EnGenius EOC-2610 Manual de usuario

EOC-2610

2.4GHz

Long Range Wireless

108 Mbps

Access Point / Client Bridge

802.11b

g/Super G

Multi -fun ction AP

Solwise Ltd

www.solwise.co.uk

[email protected]

sales@solwise.

** All specifica tions are subject to change without notice.

20080930_V1.0

EnGenius Networks Singapore Pte Ltd

215 Henderson Road #01-04 Hend erson Industrial Park Singapore 159554 Tel:(+65) 6227 1088 Fax:(+65) 6227 2766

Webs

te: www

engeniustech.com.sg Ema

: inquiry@engen

ustech.com.sg

EOC-2610 is a long range outdoor wireless Access Point / Client Bridge that operates

seamlessly in the 2.4GHz frequency spectrum and provides high bandwidth up to 108Mbps

with Super G. It features high transmitted output power and high receivable sensitivity. High

output power and high sensitivity can extend range and coverage to reduce the roaming

between Access Points to get a more stable wireless connection. It also reduces the

expense of equipment in the same environment.

It supports distance control by 1km to 30km and RSSI indicator which enables the best

transmit and receive signals for traffic communication. This product comes with PoE injector

for building in outdoor environment easily.

To protect your wireless connectivity, it can encrypt all wireless transmissions through

64/128-bit WEP data encryption and also supports WPA/WPA2. The MAC address filter lets

you select exactly which stations should have access to your network. In addition, the User

Isolation function can protect the private network between client users.

The attractive design, high performance, and array of features make EOC-2610 a suitable

wireless solution for your residence or office.

Package Content



1* 802.11b/g Long range AP/CB (EOC-2610)



1* PoE Injector (EPE-1212)



1* Power Adaptor



1* CD with User’s Manual



1* QIG



1* Metal strap



1* Special screw set

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughp ut may vary. Network conditi ons and

environmental factors lower actu al throughput rate.

EOC-2610

2.4GHz

Long Range Wireless

108 Mbps

Access Point / Client Bridge

802.11b

g/Super G

Multi -fun ction AP

Solwise Ltd

www.solwise.co.uk

[email protected]

sales@solwise.

** All specifica tions are subject to change without notice.

20080930_V1.0

EnGenius Networks Singapore Pte Ltd

215 Henderson Road #01-04 Hend erson Industrial Park Singapore 159554 Tel:(+65) 6227 1088 Fax:(+65) 6227 2766

Webs

te: www

engeniustech.com.sg Ema

: inquiry@engen

ustech.com.sg

Features

Wireless

-2.4GHz It works in 2.4GHz frequency spectrum

-High output power Transmit output power programmable for different country selections

-High Data Rate High speed transmitting rate up to 108Mbps with Super G, support large payload such as MEPG

video streaming

-Multifunction application Access Point/Client Bridge/Client Router

-Long range transmitting Transmit power control and distance control (ACK timeout)

-Signal Strength LED indicators have the best transmit and receive signal for traffic communication

Networking

Public wireless solution

An AP interface that is especially useful in public areas such as hotspots and enterprise

Signal Strength Display

RF signal strength status shown LEDs of 3 colors, making network build-up easier

-QoS(WMM) Enhance performance and density

Security

-802.11i WEP, WPA, WPA2 (Encryption support TKIP/AES)

-MAC address functions MAC address filter (AP mode)

-802.1x IEEE802.1x Authencatior

-L2 isolation

-Station isolation

Management

-Firmware Upgrade Upgrading firmware via web browser, setting are reserved after upgrade

-Reset & Backup Reset to factory default. User can export all setting into a file via WEB

-MIB MIB I, MIB II(RFC1213)

-SNMP V1, V2c

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditi ons and

environmental factors lower actu al throughput rate.

EOC-2610

2.4GHz

Long Range Wireless

108 Mbps

Access Point / Client Bridge

802.11b

g/Super G

Multi -fun ction AP

Solwise Ltd

www.solwise.co.uk

[email protected]

sales@solwise.

** All specifica tions are subject to change without notice.

20080930_V1.0

EnGenius Networks Singapore Pte Ltd

215 Henderson Road #01-04 Hend erson Industrial Park Singapore 159554 Tel:(+65) 6227 1088 Fax:(+65) 6227 2766

Webs

te: www

engeniustech.com.sg Ema

: inquiry@engen

ustech.com.sg

Technical Specifications

Hardware Specification

Physical Interface

One 10/100 Fast Ethernet RJ-45

Reset Button

One SMA Connector

One switch (external and internal antenna switching)

LED indicators

Power/ Status

LAN (10/100Mbps)

WLAN (Wireless is up)

3 x Link Quality (Client Bridge mode)



Green: Good Quality



Yellow: Marginally Acceptable Quality



Red: Bad Quality

Power Requirements

Active Ethernet (Power over Ethernet) Proprietary PoE design

Power Adapter 24V / 0.8A DC

Regulation Certifications

FCC Part 15C/15B, EN 300 328/EN 301 489-1/-17

RF Specification

Frequency Band

802.11b/g

2.412~2.472GHz

Modulation Technology

OFDM = BPSK, QPSK, 16-QAM, 64-QAM

DSSS = DBPSK, DQPSK, CCK

Operating Channels

802.11b/g

11 for North America, 14 for Japan, 13 for Europe

Receive Sensitivity (Typical)

802.11g

-92 dBm @ 6Mbps

-74 dBm @ 54Mbp

802.11b

-97 dBm @ 1Mbps

-89 dBm @ 11Mbps

Available transmit power

(Average power)

FCC

ETSI

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditi ons and

environmental factors lower actu al throughput rate.

EOC-2610

2.4GHz

Long Range Wireless

108 Mbps

Access Point / Client Bridge

802.11b

g/Super G

Multi -fun ction AP

Solwise Ltd

www.solwise.co.uk

[email protected]

sales@solwise.

** All specifica tions are subject to change without notice.

20080930_V1.0

EnGenius Networks Singapore Pte Ltd

215 Henderson Road #01-04 Hend erson Industrial Park Singapore 159554 Tel:(+65) 6227 1088 Fax:(+65) 6227 2766

Webs

te: www

engeniustech.com.sg Ema

: inquiry@engen

ustech.com.sg

Frequ ency

Power

Frequ ency

Power

2.412~2.462

GHz

IEEE802.11g

26dBm@6~24 Mbps

25dBm@36Mb ps

23dBm@48Mb ps

22dBm@54Mb ps

2.412~2.472

GHz

IEEE802.11g

26dBm@6~24 Mbps

25dBm@36Mb ps

23dBm@48Mb ps

22dBm@54Mb ps

2.412~2.462

GHz

IEEE802.11b

27dBm@1~11 Mbps

2.412~2.472

GHz

IEEE802.11b

27dBm@1~11 Mbps

Tolerance

1 dBm

Tolerance

1 dBm

Internal Antenna

Embedded 10dBi Panel antenna

External Antenna

1* SMA connector

Software Features

General

Topology

Infrastructure

Protocol / Standard

IEEE 802.3 (Ethernet)

IEEE 802.3u (Fast Ethernet)

IEEE 802.11b/g (2.4GHz WLAN)

Operation Mode

802.11 b/g

Access Point

Client Bridge

Client Router

LAN

DHCP Server

DHCP Client

VPN

VPN – pass through

Wireless

Channel Selection (Setting varies by countries)

Transmission Rate

11 b/g：54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 Mbps

Super G : 108 Mbps

Long distance transmission : 1km to 30km

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditi ons and

environmental factors lower actu al throughput rate.

EOC-2610

2.4GHz

Long Range Wireless

108 Mbps

Access Point / Client Bridge

802.11b

g/Super G

Multi -fun ction AP

Solwise Ltd

www.solwise.co.uk

[email protected]

sales@solwise.

** All specifica tions are subject to change without notice.

20080930_V1.0

EnGenius Networks Singapore Pte Ltd

215 Henderson Road #01-04 Hend erson Industrial Park Singapore 159554 Tel:(+65) 6227 1088 Fax:(+65) 6227 2766

Webs

te: www

engeniustech.com.sg Ema

: inquiry@engen

ustech.com.sg

Transmit power table

Signal Strength indication using LEDs

PPPoE(CR mode)

Security

WEP Encryption-64/128/152 bit

WPA/WPA2 Personal (WPA-PSK using TKIP or AES)

WPA/WPA2 Enterprise (WPA-EAP using TKIP)

802.1x Authenticator

Hide SSID in beacons

802.1Q VLAN

MAC address filtering, up to 50 field

L2 isolation(AP mode)

Wireless STA (Client) connected list

Web-redirect

QoS

WMM

Management

Configuration

Web-based configuration (HTTP)

Firmware Upgrade

- Upgrade firmware via web-browser

- Keep latest setting when f/w update

Administrator Setting

Administrator password change

Reset Setting

- Reboot (Press 1 second)

- Reset to Factory Default (Press 5 seconds)

System monitoring

Status, Event Log

SNMP

V1, V2c

MIB

MIB I, MIB II (RFC1213) and Private MIB

Backup & Restore

Settings through Web

Time setting

NTP (Auto-setting of time)

Time setting manually

Environment & Mechanical

Temperature Range Operating -20°C~70°C

Storage -30°C to 80°C

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditi ons and

environmental factors lower actu al throughput rate.

EOC-2610

2.4GHz

Long Range Wireless

108 Mbps

Access Point / Client Bridge

802.11b

g/Super G

Multi -fun ction AP

Solwise Ltd

www.solwise.co.uk

[email protected]

sales@solwise.

** All specifica tions are subject to change without notice.

20080930_V1.0

EnGenius Networks Singapore Pte Ltd

215 Henderson Road #01-04 Hend erson Industrial Park Singapore 159554 Tel:(+65) 6227 1088 Fax:(+65) 6227 2766

Webs

te: www

engeniustech.com.sg Ema

: inquiry@engen

ustech.com.sg

Humidity (non-condensing)

0%～90% typical

Dimensions

260mm (L) x 84mm (W) x 55mm (H)

Weight

300g

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditi ons and

environmental factors lower actu al throughput rate.

EOC-2610

2.4GHz

Long Range Wireless

108 Mbps

Access Point / Client Bridge

802.11b

g/Super G

Multi -fun ction AP

Solwise Ltd

www.solwise.co.uk

[email protected]

sales@solwise.

** All specifica tions are subject to change without notice.

20080930_V1.0

EnGenius Networks Singapore Pte Ltd

215 Henderson Road #01-04 Hend erson Industrial Park Singapore 159554 Tel:(+65) 6227 1088 Fax:(+65) 6227 2766

Webs

te: www

engeniustech.com.sg Ema

: inquiry@engen

ustech.com.sg

Access Point + Client Bridge scenario Application

Long Range Transmitting

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditi ons and

environmental factors lower actu al throughput rate.

EOC-2610

2.4GHz

Long Range Wireless

108 Mbps

Access Point / Client Bridge

802.11b

g/Super G

Multi -fun ction AP

Solwise Ltd

www.solwise.co.uk

[email protected]

sales@solwise.

** All specifica tions are subject to change without notice.

20080930_V1.0

EnGenius Networks Singapore Pte Ltd

215 Henderson Road #01-04 Hend erson Industrial Park Singapore 159554 Tel:(+65) 6227 1088 Fax:(+65) 6227 2766

Webs

te: www

engeniustech.com.sg Ema

: inquiry@engen

ustech.com.sg

Product ID & Mounting Base

t Rear

Pole mount

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditi ons and

environmental factors lower actu al throughput rate.

Otros manuales para EOC-2610

Tabla de contenidos

Otros manuales de Punto de acceso inalámbrico de EnGenius

EnGenius

EnGenius ENH200 Manual de usuario

EnGenius

EnGenius ECB3500 Manual de usuario

EnGenius

EnGenius EWS860AP The Neutron Series Manual de usuario

EnGenius

EnGenius EnStationACv2 Manual de usuario

EnGenius

EnGenius ESR-1221N Manual de usuario

EnGenius

EnGenius ECB150 Manual de usuario

EnGenius

EnGenius EOC-2610 Manual de usuario

EnGenius

EnGenius M2000 Manual de usuario

EnGenius

EnGenius ENH1350EXT Manual de usuario

EnGenius

EnGenius ENH500 Manual de usuario

EnGenius

EnGenius EOC-2610 Manual de usuario

EnGenius

EnGenius EOC-5610 Manual de usuario

EnGenius

EnGenius EWS850AP Manual de usuario

EnGenius

EnGenius ENH1750EXT Manual de usuario

EnGenius

EnGenius 11b/g Wireless Outdoor Multi-Client... Manual de usuario

EnGenius

EnGenius EWS500AP Manual de usuario

EnGenius

EnGenius ENS200 Manual de usuario

EnGenius

EnGenius Neutron EWS210AP Manual de usuario

EnGenius

EnGenius EWS357AP v3/ECW220 v2 Manual de usuario

EnGenius

EnGenius ENS202 Manual de usuario

EnGenius

EnGenius EAP1750 Manual de usuario

EnGenius

EnGenius EWS357APV3 Manual de usuario

EnGenius

EnGenius ENH700EXT Manual de usuario

EnGenius

EnGenius EAP1300EXT Manual de usuario

Manuales populares de Punto de acceso inalámbrico de otras marcas

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manual de usuario

Ubiquiti

Ubiquiti NanoStation NSM2 Manual de usuario

Cisco

Cisco Aironet 1550 Series Manual de usuario

Aruba

Aruba IAP-335 Manual de usuario

Advantek Networks

Advantek Networks AWN-AP-54MR Manual de usuario

IP-COM

IP-COM AP355 Manual de usuario

Buffalo

Buffalo AirStation WLA-L11G Manual de usuario

D-Link

D-Link DAP-3662 Manual de usuario

xG Technology

xG Technology xMax CN1300 Manual de usuario

Widelink

Widelink ezWave WAP-1100 Series Manual de usuario

Edimax

Edimax CAP1200 Manual de usuario

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manual de usuario

Aruba

Aruba AP-203R Manual de usuario

LuXout Shades

LuXout Shades LUXSHADE MOTION Manual de usuario

CreatComm

CreatComm TB5F Manual de usuario

SineDigital

SineDigital MW-1500AP(H) Manual de usuario

TP-Link

TP-Link AP9650 V1 Manual de usuario

Draytek

Draytek VIGORAP 902 Manual de usuario
