FS KVM-160217IP Manual de usuario
KVM SWITCHES
Cat5e/6/7 Rack-Mount USB
Quick Start Guide V1.0
AUTO
EXIT
MENU
SELECT
KVM Drawer
Transmit by CAT5
16 Prot KVM
StationID
ONLINE SELECTEO
2
1
910 11 12 13 14 15 1 6
34567
SCAN
8
SL· SL+
RESET
Introduction
Thank you for choosing FS KVM switches. This guide is designed to familiarize you with the layout of
the KVM switch and describes how to deploy it in your network.
Accessories
AC Power Cord x1 Cat5e Patch cable x1 RJ45 to VGA Interface
Module x8/16
USB Flash Disk x1
Grounding Wire x1
Rack-mount Kit x2 Screw x8
KVM-160217IP/KVM-080217IP
KVM-0802IP
UNLOCK
Slide Unlock
Slide Unlock
RESET
1
K/M RESET
2 3 4 5 6 7 8
AUTOSCAN
ONLINE SELECTED
Matrix KVM over IP FWUPGRADE
NORMALRECOVER UPGRADE POWER STATIONID
Front Bracket x2
NOTE: The number of RJ45 to VGA Interface Module for KVM-0802IP and KVM-080217IP is 8,
and KVM-160217IP is 16. Rack-mount Kit is provided for KVM-080217IP and KVM-160217IP
only.
Hardware Overview
Front Panel Buttons
16 Port KVM
Station ID
ONLINE SELECTED
KVM over IP
1
9 10 11 12 13 14 15 16
2 3 4 5 6 7 8
RESET SCAN
HD＆Matrix
Buttons Components Function
1~8/16 Port Selection Switch freely from port 1 to port 8/16.
Press [1] and [2] at the same time for three seconds to
reset the keyboard and mouse.
Press [5] to enhance the brightness after entering
brightness adjusting mode, or enhance the denition
after entering denition adjusting mode.
First, press the port button which is going to be set.
Then start to adjust the mode.
Press [4] for three seconds to enter denition adjusting
mode.
Number 44 is ashing on the LED tube.
Then press [5] and [6] to adjust.
Press [4] to exit or wait for ve seconds and it will
auto-exit.
First, press the port button which is going to be set.
Then start to adjust the mode.
Press [3] for three seconds to enter brightness
adjusting mode.
Number 33 is ashing on the LED tube.
Then press [5] and [6] to adjust.
Press [3] to exit or wait for ve seconds and it will
auto-exit.
1
2
3
Reset
Brightness
Denition
Adjust +
4
5
LED OSD Controls
Front Panel LEDs
KVM-080217IP/KVM-160217IP
KVM-080217IP/KVM-160217IP
AUTO
EXIT SL- SL+
AUTO
EXIT MENU
SELECT
SL- SL+
6 Adjust -/Initialize
Press [6] to reduce the brightness after entering
brightness adjusting mode, or reduce the denition
after entering denition adjusting mode.
Press [6] for three seconds to initialize the brightness
and denition of each port.
Press [7] and [8] at the same time for three seconds to
enter the auto scan mode.
7
8
Scan
Buttons Function
AUTO/EXIT Press this button to exit the current menu and return to the previous menu
or exit the LED OSD, or enter automatic conguration.
Press this button to move your menu to make corresponding adjustment.
Press this button to invoke the menu function and open the main menu.
SL-/SL+
MENU SELECT
LED State Description
Green KVM is powered on.
Power o or access non-standard VESA signal.
Energy saving mode or no signal.
Red
Flashing Green
MENU
SELECT
Front Panel Ports
Rear Panel Ports
KVM-0802IP/KVM-080217IP/KVM-160217IP
RESET
1
K/M RESET
2 3 4 5 6 7 8
AUTO SCAN
ONLINE SELECTED
Matrix KVM over IP FW UPGRADE
NORMAL RECOVER UPGRADE POWER STATIONID
RESET
1
K/M RESET
2 3 4 5 6 7 8
AUTO SCAN
ONLINE SELECTED
Matrix KVM over IP FW UPGRADE
NORMAL RECOVER UPGRADE POWER STATIONID
LEDs Status Description
KVM is powered on.
KVM has been connected to its corresponding computer
and powered on.
The computer attached to its corresponding port is up
and running.
Display the current port.
Power
Online LED lights
Selected LED lights
Station ID
Blue
Green
Orange
/
Ports Description
Reserved port for hardware upgrading.
Reserved port for hardware upgrading.
FW UPGRADE-NORMAL RECOVER
UPGRADE
100-240Vac 50-60Hz RS485 1 2 3 4 5 6 7 8
DC 12V LAN
Rack Mounting
Site Environment
Installing
Do not operate it in an area that exceeds an ambient temperature of 40°C or nearby heat sources.
The installation site should be well ventilated.
Be sure that the KVM switch is level and stable to avoid any hazardous conditions.
Do not install the equipment in a dusty environment.
The installation site must be free from leaking or dripping water, heavy dew, and humidity.
Ports Description
A power input port for AC power cord.
Turn on/o the power.
A power input port for DC power cord.
Connect the remote computer for remote control.
Connect external keyboard, mouse and monitor for local
control.
Connect computer or server.
For grounding the KVM Switch.
Reserved port for hardware upgrading.
Power Input (AC)
Power Switch
Power Input (DC)
LAN Port
USB Port
HDMI Port
RJ45 Ports
Ground Connecting Screw
RS485 Port
UNLOCK
Vac
Grounding the KVM Switch
1. Connect one end of the grounding wire to a proper earth ground, such as the rack in which the
KVM switch is mounted.
2. Secure the grounding lug to the grounding point on the KVM switch's back panel with the washers
and screws.
1. Attach the switch to the rack using six M6 screws and nuts.
2. Slide the rack-mount kit into the switch’s side mounting brackets from the back to the front, then
screw the rack-mount kit to the rack.
NOTE: The rack-mount kit is provided for KVM-080217IP and KVM-160217IP only.
V
LAN
DC
RS
Connecting the Power
Connecting to the RJ45 Ports
1. Connect an Ethernet cable to the RJ45 port of the KVM switch.
2. Connect the other end of the Ethernet cable to the RJ45 port of the supplied RJ45 to VGA
Interface Module and then connect the VGA port of the Module to a server or computer.
1. Plug the provided AC power cord into the power port on the back of the KVM switch.
2. Connect the other end of the power cord to an AC power source.
3. Open the power switch on the rear panel.
WARNING: Do not install power cables while the power switch is on.
NOTE: DC power cord is not included in the package.
V
LAN
DC
Vac Hz
RS
V
LAN
DC
Vac Hz
RS
Connecting to USB and HDMI Ports
Connect external keyboard, mouse and monitor (optional).
Connecting to the LAN Port
1. Connect an Ethernet cable to the RJ45 port of a server or computer.
2. Connect the other end of the Ethernet cable to the LAN port of the switch.
Keyboard Mouse Monitor
RS485
1 2 3 4 5 6
DC 12V LAN
V
LAN
DC
Vac Hz
RS
Opening the Console
Closing the Console
1. Release the lock and pull the KVM console.
2. Pull the KVM console all the way out until it clicks into place;
3. Open the LED panel to display the LED screen; the LED panel can be rotated up to 108°.
1. Close the LED panel and the power will automatically shut down.
2. Push the release catch in the direction of the arrow; push the LED panel all the way in until it
automatically locks up.
3. Lock the LED panel.
Opening & Closing the Console
KVM-080217IP/KVM-160217IP
NOTE: The lock can only do horizontal locking, it can’t bear any load.
UNLOCK
UNLOCK
UNLOCK
108°
LOCK
LOCK
108°
KEY
RELEASE CATCH
7 8
