Epson WorkForce Pro WP-4015 DN Manual de usuario

DO NOT INSTALL THE EPSON (OEM) INKS THAT WERE PROVIDED WITH THE PRINTER.

DO NOT POWER ON THE PRINTER BEFORE INSTALLING SAWGRASS SUBLIJET-E PRO INK CARTRIDGES.

POWER LOSS MAY CAUSE CARTRIDGE CHIP FAILURE. USE AN UNINTERRUPTIBLE POWER SUPPLY (UPS)

TO AVOID ACCIDENTAL POWER LOSS.

REMOVE CARTRIDGE BEFORE POWERING PRINTER OFF. FAILURE TO REMOVE CARTRIDGE PRIOR TO

POWERING OFF MAY RESULT IN CHIP FAILURE.

CARTRIDGE CHIP DOES NOT INDICATE DEPLETION. REPLACE CARTRIDGE ONCE THE LOW INK INDICA-

TOR LIGHT FLASHES

CAUTION

Epson WorkForce Pro WP-4015 DN

WinProle

INSTALLATION GUIDE

WIN OS

v20120713

SECTIONS:

Microsoft Windows Operating System Verication - Page 3

Epson Driver Download & Installation - Page 4

WinProle Installation & Registration - Page 10

Epson WorkForce Pro WP-4015 DN – Installation Guide

Microsoft Windows OS Verication

PAGE 3 of 15 >>

FIGURE 1

FIGURE 2

Before you begin, you will need to verify the Windows edition and system type you are using on your PC.

This is important when deciding which drivers to download.You should only download those drivers, which

are compatible with your operating system.

1.) To check the version of your operating system, rst click the Start icon in the bottom left corner of your

desktop. Then, right-click Computer. Finally, click Properties (see FIGURE 1).

2.) The following screen containing the Windows Edition and System Type should appear (see FIGURE 2).

The below example is running Windows 7 on a 64-bit OS. Please note your version number and remember

to only download those utilities which correspond with your version of Windows OS.

Epson WorkForce Pro WP-4015 DN – Installation Guide

Epson Driver Download & Installation

PAGE 4 of 15 >>

1.) Access the Epson website by entering http://www.epson.co.uk in the address eld of your web browser then

select the support section.

FIGURE 1

2.) Type 4015 into the search eld then select your printer model from the list (see FIGURE 2).

FIGURE 2

The following instructions will demonstrate how to install the Epson printer driver on computers running Windows

operating systems.

Note: Before installing the SubliJet-IQ 4015 WinProle, you will need to install the Epson printer driver.

Epson WorkForce Pro WP-4015 DN – Installation Guide

Epson Driver Download & Installation

PAGE 5 of 15 >>

3.) Ensure that the correct operating system is selected, click the Drivers & Software link to expand the

section. Click the Download to initiate the download (see FIGURE 3).

FIGURE 3

4.) Click the Download button to proceed (see FIGURE 4). The email address eld only needs to be

completed if you wish to recieve marketing emails from Epson.

FIGURE 4

Epson WorkForce Pro WP-4015 DN – Installation Guide

Epson Driver Download & Installation

PAGE 6 of 15 >>

5.) Select Desktop as your download destination and click Save (see FIGURE 5).

FIGURE 5 2

FIGURE 6

6.) Once the download has completed, double-click the executable icon to begin the installation process (see

FIGURE 6).

Epson WorkForce Pro WP-4015 DN – Installation Guide

Epson Driver Download & Installation

PAGE 7 of 15 >>

7.) Click the Run button (see FIGURE 7).

8.) Click the Setup button (see FIGURE 8).

FIGURE 7

FIGURE 8

FIGURE 9

9.) Highlight the icon that corresponds to your printer model and click OK (see FIGURE 9).

Epson WorkForce Pro WP-4015 DN – Installation Guide

Epson Driver Download & Installation

PAGE 8 of 15 >>

11.) Check Accept and click OK the license agreement to continue (see FIGURE 11).

10.) Select the appropriate language and click OK (see FIGURE 10).

FIGURE 10

FIGURE 11

Epson WorkForce Pro WP-4015 DN – Installation Guide

Epson Driver Download & Installation

PAGE 9 of 15 >>

FIGURE 12

Congratulations! The Epson printer driver installation is complete. Please proceed to the WinProle Installa-

tion & Registration section.

12.) Ensure that the pritner is powered on when you see the following window (see FIGURE 12).

13.) When the installation is complete you will see the following window, click OK (see FIGURE 13).

FIGURE 13

Epson WorkForce Pro WP4015 DN – Installation Guide

WinProle Installation & Registration

PAGE 10 of 15 >>

2.) You should now see the SubliJet-IQ_4015_v1.0.0.exe icon on

your desktop (see FIGURE 2). Double-click the icon to begin the

installation process.

FIGURE 1

FIGURE 2

1.) Download the WinProle by accessing the Sawgrass Europe website by entering

www.sawgrasseurope.com in the address eld of your web browser. Once there, navigate to:

Technical Support > SubliJet-IQ Technical Support > ICC Proles and click on the Epson

WorkForce Pro WP-4015 DN ICC Prole driver download link and save the le to your desktop: (see

FIGURE 1).

WinProle Installation

SubliJet-IQ_4015_v1.0.0.exe
