FLASHFORGE 3D PRINTER Dreamer NX Manual de usuario

Dreamer NX User Guide | www.FlashForge.com

FlashForge Dreamer NX 3D Printer

User Guide

Dreamer NX User Guide | www.flashforge.com

Content

Content.......................................................................................................................... 3

Introduction....................................................................................................................5

Notice............................................................................................................................. 6

Chapter 1: 3D Printing Technology........................................................................... 9

1.1 Process............................................................................................................ 9

Chapter 2 . About Dreamer NX................................................................................11

2.1 About Your Dreamer NX............................................................................. 11

Chapter 3. Unpacking................................................................................................15

Chapter 4 . Hardware Assembly..............................................................................18

4.1 Mounting the Extruder Set.......................................................................... 18

4.2 Installing Filament........................................................................................ 20

4.3 Plugging in Power Cable & USB Cable.................................................... 21

4.4 Loading and Unloading Filament...............................................................21

Chapter 5: Build Plate Leveling............................................................................... 24

Chapter 6: About Software....................................................................................... 27

6.1 Software Installation.....................................................................................27

6.2 Exploring FlashPrint.....................................................................................28

Chapter 7: Basic Printing.......................................................................................... 52

7.1 Single-Extrusion and Dual-Extrusion Print...............................................52

7.2 Methods of printing.......................................................................................59

7.3 Printer password lock.................................................................................. 62

Chapter 8: Supports and Service............................................................................ 65

Dreamer NX User Guide | www.flashforge.com

Preface

Note: Each device must be tested before leaving factory. If there are some

residues in extruder or some tiny scratches on the build tape, it is normal and

won’t affect the printing quality.

On the completion of this User Guide, thanks all FlashForge engineers and the

FlashForge 3D printer users for their unremitting efforts and sincere

assistance.

The FlashForge Dreamer NXUser Guide is designed for the Dreamer NXusers

to start their printing journey with FlashForge Dreamer. Even if you are familiar

with earlier FlashForge machines or 3D printing technology, we still

recommend that you read through this guide, as there is lots of important

information about the Dreamer NXfor you to get a better 3D experience.

For a better and more successful printing experience, you

can refer to the following materials:

(1) Quick Start Guide

Users will find the Quick Start Guide together with the printer accessories. The

Quick Start Guide will help you start your print journey as soon as possible.

(2) Official FlashForge Website:http://www.flashforge.com

The official FlashForge website contains the up-to-date information concerning

FlashForge software, firmware, device maintenance and so on. Users are also

able to get the contact information from there.

Dreamer NX User Guide | www.flashforge.com

Introduction

Notes：

The FlashForge Dreamer NX3D Printer User Guide contains the

information needed for you to set up and use this device.

This User Guide includes the following parts: Preface, Introduction and

After-sales service.

The Preface section includes resource acquisition channel, the overall

framework of the manual, and the problems that should be paid attention to.

The introduction section contains the presentation of 3D printing

technology, equipment introduction, unpacking and installation of equipment,

software installation and usage.

After-sales section covers how to get the support and help.

·Please read

FlashForge Dreamer NX 3D Printer User Guide

carefully before use.

·The User Guide is written based on Windows 7 OS.

·The version of the FlashPrint is the latest.

Dreamer NX User Guide | www.flashforge.com

Notice

Safety Notice

! Notices: Read all the instructions in the manual and familiarize yourself with

the FlashForge Dreamer NXUser Guide before setting-up and using. Failure to

comply with the warning and instructions may result in individual injury, fire,

equipment damage or property damage.

PLEASE STRICTLY FOLLOW ALL THE SAFETY WARNINGS AND NOTICE

BELOW ALL THE TIME.

· Work Environment Safety

①Keep your work place tidy.

②Do not operate Dreamer NXin the presence of flammable liquids, gases or

dust.

③Dreamer NXshould be placed out of children and untrained people's reach.

· Electricity Safety

①Always use the Dreamer NXwith a properly grounded outlet. Do not refit

Dreamer’s plug.

②Do not use Dreamer NXin damp or wet locations. Do not expose Dreamer

NXto burning sun.

③In case of device damage, please use the power supply provided by

FlashForge.

④Avoid using the device during an thunderstorm.

⑤In case of uncertain accident, please unplug the device if you do not use it

for long time

Dreamer NX User Guide | www.flashforge.com

·Personal Safety

①Do not touch the nozzle and build plate during printing.

②Do not touch the nozzle after finishing printing.

③Dress properly. Do not wear loose clothing or jewelry. Keep your hair,

clothing and gloves away from moving parts.

④Do not operate the device while you are tired or under the influence of drugs,

alcohol or medication.

· Cautions

①Do not leave the device unattended for long.

②Do not make any modifications to the device.

③To lower the build plate before loading/unloading filament. (The distance

between the nozzle and build plate should be kept for at least 50mm)

④Operate the device in a well-ventilated environment.

⑤Never use the device for illegal activities.

⑥Never use the device to make any food storage vessels.

⑦Never use the device to make any electrical appliance.

⑧Never put the model into your mouth.

⑨Do not remove the models with force.

· Environment Requirements

Temperature: RT 15-30℃

Moisture: 20%-70%

· Place Requirements

The device must be placed in a dry and ventilated environment. The distances

of the left, right and back side space should be at least 20cm, and the distance

Dreamer NX User Guide | www.flashforge.com

of the front side space should be at least 35cm.

· Filament Requirements

Do not abuse the filament. Please make sure you use the FlashForge filament

or the filament from the brands recommened by FlashForge.

· Filament Storage

All polymers will be degraded with time. Do not unpack until filament is needed.

Filament should be stored in clean and dry conditions.

Legal Notice

All the information in this document is subject to any amendment or change

without the official authorization from FlashForge.

FLASHFORGE MAKES NO WARRANTY OF ANY KIND WITH REGARD TO

THIS DOCUMENT, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED

WARRATIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE.

FlashForge shall not be liable for errors contained herein for incidental

consequential damages in connection with furnishing, performance or use of

this material

This document contains proprietary information protected by copyright.

Dreamer NX User Guide | www.flashforge.com

Chapter 1: 3D Printing Technology

3D printing refers to transforming three-dimensional models into physical

objects that you can hold and touch. It is also called additive manufacturing

because the 3D model is created by “adding” layers upon layers of material

until the object is fully formed.

Fused Filament Fabrication (FFF) is the most common method of 3D printing. It

is also the method that the Dreamer NX uses. It works by melting plastic

material called filament onto a print surface in high temperature. The filament

solidifies after it cools down, which happens instantaneously after it is extruded

from the nozzle. 3D objects are formed with the filament laying down multiple

layers.

1.1 Process

3D printing involves three steps:

1.) Make or download a 3D model

2.) Slice and export the 3D model

3.) Build the 3D model

1.1.1 Make a 3D Model

Currently, there are three ways of making a 3D model.

·Designing From Scratch You can use free CAD (computer-aided design)

software such as 3DTADA, AutoCAD, SolidWorks, Pro-E, and our own

software Happy 3D, which is suitable for the beginners, to design your own 3D

model.

Dreamer NX User Guide | www.flashforge.com

·3D Scanners An alternative method to making a 3D model is to scan an

object. 3D scanners work by digitizing a physical object, collecting its geometric

data, and saving it to a file on your PC. There are also apps that can turn a

mobile device into a 3D scanner.

·From the Cloud The most popular way of obtaining a 3D model is to

download it from websites that allow users to upload 3D models that they

designed.

FlashCloud: cloud.sz3dp.com/

E.g. www. thingiverse.com

1.1.2 Slice and Export the 3D Model

Slice software is the software that prepares 3D models for printing and turns

them into instructions for the 3D printers. FlashPrint is the slicing software used

for the FlashForge Dreamer NX.

Using FlashPrint, you can prepare a. stl files to be .g or .gx files for printing.

Then the files can be transferred to your Dreamer NX via USB cable, USB stick

or Wi-Fi.

1.1.3 Build the 3D Model

Once the output file has been transferred to your Dreamer NX, it will start to

turn the 3D model into a physical object by laying down layers of filament.

Dreamer NX User Guide | www.flashforge.com

Chapter 2 . About Dreamer NX

2.1 About Your Dreamer NX

2.1.1 Main view:

1. Lid

2. Extruder fan

3. Nozzle

4. Front Door

5. Build plate

6. Z axis guide rod

7. Touch screen

8. X axis guide rod

9. Timing belt

10. Spring presser

11. Turbofan

12. Filament intake

13. Side panel

14. Reset button

15. SD card slot

16. USB cable input

17. Power switch

18. Power input

Tabla de contenidos

Otros manuales de Impresora 3D de FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Focus 8.9 Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Creator Guía del usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER EN-A01 Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Adventurer 4 Series Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Foto 8.9s Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER finder Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Creator 3 Pro Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Guider2S Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Creator Pro Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER inventor Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Hunter Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Adventurer 4 Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Inventor II S Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Adventurer 3 Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Guider IIS Series Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER inventor Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Creator Pro Guía del usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER GUIDER 3 PLUS Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Creator X Guía del usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER CREATOR PRO 2 Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER finder Manual de usuario

Manuales populares de Impresora 3D de otras marcas

Ultimaker

Ultimaker S5 Material Station Manual de usuario

EcubMaker

EcubMaker TOYDIY Manual de usuario

AnyCubic

AnyCubic Kossel Plus Manual de usuario

ReDeTec

ReDeTec ProtoCycler Manual de usuario

Kywoo3D

Kywoo3D Tycoon IDEX Manual de usuario

CraftBot

CraftBot PLUS PRO Manual de usuario

3DGence

3DGence INDUSTRY F340 Manual de usuario

HP Jet Fusion 4200 Instrucciones de funcionamiento

Rokit

Rokit AEP Series Manual de usuario

AnkerMake

AnkerMake M5 Manual de usuario

DIYElectronics

DIYElectronics PRUSA I3 Instrucciones de montaje

Ackuretta

Ackuretta FreeShape 120 Manual de usuario

LONGER

LONGER LK5Pro Manual de usuario

Stratasys

Stratasys J850 Manual de usuario

MakerBot

MakerBot Replicator Manual de usuario

Stratasys

Stratasys FDM Vantage Series Manual de usuario

ZYYX

ZYYX Pro II Manual de usuario

LONGER

LONGER LK4 Pro Manual de usuario
