ESAB Aristo Origo Feed 4804 Manual de usuario

Aristo®, Origo™

Instruction manual

0444 408 201 GB 20171124 Valid for: serial no. 745-, 910-, 236-, 540-, 628-xxx-xxxx

Feed3004, Feed4804

TABLE OF CONTENTS

0444 408 201 © ESAB AB 2017

1SAFETY ....................................................................................................... 4

1.1 Meaning of symbols............................................................................... 4

1.2 Safety precautions ................................................................................. 4

2INTRODUCTION.......................................................................................... 8

2.1 Equipment............................................................................................... 8

2.2 Control panel .......................................................................................... 8

3TECHNICAL DATA ...................................................................................... 10

4INSTALLATION............................................................................................ 11

4.1 Lifting instructions ................................................................................. 11

5OPERATION ................................................................................................ 12

5.1 Connections and control devices ......................................................... 13

5.2 Water connections ................................................................................. 13

5.3 Wire feed pressure ................................................................................. 13

5.4 Replacing and inserting Feed 3004 wire .............................................. 14

5.5 Replacing and inserting Feed 4804 wire .............................................. 14

5.6 Changing feed rollers on Feed 3004..................................................... 15

5.7 Changing feed rollers on Feed 4804..................................................... 15

6MAINTENANCE........................................................................................... 16

6.1 Inspection and cleaning......................................................................... 16

7ORDERING SPARE PARTS ........................................................................ 17

DIAGRAM ............................................................................................................. 18

WEAR PARTS....................................................................................................... 20

ORDERING NUMBERS........................................................................................ 28

ACCESSORIES .................................................................................................... 29

Rights reserved to alter specifications without notice.

1 SAFETY

0444 408 201 -4- © ESAB AB 2017

1 SAFETY

1.1 Meaning of symbols

As used throughout this manual: Means Attention! Be Alert!

DANGER!

Means immediate hazards which, if not avoided, will result in immediate,

serious personal injury or loss of life.

WARNING!

Means potential hazards which could result in personal injury or loss of

life.

CAUTION!

Means hazards which could result in minor personal injury.

WARNING!

Before use, read and understand the instruction manual

and follow all labels, employer´s safety practices and Safety

Data Sheets (SDSs).

1.2 Safety precautions

Users of ESAB equipment have the ultimate responsibility for ensuring that anyone who

works on or near the equipment observes all the relevant safety precautions. Safety

precautions must meet the requirements that apply to this type of equipment. The following

recommendations should be observed in addition to the standard regulations that apply to

the workplace.

All work must be carried out by trained personnel well-acquainted with the operation of the

equipment. Incorrect operation of the equipment may lead to hazardous situations which can

result in injury to the operator and damage to the equipment.

1. Anyone who uses the equipment must be familiar with:

○ its operation

○ location of emergency stops

○ its function

○ relevant safety precautions

○ welding and cutting or other applicable operation of the equipment

2. The operator must ensure that:

○ no unauthorised person is stationed within the working area of the equipment

when it is started up

○ no-one is unprotected when the arc is struck or work is started with the

equipment

3. The workplace must:

○ be suitable for the purpose

○ be free from drafts

1 SAFETY

0444 408 201 -5- © ESAB AB 2017

4. Personal safety equipment:

○ Always wear recommended personal safety equipment, such as safety glasses,

flame-proof clothing, safety gloves

○ Do not wear loose-fitting items, such as scarves, bracelets, rings, etc., which

could become trapped or cause burns

5. General precautions:

○ Make sure the return cable is connected securely

○ Work on high voltage equipment may only be carried out by a qualified

electrician

○ Appropriate fire extinguishing equipment must be clearly marked and close at

hand

○ Lubrication and maintenance must not be carried out on the equipment during

operation

WARNING!

Wire feeders are intended to be used with power sources in MIG/MAG mode

only.

If used in any other welding mode, such as MMA, the welding cable between wire

feeder and power source must be disconnected, or else the wire feeder becomes

live or energized.

WARNING!

Arc welding and cutting can be injurious to yourself and others. Take precautions

when welding and cutting.

ELECTRIC SHOCK - Can kill

• Do not touch live electrical parts or electrodes with bare skin, wet gloves or

wet clothing

• Insulate yourself from work and ground.

• Ensure your working position is safe

ELECTRIC AND MAGNETIC FIELDS - Can be dangerous to health

• Welders having pacemakers should consult their physician before welding.

EMF may interfere with some pacemakers.

• Exposure to EMF may have other health effects which are unknown.

• Welders should use the following procedures to minimize exposure to

EMF:

○ Route the electrode and work cables together on the same side of

your body. Secure them with tape when possible. Do not place your

body between the torch and work cables. Never coil the torch or

work cable around your body. Keep welding power source and

cables as far away from your body as possible.

○ Connect the work cable to the workpiece as close as possible to the

area being welded.

FUMES AND GASES - Can be dangerous to health

• Keep your head out of the fumes

• Use ventilation, extraction at the arc, or both, to take fumes and gases

away from your breathing zone and the general area

1 SAFETY

0444 408 201 -6- © ESAB AB 2017

ARC RAYS - Can injure eyes and burn skin

• Protect your eyes and body. Use the correct welding screen and filter lens

and wear protective clothing

• Protect bystanders with suitable screens or curtains

NOISE - Excessive noise can damage hearing

Protect your ears. Use earmuffs or other hearing protection.

MOVING PARTS - Can cause injuries

• Keep all doors, panels and covers closed and securely in place. Have only

qualified people remove covers for maintenance and troubleshooting as

necessary. Reinstall panels or covers and close doors when service is

finished and before starting engine.

• Stop engine before installing or connecting unit.

• Keep hands, hair, loose clothing and tools away from moving parts.

FIRE HAZARD

• Sparks (spatter) can cause fire. Make sure therefore that there are no

inflammable materials nearby

• Do not use on closed containers.

MALFUNCTION - Call for expert assistance in the event of malfunction.

PROTECT YOURSELF AND OTHERS!

CAUTION!

This product is solely intended for arc welding.

CAUTION!

Class A equipment is not intended for use in residential

locations where the electrical power is provided by the

public low-voltage supply system. There may be potential

difficulties in ensuring electromagnetic compatibility of class

A equipment in those locations, due to conducted as well

as radiated disturbances.

NOTE!

Dispose of electronic equipment at the recycling

facility!

In observance of European Directive 2012/19/EC on Waste

Electrical and Electronic Equipment and its implementation

in accordance with national law, electrical and/or electronic

equipment that has reached the end of its life must be

disposed of at a recycling facility.

As the person responsible for the equipment, it is your

responsibility to obtain information on approved collection

stations.

For further information contact the nearest ESAB dealer.

1 SAFETY

0444 408 201 -7- © ESAB AB 2017

ESAB has an assortment of welding accessories and personal protection equipment

for purchase. For ordering information contact your local ESAB dealer or visit us on

our website.

2 INTRODUCTION

0444 408 201 -8- © ESAB AB 2017

2 INTRODUCTION

The wire feed unit Feed 3004 with control panel U6,MA23,MA24 or MA25 Pulse is

intended for MIG/MAG welding together with 400A, 500A and 600A CAN welding power

sources.

The wire feed unit Feed 4804 with control panel U6,MA23 or MA24 is intended for

MIG/MAG welding together with 400A, 500A and 600A CAN welding power sources.

The wire feed units contain four-wheel drive wire feed mechanisms as well as control

electronics.

They can be used together with wire on ESAB's MarathonPac™, or on wire bobbin (standard

Ø 300 mm, accessory Ø 440 mm).

The wire feed unit can be installed either on the power source trolley, suspended above the

workplace, on a counter balance device or on the floor with or without wheel set.

ESAB's accessories for the product can be found in chapter "ACCESSORIES" of this

manual.

2.1 Equipment

The wire feed unit is supplied with:

• instruction manual for the wire feed unit

• instruction manual in English for the control panel

Instruction manuals in other languages can be downloaded from the Internet:

www.esab.com

• decal with recommended wear parts.

2.2 Control panel

The wire feed unit is supplied with one of the following control panels:

Empty panel for use with double wire feed units or

with use of control box U82.

Knobs for setting the voltage and the wire feed speed

/ current. Other parameters are controlled by

pushbuttons, with text in the display panel.

MA23

Knobs for setting the voltage and the wire feed speed

/ current. Other settings with push buttons.

MA24

Knobs for setting the voltage / QSet™ and the wire

feed speed / current. Other settings with push

buttons.

2 INTRODUCTION

0444 408 201 -9- © ESAB AB 2017

MA25

Pulse

Knobs for setting the voltage / QSet™ and the wire

feed speed / current. Other settings with push

buttons.

See the separate instruction manual for a detailed description of the control panels.

3 TECHNICAL DATA

0444 408 201 - 10 - © ESAB AB 2017

3 TECHNICAL DATA

Feed 3004 Feed 4804

Mains voltage 42 V 50-60 Hz 42 V 50-60 Hz

Power requirement 336 VA 378 VA

Motor current Imax 8 A 9 A

Wire feed speed 0.8 - 25.0 m/min 0.8 - 25.0 m/min

Torch connection EURO EURO

Max. diameter wire bobbin 300 mm (*440 mm) 300 mm (*440 mm)

Wire dimension

Fe 0.8 - 1.6 mm 0.8 - 2.4 mm

Ss 0.8 - 1.6 mm 0.8 - 2.4 mm

Al 1.0 & 1.6 mm 1.0 & 2.4 mm

Cored wire 0.9 - 1.6 mm 0.9 - 2.4 mm

Weight 15 kg 19 kg

Dimensions (l x w x h) 690 x 275 x 420 mm 690 x 275 x 420 mm

Operating temperature -10 to +40°C -10 to +40°C

Shielding gas All types intended for

MIG/MAG welding

All types intended for

MIG/MAG welding

max pressure 0.5 MPa ( 5 bar) 0.5 MPa ( 5 bar)

Coolant ESAB's ready mixed coolant ESAB's ready mixed coolant

max pressure 0.5 MPa ( 5 bar) 0.5 MPa ( 5 bar)

Maximum permissible load at

60% duty cycle 630 A 630 A

100% duty cycle 500 A 500 A

Enclosure class IP23 IP23

*Accessories can be found in the "ACCESSORIES" chapter.

Duty cycle

The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or

cut at a certain load without overloading. The duty cycle is valid for 40°C/104°F, or below.

Enclosure class

The IP code indicates the enclosure class, i.e. the degree of protection against penetration

by solid objects or water.

Equipment marked IP23 is intended for indoor and outdoor use.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de soldadura de ESAB

ESAB

ESAB ES 180i Manual de usuario

ESAB

ESAB MECHTIG 160 Manual de usuario

ESAB

ESAB PCM-500i Manual de usuario

ESAB

ESAB Caddy 140 Manual de usuario

ESAB

ESAB Aristo Origo Feed 3004 Manual de usuario

ESAB

ESAB HandyPlasma 50 Manual de usuario

ESAB

ESAB ORIGO Mig C280 PRO Manual de usuario

ESAB

ESAB Retrofit Aristo Mig 4004i WeldCloud Manual de usuario

ESAB

ESAB Warrior 400i CC/CV Manual de usuario

ESAB

ESAB LTR 160 Manual de usuario

ESAB

ESAB Aristo Mig U5000i 400 V Manual de usuario

ESAB

ESAB Caddy Tig 1500i Manual de usuario

ESAB

ESAB ESP-101 Manual de usuario

ESAB

ESAB Caddy Tig 1500i TA34 Manual de usuario

ESAB

ESAB MIG-41 Manual de usuario

ESAB

ESAB OrigoMag C140 Manual de usuario

ESAB

ESAB Cutmaster 60 Manual de usuario

ESAB

ESAB Fabricator 252i Manual de usuario

ESAB

ESAB Origo Arc 458T Guía

ESAB

ESAB EMP 205ic AC/DC Manual de usuario

ESAB

ESAB LHJ 750 Manual de usuario

ESAB

ESAB Renegade ES 210i Manual de usuario

ESAB

ESAB Precision Plasmarc EPP-600 Manual de usuario

ESAB

ESAB LTH 161 Manual de usuario

Manuales populares de Sistema de soldadura de otras marcas

Berner

Berner PLASMACUT 54 Manual de usuario

Pro Spot

Pro Spot PR-155 Manual de usuario

Forney

Forney 210 Manual de usuario

Thermal Arc

Thermal Arc 400S Manual de usuario

Lincoln Electric

Lincoln Electric HANDYMIG 170I Manual de usuario

GYS

GYS PROTIG 201 AC/DC Manual de usuario

TAFA

TAFA 30*8B35 Manual de usuario

Lincoln Electric

Lincoln Electric INVERTEC V350-PRO CE Manual de usuario

CIGWELD

CIGWELD 636804 Guía rápida

Red-D-Arc

Red-D-Arc DC-400 Manual de usuario

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 Manual de usuario

Elettro

Elettro HI-MIG 3000 SYNERGIC Manual de usuario

WIA

WIA Weldmatic 270 CP132-2 Manual de usuario

Sonics

Sonics H520T Manual de usuario

Miller

Miller Big Blue 400D Manual de usuario

NewArc

NewArc RT2000 Guía de inicio rápido

Hypertherm

Hypertherm powermax1000 Manual de usuario

Lincoln Electric

Lincoln Electric POWER WAVE I400 Manual de usuario
