Epson PowerLite Pro G5650W Manual de usuario

PC Free Operation Guide

PC Free Summary

What You Can Do Using PC Free. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

PC Free Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Specifications for Files that can be Projected Using PC Free . . . . . . . . . . . . . . . 5

Supported movie data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Using PC Free

PC Free Operating Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Starting and Closing PC Free. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Starting PC Free. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Closing PC Free . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

PC Free Basic Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Rotating the Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Projecting Files Created with PowerPoint. . . . . . . . . . . . . . . . . . . . . . 11

Playing a Scenario . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Operations While Playing Back Scenarios. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Projecting Image and Movie Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Projecting Movies and Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Projecting Image Files in a Folder in Sequence (Slideshow) . . . . . . . . . . . . . . 14

Operation setting for slideshow. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Appendix

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Other functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Basic Scenario (SIT file) Editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Registering a Digital Certificate to the Projector . . . . . . . . . . . . . . . . . . . . . . . . . 20

Digital certificates that can be registered . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Registering a Client Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Registering a CA Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Copyright Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Contents

PC Free Summary

What You Can Do Using PC Free 4

What You Can Do Using PC Free

You can use PC Free to directly project files stored on USB storage

devices and digital cameras that are connected to the projector.

PC Free Examples

You can use PC Free to project individual movie or image files or to

continuously project slide shows using more than one file.

If you convert your PowerPoint file into a file format that can be

projected by PC Free and store the file on a USB storage device, you can

project a PowerPoint slide show without connecting a computer.

s"Projecting Files Created with PowerPoint" p.11

The supplied EasyMP Slide Converter application software makes it easy

to convert PowerPoint files. See the EasyMP Slide Converter Operation

Guide for details.

Projecting images and movies stored on a USB storage device

mpg

mp4

wmv

bmp

gif

jpg

png

s"Projecting Image and Movie Files" p.13

s"Projecting Image Files in a Folder in Sequence (Slideshow)" p.14

Projecting a PowerPoint slide show without connecting to a computer

What You Can Do Using PC Free 5

Specifications for Files that can be Projected Using PC

Free

* You can also project scenarios (SIT files) created using the EMP

SlideMaker/EMP SlideMaker2 supplied for other projectors.

Supported movie data

* Files with the extension .mpeg cannot be projected.

q•USB storage devices that incorporate security functions sometimes cannot

be used.

•Files to which DRM (Digital Rights Management) is applied cannot be

projected.

•If you use a USB storage device with a slow access speed when playing back

movies (when transmitting at higher bit rates), the movie files may not play

back correctly or the sound may skip or not be output.

•The projector does not support media formatted on some file systems. If you

have trouble when projecting, use media formatted under Windows.

•Format the media using the FAT16/32 file system.

Type File Type

(Extension)

Notes

Scenario

file

.fse

.sit*

This is the file format that can be played using

PC Free. EasyMP Slide Converter can be used

to convert PowerPoint files to this format. In

this Guide these files are known as scenarios.

Image .jpg The following cannot be projected.

•Images with a resolution greater than

8192 × 8192

•Images with a file size greater than 12 MB

•Files with the extension ".jpeg"

•CMYK color mode formats

•Progressive formats

Normally, the image may not be projected

clearly if compression is set too high.

.bmp Cannot project images with a resolution

greater than 1280 × 800.

.gif •Cannot project images with a resolution

greater than 1280 × 800.

•Cannot project animated GIFs.

.png Cannot project images with a resolution

greater than 1280 × 800.

File Type

(Extension)

Movie

Codec

Audio Codec Recording

Quality

.mpg*MPEG-2 MPEG-1 Layer1/2

MPEG contents with no

sound can be played

back.

Linear PCM and AC-3

audio cannot be played

back.

Highest frame rate:

30 fps

Maximum

resolution:

720 × 480 (NTSC)

720 × 576 (PAL)

.mp4*MPEG-4 ASP

MPEG-4 AVC

MPEG-4 AAC-LC

.wmv

.asf

WMV8

WMV9

WMA

Using PC Free

PC Free Operating Procedure 7

PC Free Operating Procedure

Starting and Closing PC Free

Starting PC Free

Procedure

ASwitch the projected image to USB.

See your projector User’s Guide.

BConnect the USB storage device or digital camera to the USB

(type A) port on the projector.

When connecting a digital camera, use the USB cable provided

with your digital camera, or the specified USB cable.

Caution:

•If you use a USB hub, the connection do not operate correctly. Devices such as

digital cameras and USB storage devices should be connected to the projector

directly.

•When connecting and using a USB-compatible hard disk, make sure you connect

the AC adaptor supplied with the hard disk.

•When connecting a digital camera or hard disk, use the USB cable provided with the

device, or the specified USB cable.

•Use a USB cable that is less than 3 m in length. If the cable exceeds 3 m, PC Free may

not function correctly.

CPC Free starts and the file list screen is displayed.

PC Free Operating Procedure 8

JPEG files and MPEG files are displayed as thumbnails (file contents are

displayed as small images). Scenarios (FSE files and SIT files) are

displayed as thumbnails as the first image in the slide. Other files or

folders are displayed as icons as shown in the following table.

* When it cannot be displayed as a thumbnail, it is displayed as an icon.

q•When AutoRun is set for a scenario, it is automatically played back with

the highest priority over other input sources. If you want to stop it from

playing back, press the Esc button on the remote control. sp.11

•You can also connect a memory card to the projector by loading it in a USB

card reader. However, some card readers may not be compatible.

•When the following screen (Select Drive screen) is displayed, press the [h]

button on the remote control or [w/],[v/],[</]and[>/]

buttons on the control panel to select the drive you want to use, and then

press the Enter button.

•To display the Select Drive screen, position the cursor on Select Drive in the

top half of the file list screen, and then press the Enter button.

•The projector can recognize up to eight media at a time.

Icon File Icon File

FSE files*SIT files*

JPEG files*MPEG files

BMP files WMV files

GIF files PFX files

(client certificate)

PNG files CER files

(CA certificate)

PC Free Operating Procedure 9

Closing PC Free

Procedure

AIf you are playing back a file, end the playback.

Ending movie or image playback sp.13

Ending scenario playback sp.11

Ending Slideshow sp.14

BRemove the USB device from the projector.

For digital cameras, hard disks, and so on, turn off the power to the

device and then disconnect.

Caution:

Do not disconnect the USB device from the projector while it is being accessed.

PC Free Basic Operations

The following describes the procedures for playing images, movies, and

scenarios, using PC Free, and projection operations.

Procedure

APress the [h] button on the remote control or [w/],

[v/ ], [</]and[>/ ] buttons on the control panel to

position the cursor on the file or folder you want to access.

qIf all files and folders cannot be displayed at the same time in the current

screen, press the Page (]) button or position the cursor on Next page at the

bottom of the screen and press the Enter button.

To return to the previous screen, press the Page ([) button or position the

cursor on Previous page at the top of the screen and press the Enter button.

BPress Enter.

The selected image is displayed.

When a folder is selected, the files in the selected folder are dis-

played. Select Back to Top on the screen that opened and press the

Enter button to return to the previous screen.

1Cursor

PC Free Operating Procedure 10

Rotating the Image

You can rotate the image in 90° increments when projecting an image file

with PC Free.

Procedure

Press the [h] button on the remote control or the [w/]and

[v/ ] buttons on the control panel to rotate the image.

Using the remote control Using the control panel
