GREISINGER G 1202 Manual de usuario

Quick reference guide

G 1202

Quick response

2 channel-alarm-thermometer

for exchangeable Type K thermocouple sensors

Table of contents
/ 19 B-H89.0.1X.DK2-1.0
Table of contents
About this documentation......................................................4
1 Foreword........................................................................................4
2 Legal notices..................................................................................4
3 Further information.........................................................................4
Safety.......................................................................................5
1 Explanation of safety symbols ........................................................5
2 Foreseeable misuse .......................................................................5
3 Safety instructions..........................................................................6
4 Intended use...................................................................................6
5 Qualified personnel.........................................................................6
The device at a glance............................................................7
1 Display elements............................................................................7
2 Connections ...................................................................................7
3 Operating elements........................................................................8
Operation.................................................................................9
1 Opening the configuration menu.....................................................9
2 Adjustment of the measuring input................................................11
Measurement Basics.............................................................12
1 Sensor/device accuracy................................................................12
2 Possible measuring errors............................................................12
2.1 Immersion depth...........................................................................12
2.2 Surface effects and poor heat transfer..........................................12
2.3 Cooling / evaporation....................................................................12
2.4 Potential shift................................................................................12
2.5 Response time .............................................................................13
Operation and maintenance.................................................13
1 Operating and maintenance notices..............................................13

 Table of contents
B-H89.0.1X.DK2-1.0 3 / 19
2 Battery..........................................................................................13
2.1 Battery indicator............................................................................13
2.2 Changing battery..........................................................................13
Error and system messages.................................................15
Technical data .......................................................................16
Disposal.................................................................................17
Service ...................................................................................18
1 Manufacturer................................................................................18
2 Calibration and adjustment service...............................................18
3 Accessories..................................................................................19

1 | About this documentation G 1202

4 / 19 B-H89.0.1X.DK2-1.0

1 About this documentation

1.1 Foreword

Read this document carefully and familiarise yourself with the operation of the product

before you use it.

Keep this document ready to hand and in the immediate vicinity of the product so that

it is available to the personnel/user for reference at all times in case of doubt.

The user must have carefully read and understood the operating manual before begin-

ning any work.

1.2 Legal notices

The liability and warranty of the manufacturer for damages and consequential damag-

es are voided with misuse, disregarding this document, disregarding safety notices,

assignment of inadequately qualified technical personnel and arbitrary modifications of

the product.

This document is entrusted to the recipient for personal use only.

Any transmission, duplication, translation into other languages or excerpts from this

operating manual require the consent of the manufacturer.

The manufacturer assumes no liability for print errors.

1.3 Further information

Software version of the product:

–V1.0 or later

For the exact product name, refer to the type plate on the rear side of the product.

NOTE

For information about the software version, press and hold the ON button to switch on

for longer than 5 seconds. The series is shown in the main display and the software

version of the product is shown in the secondary display.

G 1202 Safety | 2

B-H89.0.1X.DK2-1.0 5 / 19

2 Safety

2.1 Explanation of safety symbols

DANGER

This symbol warns of imminent danger, which can result in death, severe bodily injury,

or severe property damage in case of non-observance.

CAUTION

This symbol warns of potential dangers or harmful situations, which can cause damage

to the device or to the environment in case of non-observance.

NOTE

This symbol indicates processes, which can have a direct influence on operation or

can trigger an unforeseen reaction in case of non-observance.

2.2 Foreseeable misuse

The fault-free function and operational safety of the product can only be guaranteed if

applicable safety precautions and the device-specific safety instructions for this docu-

ment are observed.

If these notices are disregarded, personal injury or death, as well as property damage

can occur.

DANGER

Incorrect area of application!

In order to prevent erratic behaviour of the product, personal injury and property

damage, the product must be used exclusively as described in the chapter Description

in the operating manual.

–The product is not suitable for use in explosion-prone areas!

–The product must not be used for diagnostic or other medical purposes on pa-

tients!

–Not suitable for use with requirements on functional safety, e.g. SIL!

–Do not use in safety / emergency stop devices!

2 | Safety G 1202

6 / 19 B-H89.0.1X.DK2-1.0

2.3 Safety instructions

CAUTION

Risk of injury at the temperature sensor!

Devices with insertion probes entail the risk of stab injuries due to the pointed probe

design.

There is a risk of burns when measuring in high (and very low) temperatures. Use

gloves if necessary.

NOTE

This device does not belong in children's hands!

NOTE

The device housing is not designed for continuous contact with foods.

For measurements in food in accordance with EC Regulation 1935 / 2004, suitable

temperature probes must be used:

2.4 Intended use

The device is thermometer for type K interchangeable probes.

It is designed, with the appropriate probe, for precise and instantaneous temperature

measurements in the following media:

–Liquids, gases, soft plastic materials, bulk material

–Food

2.5 Qualified personnel

For commissioning, operation and maintenance, the relevant personnel must have

adequate knowledge of the measuring process and the significance of the measure-

ments. The instructions in this document must be understood, observed and followed.

In order to avoid any risks arising from interpretation of the measurements in the

concrete application, the user must have additional expertise. The user is solely liable

for damages/danger resulting from misinterpretation due to inadequate expertise.

G 1202 The device at a glance | 3

B-H89.0.1X.DK2-1.0 7 / 19

3 The device at a glance

LCD Display

Top view

Front view

3.1 Display elements

Display

Battery indicator

Evaluation of the battery status

Unit display

Display of units or min/max/hold/diff

Main display

Measurement of the current temperature of the

selected channel or value for min/max/hold

Auxiliary display

With INP = both or diFF: Display of the current

temperature of channel 2 or value for min/max/hold

With INP = CH1: Measured value of the current

temperature in min/max/hold mode

3.2 Connections

Thermocouple plugs

Connection for temperature sensor CH1 and CH2

CAUTION

The device ensures extensive protection against splashing water and rain.

However, immersion in water is not possible due to the socket opening.

–Protect the connector opening / contacts from soiling and moisture!

–Dry damp device and plug connectors as quickly as possible!

3 | The device at a glance G 1202

8 / 19 B-H89.0.1X.DK2-1.0

3.3 Operating elements

On / Off button

Press briefly

Switch on the device

Activate / deactivate lighting

Long press

Switch off the device

Reject changes in a menu

Up / Down button

Press briefly

Display of the min/max value

Change value of the selected parameter

Long press

Reset the min/max value of the current measure-

ment

Both simultaneously

Rotate display, overhead display

Function button

Press briefly

Freeze measurement (Hold)

Call up next parameter

Long press, 2s

Start menu “configuration”, (ONF appears in the

display

Operating status device is in measured value display

device is in the configuration menu

G 1202 Operation | 4

B-H89.0.1X.DK2-1.0 9 / 19

4 Operation

4.1 Opening the configuration menu

1. Press the Function button for 2 seconds to open the Configuration menu.

2. (ONF appears in the display. Release the Function button.

Parameter

Values

Meaning

__INP

Measuring channel

(H.1

Main display = channel 1

BOTH

Main display = channel 1

Secondary display = channel 2

D,FF

Main display = difference channel 1 –channel 2

Secondary display = channel 2

__AL.

Alarm *1

OFF

No alarm active

Alarm via text insertion, acoustic signal and flashing

of the background lighting

BEEP

Alarm via text insertion and acoustic signal

L,TE

Alarm via text insertion and flashing of the back-

ground lighting

_AL.LO

Min. alarm limit (only available if AL <> off)

-65.0 .. AL.X,

a min. alert is triggered if the value falls below this

value. (for °F: -85.0 .. AL.Hi)

_AL.XI

Max. alarm limit (only available if AL <> off)

-AL.LO .. 1200.0

If the value is exceeded, a max. alarm is triggered.

(for °F: AL.Hi .. 2192)

4 | Operation G 1202

10 / 19 B-H89.0.1X.DK2-1.0

POFF

Shut-off time

OFF

No automatic shut-off

0:15, 0:30, 1:00,

4:00, 12:00

Automatic shut-off after a selected time in

hours:minutes, during which no buttons have been

pressed

L,TE

Backlight

OFF

Backlight deactivated

0:15, 0:30, 1:00,

2:00, 4:00

Automatic shut-off of the backlight after a selected

time in minutes:seconds, during which no buttons

have been pressed

No automatic shut off of the backlight

UN,T

Display unit

°(

Temperature display in °C

°F

Temperature display in °F

IN,T

Factory settings

Use current configuration

YES

Reset device to factory settings.

After confirming with the function-button, the display

shows: IN,T DONE

*1= The alarm function works depending on the set measuring channel:

with INP = „(H.1“ on channel 1

with INP = „BOTH“ on channel 1 and channel 2

with INP = „D,FF“ on the difference temperature

Note to D,FF : The adjustable alarm limits continue to refer to the measuring

range limits of the device, which means: negative values can only

be set to a very limited extent!

(Note: if necessary, swapping channel 1 and channel 2 could

help here)

Tabla de contenidos

Otros manuales de Termómetro de GREISINGER

GREISINGER

GREISINGER GMH 1150 Manual de usuario

GREISINGER

GREISINGER GMH 3250 Manual de usuario

GREISINGER

GREISINGER GMH 3211 Manual de usuario

GREISINGER

GREISINGER GMH 3750 Manual de usuario

GREISINGER

GREISINGER GMH 175 Manual de usuario

GREISINGER

GREISINGER LEISTER G 1200 Instrucciones de instalación

GREISINGER

GREISINGER GTH 2448/3 Manual de usuario

GREISINGER

GREISINGER gth 1170 Manual de usuario

GREISINGER

GREISINGER G 1710 Manual de usuario

GREISINGER

GREISINGER GFTH 95 Manual de usuario

GREISINGER

GREISINGER G 1200 Series Manual de usuario

GREISINGER

GREISINGER GIR 230 TC Manual de instrucciones

GREISINGER

GREISINGER GFTH 95 Manual de usuario

GREISINGER

GREISINGER GMH 3210 Manual de usuario

GREISINGER

GREISINGER G 1720 Manual de usuario

GREISINGER

GREISINGER GMH 3221 Manual de usuario

GREISINGER

GREISINGER GMH 2710-T Manual de usuario

GREISINGER

GREISINGER G 1791 Instrucciones de instalación

GREISINGER

GREISINGER GMH 3251 Manual de usuario

GREISINGER

GREISINGER GFTH200 Manual de usuario

GREISINGER

GREISINGER GMH 3231 Manual de usuario

GREISINGER

GREISINGER G 1700 Manual de usuario

GREISINGER

GREISINGER GMH 1170 Manual de usuario

GREISINGER

GREISINGER GTH 2448 / 1 Manual de usuario

Manuales populares de Termómetro de otras marcas

Delton

Delton 981A Manual de usuario

Baker

Baker MM2P Manual de usuario

Tarmo

Tarmo 320281 Manual de usuario

Citizen

Citizen CTD 504 Manual de usuario

TFA

TFA 14.1500 Manual de usuario

Vive

Vive DMD1010 Manual de usuario

Gotemp

Gotemp THB4002 Manual de usuario

Amprobe

Amprobe TMD-53W Manual de usuario

Trotec

Trotec BP10 Manual de usuario

Radiance instruments

Radiance instruments RT616 Series Manual de usuario

Eurolec

Eurolec IR151 Manual de usuario

Scaneo

Scaneo TS42B Manual de usuario

Sper scientific

Sper scientific 800043 Manual de usuario

Microlife

Microlife NC 200 Manual de instrucciones

Motorola

Motorola MBP69SN Guía de configuración

The MeatStick

The MeatStick The MeatStick Manual de usuario

Hama

Hama TH35-A Manual de usuario

Veridian Healthcare

Veridian Healthcare 09-349 Manual de usuario
