FACTORY PARTS CATALOG

ELECTRIC RANGE

P.O. Box 212378

Augusta, Georgia 30917

PRODUCT NO. BASE MODEL NO. COLOR MARKET

FEF365BGWC FEF365BG WHITE USA

FEF365BGDC FEF365BG ALMOND USA

FEF365CGSC FEF365CG WHITE/WHITE USA

FEF365CGBC FEF365CG BLACK/BLACK USA

Publication No.

5995315404

980731

-EN/SERVICE /VLM

369

WIRING DIAGRAM # - 316002662

OWNER’S GUIDE # - 316000268

INSTALLATION GUIDE # - 316003025 ELECTRIC - RANGE

FEF365BGWC

FEF365BGDC

FEF365CGSC

FEF365CGBC

01/98 2

Publication number

5995315404 FEF365BGDC, FEF365BGWC, FEF365CGSC, FEF365CGBC

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

# - Fast Moving Parts

* - Non Illustrated Parts 3 6/98

Publication number

FEF365BGDC, FEF365BGWC, FEF365CGSC, FEF365CGBC 5995315404

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

A = FEF365BG (FEF365BGWC)

B = FEF365BG (FEF365BGDC)

C = FEF365CG (FEF365CGSC)

D = FEF365CG (FEF365CGBC)

POS. NO PART NO DESCRIPTION

* 316021108 A B C D Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316021110 A B C D Screw-8-18x1/2 Tr Sqd black

* 316071902 A B C D Gasket-edge

* 316085600 A B C D Insulator-shield thermostt

* 316112500 A B C D Template, Anti-tip bracket

1 316081601 A B C D Shield-backguard,rear wall

2 316015905 A B C D Shield-backguard,inner

11 316061851 A B - D Trim-wrapper,textured ,black

11 316061852 - - C - Trim-wrapper,textured ,white

11 316083719 A B - D Trim-wrapper,textured ,black

11 316083721 - - C - Trim-wrapper,, textured , white

14 316022504 A B C D Light-indicator

15 316023108 A B C D Support-backguard,RH

15A 316023109 A B C D Support-backguard,LH

19 316100534 A B - D Panel-control,metal ,black

19 316100535 - - C - Panel-backguard, white,white

20 # 316101001 A B C D Clock/Timer,electronic

20* 316101502 - - C - Overlay-clock

20* 316101503 A B - D Overlay-clock

23 316100300 A B C D Bracket-clock mtg

24 # 316005602 A B - D Switch-rocker,oven light ,black

24 # 316005607 - - C - Switch-rocker,oven light ,white

36 316025106 - - C - Knob-control,infinite sw ,white

36 316025108 A B - D Knob-control, infinite sw, black

40 316025800 A B - D Panel-manifold

40 316025808 - - C - Panel-manifold,white

46 316040201 A B C D Lens-light/lamp,indicator ,red

54 # 316021500 A B C D Switch-infinite, 6" element

54A# 316021501 A B C D Switch-infinite, 8" element

69 5303292005 A B C D Screw-switch mtg,8-32 x 5/32

01/98 4

Publication number

5995315404 FEF365BGDC, FEF365BGWC, FEF365CGSC, FEF365CGBC

CAUTION: Use the part number on all orders, not the position number.

BODY

# - Fast Moving Parts

* - Non Illustrated Parts 5 01/98

Publication number

FEF365BGDC, FEF365BGWC, FEF365CGSC, FEF365CGBC 5995315404

CAUTION: Use the part number on all orders, not the position number.

BODY

A = FEF365BG (FEF365BGWC)

B = FEF365BG (FEF365BGDC)

C = FEF365CG (FEF365CGSC)

D = FEF365CG (FEF365CGBC)

POS. NO PART NO DESCRIPTION

* 3203550 A B C D Plug-button

* 316021108 A B C D Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316045000 A B C D Clip-wire,harness ,main top

* 316101600 A B C D Shield-vent,smoothtop

* 5303051099 A B C D Nut,hex ,#10-32

1 316080804 A B C D Back-main, short,dipped ,black

3 316081034 A - C - Panel-bodyside,white ,RH

3 316081035 A - C - Panel-bodyside,white ,LH

3 316081036 - B - - Panel-bodyside,almond ,RH

3 316081037 - B - - Panel-bodyside,almond ,LH

3 316081038 ---D Bodyside-Panel RH, textured

3 316081039 ---D Bodyside-Panel LH, textured

5 316107300 A B C D Screw-leveling

6 316067902 A B C D Rack-oven

7 316007002 A B C D Hinge-oven door,(2)

8 3203540 A B C D Panel-oven bottom

9 316073800 A B C D Pan-broiler

10 3205234 A B C D Insert-broiler pan

12 # 316027701 A B C D Switch-oven light

13 316026800 A B C D Rod-light switch /door

14 316116400 A B C D Socket-light

15 5303013071 A B C D Light Bulb/Lamp

16 08011086 A B C D Lens-light/lamp,glass ,oven

17 316087500 A B C D Retainer-lens

18 # 316036300 A B C D Latch-door

21 3014099 A B C D Spacer-bodyside,(8)

25 3200848 A B C D Shield-heat,lower

29 3051162 A B C D Glide-drawer,front

30 5303283574 A B C D Bracket-hinge,main top RH

30A 5303283575 A B C D Bracket-hinge,main top LH

37 # 316111200 A B C D Probe-oven temp

41 3131570 A B C D Cover-hinge cutout

44 3131903 A B C D Bumper-door/drawer,rubber

45 316066100 A B C D Shield-wire, s/t vent

57 316081101 A B C D Cover-access

58 3200847 A B C D Insulation,oven bottom

58A 316047708 A B C D Insulation,oven wrapper

58B 316054200 A B C D Insulation,oven back

59 316073602 A B C D Tube-oven vent

59A 316023601 A B C D Tube-oven vent,upper

59B 316040100 A B C D Bracket-mounting,vent tube

62 # 5303935061 A B C D Terminal Block

63 5301145190 A B C D Plate-ground strap

66 # 5303051140 A B C D Element-broil

67 # 316075102 A B C D Element-bake,lower oven

68 316075300 A B C D Support-element, broil

71 316015805 A B C D Shield-rear wall

72 5303285692 A B C D Cover-light/switch rod

82 5303289913 A B C D Shield-insulation

01/98 6

Publication number

5995315404 FEF365BGDC, FEF365BGWC, FEF365CGSC, FEF365CGBC

CAUTION: Use the part number on all orders, not the position number.

BODY

# - Fast Moving Parts

* - Non Illustrated Parts 7 01/98

Publication number

FEF365BGDC, FEF365BGWC, FEF365CGSC, FEF365CGBC 5995315404

CAUTION: Use the part number on all orders, not the position number.

BODY

87 316081200 A B C D Bracket-cable mtg

88 316026400 A B C D Rod-latch,auto

89 # 316028101 A B C D Motor-latch/lock

170 316107200 A B C D Anti-tip bracket

170* 316116000 A B C D Screw-Anti tip, 1.75" concrete

01/98 8

Publication number

5995315404 FEF365BGDC, FEF365BGWC, FEF365CGSC, FEF365CGBC

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

# - Fast Moving Parts

* - Non Illustrated Parts 9 01/98

Publication number

FEF365BGDC, FEF365BGWC, FEF365CGSC, FEF365CGBC 5995315404

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

A = FEF365BG (FEF365BGWC)

B = FEF365BG (FEF365BGDC)

C = FEF365CG (FEF365CGSC)

D = FEF365CG (FEF365CGBC)

POS. NO PART NO DESCRIPTION

* 316021108 A B C D Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316021110 A B C D Screw-8-18x1/2 Tr Sqd black

* 316021112 A - C - Screw-8-18x1/2 Tr Sqd White

* 316021113 - B - - Screw-8-18x1/2 Tr Sqd Almond

* 316045000 A B C D Clip-wire,harness ,main top

* 316089600 A B C D Spacer-drawer,(2)

* 5303280311 A B C D Screw,waf hd sdr ,10-32 x 5/16 ,(2)

* 5309951550 A B C D Cleaner-cooktop

1 316011501 A B C D Drawer-utility

2 3131975 A B C D Shield-panel

4 316084405 A - C - Panel-drawer,white

4 316084406 - B - - Panel-drawer,almond

4 316084407 ---D Panel-drawer,black

4* 08067785 - B - - Screw,hex washer head ,8-18AB x 1/2

7 3051163 A B C D Glide-drawer,rear

10 5303280308 A B C D Screw-handle mtg,wafer head ,10-24T x 2

15 316010204 A B C D Element-surface,radiant ,

large/8 inch/RF,2100W ,(2) ,

limit sw incl

15B# 316010203 A B C D Element-surface,radiant ,small/6 inch ,

1200W,(2) ,limit sw incl

16 316098103 A - - - Main Top,white

16 316098104 - B - - Main Top,smooth top ,almond

16 316098105 - - C - Main Top,white

16 316098137 ---D Maintop, smoothtop,black

18 5303273062 A B C D Hinge-main top,RH

18A 5303273063 A B C D Hinge-main top,LH

26 316099101 A B C D Channel-support,element ,(2)

26A 316099201 A B C D Bracket-support, chassis

44 3131903 A B C D Bumper-door/drawer,rubber

48 316100200 A B C D Shield-wire,main top

51 80142193 A B C D Indicator light

52 316099400 A B C D Clip-spring, element mtg,(8)

53 316099300 A B C D Bracket-indicator light,hot surface ,

4 hole

60 316021105 A B C D Screw,hex ,8-18 x 3/8 ,back\bodyside

88 316099500 A B C D Pin-guide,(2)

01/98 10

Publication number

5995315404 FEF365BGDC, FEF365BGWC, FEF365CGSC, FEF365CGBC

CAUTION: Use the part number on all orders, not the position number.

DOOR
