Page 2 RH200W-en-GB_v1.1 10/17
RECEIVING WIRELESS SENSOR SIGNALS
1. In normal mode, short press SENSOR to start receiving data.
2. The signal icon will flash (diagram on left below) until reception occurs.
After 5 minutes, the icon will disappear if reception fails (center diagram).
3. Receiving a wireless signal after a manual reset or when SENSOR is pressed
will cause dashes to display in the readings area when waiting for signal.
4. For successful reception, the signal icon will appear as shown in the
diagram below on right. The selected channel number appears in the box
below the icon.
1. In normal mode, short press OUT to switch the display between INDOOR
and CHANNEL 1~8.
2. In normal mode, long press OUT to toggle auto-cycle mode ON/OFF. Auto-
cycle alternately displays the channels at 4-second intervals (the icon will
show when auto-cycle is active). In auto-cycle mode only the actively
communicating channels will appear. Short press OUT to exit mode.
3. To check the signals from multiple wireless sensors, short press OUT
repeatedly in normal mode.
4. If the signal for Channel 1~8 is lost and does not recover within 1 hour, the
signal icon will disappear. The temperature and humidity will display “Er”
for the corresponding channel.
5. If the signal does not recover within 48 hours, replace the batteries of the
“Er” channel’s sensor and then press SENSOR on the main unit to pair with
the sensors for each “Er” channel again.
Note To initiate reception after installing new batteries in the wireless sensor,
press SENSOR; otherwise, the main unit will fail to receive the sensor’s signal.
LOW TEMPERATURE ICON
When the outdoor temperature is 37.4°F (3.0°C) or below, the low temperature
icon ‘LO’flashes on the display.
LOW BATTERY CONDITION
If the main unit or the sensor batteries are low, the low battery icon will
display. The icon will only appear when the corresponding channel is displayed.
For example, if the CHANNEL 1 sensor battery is low, the icon will show only
when CHANNEL 1 is displayed. Replace the batteries by following instructions in
sections Powering the Wireless Sensor and Powering the Main Unit.
TEMPERATURE/HUMIDITY CALIBRATION
1. In normal mode, long press the CAL key to enter the calibration mode. The
current outdoor channel or “IN” (indoor) icon will flash. Short press OUT to
choose Indoor (IN) or a Channel number 1~8.
2. Short press M(MODE) to step through the temperature calibration,
humidity calibration, and channel selection modes.
3. In temperature calibration mode, use the [ +] [ -] keys to adjust the value
in 0.1° steps. Long press to scroll quickly.
4. In humidity calibration mode, use the [ +] [ -] keys to adjust the displayed
value in 1% steps. Long press to scroll quickly.
5. Long press Mat the temperature or humidity calibration screens to revert
to the previous calibration value for the selected channel.
6. To exit calibration mode, long press CAL or wait 60 seconds for the unit to
exit and return to the normal mode automatically.
7. If the reading for the selected channel is showing either dashes (flashing) or
the HI/Lo indicators, adjustment will not be possible; return unit for service.
Note: Comfort indication is a calculation based on calibrated temperature and
humidity measurements.
IMPORTANT NOTES
Attention! Please dispose of batteries and unit in an ecologically safe manner.
Always place the unit away from interfering sources such as monitors,
computers, appliances, and other devices. Avoid placing the unit on, or next to,
metal plates or surfaces
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Industry Canada License-exempt RSS-210. Operation is subject to
the following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired operation
of the device.
FCC Responsible party:
Company Name: FLIR Commercial Systems, Inc.
Address: 9 Townsend West, Nashua NH 03063 USA
Phone: 1- 603-324-7842
IC ID: 1590A-RH200WT; FCC ID: IWK-RH200W-T; CAN RSS-Gen/CNR-Gen.
SPECIFICATIONS
MAIN UNIT
Indoor temperature range/resolution: -5°C ~ 50°C (23°F ~ 122°F) / 0.1°C/°F
Temperature Accuracy: ±2°C (3.6°F), < 0°C (< 32°F)
±1°C (1.8°F), 0~40°C (32~104°F)
±2°C (3.6°F), > 40°C (> 104°F)
Humidity range/resolution: 1% ~ 99 % / 1%
Humidity Accuracy (at 25°C [77°F]): ±8%RH (20~39% RH); ±5%RH (40~70% RH)
±8%RH (71~90% RH)
Power: 1.5V AA X 4 (alkaline battery recommended)
Dimensions: 130 (W) x 112 (H) x 27.5 (D) mm (5.1 x 4.4 x 1.1 in.)
Weight: 295g (0.65 lbs.)
WIRELESS SENSOR
Outdoor temperature range: -40°C ~ 60°C (-40°F ~140°F)
Outdoor humidity range 1% ~ 99 %
Temperature resolution: 0.1°C/°F
Relative humidity resolution: 1%
Accuracy: See accuracy specs for Main Unit above
Wireless sensor signal frequency: 433MHz
No. of remote sensors: Eight (8) units max.
RF transmission range: 30m (98.4 ft.) maximum
Power: 1.5V AA X 2 batteries (alkaline recommended)
Dimensions: 61 (W) x 113.6 (H) x 39.5 (D) mm (2.4 x 4.5 x 1.5 in.)
Weight: 136g (0.3 lbs.)
