Frigidaire Gallery GLCS389F Manual de usuario

GLCS389E.eps LA20BG0058.eps LA20BR0018.eps BPLES389ECB.eps

LA20CT0092.eps DGLCS389FSA.eps 318271904.eps

Product No. GLCS389FBA GLCS389FQA GLCS389FSA

37956361H6361 37956361H6341 37956361H6311

Series 30" slide-in 30" slide-in 30" slide-in

Color black bisque white

Market North America North America North America

Wiring Diagram 318271904 318271904 318271904

Owner's Guide 318203851 318203851 318203851

Installation Instructions 318201671 318201671 318201671

Service Data Sheet 318127021 318127021 318127021

Timer Guide 318200194 318200194 318200194

Electrolux Major Appliances

North & Latin America

P.O. BOX 212378

AUGUSTA, GA 30917

Publication No.

5995470910

06/07/26

(EN/SERVICE/ECL)

377

30-INCH SLIDE-IN

DUAL FUEL RANGE

Model No.

GLCS389F

Publication No: 5995470910 GLCS389F

07/06 2

BACKGUARD

GLCS389F Publication No: 5995470910

# Functional Parts 3 07/06

* Non-Illustrated Parts

BACKGUARD

Model Index: AGLCS389F (GLCS389FSA)

BGLCS389F (GLCS389FBA)

CGLCS389F (GLCS389FQA)

POS. NO PART NO. DESCRIPTION

16 318299100 A - - Console, assy., white

16 318299102 - B - Console, assy., black

16 318299101 - - C Console, assy., bisque

19 318312210 A - - Control Panel Assembly, w/membrane, white

19 318312212 - B - Control Panel Assembly, w/membrane, black

19 318312211 - - C Control Panel Assembly, w/membrane, bisque

19A 318224404 A B C Panel, control mtg.

20 # 316418731 A B C Clock/Timer, electronic, ES510

20* 5304453707 A B C Screw, control mtg.

35 318233721 A - - Retainer, control panel, white

35 318233720 - B - Retainer, control panel, black

35 318233722 - - C Retainer, control panel, bisque

36 316223025 A - - Knob, control, white

36 316223024 - B - Knob, control, black

36 316223026 - - C Knob, control, bisque

42 318298001 A B C Trim, vent, black, upper

99A 318223900 A B C Gasket, dark grey

100 318233800 A B C Nut, hex

101 318233400 A B C Bushing, retainer

* # 318224813 A B C Harness, wiring, timer

* 08016432 A B C Screw, truss head, 8-18 x 0.375

* 5303300265 A B C Screw, 8-18 X 1/2, (2)

* 5303311333 A B C Screw, 8-32 x 3/8

Publication No: 5995470910 GLCS389F

07/06 4

BURNER

GLCS389F Publication No: 5995470910

# Functional Parts 5 07/06

* Non-Illustrated Parts

BURNER

Model Index: AGLCS389F (GLCS389FSA)

BGLCS389F (GLCS389FBA)

CGLCS389F (GLCS389FQA)

POS. NO PART NO. DESCRIPTION

1 318305600 A B C Manifold, right side

1A 318305601 A B C Manifold, left side

1B 318305410 A B C Tube, manifold, 3/8, interconnect

2 # 318233930 A B C Valve, top burner, 14000 BTU

2A # 318233940 A B C Valve, top burner, 16/17K

2B # 318233900 A B C Valve, top burner, 5000 BTU

2C # 318233910 A B C Valve, top burner, 9500 BTU

3 # 318232600 A B C Wiring Harness, w/igntr switch

10 # 316223400 A B C Burner, sealed, 14K

10A# 316223300 A B C Burner, sealed, 16/17K

10B# 316206400 A B C Burner, sealed, 5K

10C# 316212400 A B C Burner, sealed, 9.5K

11 318306106 A B C Ignitor Assembly, 14K, left rear, w/tube & holder

11A 318306107 A B C Ignitor Assembly, 16K, right front, w/tube & holder

11B 318306108 A B C Ignitor Assembly, 5K, right rear, w/tube & holder

11C 318306104 A B C Ignitor Assembly, 9.5K, left front, w/tube & holder

12 318369902 A B C Bracket, support, (2)

13 318305110 A B C Tube, regulator, to manifold

14 # 318122700 A B C Regulator, pressure

14* 5303311306 A B C Screw, 8-18 x 0.375, (3)

16 318590002 A B C Panel, regulator mtg.

37 5303307980 A B C Screw, 8-32 x 0.437, (4)

44 316237900 A B C Orifice, top burner, 14K

44A 316237912 A B C Orifice, top burner, 16K

44B 316237903 A B C Orifice, top burner, 5K

44C 316237902 A B C Orifice, top burner, 9.5K

72 316215600 A B C Screw, valve mtg., 1/4 - 20

77 318192606 A B C Bracket, burner mtg, (4)

300 318322300 A B C Bracket, inlet, long, door

301 318322301 A B C Bracket, inlet, short, block

* 318186909 A B C LP Conversion Kit

* # 318199725 A B C Wiring Harness, ignitor

* 08011955 A B C Screw, 10-24 x 0.375, square drive

* 5303211311 A B C Screw, 8 x 0.500

Publication No: 5995470910 GLCS389F

07/06 6

BODY

GLCS389F Publication No: 5995470910

# Functional Parts 7 07/06

* Non-Illustrated Parts

BODY

Model Index: AGLCS389F (GLCS389FSA)

BGLCS389F (GLCS389FBA)

CGLCS389F (GLCS389FQA)

POS. NO PART NO. DESCRIPTION

1 318259204 A B C Back, main

1A 318225110 A B C Panel, main back, upper

2 318258902 A B C Shield, insulation, upper

3 318225210 A B C Panel, bodyside, upper RH

3A 318225211 A B C Panel, bodyside, upper LH

5 318175503 A B C Screw, leveling

6 318345208 A B C Rack, oven

6A 318219500 A B C Rack, broiler pan

8 318262001 A B C Cover, element

8A 318318600 A B C Bracket, element, hidden bake

9 5303317977 A B C Pan, broiler

10 5303317976 A B C Insert, broiler pan

12 # 318089917 A B C Switch, light

14 318224000 A B C Receptacle, oven light

15 5303013071 A B C Bulb/Lamp, light

16 08011086 A B C Lens, oven light, glass

17 5304400195 A B C Retainer, light cover

29 318147411 A B C Bumper, (2)

37 # 316217002 A B C Probe, oven temp

41 5303310526 A B C Cover, hinge cutout

54 318222400 A B C Housing, oven light

58A 318285055 A B C Insulation, oven wrapper

58B 318285056 A B C Insulation, oven back

59 318072560 A B C Duct, oven vent

59A 318261600 A B C Bracket, vent tube

62 5303935061 A B C Terminal Block Kit

62* 5303323139 A B C Screw, 10-24 x 0.906

62* 5303323144 A B C Nut, 10-32

63 318264200 A B C Plate, grounding strap

66 # 318255600 A B C Element, broil, 2750W

67 318254901 A B C Element, bake, 3400W, 8 pass

68 5304403015 A B C Support, hanger, (2), broil element

70 318259100 A B C Shield, insulation, sides, (2)

71 318260007 A B C Panel, rear box

76 318056217 A B C Front, oven

80 5303320846 A B C Plate, oven mtg

81 318192400 A B C Spring, oven

82 318258708 A B C Shield, insulation, lower

83 318261400 A B C Liner, oven assy

86 5303310524 A B C Receptacle, hinge

87 318260609 A B C Bracket, cable mtg.

87A 318111804 A B C Plate, cord set mtg

89 # 318261209 A B C Motor, latch assy

90 318296902 A - - Panel, filler, white, RH

90 318296904 - B - Panel, filler, black, RH

90 318296906 - - C Panel, filler, bisque, RH

90A 318296903 A - - Panel, filler, white, LH

90A 318296905 - B - Panel, filler, black, LH

Publication No: 5995470910 GLCS389F

07/06 8

BODY

GLCS389F Publication No: 5995470910

# Functional Parts 9 07/06

* Non-Illustrated Parts

BODY

Model Index: AGLCS389F (GLCS389FSA)

BGLCS389F (GLCS389FBA)

CGLCS389F (GLCS389FQA)

POS. NO PART NO. DESCRIPTION

90A 318296907 - - C Panel, filler, bisque, LH

107 318219401 A B C Cover, fan

108# 318073018 A B C Motor, blower

* 318249401 A B C Tube, protector

108A 318251300 A B C Bracket, fan support

109 316136400 A B C Blade, fan

111 316136600 A B C Nut, fan retainer

112# 318112703 A B C Relay

119# 318005202 A B C Switch, thermal cutout

125# 316415800 A B C Motor, fan

127 318317100 A B C Adapter Assembly, vent tube, w/converter

131 318272900 A B C Box, vent

132 318003000 A B C Plate, shield

142 318123910 A B C Deflector

161# 318255503 A B C Element, convection, 350 W

163 318014110 A B C Spacer, (6)

166 318298410 A B C Bracket, base support, (2)

166A 318298403 A B C Bracket, base support, lower, (2)

170 318335500 A B C Anti-tip & accessories

185 318165800 A B C Spacer

200 318298201 A B C Frame, drawer, black, front

201 318298210 A B C Frame, drawer

219# 318003614 A B C Thermostat, safety

219A 318003613 A B C Thermostat, safety, 1.375" mtg, 105/120

263 316136500 A B C Washer, flat

* # 318224936 A B C Harness, wiring, main

* 318235300 A B C Connector assy., w/3 lugs, & instructions

* 3051050 A B C Screw, shoulder

* 3201861 A B C Screw, 6 x 0.375, (4)

* 08016432 A B C Screw, truss head, 8-18 x 0.375

* 5303211311 A B C Screw, 8 x 0.500

* 5303307980 A B C Screw, 8-32 x 0.437, (4)

* 5303323129 A B C Screw, 8 X 0.750

* 5304415832 A B C Screw, 8-18 x 0.406

* 5304436875 A B C Screw, 8-18 X 1/2, black

Publication No: 5995470910 GLCS389F

07/06 10

TOP
