MANUAL
CLICKFIT EVO HANG-
ER BOLT
ARABIC TILES CORRUGATED
ROOF
STEEL ROOF BITUMEN EPDM
2
TABLE OF CONTENTS
Introduction 3
About this document 3
Other relevant documents 3
Symbols used in this manual 3
Warranty and liability 3
Liability 3
Warranty 3
Product information 4
Intended use 4
Improper use 4
Specications 4
Requirements for the work environment 4
System and application 5
Components 5
Application 6
Safety 7
Personal protective equipment 7
Safety warnings and regulations 7
Installation 8
Preparation 8
Cutting mounting rails to required size 11
Install the hanger bolts 12
Attaching the mounting rails 17
Optional: Attaching the cable clips 19
Mounting the rst panel 20
Mounting the following panels 23
Mounting the last panel 24
Mounting multiple rows 26
Removal and recycling 26
General 26
3
INTRODUCTION
ABOUT THIS DOCUMENT
InthismanualyouwillndtheinstallationinstructionsfortheClickFitEVOmountingsystemforsolarpanelsonArabictiles,
bitumenorEPDMroofmaterial,corrugatedironroofsandsheetmetalroofs.
Thesystemissuitableformountingsolarpanelsinportraitandlandscapeorientation.
Theseinstructionsareaddressedatqualiedtechnicalpersonnel.
You can download the latest version of this manual from www.esdec.com.
OTHER RELEVANT DOCUMENTS
WheninstallingtheClickFitEVOmountingsystem,youwillneedthefollowingdocuments:
• Theprojectplan,whichyoucanmakeinthecalculatoratwww.esdec.com.
• Theinstallationmanualsforthesolarpanels,invertersandanyothercomponents.
Duringtheinstallationofthemountingsystem,itisimportanttoadheretotheinstallationmanualandtheaccompanying
standardstopreventaccidents.Payspecialattentionto(local)standards,regulationsandlegislation(amongothers):
• TheBuildingRegulations2010(latestversion)
• HealthandSafetyatWorketcAct1974
• HealthandSafetyinRoofwork-HSE
• Eurocodes0(EN1990-StructuralDesign)
• Eurocodes1(EN1991-(Inuencesonstructures)
• HD-IEC60363series-Electricalinstallationsforlowvoltage
• EN-IEC62305-2-Protectionlightning-RiskManagement
• MIS3002–ThesolarPVstandard
• MCS012-ProductCerticationSchemeRequirements:PitchedRoofInstallationKits
SYMBOLS USED IN THIS MANUAL
6Warning! Failuretofollowthisinstructioncouldresultinseriousinjuryormajordamagetotheproduct.
3Caution! Failuretofollowthisinstructioncouldresultinpersonalinjuryordamagetotheproduct.
4Note Emphasisesaninstruction.
WARRANTY AND LIABILITY
LIABILITY
Themanufactureracceptsnoliabilityfordamageorinjurycausedbythefailuretocomply(strictly)withthesafetyguidelines
andinstructionsinthismanual,orbynegligenceduringinstallationoftheproductandtheaccessorieslistedinthis
document.
EsdecBVreservestherighttochangethisdocumentwithoutnotice.
WARRANTY
Esdecextendsa20yearproductwarranty.Thewarrantyissubjecttothewarrantytermsandgeneralterms&conditionsof
EsdecBV.Thesecanbefoundonthewww.esdec.com website.
4
PRODUCT INFORMATION
INTENDED USE
TheClickFitEVOmountingsystemforsolarpanelsonstandingseamroofsisdesignedformountingsolarpanelsonpitched
roofs.Withthismountingsystem,solarpanelscanbepositionedontheroofeitherwiththeshortsideatthebottom
(portrait)orwiththelongsideatthebottom(landscape).
IMPROPER USE
Themountingsystemisnotsuitableforuseontypesofroofotherthantheonespecied.
SPECIFICATIONS
Orientation of solar panels Portraitandlandscape
Frame height of solar panel 29-50mm
Maximum area of solar panels 2.6m2
Maximum eld size Forhorizontalandverticalrails:15mpersegment
Roof material
Bitumen(insulatedandnon-insulated)
EPDM(insulatedandnon-insulated)
3ThethermaleectofsometypesofEPDMandbitumenroongcanhavea
negativeeectonthewaterproong,causingitcannotbeguaranteedon
everyroof.ConsulttheroongsuppliertodeterminewhethertheClickFit
EVOhangerboltscanbeusedwithouttakingadditionalsteps.
Corrugatedsheets
3Onacorrugatedroofwithstandardcorrugationtype177/51(NENEN494),
usetheClickFitEVOcorrugatedsheetbracket(articlenumber1008090).At
www.esdec.comyouwillndthecorrespondingmanual.
Arabic tiles
Sheet steel
Roof structure
Purlins
Trusses
Engineeredwoodboards
Roof pitch 7.1-60°
Maximum roof height 4SubjecttoEurocodeguidelinesandnationaladditions.Usethecalculator
to calculate the possibilities of your project.
Edge zone 30cmdistancetotheridge,30cmtothesideoftheroofand30cmtothe
gutter.
3Enterthedatainthecalculator,soyouaresureofchoosingtherightsystemfortheterraincategory,snowloadsand
windzonethatappliestoyourproject.
4Dependingontheroofandtheresultobtainedfromthecalculator,youcanlayseveralsegmentswithsolarpanelsnextto
eachother.Alwaysleaveaminimumof10mmofspacebetweensegmentstoallowforexpansionoftheroof.
4Ifyourprojecthasdierentspecicationsthanthese,pleasecontactEsdec.
REQUIREMENTS FOR THE WORK ENVIRONMENT
Theroofisingoodcondition.
Theroofconstructionhassucientbearingcapacitytosupporttheinstallation,takingintoaccountwindandsnow
loads.
5
SYSTEM AND APPLICATION
1 COMPONENTS
3 4 5a
67 8 13
5b
910 11 12
12
COMPONENT ARTICLE NUMBER
1a.ClickFitEVOHangerbolt-M10×200mm 1008011
b.ClickFitEVOHangerbolt-M10×250mm 1008012
c.ClickFitEVOHangerbolt-M12×250mm 1008013
d.ClickFitEVOHangerbolt-M12×300mm 1008014
e.ClickFitEVOHangerbolt-M12×350mm[DTO] 1008015
2 ClickFitEVOMountingRail 10081__
3 ClickFitEVOModuleClampuniversal 1008020(-B)
4 ClickFitEVOMountingRailEndCap 1008060(-B)
5a.ClickFitEVOEndClampSupport 1008065(-B)
b.ClickFitEVOEndCapwithoutendclampsupport 1008066(-B)
ACCESSORY ARTICLE NUMBER
6 ClickFitEVOMountingRailCoupler 1008061
7 ClickFitEVOCableClipOptimiserReady 1008062
8 ClickFitEVOSelf-drillingSheetMetalScrew 1003015
9 ClickFitEVOmountingset 1008064
10 HangerboltwasherInox80mm 1003070
11 ShellTixophaltekitforbitumenroong 1003900
12 KitforEPDMRoong 1008086
13 ClickFitEVOScrewBitTorx30 1008069
4Checkthatthecorrectcomponentsarepresentintherequirednumbersaccordingtotheprojectplangeneratedbythe
calculator.
6
2 APPLICATION
4Usethecalculatortodeterminethecorrectrailorientationforyourproject.Thecalculatortakesintoaccount,for
example,thetypeofroofcoveringandthestructuresupportingtheroof.
1 Checktherooftypeandtheroofstructuretype.Isitaroofwithpurlinsortrusses,orwithsolidengineeringwoodboards?
2 Lookupthetypeofroofcoveringofyourprojectinthetable.
3 Checkthetablefortherecommendedorientationofthesolarpanelsandrails.
ROOF MATERIAL TRUSSES PURLINS ENGINEERED WOOD
BOARDS
BITUMEN INSULATED Portraitpanelsand
horizontalrails
Landscape panels and
vertical rails
Portraitpanelsand
horizontalrails
Landscape panels and
vertical rails
BITUMEN UNINSULATED X X
Portraitpanelsand
horizontalrails
Landscape panels and
vertical rails
EPDM (INSULATED AND
NON-INSULATED) X X
Portraitpanelsand
horizontalrails
Landscape panels and
vertical rails
ARABIC TILES X X
Portraitpanelsand
horizontalrails
Landscape panels and
vertical rails
CORRUGATED SHEETS XLandscape panels and
vertical rails X
STEEL ROOF TRAPEZOIDAL XLandscape panels and
vertical rails X
STEEL ROOF CORRUGATED
SHEETS XLandscape panels and
vertical rails X
STEEL ROOF TILES SHEETS Portraitpanelsand
horizontalrails
Landscape panels and
vertical rails
Portraitpanelsand
horizontalrails
Landscape panels and
vertical rails
7
SAFETY
1 PERSONAL PROTECTIVE EQUIPMENT
Hearing
protection Safety helmet Safetyglasses Facemasks Safetygloves Safetyclothing Safety shoes
2 SAFETY WARNINGS AND REGULATIONS
Warning!
6Installation work should always be carried out by at least two skilled people.
6Donotusecomponentsfromothermountingsystems.
6Donotleaveoutparts.
6Alwaysworkaccordingtothecurrentregulationsforworkingonroofs.
6Donotperformtheinstallationinstrongwinds,orwhentheroofisslipperyorwet.
6Alwaysworkontheroofwithfallprotectionand,ifnecessary,withsafetynetsandedgeprotection.
6Neverstandonorinthegutter.
6Alwaysusealiftingaidorhoistingdevicewhenmovingheavyequipment.
6Alwaysplaceladdersonastrong,stablesurface.
Caution!
3Walkaslittleaspossibleontheroof.Useanaerialplatform,ladderorothersolution.
3Neverwalkonthesystemoronthesolarpanels.
8
INSTALLATION
1 PREPARATION
1 INSPECT THE ROOF
Theroofisingoodcondition.
Theroofconstructionhassucientbearingcapacitytosupporttheinstallation,takingintoaccountwindandsnow
loads.
3ThethermaleectofsometypesofEPDMandbitumenroongcanhaveanegativeeectonthewaterproong,
causingitcannotbeguaranteedoneveryroof.ConsulttheroongsuppliertodeterminewhethertheClickFit
EVOhangerboltscanbeusedwithouttakingadditionalsteps.
2 CHECK THE PROJECT PLAN AND COMPONENTS
Checktheprojectplan.Istherenoprojectplan?Thencreateoneintheonlinecalculatorbeforestartinginstallation.
Checkthatallcomponentsarepresent(page5).
Determinethepositionofthehangerbolts.Usethepurlinsortrussesifpresent.
3 MAKE SURE ALL THE REQUIRED TOOLS ARE AT HAND
General
Markerorchalk Brush Tape measure Hacksaw Adjustable pliers
Cordless
screwdriver Torque wrench
Ratchet with
hexagonsocket
S13
Open-end wrench
(2x) Masticgun
Hanger bolt M10 Hanger bolt M12
Drill through roong material 12.5mm 14mm
Predrill holes in roof structure 5mm 7mm
Hexagon socket S7 S10
Open-end wrench S15 S19
9
4 CLEAN AND TIDY THE ROOF
5 DETERMINE THE POSITION OF THE SOLAR PANELS ON THE ROOF
≥ 30 cm
≥ 30 cm
≥ 30 cm
4Takeintoaccountsunlightandshadeoverthewholeyear.Ifnecessary,useapoweroptimizerormicroinvertertogetthe
most out of your installation.
3Thedistancefromtheedgeofsolarpanelstoboththeridgeandtheguttermustbeatleast30cm.
3Thedistancefromthesolarpanelstothesideoftheroofmustbeatleast30cm.
10
6 DRAW THE LINES AND END POINTS FOR THE MOUNTING RAILS
4Consulttheprojectplantodeterminethepositionofthemountingrailsforyourpanel.
7 MARK THE POSITION OF THE HANGER BOLTS.
3Preferablyuseexistingscrewholesfortheinstallationofthehangerbolts,especiallyoncorrugatedroofs.Ifyouusetoo
manyscrewsinacorrugatedsheetroof,itmeansthattheroofmaterialmayhavetoolittlespacetocompensatefor
thermalexpansion/contraction.
3Whenmeasuringandmarkingtheeld,takeintoaccountthepositionofthepurlinsortrusses.
4Consulttheprojectplantodeterminethepositionofthehangerboltsforyourproject.
