EverFocus Speed Dome EPTZ1000 Manual de usuario

EPTZ1000

Outdoor Speed Dome

EPTZ500

Indoor Speed

Dome

USER MANUAL

Date: Sep. 26th, 2005

1-1

Table of Contents

OUTDOOR/INDOOR SPEED DOME OVERVIEW...........1-4

1.1. Introduction............................................................................................. 1-4

1.2. Specifications......................................................................................... 1-6

1.3. Feature .................................................................................................... 1-7

1.3.1. Profile of Outdoor and Indoor Speed Dome.................................. 1-7

1.3.2. Base Board ...................................................................................... 1-9

1.3.3. Outdoor/Indoor Speed Dome Control Board............................... 1-10

1.4. Outdoor/Indoor Speed Dome Connection...........................................1-11

1.5. Outdoor/Indoor Speed Dome Quick Operation Guide (Work with

Multi-Function Keyboard Controller) ................................................................ 1-12

OUTDOOR/INDOOR SPEED DOME INSTALLATION ..2-13

2.1. Packing List .......................................................................................... 2-13

2.2. Cable Needed........................................................................................ 2-13





Power Cable................................................................................... 2-13





Video Cable.................................................................................... 2-14





Control Cable................................................................................. 2-14





Alarm Cable ................................................................................... 2-14

2.3. Initial Setup........................................................................................... 2-14

2.3.1. Address Setting............................................................................. 2-15

2.3.2. Communication Protocol Setting................................................. 2-18

2.3.3. Transmission Speed Setting (Baud Rate Setting) ...................... 2-18

2.3.4. Video Format Setting .................................................................... 2-19

1-2

2.3.5. RS-485 Bus Terminator Resistance ............................................. 2-19

2.4. Rack and Speed Dome Installation..................................................... 2-21

2.4.1. Installation Requirements............................................................. 2-21

2.4.2. Outdoor Dome Camera Wall Mount Installation.......................... 2-21

2.4.3. Indoor Dome Camera Installation ................................................ 2-25

2.5. Separately Sold Accessories............................................................... 2-28

2.5.1. Pole mount..................................................................................... 2-28

2.5.2.

Pole adapter................................................................................... 2-28

2.5.3. Corner mount................................................................................. 2-28

2.5.4. Multi-Function Keyboard Controller

........................................... 2-28

OUTDOOR/INDOOR SPEED DOME SETUP MENU.....3-29

3.1. Structure of the Setup Menu................................................................ 3-29

3.1.1. Camera Setup Menu...................................................................... 3-30

OUTDOOR/INDOOR SPEED DOME FUNCTION SETUP

AND OPERATION ...................................................................4-34

4.1. Manual Control Mode........................................................................... 4-34

4.2. Auto Pan Mode ..................................................................................... 4-34

4.3. Position Setting.................................................................................... 4-34

4.4. Tour Mode ............................................................................................. 4-35

4.5. Alarm Link to a Position/Tour.............................................................. 4-36

4.6. Other operations................................................................................... 4-36

APPENDIX A: The Alarm I/O Connection..............................4-38

APPENDIX B: EverFocus Protocol........................................4-39

1-3

1-4

1. OUTDOOR/INDOOR SPEED DOME OVERVIEW

1.1. Introduction

Outdoor/Indoor Speed Dome, an intelligent high-speed dome camera is ready to

secure your property with its omni-directional and exact monitoring. An 18X optical

and 12X digital zoom combining with a high-performance chip makes captured

images clear and vivid. The other powerful camera functions this type of speed dome

equips with:

PAL / NTSC image format suppose.

Auto and fast focus increases the searching speed and precision.

Auto Iris adjusts the monitoring image to the best brightness.

White Balance function makes the shades of color more natural in different

light conditions.

BLC (Backlight Compensation) function makes objects clear in a high

illumination background.

Color / B&W images auto switching to enhance the sensitivity in a low light

condition or at night.

Furthermore, the micro control unit enables camera a nimble and exact movement

from minimal 0.01/sec to maximal 360/sec. It can go to every preset position in 1

second. It also has other advantages such as:

192 preset positions are available.

16 cruise tours can be set, and each tour contains up to 16 positions.

Up to256 speed domes can be supported on a RS485 bus when all speed

domes are controlled by multi-function keyboard controller.

Auto heater and fan to fit all kinds of temperature.

1-5

Provide 4 alarm inputs and 1 alarm output.

All of the features make the intelligent high-speed dome camera works for a wide

range and demanding application such as banks, airports, stations, casinos, streets

of cities, intelligent buildings, and etc.

1-6

1.2. Specifications

Model Outdoor Indoor

Power Supply AC 24V

Power consumption 18W; 70W with heater 18W

Operating temperature 40~+600~+40

Operating moisture 95%

Communication RS-485

Communication speed 1200/2400/4800/9600bps

Horizontal rotation speed 0.1°/s360°/s (1-239 grade shift gears)

Horizontal rotation range 360°unlimited rotation

Tilt rotation range 89.5°

Auto flip Rotates 180°when camera tilts to the vertical position

Auto zoom speed control Control speed auto-adjusted according to zoom length

changing

Auto Pan, 2 points scanning

Can set freely

Auto Pan speed 1239 grade available

Dwell time (2 points) 1239 second available

Preset Positions 192 positions

Running to position speed 1239 grade available,0.1º/s360º/s

Dwell time at preset position

160s available

Tour 16 group

Tour point per group 16 preset positions

Fan, Heater (outdoor model)

fan and heater auto starts 

Position Accuracy ±0.1°

Alarm 4 in 1 out with tour/position auto triggering

Proportional Pan Speed Yes

Built-in menu for functions Yes

Built-in Protocols EVF Pelco-D Pelco-P

Communication RS485

Address editable through Yes

1-7

DIP switch

Speed Dome Address 0-255

Manual Pan/tilt speed Pan: 0.1º ~ 352º/s Tilt: 0.1º ~ 352º/s

Video Output BNC

Dimension 220(W) x 310(H) mm

Weight 3.2kg

1.3. Feature

1.3.1. Profile of Outdoor and Indoor Speed Dome

Outdoor Speed Dome

Wall Mount Bracket

Housing

Inner Housing

M5 Bolt (Hex) x3

M3 Bolt x3

BNC Cable

Power Cable

RS485 Cable

Connection Bus

Bulb

Mechanical Part

Camera Module

Control board

Base PCB board

1-8

Indoor Speed Dome

Housing

Clip

BNC Cable

Power Cable

RS485 Cable

Connection Bus

Bulb

Mechanical Part

Camera Module

Control board

Base PCB board

Ceiling

Button

1-9

1.3.2. Base Board

The base board that is on the bottom of the housing connects to power cable, video

cable, control cable, alarm cable, fan and heater (fan and heater are for Outdoor Speed

Dome only). In order to connect to cables, the board needs to be taken off, and put back

after finishing connecting to all cables. The connectors of cable names are marked on the

board in white text. The details of the alarm connector (JP5) are shown on the APPENDIX

For Outdoor Speed Dome, JP1, JP3 and JP6 that are two-pin connectors on the base

board need to be taken off during installation. JP1 and JP3 are connectors for heater, and

they can be switched. JP6 is a fan controller connector that turns on/off of the fan. The 3

cables are too short to be connected to a wrong connector when putting them back.

RELAY

JP6 JP4

JP3 JP1

JP5

Video +

Video -

RS485 +

RS485 -

AC24

Outdoor Speed Dome Base board
