Front Runner JADA010 Manual de usuario

ENG

hi-lift Jack bracket

JADA010

front runner

Thank you for purchasing a Front Runner Hi-Lift Jack Bracket.

Before you start, take a moment to familiarize yourself with the Fitting Instructions and the components received.

Refer to Page 2 for a list of all the components, quantities and tools required.

READ ME !

IMPORTANT WARNING!

IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD

RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT

RUNNER PRODUCTS TO YOUR VEHICLE, CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND

DAMAGE. THEREFORE, YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO

INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY

FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.

NOTE: Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.

Please call us if you have any questions about the installation of this product.

IN THE BOX

FIGURE 1.1

1 1 X M10x40 Hex Bolt

2 3 X M10x30x3 Flat Washer

3 4 X M8x25 Button Head Bolt (Black)

4 10 X M8x16x1.6 SS Flat Washer

5 1 X Base Bracket

6 1 X M10 Wing Nut

7 1X M12 Nyloc Hex Nut

8 1 X M12 Flat Washer

11 8 X M8 Nyloc Hex Nut

12 2 X M8x16 Button Head Bolt (Black)

13 1 X M12 Machined Stud

14 2 X Support Bracket

IN THE BOX

TOOLS NEEDED

4mm

5mm

Allen Key

IN THE BOX IN THE BOX

18 2 X M8x30 Button Head Bolt (Black)

19 2 X M8 Nut Cap

20 2 X M8 x 20 Hex Bolt

IN THE BOXIN THE BOX CONTINUED

Marker

6432

1812 13411

15 1 X Handle Clamp Assembly

16 1 X M10 Tie Down Ring

17 2 X M8x20 Button Head Bolt (Black)

1GET ORGANIZED

Here is what you are looking at for JADA010

FIGURE 1.2

1GET ORGANIZED CONTINUED

JADA010_REV_B05

RECOMENDED POSITIONS

2.1

Please note that it is not recommended to mount your Hi-Lift Jack on the front or rear of your Rack

only on the sides.

For ease of instruction, we have chosen to describe one orientation of mounting the Jack Bracket.

The principals are the same, just the positioning and orientation of the brackets may vary depending

on where you want to mount the jack.

Decide where on your Rack you would like to mount the Hi-Lift Jack. The brackets can be orientated

upwards, downwards, front to back and back to front. Refer to Page 4, showing the various

mounting options.

JADA010_REV_B05

2.2

RECOMENDED POSITIONS

THIS POSITION IS NOT SUITED FOR A HI LIFT JACK.

IMPORTANT WARNING!

JADA010_REV_B05

3.1

3.2

3.3

Fit and Secure Base Bracket in desired

position as shown.

Secure as shown. Insert 2 M8 Hex Nuts

at the point indicated by the arrow.

Assemble the machined pin and

securing bolt in hole patern suited to

your jack.

FIT AND SECURE

5 2

6 2 13

3.4

Fit and Secure the handle clamp in the

desired position, using fasteners shown

in Figure 1.2

16 17

5mm

13mm

5mm

13mm

5mm

17mm

REMOVE FROM SLAT

JADA010_REV_B05

INSTALL OTHER VEHICLE AND RACK ACCESSORIES

Now's the time to visit your favorite Front Runner Dealer in person or online.

Be sure to tag us. We love to see our gear in action! #FrontRunnerOutfitters #BornToRoam

Share your adventures on:

FINISH

Congratulations! You did it. Take a step back and admire your work!
