Edimax AR-7084A Manual de usuario

publication may be reproduced, transmitted, transcribed, stored in a retrieval system,

or translated into any language or computer language, in any form or by any means,

electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without

the prior written permission of this company

This company makes no representations or warranties, either expressed or implied,

with respect to the contents hereof and specifically disclaims any warranties,

merchantability or fitness for any particular purpose. Any software described in this

manual is sold or licensed "as is". Should the programs prove defective following

their purchase, the buyer (and not this company, its distributor, or its dealer) assumes

the entire cost of all necessary servicing, repair, and any incidental or consequential

damages resulting from any defect in the software. Further, this company reserves

the right to revise this publication and to make changes from time to time in the

contents hereof without obligation to notify any person of such revision or changes.

The product you have purchased and the setup screen may appear slightly different

from those shown in this QIG. For more detailed information about this product,

please refer to the User's Manual on the CD-ROM.The software and specifications

subject to change without notice. Please visit our web site www.edimax.com for the

manual are trademarks and/or registered trademarks of their respective holders

Linux Open Source Code

Certain Edimax products include software code developed by third parties,

including software code subject to the GNU General Public License ("GPL") or

GNU Lesser General Public License ("LGPL"). Please see the GNU

(www.gnu.org) and LPGL (www.gnu.org) Websites to view the terms of each

license.

The GPL Code and LGPL Code used in Edimax products are distributed

without any warranty and are subject to the copyrights of their authors. For

details, see the GPL Code and LGPL Code licenses. You can download the

firmware-files at

http://www.edimax.com under "Download" page.

Product Introduction

Thank you for purchasing an Edimax product. This router is a cost-effective router, an

ADSL2+ modem, Ethernet network switch and wireless access point (for wireless

model only). You can surf the Internet and share the connection through the Edimax

router without investing in other devices.

This router can support downstream transmission rates of up to 24Mbps and

upstream transmission rates of up to 1Mbps. It supports PPPoA (RFC 2364 - PPP

over ATM Adaptation Layer 5), RFC 1483 encapsulation over ATM (bridged or routed),

PPP over Ethernet (RFC 2516), and IPoA (RFC1577) to establish a connection with

ISP. The product also supports VC-based and LLC-based multiplexing.

With the web management interface, users can easily configure the various functions

of the router including DHCP server, NAT, virtual server, DMZ, access control, IP filter,

PPTP/IPSec/L2TP pass-through, DDNS, UPnP, and Wireless.

1. Minimum Requirements

The following devices are necessary to configure the ADSL2+ Router:

zA PC with an Ethernet Adapter (required) and a Web-Browser (Internet Explorer

4.0 or higher)

zRJ-45 Ethernet crossover cable

zRJ-11 Phone Line

2. Product Package

This package contains the following components:

One ADSL2+ Router (Annex A or B)

One Dipole Antenna (only for wireless AR-7084gA or AR-7084gB)

One Power Adapter

One RJ-45 Ethernet Cable (100 cm)

One RJ-11 Telephone Line (180 cm)

One Quick Installation Guide

One CD-ROM (Including the Setup Wizard, Multi-languages Quick Installation

Guide and User’s Manual)

Rear Panel

1) Antenna Connector ( For wireless AR-7084gA or AR-7084gB only )

The antenna connector of the router is reverse SMA connector. It allows you to

connecting an external antenna with reverse SMA connector to the router easily.

2) Reset

The Reset button can be used to reset the router or restore to factory defaults.

zIf problems occur with your router, press the router’s reset button with a

pencil tip (for less than 5 seconds) and the router will re-boot itself, keeping

your original configurations.

zIf problems persist or you experience extreme problems or you forgot your

password, press the reset button for longer than 5 seconds and the router

will reset itself to the factory default settings (warning: your original

configurations will be replaced with the factory default settings)

3) Power Jack

Please plug the power adapter attached with theADSL Router to the power jack.

The power adapter is 12VDC, 1A.

4) Local Area Network (LAN)

The router’s 4 LAN ports are where you connect your LAN’s PCs, printer servers,

hubs and switches etc.

5) ADSL

Connect the supplied RJ-11 telephone line to this port and your ADSL/telephone

network.

Front LEDs

On the router’s front panel there are LED lights that inform you of the router’s current

status. Below is an explanation of each LED and its description.

LED Light

Status Description

The router is readyPWR

(Green)

Off Wireless LAN is disabled

Blinking Wireless traffic is transmitting or receiving

WLAN

(Yellow)

On Connected to an ADSL DSLAN successfullyADSL

(Green) Blinking No connection

On The LAN cable is connected to the router

Off No network connection.

LAN

LNK/ACT

(Port

1-4) Blinking Network traffic transferring or receiving through the LAN port

3. Install ADSL Router

Step 1. Connect the ADSL Line

Connect the router from the WAN port to your telephone socket with micro filter

plugged in through the supplied RJ-11 telephone line.

Step 2. Connect the router to your LAN network

Connect the router to your PC, hub or switch by attached the Ethernet cable to the

LAN port of the router.

Step 3. Connect the Power Adapter to the Router

Connect the power adapter to the power jack on the rear panel of router.

Step 4. Check ADSL light status

Please check on the front panel of the router for theADSL LED. The light indicates

whether there is broadband going in your telephone line or not. If the light is solid we

can proceed to the setup. However, if the light is blinking, please call your Internet

Service Provider (ISP) first and inform them about the flashing ADSL light.

Step 5. Firewall settings.

Please turn off all personal firewall before the setup as they might block the

communication of your PC and the router.

Note

：

You must use the power adapter shipped along with the router , do NOT

use any other power adapter from other sources.

1. Configure the PC LAN setting to automatically obtain an IP address from the router

by following below steps.

zClick “Start” in the task bar then select the “Control Panel” to open it.

zClick “Switch to Classic View” on the left top to see more setting icon…

zFind an icon “Network Connection” then Double-Click to open the network

connection setting.

zYou will see an icon “Local Area Connection”,click the icon then Right-Click the

mouse to open the sub-menu and select the “Properties” for setting the IP.

zSelect the “Internet Protocol (TCP/IP)” then click the “Properties”

zEnsure the parameter marked in blue are checked in “Obtain an IP address

automatically” and “Obtain DNS server address automatically” then press

“OK” to close.

2. Power on sequence for the networking devices and PC.

zFirstly, power off the modem followed by router and PC.

zSecond, power on the modem.

Third power on the router followed by PC for next step.

1. Enter the router’s default IP address: “192.168.2.1” into your PC’s web browser

and press “enter”.

2. The login screen below will appear. Enter the “User Name” and “Password” and

click “OK” to login.

The default User name is “admin” and the Password is “1234”,

Note: It’s highly recommended to change and save Router's log-in settings in

another location.

The main page will appear, click “Quick Setup”Following example is for “PPPoE”

WAN setting.
