MCIMX6Q-SDP

NXP SEMICONDUCTORS

Buy Now

Quick Start Guide

SABRE Platform for Smart Devices

Based on the i.MX 6 Series

Quick Start Guide

About the SABRE Platform for Smart Devices

Based on the i.MX 6 Series

The Smart Application Blueprint for Rapid

Engineering (SABRE) platform for smart

devices is the latest in a series of high-

performance, highly integrated development

kits from Freescale that introduce designers

to market-focused uses of the i.MX 6 series

applications processor.

The SABRE platform for smart devices can

be targeted towards any device requiring

an intelligent display, connectivity, low

power consumption and an amazing

user experience, and comes equipped

with either an i.MX 6Quad applications

processor or an i.MX 6DualLite applications

processor. Included with the design are

links to the hardware design files, tools and

board support packages (BSP) for Linux

and Android

™

along with bootable Android

image on an SD card to get you up and

running quickly.

freescale.com

The following features are available with

the SABRE platform for smart devices

based on the i.MX 6 series:

• i.MX 6Quad applications processor

1 GHz or i.MX 6DualLite applications

processor 1 GHz

• 1 GB DDR3 533 MHz

• 10" LVDS display panel with capacitive

touch screen

• 8 GB eMMC iNAND

• Two SD card slots

• SATA 22-pin connector

• HDMI connector

• Secondary LVDS connector

• LCD expansion port connector

• EPDC expansion port connector

• Two five-megapixel cameras

• Two 3.5 mm audio ports

(stereo HP and microphone)

• Two board-mounted

digital microphones

• External stereo speakers

• 4 MB SPI NOR flash

• USB OTG connector

• Debug out via USB µAB

device connector

• Gigabit Ethernet connector

• JTAG 20-pin connector

• mPCIe connector

• GPS module with antenna

• Sensor package including:

3-axis accelerometer

Digital compass

Ambient light sensor

Quick Start Guide

Get to Know SABRE Platform for

Smart Devices Based on the i.MX 6 Series

External Speakers

U17–Ambient Light

Sensor

GPS Antenna

U19–GPS Module

J11–MIPI Display

Connector

CON2–DC Battery Connector

J5–MIPI Camera Connector

U14–SPI NOR Flash

No Manual SD Switch

On SDP

freescale.com

P1–DC Power Connector

CON1–SIM Card

Connector

J1–Mini PCIe Connector

SW2–Board Reset Button

J7–Ethernet Connector

J9–DVP Camera Connector

U18–Accelerometer

U20–eCompass

J2–Headphone Output Jack

J4–Microphone Input Jack

SW1–Optional Power Button

SW4–Volume Up Button

SW5–Volume Down Button

J6–JTAG Connector

J8–HDMI Connector

SW6-Boot Mode

Selector Switch

J13–Bluetooth®

Cable Connector

Quick Start Guide

J504–LCD Expansion

Port Connector

J506–22-Pin SATA

Connector

J502–LVDS1

Connector

J503–LVDS0 Connector

BT500–Lithium

Coin Cell Connector

CON500–External

Speaker Connector

J509–Serial-To-USB

Debug Port

J508–EPDC Expansion

Port Connector

J507–SD3

Card Socket

J500–SD2 AUX

SDIO Socket

J505–Micro USB

Connector

freescale.com

Getting Started

This section describes how to use the SABRE platform for smart devices board and kit

components. This section also describes the PC requirements to develop applications

using the platform.

Item Description

Smart device platform Main board, LVDS display and speaker board, pre-assembled

Cable USB cable (micro-B to standard-A)

Power Supply 5 V/5 A universal power supply

Documentation Quick Start Guide (this document)

8 GB SD card Bootable demonstration code for smart device platform

Development Kit Contents

1Unpacking

the Kit

The SABRE platform for smart devices is shipped with the items listed in Table 1. Ensure

the items listed in Table 1 are available in the i.MX 6 series development kit. Remove the

platform from the antistatic bag and perform a visual inspection.

Table 1: SABRE Platform for Smart Devices Based on i.MX 6 Series Development Kit Contents

Quick Start Guide

“Jump Start Your Design” Contents

Download Software

and Tools

Download installation software and documentation under

“Jump Start Your Design” at freescale.com/SABRESDP.

Table 2 lists the documents available on the kit website.

Item Description

SABRE platform for smart

devices documentation

• Schematics, layout and Gerber files

• SABRE Platform for Smart Devices Based on the

i.MX 6 Series Quick Start Guide (this document)

Software development tools Android and Linux BSPs

SABRE platform for smart

devices demo images Copy of the Android image provided on the SD card

Table 2: “Jump Start Your Design” Contents

Getting Started

freescale.com

Setting Up the System

1Insert

SD Card

Insert the supplied SD card into socket

SD3.

2Connect USB

Debug Cable (Optional)

Connect the micro-B end of the supplied

USB cable into debug port J509. Connect

the other end of the cable to a PC acting

as a host terminal. If needed, the serial-

to-USB drivers can be found at

ftdichip.com/FTDrivers.htm.

Terminal window configuration: 115.2

kbaud, 8 data bits, 1 stop bit, no parity.

3Connect Ethernet

Cable (Optional)

Connect an Ethernet cable to the Ethernet

jack J7.

4Connect

Power Supply

Connect the 5 V power supply cable to

the 5 V DC power jack P1. When power

is connected to the smart device, it will

automatically begin the boot sequence.
