IMPORTANT:

Go to www.extron.com for the

complete product specifications.

IPA T RLY4 • Setup Guide

This guide provides instructions for an experienced installer to install the Extron IPA T RLY4 relay accessory and to make all

connections.

The IPA T RLY4 is an IPLink®Accessory product. The relay accessory consists of four output relays with normally open (when the

relay is de-energized) (NO) and normally closed (NC) contacts.

The relay accessory converts a solid state (up to 12 VDC) signal, from a Flex I/O port or Digital I/O port on an Extron control

processor, to a relay contact closure. The relay contacts can handle up to 24 VAC or 24 VDC as a tally signal, contact closure

signal, or control signal to drive devices in your system, such as a lighting system (see gure 1) or remote screens. The relay

contacts are protected by an overvoltage circuit.

The compact IPA T RLY4 can be concealed out of the way anywhere in your system with the included hook and loop fastener strip.

IPAT RLY4

1 2 3 4 C

INPUTS

PWR OUT = 6W

V C G

VOL

POWER

12V

1.0A MAX

Tx Rx

RTS CTS

CO M 1

1 2 4 G

DIGITAL I/O

Tx Rx

CO M 2

-S+V +S G

eB US

C1 2

RE LAYS

IR/S

LAN

Extron

IPCP Pro 255Q xi

Ethernet Control

Processor

Extron

IPA T RLY4

Relay Accessory

NO C NC NO C NC NO C NC NO C NC

RELAY 1 RELAY 2 RELAY3 RELAY 4

Lighting System

Front

Rear

Extron

12 V Power

Supply

+12 VDC

(Common)

Figure 1. Typical IPA T RLY 4 Application

Connections

NOTE: The 5-pole captive screw input connector and four 3-pole captive screw output connectors are included with the

unit, but you must supply the cable. Extron recommends the CTL Series cable, available non-plenum and plenum bulk

rolls and plenum pre-cut lengths.

IPA T RLY4 1 2 3 4 C

INPUTS

NO C NC NO C NC NO C NC NO C NC

RELAY 1 RELAY 2 RELAY 3 RELAY 4

BB BB BB BB

Figure 2. IPA T RLY4 Connections

Input Connections

AInputs — Connect the 12 VDC source to the common voltage (C) terminal of the 5-pole captive screw

connector. Connect the appropriate terminal (1 though 4) to the digital output or flex I/O of the Extron control

processor.

IPA T RLY4 • Setup Guide (Continued)

ATTENTION:

• Connect +12 VDC to the C pin only and connect the return to one or all of the Input pins (1 through 4) for the relays that

you will use. Reversing the connections can damage the power supply.

• Raccordez une source +12Vcc uniquement à la broche C du connecteur et raccordez le circuit de retour à une ou

plusieurs broches d’entrée (1 à 4) pour les relais utilisés. Inverser les raccordements pourrait endommager la source

d’alimentation.

• Observe proper polarity when making connections to the Power port on the MLC 104 IP Plus controller. Miswiring can

damage the port.

• Veillez à respecter la polarité appropriée lorsque vous effectuez des raccordements au port d’alimentation du

contrôleur MLC 104 IP Plus. Une erreur de raccordement pourrait endommager le port.

NOTES:

• Connect the I/O control line to the Input 1 terminal for relay 1, Input 2 for relay 2, and so on.

• Figure 3 is a wiring diagram of a typical application: an Extron MLC 104 IP Plus controlling an IPA T RLY4 relay function

(see the MLC 104 Plus Series User Guide for information on conguring the MLC to control the IPA T RLY4).

• Figure 4 shows an application that includes an external power supply and an Extron IPCP Pro Dual-NIC Controller.

When the relay accessory is connected to an IO port of an IPCP Pro module, ground the external power supply to the

IO port ground pin on the control processor.

IPA T RLY4 1 2 3 4 C

INPUTS

GROUND

+12V OUT

GROUND

IR OUT

GROUND

SCP

GROUND

DISPLAY

RS-232/IR A B C D E

COMM LINK

LAN

PRESS TAB WITH

TWEEKER TO REMOVE

A B

MLS

RS-232

POWER

12V

DIGITAL

I/O

IR IN

GROUND

+12V IN

MLC 104 IP Plus

Right Side

IPA T RLY4

Front Panel

+12 VDC

Relay 1

Relay 2

Relay 3

Figure 3. Wiring Diagram for Connection to an MLC 104 IP Plus

LAN

GTx Rx GTx Rx

COM 2 COM 3

RELAYS

2143CC

COM 1

GTx Rx

RTS CTS

IR/SERIAL

1234G

DIGITAL I/O

eBUS

+V +S -S G

PWR OUT = 6W

AV LAN 2

AV LAN 1

AV LAN 3

IPA T RLY4 1 2 3 4 C

INPUTS

Ground

all devices

– Return

+12 VDC input

Ridged

Smooth

1AMAX

100-240V 50-60Hz

External

12 VDC

Power Supply

2134

IPCP Pro Control Processor with Internal Power Supply

ithin another device)

IPA T RLY4

Figure 4. Wiring Diagram for Connection to an IPCP Pro Control Processor with Internal Power Supply

Output Connections

BOutputs (see figure 2 on page 1) — For each relay:

For the normally open contacts, connect a device between the NO and C terminals of the 3-pole captive screw connectors.

For the normally closed contacts, connect a device between the NC and C terminals of the 3-pole captive screw connectors.

NOTE: Figure 5 shows wiring diagrams for a typical application: an Extron IPA T RLY4 driving a screen controllers of

various types. These are examples only. Your equipment may have different wiring requirements (see the manual from

the applicable manufacturer for specific wiring instructions).

NO C NC NO C NC NO C NC NO C NC

RELAY 1 RELAY 2 RELAY 3 RELAY 4

NO C NC NO C NC NO C NC NO C NC

RELAY 1 RELAY 2 RELAY 3 RELAY 4

UP DOWN STOP

Typical Stewart Low Voltage Controller*

COMMON

RED BLACK

Typical Da-Lite or Draper Low Voltage Controller

WHITE (DA-LITE)

BLUE (DRAPER)

IPA T RLY4 IPA T RLY4

†

Figure 5. Wiring Diagrams for Connection to a Screen Controller (See the NOTES below)

NOTES:

• * For a typical Stewart screen controller, a momentary closure on relay 1, 2, or 3 causes the screen to move up,

down, or stop.

• For a typical Da-Lite or Draper screen controller, a momentary closure on relay 1 or 2 causes the screen to move

up or down. A momentary closure on relay 3 causes the screen to stop in its current position.

Use 1N4001 or equivalent diodes (not included) for reverse bias protection.

Recommended diode specifications:

• 100 mA maximum through diode

• 50 V maximum reverse bias

Operation

When an input signal is applied to one of the input terminals of the IPA T RLY4, the signal toggles the state of that IPA T RLY4

output relay; the relay NO contacts close, routing the signal for the connected device, and its NC contacts open, interrupting the

signal for the connected device. See the chart below for clarication.

I/O mode I/O state Relay state

NO NC

Output On

(closed)

Closed Open

Off (open Open Closed

†

68-739-03 Rev. E

10 22

For information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related topics, see the

Extron Safety and Regulatory Compliance Guide on the Extron website.

All trademarks mentioned are the property of their respective owners.

Worldwide Headquarters: Extron USA West, 1025 E. Ball Road, Anaheim, CA 92805, 800.633.9876
