Fluke 726 Guía de configuración

Manual Supplement

Manual Title: 726 Users Supplement Issue: 2

Print Date: September 2005 Issue Date: 3/08

Revision/Date: Page Count: 6

This supplement contains information necessary to ensure the accuracy of the

above manual. This manual is distributed as an electronic manual on the

following CD-ROM:

CD Title: 725/726

CD Rev. & Date: 4, 9/2005

CD PN: 1549615

726 Users Manual Supplement

3/07 1

Change #1

On page 2, replace the Pulse row with the following:

Pulse 1-100,000

Frequency Max 15 kHz

1-10,000

Frequency Range 2 CPM to 15 kHz

On page 12, Table 4, replace the Description for Number Lwith the following:

Cycles through:

ESlow repeating 0 % - 100 % - 0 % ramp

PConfigurable repeating 0 % - 100 % - 0% ramp

NConfigurable repeating 0 % - 100 % - 0 % ramp in 25 % steps

LUsed for the pulse train and totalizer functions.

On page 13, replace Figure 4 with the following:

Manual Supplement 726 Users

2 3/07

Low Battery

Symbol

Loop

Indicator

Memory Locations

for Calibrator Setups

Units

Display

Auto

Ramp

Mode

Indicator

HART Mode

Indicator

% Error

Indicators

Figure 4. Elements of a Typical Display

726 Users Manual Supplement

3/07 3

On page 14, under Configuration Menus, add the following under the last bullet:

•Step time

•Ramp time

On page 15, under Shut Down Mode, replace numbered steps with the following:

1. Press Cuntil SHUT DOWN appears on the display.

2. Use Xand Wto increase or decrease the time.

3. Use Yand Zto turn on and off.

4. Press Sto save the setting.

On page 16, under Hart®Resistor ON/OFF, replace step 2 with the following:

2. Use Vor Yand Zto toggle ON and OFF.

Add the following below the Note:

Step Time

Step Time sets the ramp step Ntime from 1 sec to 99 sec.

1. Press Cuntil STEP TIME appears on the display.

2. Use Xand Wto set the step time.

3. Press Sto save the setting.

Manual Supplement 726 Users

4 3/07

Ramp Time

Ramp Time sets the ramp Ptime from 5 sec to 99 sec.

1. Press Cuntil RAMP TIME appears on the display.

2. Use Xand Wto set the ramp time.

3. Press Sto save the setting.

On page 25, Table 6, add the following:

Cu10 10 ΩCopper 0.0042 Ω/°C -100 to 250

On page 42, under Auto Ramping the Output, replace the 2nd and 3rd bullets with the following:

•P0 % - 100 % - 0 % configurable time smooth ramp. Set ramp time using configuration

menu.

•N0 % - 100 % - 0 % Stair-step ramp in 25 % steps, pausing at each step. Set ramp

time using configuration menu. Steps are listed in Table 7.

On page 60, under Frequency Measurement, add the following to the bottom of the table:

Sensitivity: 1 V peak to peak minimum

Waveform: Squarewave

726 Users Manual Supplement

3/07 5

On page 62, change the Range entries for “Thermocouple in mV read” and “Thermocouple in

mV source”:

From:

-10 °C to 75 °C

To: -10 mV to 75 mV

On page 63, under the RTD Accuacy (Read and Source) (ITRS-90) table, replace the CU10 row

with the following:

Cu10 -100.0 250.00 1.8

On page 64, under Pulse Read and Pulse Source, replace the Frequency entry with the

following:

2 CPM to 15 kHz

Manual Supplement 726 Users

6 3/08

Change #2

On page 7, Table 2, add the following:

;Conforms to Australian C-Tick directives
