EtherWAN EX34000 Manual de usuario

Hardened PoE Ethernet Switch

This quick start guide describes how to install and use the Hardened PoE Ethernet Switch. Capable of operating at temperature extremes of

-10°C to +60°C, this is the switch of choice for harsh environments constrained by space.

Physical Description

The Terminal Block and Power inputs

Power Input Assignment

Power3 48VDC DC Jack

＋48VDC

Power2 －Power Ground

＋48VDC

Power1 －Power Ground

Earth Ground

Terminal Block

Relay Alarm Assignment

FAULT

*Relay warning signal disable for following:

1. The relay contact closes if Power1 and

Power2 are both failed but Power3 on.

2. The relay contact closes if Power3 is failed

but Power1 and Power2 are both on.

DC Terminal Block Power Inputs: There are two pairs of power inputs can be used to power up this switch. Redundant power supplies function is

supported.

The 10/100Base-TX and 100Base-FX Connectors

The 10/100Base-TX Connections

The following lists the pinouts of 10/100Base-TX ports.

Pin Regular Ports Uplink port

1 Output Transmit Data + Input Receive Data +

2 Output Transmit Data - Input Receive Data -

3 Input Receive Data + Output Transmit Data +

4 NC NC

5 NC NC

6 Input Receive Data - Output Transmit Data -

7 NC NC

8 NC NC

The 100Base-FX Connections

The fiber port pinouts

The Tx (transmit) port of device I is connected to the Rx (receive) port of device II, and the Rx (receive) port of

device I to the Tx (transmit) port of device II.

The WDM 100Base-FX Connections

The fiber port pinouts

Only one single-mode optical fiber is required to transmit and receive data.

Hardened PoE Ethernet Switch

The Port Status LEDs

LED State Indication

10/100Base-TX, 100Base-FX

Steady A valid network connection established.

Link/ACT

(Green) Flashing Transmitting or receiving data.

ACT stands for ACTIVITY.

Functional Description

•Meets IEC61000-6-2 EMC Generic Standard Immunity for industrial environment.

•Supports IEEE802.3af Power over Ethernet (PoE) Power Sourcing Equipment (PSE).

•Supports IEEE802.3/802.3u/802.3x. Auto-negotiation: 10/100Mbps, Full/Half-duplex, Auto-Negotiation, Auto MDI/MDIX.

•100Base-FX: Multi/Single mode SC or ST type, WDM Single mode SC type.

•Supports 1024 MAC addresses. Provides 1M bits buffer memory.

•Alarms for power and port link failure by relay output.

•Power Supplies: Redundant 48VDC Terminal Block power inputs and 48VDC DC JACK with 100-240VAC external power

supply.

•Operating voltage and Max. current consumption: 1.5A @ 48VDC. Power consumption: 72W Max.

•Operating temperature ranges from -10℃to 60℃.

•Supports DIN-Rail, Panel, or Rack Mounting installation.

Assembly, Startup, and Dismantling

•Assembly: Place the switch on the DIN rail from above using the slot. Push the front of the switch toward the mounting

surface until it audibly snaps into place.

•Startup: Connect the supply voltage to start up the switch via the terminal block (or DC JACK).

•Dismantling: Pull out the lower edge and then remove the switch from the DIN rail.
