CMOS 8-BIT SINGLE CHIP MICROCOMPUTER

(S1C88 Family In-Circuit Emulator)

S5U1C88000H5

Manual

NOTICE

No part of this material may be reproduced or duplicated in any form or by any means without the written permission of Seiko

Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any

liability of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or

circuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such

as medical products. Moreover, no license to any intellectual property rights is granted by implication or otherwise, and there

is no representation or warranty that anything made in accordance with this material will be free from any patent or copyright

infringement of a third party. This material or portions thereof may contain technology or the subject relating to strategic

products under the control of the Foreign Exchange and Foreign Trade Law of Japan and may require an export license from

the Ministry of International Trade and Industry or other approval from another government agency.

Windows 95, Windows 98 and Windows NT are registered trademarks of Microsoft Corporation, U.S.A.

PC/AT and IBM are registered trademarks of International Business Machines Corporation, U.S.A.

All other product names mentioned herein are trademarks and/or registered trademarks of their respective owners.

The information of the product number change

Configuration of product number

Devices

Comparison table between new and previous number

S1C88 Family processors

Starting April 1, 2001, the product number has been changed as listed below. Please use the new

product number when you place an order. For further information, please contact Epson sales

representative.

S1 C 88104 F 0A01

Packing specification

Specification

Package (D: die form; F: QFP)

Model number

Model name (C: microcomputer, digital products)

Product classification (S1: semiconductor)

Development tools

S5U1 C 88348 D1 1

Packing specification

Version (1: Version 1 ∗2)

Tool type (D1: Development Tool ∗1)

Corresponding model number (88348: for S1C88348)

Tool classification (C: microcomputer use)

Product classification

(S5U1: development tool for semiconductor products)

∗1: For details about tool types, see the tables below. (In some manuals, tool types are represented by one digit.)

∗2: Actual versions are not written in the manuals.

Previous No.

E0C88104

E0C88112

E0C88308

E0C88316

E0C88317

E0C88348

E0C88P348

E0C88349

New No.

S1C88104

S1C88112

S1C88308

S1C88316

S1C88317

S1C88348

S1C8P348

S1C88349

Previous No.

E0C88365

E0C88F360

E0C88408

E0C88409

E0C88816

E0C88832

E0C88862

E0C88F816

New No.

S1C88365

S1C8F360

S1C88408

S1C88409

S1C88816

S1C88832

S1C88862

S1C8F816

Comparison table between new and previous number of development tools

Development tools for the S1C88 Family

Development tools for the S1C63/88 Family

Previous No.

88ISAIF

ADP88348

ADP88360

DEV88104

DEV88112

DEV88308

DEV88316

DEV88317

DEV88348

DEV88365

DEV88408

DEV88409

New No.

S5U1C88000H4

S5U1C88348X

S5U1C88360X

S5U1C88104D

S5U1C88112D

S5U1C88308D

S5U1C88316D

S5U1C88317D

S5U1C88348D

S5U1C88365D

S5U1C88408D

S5U1C88409D

Previous No.

DEV88816

DEV88832

DEV88862

DMT88348-DB

ICE88UR

PRC88316

PRC88348

PRC88365

PRC88409

PRC88816

SAP88

URS88348

New No.

S5U1C88816D

S5U1C88832D

S5U1C88862D

S5U1C88348T

S5U1C88000H5

S5U1C88316P

S5U1C88348P

S5U1C88365P

S5U1C88409P

S5U1C88816P

S5U1C88000S

S5U1C88348Y

Previous No.

ADS00002

GWH00002

URM00002

New No.

S5U1C88000X1

S5U1C88000W2

S5U1C88000W1

CONTENTS

S5U1C88000H5 EPSON i

(S1C88 FAMILY IN-CIRCUIT EMULATOR)

S5U1C88000H5 Manual (S1C88 Family In-Circuit Emulator)

This manual explains the use of the in-circuit emulator (S5U1C88000H5), setting up the system and

starting up the debugger.

For the functions and operations of the debugger, see the help topics displayed in the debugger.

See also the tool manuals below which are provided for each model.

- S5U1C88xxxP Manual

- S5U1C88xxxD Manual or S1C88 Family Development Tool Manual

CONTENTS

CHAPTER 1PREFACE ________________________________________________ 1

1.1 Outline...........................................................................................................1

1.2 Operating Environment ................................................................................ 1

CHAPTER 2 S5U1C88000H5 PACKAGE __________________________________ 2

2.1 Components ..................................................................................................2

2.2 Component Specifications ............................................................................ 2

CHAPTER 3IN-CIRCUIT EMULATOR (S5U1C88000H5) ______________________ 3

3.1 Outline...........................................................................................................3

3.2 Operating Environmental Conditions .......................................................... 3

3.3 Specifications of Operation Panel................................................................4

CHAPTER 4SETTING UPEQUIPMENT ____________________________________ 5

CHAPTER 5INSTALLING SOFTWARE ______________________________________ 6

CHAPTER 6OPERATION ______________________________________________ 8

6.1 Starting up S5U1C88000H5 for Windows 98............................................... 8

6.2 End Procedure .............................................................................................. 9

6.3 Initial Setup File (ICE88UR.INI) and Parameter File (.PAR) ..................... 9

6.4 Debugging.....................................................................................................9

CHAPTER 7PRECAUTIONS ____________________________________________ 10

APPENDIX LIST OF MENUS, SHORTCUT KEYS AND DEBUG COMMANDS ___________ 11

1 PREFACE

S5U1C88000H5 EPSON 1

(S1C88 FAMILY IN-CIRCUIT EMULATOR)

CHAPTER 1PREFACE

1.1 Outline

The S5U1C88000H5 package, one of the software development tool packages for the 8-bit single chip

microcomputer S1C88 Family, consists of an in-circuit emulator (S5U1C88000H5) and a debugger

(S5U1C88000H5 for Windows 98). It allows the programmer to efficiently debug the target system and the

target program.

This system can be used for all the S1C88 Family models. The S5U1C88000H5 in-circuit is compatible

with each model of the S1C88 Family by installing the Peripheral Circuit Board (S5U1C88xxxP) that is

provided for each model.

The S5U1C88000H5 system provides an advanced software developing environment that uses a personal

computer as the host computer.

ICE88UR

E0C88Family In-Circuit Emulator

Fig. 1.1.1 S5U1C88000H5 external view

1.2 Operating Environment

To construct an S5U1C88000H5 system, the following equipment is necessary in addition to this package:

Personal computer

- IBM-PC/AT or compatible model with Windows 98 installed.

- 80486DX2 66 MHz CPU or higher and 24MB RAM are recommended.

- A USB port is required in the personal computer.

- A hard disk drive, a 3.5" floppy disk drive (1.44MB) and a mouse are required.

Display unit

- A 16 or more color display.

- 1024 ×768 dot display is recommended.

Peripheral Circuit Board, other development tools

- Prepare the Peripheral Circuit Board and development tools (software) for the model to be developed.

Basic software

- The S5U1C88000H5 system is compatible with Windows 98 service pack 1 or Windows 98 SECOND

EDITION. Note that it is not guaranteed to work with other versions.

∗The name 'ICE88UR' on the development

tool is the old name of the product.

2 S5U1C88000H5 PACKAGE

2EPSON S5U1C88000H5

(S1C88 FAMILY IN-CIRCUIT EMULATOR)

CHAPTER 2 S5U1C88000H5 PACKAGE

2.1 Components

After unpacking the S5U1C88000H5 package, check to see that all the following components are included.

Figure 2.1.1 shows the package drawing.

• S5U1C88000H5 main unit

• AC adapter • USB interface cable

• AC cable

• Floppy disk

(3.5" 2HD, 1.44MB) • User registration card

• Warranty card

Registration

..............

..........

............

........

• S5U1C88000H5 Manual

One each

for English and Japanese One each

for English and Japanese

One

One each

for English and Japanese

DISK

POWER

EMU

SLP/HALT

RESET

TRGOUT

STOPOUT

TRCIN

BRKIN

GND

ICE88UR

E0C88 Family In-Circuit Emulator

ON/OFF

DIAG

EPSON

CMOS 8-bit Microcomputer S1C88 Family

S5U1C88000H5 Manual

SEIKO EPSON CORPORATION

Fig. 2.1.1 S5U1C88000H5 package

2.2 Component Specifications

Table 2.2.1 shows the component specifications in the S5U1C88000H5 package.

Table 2.2.1 S5U1C88000H5 component specifications

Components

S5U1C88000H5

main unit

USB I/F cable

AC adapter

AC cable

Accessories

Package

Remarks

Rubber feet included

Peripheral Circuit board is sold separately

Rubber feet excluded

Outside: 5 V, Inside: 0 V

One each for English

and Japanese

Items

Dimensions

Weight

External color

Input voltage

Current consumption

Board mounted

Length

Dimensions

Input voltage

Input frequency

Power consumption

Output voltage/current

Length

Plug type

System disk

Manual

Warranty card

User registration card

Dimensions

Materials

Total weight of package

Specifications

270 (W) ×192 (D) ×79 (H) mm

Approx. 2.5 kg (main body)

Cygnus white

DC 5 V

2 A, max.

ICE board (one)

2 m

160 ×80 ×60 mm

AC 90 V to 264 V

47 Hz to 63 Hz

25 W, max. (in ICE system load)

DC 5 V/5 A, with overcurrent protection

1.8 m

Bipolar with ground

3.5" 2HD, 1.44MB (two)

S5U1C88000H5 Manual

380 (W) ×260 (D) ×225 (H)

W carton, cardboard

Approx. 4 kg

3 IN-CIRCUIT EMULATOR (S5U1C88000H5)

S5U1C88000H5 EPSON 3

(S1C88 FAMILY IN-CIRCUIT EMULATOR)

CHAPTER 3

-C

IRCUIT

MULATOR

(S5U1C88000H5)

3.1 Outline

The S5U1C88000H5 emulates the functions of the S1C88 core CPU and is used by installing a Peripheral

Circuit Board for each model. The S5U1C88000H5 is connected to a personal computer via the USB port.

The following shows the features of the S5U1C88000H5:

- Supports all the S1C88 Core CPU models

- 576KB of emulation memory built-in

- Advanced emulation functions (continuous execution, step execution, trace, break, coverage, etc...)

- On-the-fly function for real time monitoring memory.

See help topics of the debugger for details of the debugging functions.

Emulation Memory

The S5U1C88000H5 built-in emulation memory consists of the following two parts:

(1) 64KB emulation memory

This part corresponds to a 64KB area from address 000000H to address 00FFFFH in the accessible

memory space of the S1C88 core CPU.

(2) 512KB emulation memory

This part can be allocated to a 512KB area within address 010000H to address FFFFFFH. To allocate

the emulation memory to a 512KB area to be used, specify the address in a parameter file that is read

at the S5U1C88000H5 system start-up.

Thus the emulation memory can be used as an external memory that is generally prepared on the target

board if the capacity of the external memory is 512KB or less. It is especially useful for debugging sys-

tems that have ROMs as the external memories.

Further, external RAM on the target board can also be debugged like the emulation memory.

See the development tool manual of the model to be developed or the "S1C88 Family Development Tool

Manual" for specifying memory configuration.

3.2 Operating Environmental Conditions

Table 3.2.1 shows the environmental conditions that have to be used to operate the S5U1C88000H5.

Table 3.2.1 Environmental conditions

Remarks

No condensation

Items

Operating temperature

Storage temperature

Operating humidity

Storage humidity

Resistance to vibration

Specifications

5 to 40 °C

-10 to 60 °C

35 to 80%

20 to 90%

Operating: 0.25 m/S2

Transportation: 1 m/S2

3 IN-CIRCUIT EMULATOR (S5U1C88000H5)

4EPSON S5U1C88000H5

(S1C88 FAMILY IN-CIRCUIT EMULATOR)

3.3 Specifications of Operation Panel

Figure 3.3.1 shows the external view of the panels and Table 3.3.1 shows the function of each part of the panels.

Fig. 3.3.1 External view of S5U1C88000H5 panels

Table 3.3.1 Function list of operation parts

No.

Position

Side

Front

Back

Function

The breaker cuts off the power of the S5U1C880000H5 system (ICE

board, Peripheral Circuit board and target board) at consumption

current of 4 A or more. A small staff of the breaker comes up at the

shut-off. The staff should be at the recessed position for normal

operating status. The breaker does not work at the normal operation.

Upon coincidence of trigger conditions with a tracing trigger point, a

pulse is output from this terminal.

When the S1C88 CPU is in HALT or SLEEP status, low level signal

is output from this terminal. This is used to measure execution rate

of the CPU. At the break mode, low level signal is also output.

Information is stored in the trace memory by connection with a

signal of the target system.

A running program enters in break status by input a low level signal

from the target system.

In case the above terminal is monitored with such an oscilloscope,

the GND line of the oscilloscope is connected to this terminal. This

is also used as a GND in case the signals are input to the above

terminals.

This green LED lights upon power-on of S5U1C880000H5.

This red LED lights when the target program is in running status.

This yellow LED lights when the S1C88 CPU stops executing the

program.

This switch reset S5U1C880000H5. (for maintenance)

Setting up when the S5U1C880000H5 power on, execute the self

diagnostic test or not

This is a connector to connect the USB interface cable.

This is a connector to connect the DC cable of the AC adapter

dedicated for S5U1C880000H5.

Turns the S5U1C880000H5 power on and off.

Indicated symbol

TRGOUT

STOPOUT

TRCIN

BRKIN

GND

POWER

EMU

SLP/HLT

RESET

DIAG

DC 5V

POWER SW

Name

Circuit breaker

Tracing trigger output

terminal

HALT/SLEEP status

output terminal

Trace input terminal

Break input terminal

Ground terminal

for above

Power-on LED

Emulation LED

Halt LED

Reset switch

Diagnostic switch

Connector for connecting

USB interface cable

DC input connector

Power switch

Note: In case of change the mode by the diagnostic switch, be sure to shift it at power off the S5U1C88000H5.

POWER

POWERSW

DC5VIN

EMU

SLP/HALT

RESET

TRGOUT

STOPOUT

TRCIN

BRKIN

GND

ICE88UR

E0C88 Family In-Circuit Emulator

OFF

7 8 2

345610 12119

ON/OFF

DIAG

Front

Front ←

Back

Side

Tabla de contenidos

Otros manuales de Hardware de computadora de Epson

Epson

Epson S1C60N03 Manual de usuario

Epson

Epson S5U1C63000A Manual de usuario

Epson

Epson S5U1C63007P Manual de usuario

Epson

Epson Discproducer PP-50BD Manual de usuario

Epson

Epson S1C88 Series Manual de usuario

Epson

Epson S1C62 Family Manual de usuario

Epson

Epson OT-WL02 Manual de uso y cuidado

Epson

Epson G-Series Manual de usuario

Epson

Epson S1C63656 Manual de usuario

Epson

Epson S5U13C00M00C100 Manual de usuario

Epson

Epson UB-U01III Manual de usuario

Epson

Epson E0C6006 Manual de usuario

Epson

Epson S1C17704 Manual de usuario

Epson

Epson DNUB-E1 Manual de usuario

Epson

Epson UB-R04 Manual de usuario

Epson

Epson C32C824151 - UB E02 Print Server Manual de uso y cuidado

Epson

Epson S1C88655 Manual de usuario

Epson

Epson ARM720T Core cpu Manual de usuario

Epson

Epson E0C6001 Manual de usuario

Epson

Epson S1C63558 Manual de usuario

Epson

Epson S1C63666 Manual de usuario

Epson

Epson M-G3 Series Manual de usuario

Epson

Epson S5U1C88348T Manual de usuario

Epson

Epson S2R72A21 Instrucciones de instalación y funcionamiento

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario
