EN | 13
Status indicator Meaning
Flashing orange Channel (sender) not taught-in into any receiver
Flashing orange
rapidly
Channel (transmitter) in bidirectional program-
ming mode. Operation of already programmed
receivers is not possible.
In group teach-in mode every 3 seconds (even
without button pressing)
Orange then green Channel (transmitter) is operating bidirectionally
and receiver has received the signal
Orange then ashing
red
Channel (transmitter) is operating bidirectionally
and one of the receivers has not received the
signal
Red then green Channel (transmitter) is operating bidirectionally
and receiver has received the signal, batteries
weak
Red then ashing red Channel (transmitter) is operating bidirectionally
and one of the receivers has not received the
signal, batteries weak
Green Channel (transmitter) is operating unidirection-
ally:
Transmit signal is being sent
Green with repeat,
then red (unidirec-
tional)
Channel (transmitter) is deleted
Alternating orange
and green (or red),
then red (bidirec-
tional)
Channel (transmitter) is deleted
Flashing red Batteries weak
The transmitting power or radio range will be reduced by declining
battery output. The display shows weak batteries with BAT. No
more functions are executed and there is no display if the voltage
drops below 2 V.
Group control unit
A group is understood to mean the control of several receivers
at the same time. The selected group is controlled by a travel
command. All 10 channels (transmitter) can be used for the group
control.
Any number of receivers can be programmed and controlled in each
channel.
Joystick
Pressing the joystick briey up and down enables you to select
from 10 channels. The channels are shown in the display with the
channel number or with the name input by the user.
An additional channel is reserved for the central channel (All) which
is automatically assigned to all individual channels. You can select
the central channel by moving the joystick briey to the left. When
the central channel is selected, this controls all radio channels
simultaneously.
If the hand-held transmitter has two or more bidirectional individual
channels, you can congure and select two group control systems
by moving the joystick briey to the right. The bidirectional channels
can be allocated for a group via the “Administration” menu.
Selection button
Pressing the selection button briey allows you to query the
current mode (automatic/manual) of the programmed receivers
(bidirectional receivers only) and the handheld transmitter channel.
Pressing the selection button for longer (approximately 1 second)
switches o automatic mode of the current bidirectional channel or
all unidirectional channels. The operating mode display lights red
and changes to MANUAL mode in the display. →The receiver now
only carries out manual travel commands and does not respond to
automatic travel commands.
