Flycam FLCM-FLN-CH Manual de usuario

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Assem bly Manual

Flycam Quick Release Camera Hook

with 4 x Ball Studs (1/4”-20) & (3/8”-16)

Quick Release Camera Hook for Flycam Flowline

Body Support Rigs (FLCM-FLN-CH)

• Similarly, remove the second screw.

• Now, remove the Hook from the Flowline

Support Arm.

• As shown in the image, take the Cord

bundle out from the Cup and pull the Cord

unl a Cord lock comes out.

• Separate the Cord and the Cord lock.

• Keep the lock aside to re-aach it later.

• Insert the Ball Stud in the quick-release

Camera Hook, as shown in the image.

NOTE: Quick-release catch is secured to the

Ball Stud.

Camera Hook Setup

• Loosen the screw of the Camera Hook

aached to the Flowline Support Arm

(Not Included) using an Allen key.

• Similarly, separate the Cord from the Cup to

mount it back later.

• Properly aach the Cord to the Quick

release Camera.

• Aer aaching the Cord, properly e it to

the Cap.

NOTE: The quick-release head is aached to

the Rig's Suspension Cable.

• Insert the Ball stud in the Camera by

properly matching its thread.

NOTE: The Hook has a quick-release head and

four-ball studs that can be mounted on

almost any Camera, Cage, or Rig with 1/4"-20

or 3/8"-16 threads on top.

NOTE: It has a thumbscrew that ensures a

solid connecon for your Rig.

• The standard Camera hook by Flycam is

universal and can be used on any Camera.

• Remove the Cap from the Quick-release

Camera Hook.

• Insert the Cord into the Cap.

• Aer inserng the Ball stud, aach the

quick-release Camera hook to the Ball Stud.

NOTE: Solid and secure aachment via

thumbscrew.

YOUR PROAIM QUICK RELEASE CAMERA HOOK FOR FLYCAM

FLOWLINE BODY SUPPORT RIGS

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
