Extron electronics FOXBOX SR HDMI Manual de usuario

User Guide

FOXBOX SR HDMI

Fiber Optic Extenders

Fiber Optic Scaling Receiver for HDMI, Audio, and RS-232

68-1990-01 Rev. A

10 12

Safety Instructions • English

WARNING: This symbol, , when used on the product, is

intended to alert the user of the presence of uninsulated

dangerous voltage within the product’s enclosure that may

present a risk of electric shock.

ATTENTION: This symbol, , when used on the product, is

intended to alert the user of important operating and maintenance

(servicing) instructions in the literature provided with the

equipment.

For information on safety guidelines, regulatory compliances, EMI/EMF compatibility,

accessibility, and related topics, see the Extron Safety and Regulatory Compliance

Guide, part number 68-290-01, on the Extron website, www.extron.com.

Instructions de sécurité • Français

AVERTISSEMENT: Ce pictogramme, , lorsqu’il est utilisé sur le

produit, signale à l’utilisateur la présence à l’intérieur du boîtier

du produit d’une tension électrique dangereuse susceptible de

provoquer un choc électrique.

ATTENTION: Ce pictogramme, , lorsqu’il est utilisé sur le

produit, signale à l’utilisateur des instructions d’utilisation ou de

maintenance importantes qui se trouvent dans la documentation

fournie avec le matériel.

Pour en savoir plus sur les règles de sécurité, la conformité à la réglementation, la

compatibilité EMI/EMF, l’accessibilité, et autres sujets connexes, lisez les informations

de sécurité et de conformité Extron, réf. 68-290-01, sur le site Extron, www.extron.fr.

Sicherheitsanweisungen • Deutsch

WARNUNG:Dieses Symbol auf dem Produkt soll den

Benutzer darauf aufmerksam machen, dass im Inneren

des Gehäuses dieses Produktes gefährliche Spannungen

herrschen, die nicht isoliert sind und die einen elektrischen

Schlag verursachen können.

VORSICHT: Dieses Symbol auf dem Produkt soll dem Benutzer

in der im Lieferumfang enthaltenen Dokumentation besonders

wichtige Hinweise zur Bedienung und Wartung (Instandhaltung)

geben.

Weitere Informationen über die Sicherheitsrichtlinien, Produkthandhabung,

EMI/EMF-Kompatibilität, Zugänglichkeit und verwandte Themen finden Sie in den

Extron-Richtlinien für Sicherheit und Handhabung (Artikelnummer 68-290-01) auf

der Extron-Website, www.extron.de.

Instrucciones de seguridad • Español

ADVERTENCIA: Este símbolo, , cuando se utiliza en el

producto, avisa al usuario de la presencia de voltaje peligroso

sin aislar dentro del producto, lo que puede representar un

riesgo de descarga eléctrica.

ATENCIÓN: Este símbolo, , cuando se utiliza en el producto,

avisa al usuario de la presencia de importantes instrucciones

de uso y mantenimiento recogidas en la documentación

proporcionada con el equipo.

Para obtener información sobre directrices de seguridad, cumplimiento de

normativas, compatibilidad electromagnética, accesibilidad y temas relacionados,

consulte la Guía de cumplimiento de normativas y seguridad de Extron, referencia

68-290-01, en el sitio Web de Extron, www.extron.es.

Chinese Simplified（简体中文）

警告：产品上的这个标志意在警告用户该产品机壳内有暴露的危险

电压，有触电危险。

注意：产品上的这个标志意在提示用户设备随附的用户手册中有

重要的操作和维护(维修）说明。

关于我们产品的安全指南、遵循的规范、EMI/EMF 的兼容性、无障碍

使用的特性等相关内容，敬请访问 Extron 网站 www.extron.com，参见 Extron

安全规范指南，产品编号 68-290-01。

Chinese Traditional（繁體中文）

警告: 若產品上使用此符號，是為了提醒使用者，產品機殼內存在著

可能會導致觸電之風險的未絕緣危險電壓。

注意 若產品上使用此符號，是為了提醒使用者。

有關安全性指導方針、法規遵守、EMI/EMF 相容性、存取範圍和相關主題的詳細

資訊，請瀏覽 Extron 網站：www.extron.com，然後參閱《Extron 安全

性與法規遵守手冊》，準則編號 68-290-01。

Japanese

警告:この記号が製品上に表示されている場合は、筐体内に絶縁されて

いない高電圧が流れ、感電の危険があることを示しています。

注意:この記号が製品上に表示されている場合は、本機の取扱説明書に記載されてい

る重要な操作と保守(整備)の指示についてユーザーの注意を喚起するものです。

安全上のご注意、法令遵守、EMI/EMF適合性、その他の関連項目に

ついては、エクストロンのウェブサイト www.extron.comより

『Extron Safety and Regulatory Compliance Guide』 (P/N 68-290-01) をご覧ください。

Korean

경고: 이 기호 , 가 제품에 사용될 경우, 제품의 인클로저 내에 있는

접지되지 않은 위험한 전류로 인해 사용자가 감전될 위험이 있음을

경고합니다.

주의: 이 기호 , 가 제품에 사용될 경우, 장비와 함께 제공된 책자에 나와

있는 주요 운영 및 유지보수(정비) 지침을 경고합니다.

안전 가이드라인, 규제 준수, EMI/EMF 호환성, 접근성, 그리고 관련

항목에 대한 자세한 내용은 Extron 웹 사이트(www.extron.com)의

Extron 안전 및 규제 준수 안내서, 68-290-01 조항을 참조하십시오.

FCC Class A Notice

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instruction guide, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is

likely to cause interference; the user must correct the interference at his own expense.

NOTE: This unit was tested with shielded I/O cables on the peripheral devices. Shielded

cables must be used to ensure compliance with FCC emissions limits.

For more information on safety guidelines, regulatory compliances,

EMI/EMF compatibility, accessibility, and related topics, see the “Extron Safety

and Regulatory Compliance Guide” on the Extron website.

Specifications Availability

Product specification are available on the Extron website, www.extron.com.

Conventions Used in this Guide

Notifications the following are used:

WARNING: A warning indicates a situation that has the potential to result in death or

severe injury.

ATTENTION: Attention indicates a situation that may damage or destroy the product or

associated equipment.

NOTE: A note draws attention to important information.

TIP: A tip provides a suggestion to make working with the application easier.

Software Commands

Commands are written in the fonts shown here:

^AR Merge Scene,,Op1 scene 1,1 ^B 51 ^W^C

[01] R 0004 00300 00400 00800 00600 [02] 35 [17] [03]

EX!*X1&*X2)*X2#*X2!CE}

NOTE: For commands and examples of computer or device responses mentioned

in this guide, the character “0” is used for the number zero and “O”

represents the capital letter “o.”

Computer responses and directory paths that do not have variables are written in the font

shown here:

Reply from 208.132.180.48: bytes=32 times=2ms TTL=32

C:\Program Files\Extron

Variables are written in slanted form as shown here:

ping xxx.xxx.xxx.xxx —t

SOH RData STX Command ETB ETX

Selectable items, such as menu names, menu options, buttons, tabs, and field names are

written in the font shown here:

From the File menu, select New.

Click the OK button.

Trademarks

All trademarks mentioned in this guide are the properties of their respective owners.

Contents

Introduction............................................................ 1

About this Guide ................................................ 1

About the FOXBOX SR HDMI .............................. 2

System Compatibility ...................................... 2

Cable Transmission Modes .............................. 3

Features.............................................................. 3

Installation.............................................................. 4

Rear Panel Features............................................. 4

Making Connections....................................... 7

Front Panel Configuration Port.......................... 11

Operation.............................................................. 12

Front Panel Indications and Controls ................. 12

Operation ......................................................... 13

Menu System Overview................................. 13

Menu and Submenus.................................... 14

Remote Control ................................................... 20

Simple Instruction Set Control........................... 20

Host-to-Unit Instructions............................... 20

Symbol Definitions........................................ 21

Unit-initiated Messages................................. 22

Error Responses............................................. 22

Using the Command and Response Table...... 22

Signal Processing Product Control Program ....... 27

Installing the Software .................................. 27

Starting the Program..................................... 27

Firmware Upgrade ........................................ 32

Reference Information....................................... 36

Part Numbers.................................................... 36

FOXBOX SR HDMI Part Numbers................... 36

Included Parts ............................................... 36

Mounting Accessories................................... 37

Cables .......................................................... 37

Adapters....................................................... 37

Mounting the Unit............................................ 38

Tabletop Use................................................. 38

Mounting ..................................................... 38

FOXBOX SR HDMI • Contents v

FOXBOX SR HDMI • Contents vi

Introduction

WARNING: Risk of eye injury: The FOXBOX SR HDMI outputs continuous invisible

light, which may be harmful to the eyes; use with caution.

•Do not look into the rear panel fiber optic cable connectors or into the

fiber optic cables themselves while the receiver is powered on.

•Plug the attached dust caps into the optical transceivers when the fiber

cable is unplugged.

• About this Guide

• About the FOXBOX SR HDMI

• Features

About this Guide

This guide contains information about the ultra-high performance Extron

FOXBOX SR HDMI scaling fiber optic receiver (see figure 1).

12V

1.0A MAX

POWER

LINK

OPTICAL

RxTx

OFF

LINK

HDMI AUDIO

HDMI

AUDIO

OUTPUTS

REMOTE

RS-232

Tx Rx

RS-232

OVER FIBER ALARM

Tx Rx 1 2

L R

FOXBOX Rx HDMI

12V

1.0A MAX

POWER

FOXBOX Tx HDMI

AUDIO INPUT

RS-232

OVER FIBER ALARM

Tx Rx 1 2

HDMI

LINK

OPTICAL

RxTx

LINK

POWER

12V

3AMAX

OUTPUT

4/8

OHMS

INPUTS

REMOTE

VOL/MUTE

10V 50mA

MPA152

CUS

LISTED

17TT

AUDIO/VIDEO

APPARATUS

CLASS2 WIRING

DONOT GROUND

ORSHORT

SPEAKEROUTPUTS!

100

LINK

ACT

COM IR INPUT RELAY

TX RX

IPL250

OFF

DISPLAY

MUTE

SCREEN

DOWN

VCR

DVD

DOC

CAM

LAPTOP

TCP/IP

Extron

FOXBOX Tx HDMI

Fiber Optic Transmitter

Projector

Local Monitor

Up to 30 km (18.75 miles)

singlemode ber

SM Model

HDMI

HDMl

Extron

SI 26X

Two-way Ceiling

Speakers

Audio

Output

Extron

MPA 152

Mini Power

Amplier

Blu-ray Player

RS-232

TouchLink™

Control

System

Extron

FOXBOX SR HDMI

Fiber Optic Receiver

Figure 1. Typical FOXBOX SR HDMI Application

FOXBOX SR HDMI • Introduction 1

About the FOXBOX SR HDMI

The FOXBOX SR HDMI is an ultra-high performance scaling fiber optic receiver that accepts a

proprietary optical signal on a single LC connector from a compatible fiber optic transmitter

or daisy-chained receiver located up to 30 km (18 miles) away.

The receiver outputs a single link of HDMI video, digital audio (embedded in the HDMI

output), analog audio, and RS-232 serial commands. The receiver can scale its video output

to one of several resolutions and rates.

NOTE: For HDCP compliance:

• A FOXBOX SR HDMI receiver must be paired with a FOXBOX HDMI or

PowerCage FOX HDMI transmitter.

• You must connect both fiber optic cables between the transmitter and

receiver.

• A signal cannot be daisy-chained and retain HDCP compliance.

• The bidirectional Consumer Electronics Control (CEC) is not supported.

If the receiver is appropriately configured and has a second fiber optic cable installed, it also

can either:

• Receive an RS-232 return from a controlled device and send it to the transmitter via a

proprietary optical signal, or

• Output a daisy-chained signal to another receiver.

If either RS-232 return or daisy-chained communications are implemented, the receiver

outputs a proprietary signal on the second fiber optic cable carrying the signal.

For video resolutions up to 1600 x 1200, 1080p, or 1920 x 1200, the video output of the

receiver is a perfect, pixel-for-pixel recreation of the video signal input from the transmitter.

The single link of HDMI video output by a FOXBOX SR HDMI can be converted to DVI-D

video with the appropriate adapter.

The receiver has built-in color bars, crosshatch, grayscale, alternating pixels, and crop test

patterns, which are available under RS-232 Simple Instruction Set (SIS™) control, to assist in

setting up the display equipment and image and audio adjustments. The receiver has image,

audio, fiber light status, and lost-light alarm indicators.

System Compatibility

The FOXBOX SR HDMI receiver operates interchangeably with all HDMI, DVI, and VGA

transmitters in the Extron FOXBOX, PowerCage FOX, and FOX 500 families, including Plus

and non-Plus units.

NOTES: •Although the receiver can operate with non-HDMI transmitters, the video

output is not HDCP-compliant.

•The receiver is not compatible with the FOX AV, PowerCage FOX AV,

FOX 3G HD-SDI, PowerCage FOX 3G HD-SDI, and FOX 3G DVC transmitters.

FOXBOX SR HDMI • Introduction 2

Cable Transmission Modes

The receiver is further categorized by the type of fiber optic cable, multimode or singlemode,

which defines the effective range of transmission:

• Multimode (MM) — Long distance, up to 2 km (6,560 feet) (depending on the fiber

cable)

• Singlemode (SM) — Very long distance, up to 30 km (18.75 miles)

NOTE: The multimode and singlemode units are physically and functionally identical,

with the exception of the effective range of transmission. In this manual, any

reference applies to either transmission mode unless otherwise specified.

Features

Ultra high performance — The FOXBOX SR HDMI receives pixel-for-pixel HDMI or DVI-D

(with an adapter) video transmission, up to 1920 x 1200 at 60 Hz.

Video output — The receiver outputs a single link of HDMI video.

Compatible with the FOX Matrix Switchers, and FOX 500, FOXBOX, and

PowerCage FOX transmitters and receivers (with the exception of the FOX DA6,

FOX 2G, and FOX 3G HDSDI products)

Analog audio output — The receiver outputs balanced or unbalanced stereo audio on a

5-pole captive screw connector and digital audio embedded in the HDMI output.

Links monitoring — The receiver panel has indicators for monitoring image and audio

transmission and the fiber optic link.

Loss-of-light alarms — The receivers panel has discrete outputs that indicate if either of

the fiber optic links has suffered a loss of the light signal.

Signal Processing Product Control Program — For RS-232 remote control from a PC, the

Extron Signal Processing Product Control Program, which runs under Microsoft® Windows®,

provides a graphical interface with drag-and-drop, point-and-click operation.

Simple Instruction Set — The receiver uses SIS commandsfor easy remote control

operation.

Analog audio level — The analog audio output is at the consumer level (-10 dBV).

Auto Image™ — The auto imaging feature automatically sizes and centers the input to fill

the screen.

Upgradable firmware — The firmware that controls the operation of the receiver can be

upgraded in the field via an RS-232 link without taking the unit out of service. Firmware

upgrades are available for download on the Extron website, www.extron.com, and they

can be installed using the Signal Processing Product Control Program.

Memory presets — 30 memory presets are a time-saving feature that lets you store input

size and position settings relative to a specific input resolution. You can then recall those

settings, when needed, using the SIS or the control software.

LockIt™ HDMI Cable Lacing Bracket — The receiver includes a LockIt bracket to secure

the HDMI cable to the unit.

Rack mounting — The receiver is rack mountable in any conventional 19-inch wide rack,

using an Extron 9.5-inch or 6-inch deep rack shelf.

Power — The 100 VAC to 240 VAC, 50-60 Hz external power supply provides worldwide

power compatibility.

FOXBOX SR HDMI • Introduction 3

Installation

This sections details the installation of the FOXBOX SR HDMI, including:

• Rear Panel Features

• Front Panel Configuration Port

Rear Panel Features

FOXBOX SR HDMI

LINK

OPTICAL

RxTx

HDMI

AUDIO

OUTPUTS

REMOTE

RS-232

Tx Rx

RS-232

OVER FIBER ALARM

Tx Rx 1 2

POWER

12V

1.0 A MAX LR

OFF

HDMI AUDIO

143 28 5 76

Figure 2. FOXBOX SR HDMI Scaling Receiver Rear Panel Features

aFiber optic connectors and LEDs —

WARNING: Risk of eye injury: The FOXBOX SR HDMI outputs continuous

invisible light, which may be harmful to the eyes; use with caution.

•Do not look into the rear panel fiber optic cable connectors or into

the fiber optic cables themselves while the receiver is powered on.

•Plug the attached dust caps into the optical transceivers when the

fiber cable is unplugged.

NOTE: You can connect the transmitter to one or more receivers in one of three

ways:

• One-way (transmitter Tx to receiver Rx) only — Connect fiber cable

Äfrom the transmitter Tx connector only.

• Two-way (transmitter to receiver and return) — Connect fiber

cable Äfrom the transmitter Tx connector and fiber cable Åback to

the transmitter Rx connector (see figure 3).

• One-way (transmitter to receiver) with daisy

chain (receiver to receiver) — Connect fiber

cable Äfrom a fiber optic source and cable Åto

the next receiver in the daisy chain (see figure 4).

Set each receiver in the daisy chain to daisy chain

mode. Up to 10 properly-configured receivers can be

connected in a daisy chain to a single transmitter.

FromTransmitter

or Daisy-Chained

Receiver

1a 1a

Tx Rx

Figure 4. Daisy Chain Configuration Figure 3. Two Way

Configuration

Transmitter

Receiver

1b 1a

Tx Rx

FOXBOX SR HDMI • Installation 4

Otros manuales para FOXBOX SR HDMI

Tabla de contenidos

Otros manuales de Receptor de Extron electronics

Extron electronics

Extron electronics MTP A/V Series Manual de usuario

Extron electronics

Extron electronics HDMI 201 Rx Manual de usuario

Extron electronics

Extron electronics XTP T HD 4K Manual de usuario

Extron electronics

Extron electronics TPT101 Manual de usuario

Extron electronics

Extron electronics MTP R 15HD RSA D Manual de usuario

Extron electronics

Extron electronics DTP3 T 202 Manual de usuario

Extron electronics

Extron electronics HFX 100 Tx Manual de usuario

Extron electronics

Extron electronics DTP DVI 230 Manual de usuario

Extron electronics

Extron electronics MTP U R A Manual de usuario

Extron electronics

Extron electronics DTP2 T 211 Manual de usuario

Extron electronics

Extron electronics Digital Video Transmitter and Receiver HDMI 201... Manual de usuario

Extron electronics

Extron electronics DFX 100 Tx Manual de usuario

Extron electronics

Extron electronics MTP R 15HD RSA D Manual de usuario

Extron electronics

Extron electronics PowerCage FOX SR HDMI Manual de usuario

Extron electronics

Extron electronics Fiber Optic Transmitters-Receivers FOX 2G Rx... Manual de usuario

Extron electronics

Extron electronics XTP FT HD 4K Manual de usuario

Extron electronics

Extron electronics VersaTools MTP T SV Manual de usuario

Extron electronics

Extron electronics TP Receiver Manual de usuario

Extron electronics

Extron electronics Digital Video Transmitter and Receiver DVI 201... Manual de usuario

Extron electronics

Extron electronics MTP/HDMI U R Manual de usuario

Extron electronics

Extron electronics FOXBOX DVI Plus Manual de usuario

Extron electronics

Extron electronics FOX II T DP 4K Manual de usuario

Extron electronics

Extron electronics Fiber Optic Transmitter-Receiver Pair FOX 500 DVI... Manual de usuario

Extron electronics

Extron electronics Dual Link DVI Transmitter and Receiver DVI DL 201... Manual de usuario

Manuales populares de Receptor de otras marcas

Garmin

Garmin GA 23 Manual de usuario

Aiphone

Aiphone PS-12F Manual de usuario

IMES

IMES TCS-01CA-PMI Manual de usuario

BWI Eagle

BWI Eagle AIR-EAGLE SR Manual

AMIMON

AMIMON AMN12310 WHDI Manual de usuario

Dual

Dual DMCPA79BT Instrucciones de funcionamiento

Sound Associates

Sound Associates SA652P Manual de usuario

Sherwood

Sherwood NewCastle R-772 Manual de usuario

Audio

Audio A10-RX Series Manual de usuario

AllSee

AllSee PushShare PSRV1.1 Manual de usuario

DEMAG

DEMAG DRC-DR D2 Manual de usuario

Teleco

Teleco TVRCL868A02 Manual de usuario

Bosch

Bosch RF3222E Manual de usuario

Kramer

Kramer 631R Manual de usuario

Xpress

Xpress xmc10 Manual de usuario

JVC

JVC KD-MR1BTS Manual de usuario

Omega Engineering

Omega Engineering UWTC-REC3 Manual de usuario

e-survey

e-survey E300 Pro Manual de usuario
