Getting Started

Thank you for purchasing ScanSnap iX500 (hereinafter referred to as "the ScanSnap"). This manual

describes the preparation required for use of the ScanSnap. Follow the preparation procedures

described in this manual.

For details about ScanSnap functions and features, basic operation, daily care, and consumable replacement,

refer to the Operator's Guide (PDF) which is available on the Setup DVD-ROM.

Microsoft product screenshots are reprinted with permission from Microsoft Corporation.

Microsoft, Windows, Windows Vista, Excel, and PowerPoint are either registered trademarks or trademarks of

Microsoft Corporation in the United States and/or other countries.

Apple, the Apple logo, Mac, Mac OS, OS X, iPhoto, iTunes, and App Store are trademarks of Apple Inc.

ABBYY™FineReader™Engine ©ABBYY. OCR by ABBYY

ABBYY and FineReader are trademarks of ABBYY.

The Wi-Fi Protected Setup logo is a trademark of Wi-Fi Alliance.

Other company names and product names are the registered trademarks or trademarks of the respective

companies.

July 2013

Preparing

Make sure that all items shown below are included in the package.

If any other packaging is provided, make sure to store it as well. Make sure to handle the components with

care. The box and packaging materials are required for storage and transportation of the ScanSnap. Do not

throw them away. If anything is missing or damaged, contact your FUJITSU scanner dealer or an authorized

FUJITSU scanner service provider.

Checking the Components

567 89

23 4

1. ScanSnap (× 1)

2. AC cable (× 1) (*1)

3. AC adapter (× 1)

4. USB cable (USB 3.0 supported) (× 1)

5. Safety Precautions (× 1)

6. Setup DVD-ROM (× 1)

7. Adobe®Acrobat®DVD-ROM (× 1)

8. ScanSnap Carrier Sheet (× 1)

9. Rack2-Filer Smart with Magic Desktop

(× 1) (*2)

*1 : The contents may vary depending on the country and the ScanSnap model purchased.

*2 : Bundled with FI-IX500-D

Before using the ScanSnap, make sure to read and understand the information provided in the "Safety

Precautions" document.

To refer to the "Operator’s Guide", insert the Setup DVD-ROM into the DVD-ROM drive, and follow the

procedure below.

The ScanSnap can be connected to a

computer or a mobile device via wireless

LAN. To use this function, make sure a

wireless LAN is available in advance.

When you connect the ScanSnap to a

wireless LAN, information for a wireless

access point or router such as a SSID

(network name) or security key (password)

may be required. For details, refer to the

manual of your wireless access point or

router.

Read the Safety Precautions

Symbols Used in This Manual

Symbol Description

This indication alerts operators to an operation that, if not strictly observed, may result in

safety hazards to personnel or damage to the product.

Referring to the "Operator's Guide"

Click the [Manuals] button in the [ScanSnap Setup] dialog box, and then the [Operator's

Guide] button.

Double-click the [Operator's Guide] icon in the [ScanSnap] window.

Using in a Wireless LAN Environment

ATTENTION

No more than one computer can be connected to the ScanSnap via wireless LAN.

CAUTION

Wireless Access Point or Router

Mobile Device

Computer

Removing the Protective Packaging

Follow the procedure described below to remove the protective packaging before using the ScanSnap.

1. Open the ADF paper chute (cover) (1), and

pull the tape to remove the protective foam

sheet (2) from the stacker. Open the stacker

(3) and pull the tape to remove the

protective sheet from the ADF top section

(4).

2. Pull the ADF release tab to open the ADF

top section, and pull the tape to remove the

protective card from the side guides.

Installing the Software

Windows®Installation (Jpage 4)

Mac OS Installation (Jpage 7)

CAUTION

If the magnetic part of the ADF top section makes contact with the black magnetic part

of a magnetic card or IC card, the data on the card may be lost.

ATTENTION

zDo not connect the ScanSnap to your computer before installing the software.

zIf you have no DVD-ROM drive, please visit the following web page:

http://scansnap.fujitsu.com/g-support/en/

HINT

When you export the data scanned by the ScanSnap to your mobile device, download ScanSnap Connect

Application from an available source such as iTunes, App Store, or Google Play.

ADF Top

Section

ADF Paper Chute (cover)

Stacker

Protective

Card and

Tape

ADF Top

Section

ADF Release Tab

Magnets

■Software

You can install the following software.

zScanSnap Manager (Scanner driver)

zScanSnap Organizer (File management application)

zCardMinder (Business card management application)

zABBYY FineReader for ScanSnap™(OCR application)

Install other software bundled with the ScanSnap as needed.

For details about each software and its installation procedures, refer to "Installing the Software" in the

Operator's Guide.

■System Requirements

For the latest information on requirements, please visit the ScanSnap Support Site at:

http://scansnap.fujitsu.com/g-support/en/

*1 : The software bundled with the ScanSnap operates as a desktop application.

*2 : Service Pack 2 or later is required.

*3 : Service Pack 3 or later is required.

*4 : When the font size is large, some screens may not be displayed properly.

In that case, use a smaller font size.

*5 : For Windows®8, Windows Vista®, and Windows®XP, if Microsoft®.NET Framework 3.5 SP1 is not

installed, a maximum of 500 MB of additional free hard disk space is required for it.

*6: Some computers do not recognize the ScanSnap when it is connected to a USB 3.0 port.

For the latest information on USB 3.0, please visit the following web page:

http://scansnap.fujitsu.com/g-support/en/

Windows

Installation

Operating system Windows®8 (32-bit/64-bit) (*1)

Windows®7 (32-bit/64-bit)

Windows Vista®(32-bit/64-bit) (*2)

Windows®XP (32-bit) (*3)

CPU Intel®Core™2 Duo 2.2 GHz or higher

(Recommended: Intel®Core™ i5 2.5 GHz or higher)

Memory 32-bit: 1 GB or more (Recommended: 4 GB or more)

64-bit: 2 GB or more (Recommended: 4 GB or more)

Display resolution (*4) Windows® 8: 1024

768 pixels or higher

Windows® 7/Windows Vista®/Windows® XP: 800

600 pixels or higher

Hard disk space (*5) 4386 MB or more of free hard disk space

Additionally, 1 GB or more of free hard disk space is required for ScanSnap iX500

Deluxe (FI-IX500-D/FI-IX500-DC). For details, refer to the manuals for Rack2-Filer

Smart with Magic Desktop.

USB port USB 3.0 (*6)/USB 2.0/USB 1.1

ATTENTION

zIf the system requirements above are not satisfied, the ScanSnap may not operate.

zScanning speed will slow down in the following cases:

- The CPU or the memory does not meet the required specifications

- The version of the USB port or the USB hub is USB 1.1

zThe actual increase in used disk space after installation and the required disk space for installation may

differ from each other depending on your Windows®system disk management.

■Installation

1. Turn your computer on and log on as a user with Administrator privileges.

2. Insert the Setup DVD-ROM into the DVD-ROM drive.

DThe [ScanSnap Setup] dialog box appears.

3. Click the [Install Products] button.

DThe [Install Products] dialog box appears.

4. Click the [ScanSnap] button.

Follow the instructions on the screen to continue with

the installation.

DWhen you proceed with the operation, the [ScanSnap -

Connecting the ScanSnap] dialog box appears.

HINT

When the installation is complete, a pop-up balloon which indicates that the latest updates are available on the download

server may appear. For details, refer to the ScanSnap Online Update Help.

HINT

If the [ScanSnap Setup] dialog box does not appear, double-click "ScanSnap.exe" in the DVD-ROM via Windows

Explorer.

5. Follow the instructions on the screen to connect

the ScanSnap to the computer.

Click the [Next] button, and follow the instructions on

the screen to connect the ScanSnap to the

computer.

For details, refer to "Connecting the ScanSnap"

(page 9).

DWhen the connection check is complete, the

[ScanSnap Wireless Network Setup] dialog box

appears.

Check the ScanSnap operation before connecting

the ScanSnap to a wireless LAN.

6. Check the operation of the ScanSnap.

For details, refer to "Scan Test (USB Connection)" (page 11).

7. Select whether you want to configure the

wireless settings for connecting the ScanSnap to

a wireless LAN.

DTo configure the wireless settings, click the [Setup

Now] button, and then follow the instructions on the

screen. For details, refer to "Connecting the

ScanSnap to a Wireless LAN" (page 12).

DOtherwise, click the [Later] button.

8. Remove the Setup DVD-ROM from the DVD-ROM drive.

HINT

If you want to configure the wireless settings for connecting the ScanSnap to a wireless LAN at another

time, refer to the Operator' s Guide.

ATTENTION

If installation is not completed successfully, click the [Manuals] button in the [ScanSnap Setup] dialog box,

and then the [Troubleshooting (installation)] button, and refer to Troubleshooting (installation).

■Software

You can install the following software.

zScanSnap Manager (Scanner driver)

zCardMinder (Business card management application)

zABBYY FineReader for ScanSnap™(OCR application)

Install other software bundled with the ScanSnap as needed.

For details about each software and its installation procedures, refer to "Installing the Software" in the

Operator's Guide.

■System Requirements

For the latest information on requirements, please visit the ScanSnap Support Site at:

http://scansnap.fujitsu.com/g-support/en/

* : It is recommended to apply the latest updates to Mac OS.

■Installation

1. Turn your computer on and log on as a user with Administrator privileges.

2. Insert the Setup DVD-ROM into the DVD-ROM drive.

DThe [ScanSnap] window appears.

Mac OS Installation

Operating system (*) OS X v10.8 (Recommended: 10.8.1 or later)

Mac OS X v10.7 (Recommended: 10.7.4 or later)

Mac OS X v10.6 (Recommended: 10.6.8)

CPU Intel®Core™2 Duo 2.4 GHz or higher

(Recommended: Intel®Core™ i5 2.5 GHz or higher)

Memory 2 GB or more (Recommended: 4 GB or more)

Display

resolution 1024

768 pixels or higher

Hard disk space 2450 MB or more of free hard disk space

USB port USB 3.0/USB 2.0/USB 1.1

ATTENTION

zIf the system requirements above are not satisfied, the ScanSnap may not operate.

zScanning speed will slow down in the following cases:

- The CPU or the memory does not meet the required specifications

- The version of the USB port or the USB hub is USB 1.1

HINT

When the installation is complete, the [ScanSnap Online Update] window may appear. For details, refer to

the ScanSnap Online Update Help.

3. Double-click the [ScanSnap] icon.

Follow the instructions on the screen to continue with

the installation.

DWhen you proceed with the operation, the [ScanSnap

- Connecting the ScanSnap] window appears.

4. Follow the instructions on the screen to connect

the ScanSnap to the computer.

Click the [Next] button, and follow the instructions on

the screen to connect the ScanSnap to the

computer.

For details, refer to "Connecting the ScanSnap"

(page 9).

DWhen the connection check is complete, the

[ScanSnap Wireless Network Setup] window

appears.

Check the ScanSnap operation before connecting the

ScanSnap to a wireless LAN.

5. Check the operation of the ScanSnap.

For details, refer to "Scan Test (USB Connection)" (page 11).

6. Select whether you want to configure the

wireless settings for connecting the ScanSnap to

a wireless LAN.

DTo configure the wireless settings, click the [Setup

Now] button, and then follow the instructions on the

screen. For details, refer to "Connecting the

ScanSnap to a Wireless LAN" (page 12).

DOtherwise, click the [Later] button.

7. Remove the Setup DVD-ROM from the DVD-ROM drive.

HINT

If you want to configure the wireless settings for connecting the ScanSnap to a wireless LAN at another

time, refer to the Operator' s Guide.

Connecting the ScanSnap

1. Connect the AC cable to the AC adapter

(collectively called the "power cable").

2. Plug the power cable into the power

connector at the back of the ScanSnap, and

the other end to an AC outlet.

3. Remove the tape seal on the USB connector

of the ScanSnap.

4. Connect the USB cable to the USB connector

on the ScanSnap and the USB port on your

computer.

ATTENTION

zOnly one ScanSnap can be used by a computer at a time.

zUse only the cable supplied with the ScanSnap.

CAUTION

Do not use AC adapters other than the one supplied with this ScanSnap. Doing so may

cause damage to the ScanSnap.

ATTENTION

zWhen connecting to USB hub, make sure to

connect the ScanSnap to the USB hub which is

connected to a USB port of your computer. Use a

powered USB hub (with AC adapter).

zIf USB port or USB hub is USB 1.1, scanning speed

will slow down.

zConnect the USB cable with the USB mark facing

up.

AC Adapter

AC Cable

AC Outlet

Power Cable

Power Connector

Tape Seal

USB Cable

5. Open the ADF paper chute (cover) of the ScanSnap.

DThe ScanSnap is powered on and the [Scan] button lights

in blue.

6. Check the ScanSnap Manager icon.

DThe ScanSnap Manager icon is displayed in the menu that

appears when you click on the notification area, at the far

right of the taskbar.

To have the ScanSnap Manager icon always displayed on the

notification area, drag the icon and drop it onto the notification

area.

DThe ScanSnap Manager icon appears in the Dock.

ATTENTION

zThe bottom of the ScanSnap may become hot when the

ScanSnap is used, but this heat does not affect operation

or cause any physical harm. However, be careful not to

drop the ScanSnap when carrying it.

zWhen the ScanSnap is turned on and left unused for 4

hours, it will turn itself off automatically. To turn the

ScanSnap back on, perform one of the following

operations:

- Press the [Scan] button (Scanning does not start).

- Close the ADF paper chute (cover) and open it again

The time until power-off can be changed. For details, refer to

the Operator's Guide.

HINT

When you close the ADF paper chute (cover), the

ScanSnap will turn off.

ATTENTION

If the ScanSnap Manager icon is , right-click on and select [To establish connection] from the

menu. You can reference the appropriate actions for connecting the scanner.

ATTENTION

If the ScanSnap Manager icon is , while holding down the [control] key, click and then select

[To establish connection] from the menu. You can reference the appropriate actions for connecting

the scanner.

[Scan] Button

ADF Paper Chute (cover)

Otros manuales para ScanSnap iX500

Tabla de contenidos

Otros manuales de Escáner de Fujitsu

Fujitsu

Fujitsu M3097DE Manual de usuario

Fujitsu

Fujitsu ScanPartner 620C Manual de usuario

Fujitsu

Fujitsu ScanSnap S300 Manual de usuario

Fujitsu

Fujitsu S510 - ScanSnap - Document Scanner Manual de usuario

Fujitsu

Fujitsu ScanSnap fi-5110EOX Manual de usuario

Fujitsu

Fujitsu fi-6800 Manual de usuario

Fujitsu

Fujitsu FI-4010CU Manual de usuario

Fujitsu

Fujitsu fi-6800 Manual de usuario

Fujitsu

Fujitsu fi-4220C2 Manual de usuario

Fujitsu

Fujitsu ScanSnap FI-4110EOX2 Manual

Fujitsu

Fujitsu fi-6800 Manual

Fujitsu

Fujitsu C150-E049-02EN Manual de instalación y operación

Fujitsu

Fujitsu ScanPartner SP30 Manual

Fujitsu

Fujitsu fi-7800 Manual

Fujitsu

Fujitsu PA03360-B505 - ScanSnap S500 Manual

Fujitsu

Fujitsu FI-4010CU Manual

Fujitsu

Fujitsu Mobile Color Scanner Manual de usuario

Fujitsu

Fujitsu ScanPartner 15C Guía de referencia

Fujitsu

Fujitsu ScanPartner 15C Manual de usuario

Fujitsu

Fujitsu M3093GX Manual de operación y mantenimiento

Fujitsu

Fujitsu fi-6400 Manual de instrucciones

Fujitsu

Fujitsu FI-5900C Manual de usuario

Fujitsu

Fujitsu fi-65F Manual de usuario

Fujitsu

Fujitsu ScanSnap iX100 Manual de usuario

Manuales populares de Escáner de otras marcas

Plustek

Plustek Scanner Manual de usuario

Z/I Imaging

Z/I Imaging PhotoScan 2001 Manual de usuario

Renkforce

Renkforce DS100-5M Manual de usuario

Image Access

Image Access WideTEK A2 Manual de usuario

Canon

Canon imageFORMULA CR-120N Manual de usuario

GeoSlam

GeoSlam ZEB Horizon Instrucciones de instalación

Kodak

Kodak i5800 Scanner Manual de usuario

Kodak

Kodak i7300 Manual de usuario

Revopoint

Revopoint POP Manual de usuario

Eddyfi Technologies

Eddyfi Technologies Floormap X Manual de usuario

Faselase

Faselase F6 Manual de usuario

Uniden

Uniden BC340CRS Manual de usuario

Infinite Peripherals

Infinite Peripherals INFINEA TAB M Manual de usuario

Mustek

Mustek PageExpress 4800 Pro Manual de usuario

Optex

Optex 750830 Manual de usuario

Innova

Innova 5210 Manual de usuario

Visioneer

Visioneer CardReader 100 Guía de inicio rápido

Rohde & Schwarz

Rohde & Schwarz TSME6 Manual de usuario
