Elcometer 456 Manual de usuario

English

Elcometer 4562

Coating Thickness Gauge

Basic Models

Operating Instructions

Op_456_2_English.book Page -1 Friday, February 17, 2006 3:35 PM

English

These instructions apply to the following

Elcometer 4562models:

• Ferrous (F)

• Non-Ferrous (NF)

• Dual Ferrous/Non-Ferrous (FNF)

Equipment described in these instructions is

covered by the following Patents:

FNF UK Patent No: GB2306009B

FNF US Patent No: 5886522

F1 2 UK Patent No: 2367135B

F1 2 US Patent No. US 6,762,603

F1 2 German Patent Pending

This product meets the emc directive

89/336/EEC, amended 92/31/EEC and

93/68/EEC.

and are registered

trademarks of Elcometer Instruments Ltd.

All other trademarks acknowledged.

reproduced, transmitted, transcribed, stored (in a

retrieval system or otherwise) or translated into any

language, in any form or by any means (electronic,

mechanical, magnetic, optical, manual or otherwise)

without the prior written permission of

Elcometer Instruments Ltd.

Doc.No. TMA-0302 Issue 02

Text with Cover No: 18612

Op_456_2_English.book Page 0 Friday, February 17, 2006 3:35 PM

CONTENTS

Section Page

1 About your gauge................................................ 3

1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.2 Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.3 What this box contains . . . . . . . . . . . . . . . . . . . . . 5

1.4 Conventions in these instructions . . . . . . . . . . . . . 5

1.5 Quick-start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2 Getting started ..................................................... 6

2.1 Fitting the batteries . . . . . . . . . . . . . . . . . . . . . . . . 6

2.2 Battery condition. . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.3 Fitting probes (separate versions only) . . . . . . . . . 7

2.4 The controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.5 Switching the gauge on . . . . . . . . . . . . . . . . . . . . 9

2.6 Switching the gauge off . . . . . . . . . . . . . . . . . . . . 9

2.7 The screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.8 Selecting a language . . . . . . . . . . . . . . . . . . . . . 11

2.9 Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3 Taking a reading ................................................ 13

3.1 Before you start . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4 The reading screen and menus........................ 14

4.1 Reading screen . . . . . . . . . . . . . . . . . . . . . . . . . 14

4.2 Main MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4.3 Main MENU - Extended menu off . . . . . . . . . . . . 16

4.4 Main MENU - Extended menu on . . . . . . . . . . . . 18

5 Calibration adjustment...................................... 23

5.1 Calibration method . . . . . . . . . . . . . . . . . . . . . . . 23

5.2 Calibration foils and standards . . . . . . . . . . . . . . 24

5.3 Calibration adjustment procedure . . . . . . . . . . . . 26

6 Statistics............................................................. 32

6.1 Enlarge stats . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

6.2 Stats on LCD . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

6.3 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

6.4 Clear stats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

6.5 Select stats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Op_456_2_English.book Page 1 Friday, February 17, 2006 3:35 PM

7 Probes ................................................................ 35

7.1 Ferrous (F) probes . . . . . . . . . . . . . . . . . . . . . . . 35

7.2 Non-ferrous (N) probes . . . . . . . . . . . . . . . . . . . . 35

7.3 Dual ferrous/non-ferrous (FNF) probes . . . . . . . 35

7.4 Probe interchangeability . . . . . . . . . . . . . . . . . . . 36

7.5 F1 2 probes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

7.6 F1 2 High temperature PINIP™ probes . . . . . . . 37

7.7 Coatings on galvanised or metallised steel . . . . 37

8 Personalised welcome screen ......................... 38

9 Storage and transit............................................ 39

10 Maintenance....................................................... 39

11 Statistics terminology ....................................... 40

12 Technical data.................................................... 41

13 Accessories ....................................................... 43

14 Related equipment ............................................ 45

15 Fitting the wrist harness ................................... 45

16 Probe measurement performance ................... 46

17 Probe capabilities.............................................. 47

18 Error messages ................................................. 54

19 Index ................................................................... 56

Op_456_2_English.book Page 2 Friday, February 17, 2006 3:35 PM

hank you for your purchase of this Elcometer 4562

Coating Thickness Gauge. Welcome to Elcometer.

Elcometer are world leaders in the design, manufacture

and supply of coatings inspection equipment. Our

products cover all aspects of coating inspection, from

development through application to post application

inspection.

The Elcometer 4562Coating Thickness Gauge is a world

beating product. With the purchase of this gauge you

now have access to the worldwide service and support

network of Elcometer. For more information visit our

website at www.elcometer.com.

1 ABOUT YOUR GAUGE

The Elcometer 4562Coating Thickness Gauge is a

handheld gauge for fast and accurate measurement of

the thickness of coatings on metal substrates.

The gauge is available in

three versions; Basic,

Standard and Top. This

manual describes the

operation of the

Elcometer 4562Basic.

All versions of the gauge

feature an easy-to-use

menu driven graphical

interface which guides the

user through tasks such as

gauge configuration and

calibration adjustment.

The gauge is available either with a built-in integral

probe or as a separate probe version. A wide range of

probes is available to suit requirements - see page 35.

Separate probes may be standard, miniature or Plug in

Integral Probes (PINIP™), and must be ordered

separately.

Figure 1. Elcometer 4562

Coating Thickness Gauge

Op_456_2_English.book Page 3 Friday, February 17, 2006 3:35 PM

1.1 Features

• A range of smooth and rough surface calibration

adjustments.

• Menu driven backlit graphical user interface.

• Interchangeable probes (separate versions only).

• Simple statistics.

• Infrared interface.

1.2 Standards

The Elcometer 4562can be used in accordance with the

following National and International Standards:

Ferrous (F) Non-Ferrous (NF)

BS 5411 (11) BS 5411 (3)

BS 3900 (C5) BS 3900 (C5)

ISO 2178 BS 5599

ISO 2808 ISO 2360

BS EN ISO 1461 ISO 2808

DIN 50981 DIN 50984

ASTM B 499 ASTM D 1400

ASTM D1186 ASTM B 244

ISO 19840

SSPC-PA2 (2004)

Op_456_2_English.book Page 4 Friday, February 17, 2006 3:35 PM

1.3 What this box contains

• Elcometer 4562Gauge with integral probe, or

Elcometer 4562Gauge and separate probe

(probe must be ordered separately)

• Calibration foils

• Gauge carrying pouch

• Wrist harness

• Batteries

• Operating instructions

1.4 Conventions in these instructions

The Elcometer 4562is controlled using a simple menu

structure which helps you get the most from your gauge

- see page 18.

As an example, the LANGUAGES option which is in

SETUP from the MAIN MENU would be shown in these

instructions as MENU/SETUP/LANGUAGES.

These instructions include images of Elcometer 4562

screens with units set to microns (µm). Similar screens

will be seen when the gauge is set to other units such as

mils or inches.

1.5 Quick-start

To quickly configure the gauge and start taking readings:

1. Fit batteries: see page 6

2. Fit probe (separate versions only): see page 7

3. Switch on: see page 9

4. Select language: see page 11

5. Try taking a reading: see page 13

6. Adjust calibration: see page 23

The gauge is now configured and ready to use.

To maximise the benefits of your new

Elcometer 4562, please take some time to read these

Operating Instructions. Do not hesitate to contact

Elcometer or your Elcometer supplier if you have any

questions.

Op_456_2_English.book Page 5 Friday, February 17, 2006 3:35 PM

2 GETTING STARTED

2.1 Fitting the batteries

1. Open battery compartment cover; press down in

direction of arrow using thumb nail.

2. Insert 2 x LR03 (AAA), alkaline dry batteries taking

care to ensure correct battery polarity (Figure 2).

3. Close battery compartment cover.

Rechargeable batteries can be used but they will only

have 25% to 30% of the life of alkaline batteries.

Figure 2. Fitting batteries -

ensure correct battery polarity

2.2 Battery condition.

Symbol Battery condition/action required

100%

66% to 100%

33% to 66%, replacement recommended.

16% to 33%, replacement required.

<16%, gauge beeps every 10 seconds and

symbol flashes - immediate replacement

required.

5 loud beeps, gauge switches off

automatically.

Op_456_2_English.book Page 6 Friday, February 17, 2006 3:35 PM

2.3 Fitting probes (separate versions only)

To ensure correct transfer of data from the

probe and detection of the new probe, the

gauge must be switched off when

separate probes are fitted.

A probe must be calibrated once it has been fitted -

see “Calibration adjustment” on page 23.

2.3.1 To fit the probe

Align connector keyway and push

in direction shown. The connector

locks automatically.

Note: The design of the probe

connector allows some movement

between the probe and the gauge.

This is intentional and does not

affect measurement performance.

2.3.2 To release the probe

Grasp knurled section and pull

gently away from the gauge. The

connection will unlock and the

probe will release.

2.3.3 To fit the PINIP™

Twist the PINIP™ until the

connector locates. Taking

care not to cross the

threads, lock the probe by

turning the locking ring 1½

times clockwise, or until

tight.

Op_456_2_English.book Page 7 Friday, February 17, 2006 3:35 PM

2.4 The controls

The gauge is operated by 5 keys (Figure 3).

• On/Off key : Switches the gauge on or off.

• Softkeys: The function of these keys varies and is

described by symbols and writing on the bottom line

of the screen.

• LED: Red/green flashes when the gauge is switched

on, green flashes when a reading is taken.

Figure 3. Elcometer 4562control keys

Softkeys

On/Off key

LED

Op_456_2_English.book Page 8 Friday, February 17, 2006 3:35 PM

Otros manuales para 456

Tabla de contenidos

Otros manuales de Instrumento de medición de Elcometer

Elcometer

Elcometer 311 Manual de usuario

Elcometer

Elcometer Elcomotor 312 Manual de usuario

Elcometer

Elcometer SAGOLA Classic S1 Manual de usuario

Elcometer

Elcometer SCM400 Manual de usuario

Elcometer

Elcometer 320 Manual de usuario

Elcometer

Elcometer 2020 Manual de usuario

Elcometer

Elcometer 456 Manual de usuario

Elcometer

Elcometer MTG2 Manual de usuario

Elcometer

Elcometer Protovale 331 Manual de usuario

Elcometer

Elcometer AVU Manual de usuario

Elcometer

Elcometer Zahn 2210 Manual de usuario

Elcometer

Elcometer 138/2 Manual de usuario

Elcometer

Elcometer 415 Manual de usuario

Elcometer

Elcometer 138 Manual de usuario

Elcometer

Elcometer protovale P330 Manual de usuario

Elcometer

Elcometer 550 Manual de usuario

Elcometer

Elcometer E224C-BI Manual de usuario

Elcometer

Elcometer E130-S Manual de usuario

Elcometer

Elcometer FD700DL+ Manual de usuario

Elcometer

Elcometer 415 Manual de usuario

Elcometer

Elcometer 319 S Manual de usuario

Elcometer

Elcometer 3505 Manual de usuario

Elcometer

Elcometer 207 Manual de usuario

Elcometer

Elcometer 130 Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
