ERNITEC Orion DX 822IR Manual de usuario

User’s Manual

Orion DX 822IR

SSSSSeriesseries

User’s Manual – Orion DX 822IR

www.ernitec.com

V 01101116

Caution and Preventive Tips

Important Information

Before proceeding, please read and observe all instructions and warnings in this manual.

Retain this manual with the original bill of sale for future reference and, if necessary,

warranty service. When unpacking your unit, check for missing or damaged items. If any

item is missing, or if damage is evident, DO NOT INSTALL OR OPERATE THIS

PRODUCT. Contact your dealer for assistance.

Handle with care, do not drop the unit

Mount the unit in an equipment rack or place it on a solid, stable surface

Indoor use only. Do not place the unit in a humid, dusty, oily, or smoky site

Do not place it in an area with poor ventilation or in an area close to fire or other

sources of heat. Doing so may damage the unit as well as cause fire or an electric

shock

When cleaning is necessary, shut down the system and unplug the unit from the

outlet before uncovering the top cover. Do not use liquid cleaners or aerosol

cleaners. Use only a damp cloth for cleaning

Always shut down the system prior connecting or disconnecting accessories, with

the exception of USB devices

Under copyright laws, the contents of this user manual may not be copied, photocopied,

translated, reproduced or reduced to any electronic medium or machine-readable format,

in whole or in part, without prior written permission of the company.

Important Information

Before proceeding, please read and observe all instructions and warnings in this manual.

Retain this manual with the original bill of sale for future reference and, if necessary,

warranty service. When unpacking your unit, check for missing or damaged items. If any

item is missing, or if damage is evident, DO NOT INSTALL OR OPERATE THIS

PRODUCT. Contact your dealer for assistance.

User’s Manual – Orion DX 822IR

www.ernitec.com

V 01101116

Regulation

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause

undesired operation.

This symbol on the product or on its packaging indicates that this product

shall not be treated as household waste in accordance with Directive

2002/96/EC. Instead it shall be handed over to the applicable collection

point for the recycling of electrical and electronic equipment. By proper

waste handling of this product you ensure that it has no negative

consequences for the environment and human health, which could

otherwise be caused if this product is thrown into the garbage bin. The

recycling of materials will help to conserve natural resources.

For more details information about recycling of this product, please contact

your local city office, your household waste disposal service or the shop

where you purchased the product.

This symbol intends to alert the user to the presence of unprotected

“Dangerous Voltage”within the product’s enclosure that may be strong

enough to cause a risk of electric shock.

This symbol intends to alert the user to the presence of important operating

and maintenance (servicing) instructions in the literature accompanying the

appliance.

Compliance is evidenced bywritten declaration from our suppliers,assuring

that any potential trace contamination levels of restricted substances are

below the maximum level set by EU Directive 2002/95/EC, or are exempted

due to their application.

User’s Manual – Orion DX 822IR

www.ernitec.com

V 01101116

Table of Contents

1. Overview ..............................................................................................................4

1.1 Features................................................................................................................4

1.2 Package Contents.................................................................................................5

1.3 Dimensions............................................................................................................6

1.4 Connectors.........................................................................................................7

2. Camera Cabling...................................................................................................8

2.1 Power Connection.................................................................................................9

2.2 Ethernet Cable Connection ...................................................................................9

2.3 Audio/AIarm I/O & RS-485 Connection ...............................................................10

3. System Requirements.......................................................................................11

4. Access Camera..................................................................................................12

5. Setup Video Resolution....................................................................................15

6. Configuration Files Export / Import .................................................................16

7. Tech Support Information.................................................................................17

7.1 Delete the Existing DCViewer .............................................................................17

7.2 Setup Internet Security........................................................................................18

Appendix: Technical Specifications

User’s Manual – Orion DX 822IR

www.ernitec.com

V 01101116

1. OVERVIEW

With the latest encoding technology and built-in IR LEDs, Network IR PTZ

Camera presents strong HDR and high sensitivity performance, and is

capable of capturing high resolution images during daylight hours and even,

in pitch-black darkness.

At night, or in any environment where there is low/zero lighting, Network IR

PTZ Camera is able to provide effective illumination to the objects 200 meters

away, and also deliver crystal clear and image with high quality 30x optical

zoom lens in long distance.

With delicate mechanism design, Network IR PTZ Camera features Servo

Feedback technology, which makes the camera precisely return to the

previous position without stalling, and ensures the target monitoring region

is fully secured when encountering environmental vibrations. IP66

International standard is also guaranteed for outdoor installation.

Furthermore, combining 0 downtime power switching (ZDT) technology, the

camera ensures smooth streaming without sudden power-loss.

1.1 FEATURES

Sony Progressive Scan CMOS Sensor 2M/3M/4M Resolution*

Up to 30x Optical Zoom

10x Digital Zoom Support

High Dynamic Range (120dB)

Quad Stream Support

Quad Codec: H.264 Baseline / Main / High Profile + MJEPG

True Day & Night (ICR)

2D/3D Noise Reduction

802.3at PoE+ With 4 Pair Support for IR & Heater Activation

Cisco UPoE Support

Servo Feedback

Weatherproof (IP66 International)

0 Downtime Power Switching (ZDT)

IR Distance up to 200m*

IR Illumination Adjustment by Zoom Ratio

*Optional

User’s Manual – Orion DX 822IR

www.ernitec.com

V 01101116

1.2 PACKAGE CONTENTS

Please check the box contains the items listed here. If any item is missing or

has defects, DO NOT install or operate the product and contact the dealer

for assistance.

Outdoor

Network IR PTZ Camera

M4 Security Screw with Rubber

Quick Guide

3-Pin Power

Terminal Block

14-Pin Alarm/Audio I/O

Terminal Block

NOTE: To purchase power adaptor, please contact the camera manufacturer for

further information.

User’s Manual – Orion DX 822IR

www.ernitec.com

V 01101116

1.3 DIMENSIONS

User’s Manual – Orion DX 822IR

www.ernitec.com

V 01101116

1.4 CONNECTORS

Refer to the diagrams below for the positions of the reset button and various

connectors of the camera. Definition of the reset button and the connectors

are given as follow.

*Do NOT connect external power supply to the alarm I/O connector of the camera.

**Please contact the manufacturer for compatible PoE injector.

NOTE: DV 12V power jack and AC 24V power connector cannot be used at

the same time in case of unexpected damage.

NOTE: It is not recommended to record with the SD card for 24/7

continuously, as it may not be able to support long term continuous data

read/write. Please contact the manufacturer of the SD card for information

regarding the reliability and the life expectancy.

No.

Connector

Definition

Audio/Alarm I/O & RS-485

Connector *

Audio/Alarm I/O & RS-485 connection

Power Connector (DC 12V)

DC 12V power connection

RJ-45 Port **

IEEE 802.3at (PoE+) 4-Pair 60W only

Power Connector (AC 24V)

AC 24V power connection

BNC

For analog video output

Reset Button

Press the button with a proper tool for at least 20

seconds to restore the system.

SD Card Slot

Insert the SD card into the card slot to store

videos and snapshots. Do not remove the SD

card when the camera is powered on.

User’s Manual – Orion DX 822IR

www.ernitec.com

V 01101116

2. CAMERA CABLING

The outdoor models are being IP66-rated to prevent water from entering the

camera. However, water might still enter the camera if it is being improperly

installed. Please make sure the warnings below are strictly followed when

installing the camera.

Place all cables and the adaptor in dry and well-waterproofed

environments, e.g. waterproof boxes. The purpose is to prevent

moisture accumulation inside the camera and moisture penetration

into cables.

While running cables, slightly bend the cables to a U-shaped curve to

make a low point (as demonstrated in the figures below). The purpose

is to prevent water from entering the camera along the cables from

above.

The cable entry hole of the outdoor mounting kit (indicated in the figure

below) needs to be sealed with thread seal tape to avoid water from

entering the camera.

User’s Manual – Orion DX 822IR

www.ernitec.com

V 01101116

2.1 POWER CONNECTION

To power up the camera, connect the DC 12V / AC 24V power adaptor to the

power connector of the camera and the power outlet. Refer to the diagram

and pin definition table below for AC 24V power connection.

Definition

AC 24V N

GND

AC 24V L

Alternatively, users can use an Ethernet cable and connect it to the RJ-45

port of the camera and an IEEE 802.3at (PoE+) 4-Pair 60W switch.

Zero Downtime Power Switching (ZDT)

When users connect DC12V power jack and the RJ-45 port at the same time,

the power input comes from the DC 12V connector. If the DC 12V power

source fails, the camera will switch power input seemly to the RJ-45 port until

the DC 12V power source is restored.

2.2 ETHERNET CABLE CONNECTION

To connect one end of the Ethernet cable to the RJ-45 connector of the

camera, and plug the other end of the cable to the network switch or PC.

NOTE: In some cases, Ethernet crossover cable might be needed

when connecting the camera directly to the PC.

NOTE: Check the status of the link indicator and activity indicator

LEDs. If the LEDs are unlit, please check the LAN connection.

Green Link Light indicates good network connection.

Orange Activity Light flashes for network activity indication.

Tabla de contenidos

Otros manuales de Cámara de seguridad de ERNITEC

ERNITEC

ERNITEC MicroView MVID-03IR-E Manual de usuario

ERNITEC

ERNITEC DS-2CD6986F-H Manual de usuario

ERNITEC

ERNITEC Orion/3-DN Outdoor Instrucciones de montaje

ERNITEC

ERNITEC MicroView MVCLOUD-201 Manual de usuario

ERNITEC

ERNITEC Orion SX Series Manual de usuario

ERNITEC

ERNITEC MicroView MVIC-O4IR-E Manual de usuario

ERNITEC

ERNITEC MicroView MVCLOUD-201 Manual de usuario

ERNITEC

ERNITEC Orion/2 Manual de usuario

ERNITEC

ERNITEC DS-2CD6924G0-IHS Manual de usuario

ERNITEC

ERNITEC Orion/2 Manual de usuario

ERNITEC

ERNITEC MVID-04IR-E Manual de usuario

ERNITEC

ERNITEC MERCURY SX 5TH GENERATION Manual de usuario

ERNITEC

ERNITEC Orion DX 832 IR Manual de usuario

ERNITEC

ERNITEC Orion Manual de usuario

ERNITEC

ERNITEC MicroView MVIC-04IR-E Manual de usuario

ERNITEC

ERNITEC Mercury SX4 series Manual de usuario

ERNITEC

ERNITEC EVA 101 Manual de usuario

ERNITEC

ERNITEC ECB Series Manual de usuario

ERNITEC

ERNITEC Performance Series Manual de usuario

ERNITEC

ERNITEC Orion/2 Guía

ERNITEC

ERNITEC MicroView MVIB-04IR-E Manual de usuario

ERNITEC

ERNITEC Corona IP-452 IR Manual de usuario

ERNITEC

ERNITEC Orion DX 3 Manual de usuario

ERNITEC

ERNITEC SX Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
