scanner information.

Note that required applications will differ

depending on the form of operation.

For details, refer to the Scanner Central Admin

User’s Guide.

•Other Software (Legacy)

Software that were bundled with older versions

of scanners are also included.

•TWAIN Driver

Conforms to the TWAIN standard. Used when

you operate the scanner using TWAIN-compliant

applications.

•ISIS Driver

Conforms to the ISIS standard. Used when you

operate the scanner using ISIS-compliant appli-

cations.

•Image Processing Software Option

A software option featuring advanced binariza-

tion of scanned images. Can be installed together

with the scanner drivers (TWAIN/ISIS).

•ScandAll PRO

A TWAIN/ISIS-compliant image scanning soft-

ware. You can define scanning settings as batch

profiles, to suit your various operation require-

ments. By defining scanning settings as batch

profiles, you can easily perform scans in accor-

dance with various operation requirements.

•Scan to Microsoft SharePoint

A software program that allows you to upload

your files easily from ScandAll PRO to a

SharePoint site. Can be installed together with

ScandAll PRO.

■System Requirements

The system requirements for fi-5950 are as follows.

*1: Scanner Central Admin Agent is not supported.

*2: ScandAll PRO and Scan to Microsoft SharePoint are

not supported.

*3: The software operates as a desktop application.

*4: PaperStream IP and PaperStream Capture are not

supported.

■Installing the Bundled Software

Install the bundled software from the Setup DVD-ROM

in the following procedure.Note that there are two ways

to install the bundledsoftware: select [Installation (Rec-

ommended)] toinstall all the software required to oper-

ate thescanner, or [Installation (Custom)] to select

andinstall the software as needed.

Installation (Recommended)

The following software are installed:

• PaperStream IP (TWAIN) Driver

• Software Operation Panel

• Error Recovery Guide

• PaperStream Capture

• Manual

• Scanner Central Admin Agent

1. Turn on the computer and log onto Windows®

as a user with Administrator privileges.

2. Insert the Setup DVD-ROM into the DVD drive.

⇒

The [fi Series Setup] screen appears.

3. Click the scanner model.

4. Click the [Installation (Recommended)] button.

5. Follow the instructions on the screen to pro-

ceed with the installation.

Operating

system

•Windows®2000 Professional (*1) (*2)

•Windows®XP Professional

•Windows®XP Professional x64 Edition

•Windows®XP Home Edition

•Windows Server®2003, Standard Edition

(*1) (*2) (*4)

•Windows Server®2003, Standard

x64 Edition (*1) (*2) (*4)

•Windows Server®2003 R2, Standard

Edition (*4)

•Windows Server®2003 R2, Standard

x64 Edition (*4)

•Windows Vista®Home Basic

(32-bit/64-bit)

•Windows Vista®Home Premium

(32-bit/64-bit)

•Windows Vista®Business (32-bit/64-bit)

•Windows Vista®Enterprise (32-bit/64-bit)

•Windows Vista®Ultimate (32-bit/64-bit)

•Windows Server®2008 Standard

(32-bit/64-bit)

•Windows Server®2008 R2 Standard

•Windows®7 Home Premium

(32-bit/64-bit)

•Windows®7 Professional (32-bit/64-bit)

•Windows®7 Enterprise (32-bit/64-bit)

•Windows®7 Ultimate (32-bit/64-bit)

•Windows Server®2012 Standard

(64-bit)

•Windows®8 (32-bit/64-bit) (*3)

•Windows®8 Pro (32-bit/64-bit) (*3)

•Windows®8 Enterprise (32-bit/64-bit)

(*3)

DVD drive Essential for installing the software

Interface •Ultra SCSI (68-pin)

•USB2.0 (High-Speed)

HINT

Windows XP screen examples are used to

explain the operations. The screens and

operations may differ slightly depending on

the operating system you are using.

ATTENTION

•If an old version of the software is

installed already, uninstall it first. For

how to uninstall software, refer to "2.5

Uninstalling Supplied Programs" (page.

10).

•Log on as a user with "Administrator"

privileges (Administrators).

HINT

If the [fi Series Setup] screen does not

appear, double-click "Setup.exe" in the Setup

DVD-ROM via Windows Explorer or

[Computer].

Installation (Custom)

1. Perform steps 1. to 3. in "Installation (Recom-

mended)" (page. 7).

2. Click the [Installation (Custom)] button.

3. Select the check box for the software to install

and click the [Next] button.

4. Follow the instructions on the screen to pro-

ceed with the installation.

2.4 Checking Scanner Driver

Operation

This section explains how to check the operation of the

installed scanner driver by using ScandAll PRO.

For details about scanning documents by using Paper-

Stream Capture and the PaperStream IP driver, refer to

the help of each software.

Make sure that the scanner driver is installed properly,

following the procedure below.

■

Checking the Operation of the

Scanner Driver

1. Load the document on the scanner.

For information about how to load the document, refer

to section "2.6 Loading Documents on the ADF for

Scanning" in the "fi-5950 Operator's Guide."

2. Launch ScandAll PRO.

From the [start] menu, select [All Programs] D

[Fujitsu ScandAll PRO] D[ScandAll PRO].

3. In ScandAll PRO, select [Tool] on the menu, and

then select [Preferences].

⇒ The [Setup] dialog box appears.

4. On the [Scan] tab, select a driver.

To check the operation of TWAIN driver, select

[TWAIN].

To check the operation of the ISIS driver, select [ISIS].

5. Click the [OK] button to close the [Setup] dialog

box.

6. In ScandAll PRO, select [Scan] on the menu, and

then select [Select Scanner].

7. Select a scanner in the displayed dialog box.

To use TWAIN driver:

Select [FUJITSU fi-5950d], and then click the [Select]

button.

To use ISIS driver:

Select [Fujitsu fi-5950], and then click the [Select]

button.

8. Select [Scan] on the menu, and then select [Scan

Settings].

9. In the [Scan Settings] dialog box, clear the [Save to

file] checkbox.

10. Click [Scanner Settings].

⇒ A setup dialog box appears for you to configure

scanner driver settings.

11. Configure scanner settings such as the resolution

and paper size.

TWAIN driver/ISIS driver scanner drivers:

Configure scan settings, and then click the [OK]

button.

12. In the [Scan Settings] dialog box, click the [Scan]

button.

⇒ The document is scanned and the scanned image is

displayed in the [ScandAll PRO] window.

If the scanned document image is displayed in the window, it

means that the scanner driver is installed properly.

For further information about how to scan documents, refer to

rhe "fi-5950 Operator's Guide" or "ScandAll PRO User's

Guide" contained in the Setup DVD-ROM.

HINT

You only check the operation now, so you do

not have to save to file.

HINT

For a TWAIN driver, the scanner driver setup

dialog box may be displayed again after the

[OK] button is clicked. If this occurs, click the

[Scan] button in the dialog box.

2.5 Uninstalling Supplied

Programs

The following explains how to uninstall software applications

provided with the scanner.

1. Start your computer.

2. Exit all applications.

3. From the [start] menu, select [Control Panel] D

[Add or Remove Programs].

⇒ In the [Add or Remove Programs] dialog box, you

can view a list of installed applications.

4. Select an application you want to uninstall as

follows:

•PaperStream IP (TWAIN) driver:

[PaperStream IP (TWAIN)]

•PaperStream IP (ISIS) driver: [PaperStream IP

(ISIS) Bundle]

•2D Barcode for PaperStream: [2D Barcode for

PaperStream]

•PaperStream Capture: [PaperStream Capture]

•Manual: [fi-Scanner manuals for fi-5950]

•To remove TWAIN driver, select "Scanner

Utility for Microsoft Windows."

•To remove ScandAll PRO,

select "Fujitsu ScandAll PRO."

After ScandAll PRO, you can also remove Scan

to Microsoft SharePoint.

•To remove Scan to Microsoft SharePoint,

select "Scan to Microsoft SharePoint."

•To remove ISIS driver,

select "ISIS Driver - Fujitsu fi-5950."

•To remove Error Recovery Guide,

select "Error Recovery Guide."

•To remove Software Operation Panel (Software

Operation Panel is installed together with

TWAIN driver/ISIS driver.), select "Software

Operation Panel."

•Scanner Central Admin Agent: Uninstall by

referring to the Scanner Central Admin User’s

Guide.

•To remove FUJITSU Scanner USB HotFix,

select "FUJITSU Scanner USB HotFix."

5. Click the [Change/Remove] button or the [Remove]

button.

6. When you see a confirmation dialog box, click the

[OK] button or the [Yes] button.

⇒ Upon clicking the button, uninstallation is

started.

ATTENTION

Be sure to log on as a user with

"Administrator" privileges."

HINT

For information about how to uninstall Image

Processing Software Option, refer to the

"Image Processing Software Option User’s

Guide."

HINT

Displays may vary depeinding on the

operating system you are using. Follow the

on-screen instructions.

Examples:

In Windows 2000, the window and button

names described above are as follows:

•[Add or Remove Programs] D[Add/

Remove Applications]

•The [Changel/Remove] button DThe [Add/

Remove] button

In Windows Vista/Windows 7, the window

and button names described above are as

follows:

•[Add or Remove Programs] D[Uinsnstall a

program]

•the [Change/Remove] or the [Remove]

button Dthe [Uninstall/Change] or the

[Uninstall] button

Otros manuales para Fujitsu fi-5950

Tabla de contenidos

Otros manuales de Escáner de Fujitsu

Fujitsu

Fujitsu ScanSnap iX1600 Manual de usuario

Fujitsu

Fujitsu ScanZen Eco Series Manual de usuario

Fujitsu

Fujitsu Fi-4750c - Color Duplex Document Scanner 50ppm 90ipm... Manual de usuario

Fujitsu

Fujitsu S510 - ScanSnap - Document Scanner Manual de usuario

Fujitsu

Fujitsu FI-5530C2 Manual de usuario

Fujitsu

Fujitsu fi-5000N Manual

Fujitsu

Fujitsu ScanSnap iX100 Instrucciones de montaje

Fujitsu

Fujitsu ScanSnap S1300 Manual de usuario

Fujitsu

Fujitsu fi-6800 Manual de usuario

Fujitsu

Fujitsu S510M - ScanSnap - Document Scanner Manual

Fujitsu

Fujitsu ScanSnap S300 Manual de usuario

Fujitsu

Fujitsu M4097D - Fb 50PPM SCSI A3 Dupl 100Sht Adf Guía de configuración

Fujitsu

Fujitsu C150-E146-02EN Manual

Fujitsu

Fujitsu fi-600F Manual

Fujitsu

Fujitsu Fi-4750c - Color Duplex Document Scanner 50ppm 90ipm... Guía de configuración

Fujitsu

Fujitsu fi-5110 SERIES S500 Guía de configuración

Fujitsu

Fujitsu ScanSnap S1100 Manual de usuario

Fujitsu

Fujitsu i-4990C Manual

Fujitsu

Fujitsu M3099EX Manual de usuario

Fujitsu

Fujitsu M4097D - Fb 50PPM SCSI A3 Dupl 100Sht Adf Guía de configuración

Fujitsu

Fujitsu ScanSnap N1800 Manual de usuario

Fujitsu

Fujitsu PA03360-B505 - ScanSnap S500 Manual

Fujitsu

Fujitsu S1500 - ScanSnap Deluxe Bundle Instrucciones de instalación

Fujitsu

Fujitsu M3093DE Manual

Manuales populares de Escáner de otras marcas

Plustek

Plustek Scanner Manual de usuario

Z/I Imaging

Z/I Imaging PhotoScan 2001 Manual de usuario

Renkforce

Renkforce DS100-5M Manual de usuario

Image Access

Image Access WideTEK A2 Manual de usuario

Canon

Canon imageFORMULA CR-120N Manual de usuario

GeoSlam

GeoSlam ZEB Horizon Instrucciones de instalación

Kodak

Kodak i5800 Scanner Manual de usuario

Kodak

Kodak i7300 Manual de usuario

Revopoint

Revopoint POP Manual de usuario

Eddyfi Technologies

Eddyfi Technologies Floormap X Manual de usuario

Faselase

Faselase F6 Manual de usuario

Uniden

Uniden BC340CRS Manual de usuario

Infinite Peripherals

Infinite Peripherals INFINEA TAB M Manual de usuario

Mustek

Mustek PageExpress 4800 Pro Manual de usuario

Optex

Optex 750830 Manual de usuario

Innova

Innova 5210 Manual de usuario

Visioneer

Visioneer CardReader 100 Guía de inicio rápido

Rohde & Schwarz

Rohde & Schwarz TSME6 Manual de usuario
