Frigidaire FGF316D Manual de usuario

71191100.eps L24G0027.eps L24B0003.eps L24V0004.eps L24T0033.eps L24D0006.eps

316255203d.eps 316255203s.eps

Product No. FGF316DQB FGF316DSB

Series 30" f/s gas 30" f/s gas

Color bisque white

Market North America North America

Wiring Diagram 316255203 316255203

Owner's Guide 316257510 316257510

Installation Instructions 316259327 316259327

ELECTROLUX HOME PRODUCTS, INC.

P.O. Box 212378, Augusta, GA 30917

Publication No.

5995416905

04/09/22

(EN/SERVICE/ECL)

369

30-INCH FREE-

STANDING GAS

RANGE

Model No.

FGF316D

Publication No: 5995416905 FGF316D

09/04 2

BACKGUARD

FGF316D Publication No: 5995416905

# Functional Parts 3 09/04

* Non-Illustrated Parts

BACKGUARD

Model Index: AFGF316D (FGF316DSB)

BFGF316D (FGF316DQB)

POS. NO PART NO. DESCRIPTION

12 # 316032404 A B Thermostat

12* 316097602 A B Insulator

18 316263404 A - End Cap, white, RH

18 316263406 - B End Cap, bisque, RH

18A 316263405 A - End Cap, white, LH

18A 316263407 - B End Cap, bisque, LH

19 316263301 A - Panel, backguard, white

19 316263302 - B Panel, backguard, bisque

24 # 316118101 A - Switch, oven light, white, rocker

24 # 316118104 - B Switch, oven light, bisque, rocker

32 316102303 A - Knob, thermostat, white

32 316102329 - B Knob, thermostat, bisque

36 316009009 A - Knob, top valve, white, (4)

36 316102323 - B Knob, top valve, bisque, (4)

40 316201812 A - Panel, manifold, white

40 316201813 - B Panel, manifold, bisque

* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black

* 316021108 A B Screw, cup pt, 8-18 x 0.375, chrome

* 316021109 A B Screw, 8-18 x 0.5, chrome

* 316021110 A B Screw, 8-18 x 0.5, black

Publication No: 5995416905 FGF316D

09/04 4

BURNER

FGF316D Publication No: 5995416905

# Functional Parts 5 09/04

* Non-Illustrated Parts

BURNER

Model Index: AFGF316D (FGF316DSB)

BFGF316D (FGF316DQB)

POS. NO PART NO. DESCRIPTION

1 # 316269100 A B Pipe, manifold

2 # 5303935237 A B Valve, top burner, w/mtg screw

* 316215600 A B Screw, valve mtg., 1/4 - 20

3 316001830 A B Wiring Harness, w/igntr switch

8 # 316135700 A B Module, spark

10 # 316103800 A B Burner, top, front, venturi ring

10A# 316103801 A B Burner, top, rear, venturi ring

11A# 316081705 A B Ignitor, top burner, 50"

12 3016993 A B Retainer, ignitor

14 # 316091705 A B Regulator, pressure

14* 316021104 A B Screw, hex, 8-18 x 3/8, nick, (3), regulator brkt

17 # 3203459 A B Valve, safety

18 # 316114300 A B Burner, oven

19 # 5303935066 A B Ignitor, oven kit, w/nut & instr

20 3203265 A B Baffle, oven burner

21 5303013272 A B Nut, hex head sems

36 316065004 A B Tubing, 3/8, alum

48 3018603 A B Bracket, support, oven burner

49 3131438 A B Bracket, safety valve

* 5303271648 A B Screw, wafer hd sq dr, 8-18AB x 0.5

Publication No: 5995416905 FGF316D

09/04 6

BODY

FGF316D Publication No: 5995416905

# Functional Parts 7 09/04

* Non-Illustrated Parts

BODY

Model Index: AFGF316D (FGF316DSB)

BFGF316D (FGF316DQB)

POS. NO PART NO. DESCRIPTION

1 316029416 A B Panel, main back

3 316216402 A - Panel, bodyside, white, RH

3 316216403 A - Panel, bodyside, white, LH

3 316216406 - B Panel, bodyside, bisque, RH

3 316216407 - B Panel, bodyside, bisque, LH

3* 316021131 A - Screw, bodyside, 8-18 X 11/16, white

3* 316021133 - B Screw, bodyside, 8-18 X 11/16, bisque

4 316067210 A B Burner Box

5 316129200 A B Screw, leveling, plastic, with stop

6 316067902 A B Rack, oven

7 316216508 A B Hinge, oven door, RH

7A 316216509 A B Hinge, oven door, LH

8 5303300701 A B Panel, oven bottom

8* 316064600 A B Support, oven bottom

14 316116400 A B Receptacle, oven light

15 5303013071 A B Bulb/Lamp, oven light

21 3014099 A B Spacer, bodyside

27 5303284616 A B Clip, thermo bulb mtg

32 316107501 A B Channel, burner support

32* 5303289684 A B Fastener, tanden wire, (2)

33 316055600 A B Shield, spark module, galv steel

34 3018607 A B Plate, cover

35 316116600 A B Gasket, flue

36 316204401 A B Flue, black

39 3202006 A B Cord, electric power

41 316233400 A B Cover, hinge cutout, RH

41A 316233500 A B Cover, hinge cutout, LH

43 3131732 A B Screw, 8-18 x 1.438, oven bottom

54 5303271606 A B Housing, oven light

58A 3017142 A B Insulation, oven wrapper

58B 316054202 A B Insulation, 1", oven back

73 316109902 A B Base, low broil

93 316110000 A B Shield, ignitor, metal

170 5303935180 A B Anti-tip Kit, w/bracket, screw

170* 316107200 A B Bracket, anti-tip

170* 316112500 A B Template, anti-tip

170* 316116000 A B Screw, concrete, 1.75", anti-tip brkt

185 316112900 A B Shield, thermo bulb

* 316246400 A B Plug, button, oven probe

* 316249100 A B Plate-weight, (3)

* 5303305324 A - Paint, touch-up, white

* 5304414035 - B Paint, touch-up, bisque

* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black

* 316021108 A B Screw, cup pt, 8-18 x 0.375, chrome

* 316021110 A B Screw, 8-18 x 0.5, black

* 316089500 A B Screw, 10-16 x .486

* 5303271648 A B Screw, wafer hd sq dr, 8-18AB x 0.5

* 5303280311 A B Screw, wafer hd sq dr, 10-32 x 0.312

* 5303285179 A B Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995416905 FGF316D

09/04 8

TOP/DRAWER

FGF316D Publication No: 5995416905

# Functional Parts 9 09/04

* Non-Illustrated Parts

TOP/DRAWER

Model Index: AFGF316D (FGF316DSB)

BFGF316D (FGF316DQB)

POS. NO PART NO. DESCRIPTION

1 316110201 A B Carriage, low broil

2 316236401 A B Liner, low broil

2A 316110800 A B Shield, broiler

2B 316237600 A B Shield, low broil, top

4 316231211 A - Panel, drawer, white

4 316231214 - B Panel, drawer, bisque

5 316129100 A B Fastener, push-in nut, nylon, spacer

9 316081900 A B Pan, broiler

10 316082000 A B Insert, broiler pan

13 316111502 A B Glide, low broil, chassis

13A 316111600 A B Glide, low broil, inner

13B 316111501 A B Glide, low broil, outer

16 316273001 A - Main Top, white

16 316273003 - B Main Top, bisque

17 316066900 A B Rod, maintop support

18 08067747 A B Bracket, hinge, main top RH

18A 08067746 A B Bracket, hinge, main top LH

20 # 316277801 A B Grate, black, (4)

25 316104500 A B Cover, vent, chrome

39 316019511 A - Handle, drawer, white

39 316019513 - B Handle, drawer, bisque

85 316115600 A B Rack, low broil

* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black

* 316021108 A B Screw, cup pt, 8-18 x 0.375, chrome

* 316021109 A B Screw, 8-18 x 0.5, chrome

* 316021110 A B Screw, 8-18 x 0.5, black

* 316021120 A B Screw, shoulder head, 8-18 x 5/8, (2), square drive

* 5303280311 A B Screw, wafer hd sq dr, 10-32 x 0.312

Publication No: 5995416905 FGF316D

09/04 10

DOOR
