IMPORTANT:

Go to www.extron.com for the

complete user guide and installation

instructions befor

e connecting the

oduct to the power sou

rce.

www.extron.com

FPC 6000 • Setup Guide

Overview

The Extron FPC 6000 uses an Extron TLP Pro 1520M TouchLink®touchscreen to provide an intuitive 15-inch front panel controller for

Extron FOX®matrix switchers. The FPC 6000 is a stand-alone device that does not require an external controller. This guide provides

instructions for experienced installers to mount and install the touchpanel.

Setup Checklist

The FPC 6000 touchpanel ships with a Power over Ethernet power injector and a 7U high, 19-inch wide, rack-mountable metal panel.

When it ships, the touchpanel is already mounted in the panel

Get Ready

Obtain the following network information from your network administrator:

DHCP status — on or off. If DHCP is off, you must also obtain:

IP address for the FPC 6000 — by default, this is 192.168.254.251

Subnet mask for the FPC 6000 — by default, this is 255.255.255.0

Gateway for the FPC 6000 — by default, this is 0.0.0.0

User name for the FPC 6000 — by default, this is admin

Password for the FPC 6000 — by default, this is extron

IP address for the matrix switcher

Password for the matrix switcher

Mount and Cable All Devices

NOTE: The FPC 6000 ships with a PoE power injector. You can use a 12 VDC 3.0 A power supply instead, but that power supply

must be purchased separately.

ATTENTION:

• Do not power on the touchpanels or control processors until you have read the Attention in the “Rear Panel Features”

section of the FPC 6000 User Guide.

• Ne branchez pas les écrans tactiles ou les contrôleurs avant d’avoir lu la mise en garde dans la section «Rear Panel

Features » du FPC 6000UserGuide.

Choose a suitable location and mount the units. When the FPC 6000 ships it is already mounted in a 7U high, 19-inch wide, rack-

mountable metal panel. Secure the panel to any standard instrument rack or console (see Mounting on the next page).

A Power over Ethernet (PoE) power injector is provided with the FPC 6000. Connect the power injector to the FPC 6000 (see

ﬁgure 4 on page 4).

Connect the power injector to the LAN and power it on (see ﬁgure 4).

Set up the FPC 6000 for Network Communication

Use the Setup Menu (see page 4) to set the DHCP status and, if necessary, the IP address, subnet mask, gateway, and related

settings for the touchpanel.

The FPC 6000 requires no further conguration.

FPC 6000 • Setup Guide (Continued)

Mounting

Extron recommends mounting the FPC 6000 in a rack, using

the provided rack mounting panel. However, Wall Mounting

the FPC 6000 is another option.

ATTENTION:

• All structural steps and electrical installation must

be performed by qualied personnel in accordance

with local and national building codes and electrical

codes.

• Toute étape structurelle et installation électrique,

doit être effectuée par un personnel qualié,

conformément aux codes du bâtiment, aux codes

incendie et sécurité, et aux codes électriques,

locaux et nationaux.

1. When the FPC 6000 ships it is already mounted in a 7U

high, 19-inch wide, rack-mountable metal panel. Decide

where the FPC 6000 will be mounted.

2. Use the four provided rack-mounting screws to secure

the FPC 6000 to any standard equipment rack or control

console.

Follow the instructions in the Underwriters Laboratories

Guidelines for Rack Mounting (see the FPC 6000 User

Guide, available at www.extron.com) to ensure the rack

is mounted safely.

FPC 6000

#10-32 screws (4)

Figure 1. Rack Mounting the FPC 6000

Wall Mounting the FPC 6000

The FPC 6000 can also be wall-mounted, either using the Extron BB 700M wall box or directly into drywall. Some local building codes

require the touchpanel to be mounted in a wall box. To use the BB 700M, see the TLP Pro 1220MG, TLP Pro 1520MG, and TLP Pro

1720MG Setup Guide, at www.extron.com. If the wall box is not required by local building codes, you can mount the touchpanel

directly into drywall.

ATTENTION:

• Do not install the FPC 6000 in a re resistant rated wall or partition assembly.

• Ne pas installer le FPC 6000 dans un mur résistant au feu ou une cloison.

• All structural steps and electrical installation must be performed by qualied personnel in accordance with local and national

building codes and electrical codes.

• Toute étape structurelle et installation électrique, doit être effectuée par un personnel qualié, conformément aux codes du

bâtiment, aux codes incendie et sécurité, et aux codes électriques, locaux et nationaux.

Product Category

Front Panel Features

AABBCCDD

EFF GG

Figure 3. FPC 6000 Front Panel

gure 3

ACommunication LED — Lights briey when unit is

powered on. Otherwise no function.

BStatus Light — Lights briey when unit is powered on.

Otherwise no function.

CAmbient Light Sensor — Monitors ambient light level and

adjusts screen brightness.

DCapacative Touch Screen — A 15.6 inch screen with

1366x768 resolution.

ESpeakers — Provide audible feedback from button

presses.

FMotion Sensor — Detects motion in front of the

touchpanel.

GMenu Button — Activates the setup menu and calibration

screen (see Setup Menu on page 4). It is accessed

from under the touchpanel. It performs the same function

as the rear panel Menu button but is easier to reach when

the touchpanel is installed.

NOTE: Extron recommends using the FPC

Settings link on the Login Screen (see

page 5) to open the on-screen menus.

1. Download the cut-out template for the

TLP Pro 1520MG from www.extron.com.

Print it at 100% (no scaling).

2. Use the template to mark the wall, cut the

hole, and drill the four pilot holes.

The size of the cut-out hole is 8.90 inches

(22.61 cm) wide x 5.70 inches (14.48 cm) high.

3. The FPC 6000 ships, already mounted, in a

rack-mountable metal panel. Remove the FPC

6000 from the panel and, remove the mounting

plate that is attached to the panel by screws.

4. Secure the mounting plate to the mounting

surface with four #10 screws. The installer

must use screws and fasteners that are

appropriate for the mounting surface.

5. Run and connect cables to the back of the

touchpanel (see Rear Panel Features on the

next page).

6. Insert the two provided Phillips pan head #6-

32 x ¾-inch length screws with washers in the

mounting screw slot (see ﬁgure 4, J, on the

next page). Leave a gap for the ange at the

bottom of the mounting plate to t into.

7. Hold the touchpanel at a slight angle and

lower the notches at the top of the back

panel (See gure 2, 4) over the hooks of the

mounting plate.

8. Swing the bottom of the touchpanel inwards

so that it lies at against the mounting plate

with the ange at the bottom of the mounting

plate sitting in a groove in the bottom of the

touchpanel.

9. Secure the touchpanel to the mounting plate

with the mounting screws.

FPC 6000

Back View

Hold the touchpanel at a slight angle

Mount the touchpanel over the two

hooks on the mounting plate.

Add the mounting plate. Align with

the wall box and mark holes for screws.

Secure the mounting plate

to the wall with screws (4).

Place the provided mounting screws (2)

with washers in the mounting screw slot

in the touchpanel.

Secure the touchpanel by tightening the

mounting screws against the base of the

mounting plate.

Figure 2. Wall Mounting the FPC 6000

FPC 6000 • Setup Guide (Continued)

Rear Panel Features

EFFG

Figure 4. FPC 6000 Rear Panel

gure 4 AReset LED — Provides feedback about the reset

status when the user presses the reset button (see

Reset Modes: a Brief Summary on page 7)

BReset Button — Press the Reset button to reset

the unit in any of three different modes (see Reset

Modes: a Brief Summary).

CMenu Button — Activates the setup menu and

calibration screen (see Setup Menu, below).

NOTE: Extron recommends using the FPC

Settings link on the Login Screen (see

page 5) to open the on-screen menus.

DUSB Connectors — No function in FPC 6000.

EAudio Output — No function in FPC 6000.

FXTP/LAN/PoE Input

NOTE: The FPC 6000 can be powered by either the provided PoE

power injector or a 12 VDC, 3.0 A power supply (which must be

purchased separately). Do not remotely power the touchpanel using

an XTP device.

• XTP input — Do not connect the FPC 6000 directly to an XTP source.

• LAN input — If you use the provided 12 VDC power supply, connect

the FPC 6000 directly to the network using a twisted pair cable,

terminated with an RJ-45 connector.

• PoE input — If you use the provided PoE power injector, connect the

FPC 6000 to the power injector output and connect the power injector

input to the LAN (see gure 4).

100-240V~50/60 Hz

1.1A MAX INPUT OUTPUT

POWERED TLP

LAN

To Network Device To FPC 6000

Extr

on PI 140

Figure 5. Connecting the PoE Power Injector

ATTENTION:

• Do not power on the touchpanels or control processors until you have read the Attention in the “Rear Panel Features”

section of the FPC 6000 User Guide.

• Ne branchez pas les écrans tactiles ou les contrôleurs avant d’avoir lu la mise en garde dans la section «Rear Panel

Features » du FPC 6000 User Guide.

GHDMI Input — No function in FPC 6000.

HMounting Slot (2) — Used to attach the mounting plate to the FPC 6000.

I12 VDC Power Supply Input — If you are not using PoE, connect a 12 VDC, 3.0 A power supply to this captive screw connector.

The power supply must be purchased separately. Extron recommends the PS 1230 Limited Power Source (LPS).

JMounting Screw Slot (2) — Used to secure the mounting plate to the FPC 6000.

Setup Menu

Press the FPC Settings link on the Login screen to open the

setup menu. Select any of the ve available screens (Status,

Network, Display, Audio, and Advanced) by pressing the

appropriate button in the navigation bar at the top of the screen

(for more information, see the FPC 6000 User Guide).

The setup menu is used to congure the network settings for

the FPC 6000.

StatusDisplay Audio Advanced Exit

Network

Info

Model: FPC 6000

Part Number:60-1706-01

Firmware

Version: 1.00.0001-b003

Network

IP Address:

DHCP:

Host Name:

Off

192.168.254.251

FCP-6000-AB-CD-EF

Display

Resolution:

GUI Project:

Sleep Timer:

1366x768

N/A

5 Minutes

Audio

Master Vo lume:

Master Mute: Off

Advanced

Controller IP:N/A

Project Size:N/A

Bootloader

Version: 1.00.0000

PoE: Active

Figure 6. Setup Menu: Status Screen for FPC 6000

Product Category

FPC 6000 Web Page

1. Open a web browser on a PC connected to the same

subnet as the FPC 6000.

2. Enter the IP address of the FPC 6000 into the web browser.

3. In the dialog box that opens, enter the touchpanel user

name (by default, this is admin) and password (by default,

this is extron).

A single page provides read-only information about the unit.

It also allows you to update the FPC 6000 rmware (see the

FPC 6000 User Guide for more information).

Figure 7. FPC 6000 Web Page

Operation

The FPC 6000 has a Login Screen and four main screens (Ties, Status, I/O Info, and Customize) that allow you to control, monitor,

access, and manage a range of Extron matrix switchers through a direct connection or over a local area network.

When the FPC 6000 is powered on, it opens to the login screen.

1. Press the Matrix IP Address text box. An on-screen keyboard appears.

2. Enter the IP address of the matrix switcher. If you have previously connected to the

matrix switcher, the IP address may already be displayed, or may be available in the

drop-down menu.

3. Press the Port text box and enter the port number. This is usually 23.

4. Press the Password text box and enter the password for the matrix switcher.

5. Press Connect. The FPC 6000 attempts to connect to the matrix switcher.

If the connection is successful, the FPC 6000 opens to the Ties screen.

If the connection is unsuccessful, you will see an error message. Check that you have

the correct values for the IP address, port number, and password before re-entering

the values.

Ties

Press the Ties menu button. When the Ties screen is selected, the label on the button

changes to Ties/Refresh.

Extron

Matrix IP Address

Port

Password

DISCONNECT CONNECT

FPC IP: 192.168.254.251

FPC Settings

Figure 8. FPC 6000 Login Screen

AMenu Buttons — For navigating to the other main

screens.

BInput Buttons — The block of numbered buttons on

the left shows 20 matrix switcher inputs at a time.

Use the scroll bar to see more. Inputs with an active

source have a blue rectangle in the top right corner.

CChange View — Use these tabs to toggle between

the standard view (matrix mode) and the alternative

view (keypad mode) that allows you to work with a

single input or output at a time.

DOutput Buttons — The block of numbered buttons

on the right shows 20 matrix switcher outputs at a

time. Use the scroll bar to see more.

EPresets — This menu allows you to save the current

conguration as a Global preset or replace the current

conguration with a previously saved preset.

FMute Selection — Allows only AV mute. FOX matrix

switchers do not allow breakaway.

AA B

Figure 9. FPC 6000 Ties Screen

GMute Controls — Allow you to mute audio and video on a selected output.

HTake — Use this screen to set up potential ties. For those ties to go into effect, press Take.

ISelect All — Allows you to set up potential ties from one input to all outputs.

JClear Selection — Use this button to clear potential ties before they go into effect.

FPC 6000 • Setup Guide (Continued)

For complete instructions about creating and breaking ties, or saving and recalling presets, see the FPC 6000 User Guide.

Create Ties

NOTE: One input can be tied to multiple outputs but each output can be tied to only one input.

1. Press an input button to select it. The color of the button changes to blue. If the input is already tied to one or more outputs,

those output buttons change color to orange.

2. Press one or more previously untied output buttons to select them. The selected button changes color and an orange plus sign

appears in the bottom right corner of the button. The Take button becomes activated.

3. Press Take. The tie is saved.

Break Ties

1. Press an input button to select it. The color of the button changes to blue and any outputs already tied to that input change to

orange.

2. Press one or more of the previously tied output buttons to select them. An orange minus sign appears in the bottom right corner

of the button. The Take button becomes activated.

3. Press Take. The tie is broken.

Select All

1. Press an input button to select it. The color of the button changes to blue and any outputs already tied to that input change to

orange.

2. Press Select All. All the output buttons are selected. The Take button becomes active and a new, Break button is also

available.

3. Press Take to tie the selected input to all outputs.

Or press Break to break all existing ties to the selected input.

Save Presets (Global Presets only)

NOTE: To save rooms or room presets, you must use Simple Instruction Set™ commands (see the user guide for your matrix

switcher). The FPC 6000 can save global presets and recall global and room presets.

1. Press Presets to open the presets menu.

2. Press Save As.... A drop-down menu shows all the previously saved and unassigned presets.

3. Select a preset. You can overwrite an existing preset or select [unassigned] and create a new preset.

4. If you select an unassigned preset, an on-screen keyboard opens. Enter a name for the preset.

5. Press Submit on the keyboard (for a new preset) or press Save Preset to overwrite an existing preset.

Recall Presets

When you recall a preset, it overwrites the current conguration for the matrix switcher.

1. Press Presets to open the presets menu.

2. Press Recall from....

3. Select either Global or Room from the Preset Type.

4. If you select Global, a list of global presets appears. Select a preset and press Recall Preset.

5. If you select Room, a list of rooms appears. Select a room. A list of presets for that room appears. Select a preset and press

Recall Preset.

Status

Press the Status menu button.

The Status screen is read-only and provides information

about the status of the matrix switcher.

Figure 10. FPC 6000 Status Screen

Product Category

I/O Info

The I/O Info screen allows you to nd complete

information about a single input or output. Press I/O Info

in the menu bar.

Select either the Inputs or Outputs tab.

If you select Inputs, press an input button. If there are

any tied outputs, they are listed on the right of the screen.

If you select Outputs, press any output button. If it is tied

to an input, that input is shown on the right of the screen.

I/O INFORMATION

CONNECT

STAT US

TIES

CUSTOMIZE

I/O INFO

Input 3

Input 1

Input 2

Input 4

Input 7

Input 8

Input 5

Input 6

Input 11

Input 12

Input 9

Input 10

Input 14

Input 16

Input 13

Input 15

Input 17

Input 20

Input 17

Input 19

Change ViewOutputsInputs

Selected Input:

Input 11

Tied Outputs:

Output 10

Output 15

Output 17

SFP Module Status

Board Config Type

JDSU -4.00 -4.88 38

Slot 1, Unknown or Mixed

Figure 11. FPC 6000 I/O Info Screen

Customize

The Customize screen allows you to change the

appearance of the graphical user interface.

Press Customize in the menu bar.

1. Select one of the three options:

• Dark (default)

• Medium

• Light

The selected option is highlighted in blue.

2. Press Save Changes to save the selection.

Reset Modes: a Brief Summary

The FPC 6000 offers the following reset modes (see the FPC 6000 User Guide for complete information):

• Use Factory Firmware — With the unit powered off, press and hold the Reset button (see ﬁgure 4, Bon page 4) while

reapplying power to the unit.

• Reset All IP Settings — Press and hold the Reset button for 6 seconds. After the Reset LED (see ﬁgure 4, A) ashes twice,

release and momentarily press the Reset button. Use this mode to reset all network settings to factory defaults without

affecting user-loaded les.

• Reset to Factory Defaults — Press and hold the Reset button for 9 seconds. After the Reset LED ashes three times,

release and momentarily press the Reset button. Use this mode to return the touchpanel to factory default settings.

Figure 12. FPC 6000 Customize Screen

All trademarks mentioned are the property of their respective owners.

FPC 6000 • Setup Guide (Continued)

68-3259-50 Rev. A

06 18

Otros manuales para FPC 6000

Tabla de contenidos

Otros manuales de Controladores de Extron electronics

Extron electronics

Extron electronics IPA T RLY4 Manual de usuario

Extron electronics

Extron electronics MLC 62 IR D Manual de usuario

Extron electronics

Extron electronics MEDIALINK MLC 52 Series Manual de usuario

Extron electronics

Extron electronics MEDIALINK MLC 52 Series Manual de usuario

Extron electronics

Extron electronics RAC 104 Manual de usuario

Extron electronics

Extron electronics Basic MediaLink Controllers MLC 52 RS Manual de usuario

Extron electronics

Extron electronics MediaLink Controllers with IP Link MLC 104 IP... Manual de usuario

Extron electronics

Extron electronics VNM EC 200 Manual de usuario

Extron electronics

Extron electronics MediaLink Controllers with IP Link MLC 104 IP... Manual de usuario

Extron electronics

Extron electronics Control Modules ACM Manual de usuario

Extron electronics

Extron electronics RAC 104 Manual de usuario

Extron electronics

Extron electronics MLC Plus 84 D Manual de usuario

Extron electronics

Extron electronics MediaLink MLC 104 Plus Series Manual de usuario

Extron electronics

Extron electronics MEDIALINK MLC 52 Series Manual de usuario

Extron electronics

Extron electronics MEDIALINK MLC 206 Manual de usuario

Extron electronics

Extron electronics FPC 6000 Manual de usuario

Extron electronics

Extron electronics CCI Pro 700 Manual de usuario

Extron electronics

Extron electronics CTR 8 Manual de usuario

Extron electronics

Extron electronics MediaLink MLC Plus 50 Manual de usuario

Extron electronics

Extron electronics MLC 206 Manual de lista de piezas

Extron electronics

Extron electronics MediaLink MLC Plus 100 Manual de usuario

Extron electronics

Extron electronics VNM Enterprise Manual de usuario

Extron electronics

Extron electronics MediaLink MLC Plus 50 Manual de usuario

Extron electronics

Extron electronics MLC 206 Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
