EDIFIER TWS5 Manual de usuario

www.edifier.com

TWS5

Truly Wireless Stereo Earbuds

EN · Product Description and Accessories

There are diﬀerent size of ear tips attached in the package, please select

the suitable ones to wear.

Note: Images are for illustrative purposes only and may diﬀer from the

actual product.

USB charging cableEar tips x 3 PairsCharging case

Multi-function button

LED light

■ User Guide

● Charge the Earbuds

During using, if only red light ﬂashes, it indicates the earbuds are at low

battery level, please use them after fully charged.

Charging: place the earbuds in the charging case

Red light lit = charging Red light oﬀ =fully charged

Charging time: around 2 hours for a full charging

Warning: The rechargeable batteries that provide power for this product

must be disposed properly for recycling. Do not dispose of batteries in

ﬁre to prevent an explosion.

● Charge the Charging Case

Green lights of the charging case indicate the battery capacity:

When the green lights are all lit, the charging case can charge earbuds

three times;

When only the leftmost green light is lit, it indicates the charging case

is at low battery level, please charge it in time; the green lights will be

all lit after fully charged.

Rated input: 5V 60mA(earbuds) 5V 500mA(charging case)

● Power ON/OFF

1. Power on automatically when taken out from the charging case;

2. Power oﬀ automatically while placed in the charging case.

● TWS Pairing of the Left and Right Earbuds

The left and right earbuds have ﬁnished TWS pairing before leaving

factory. If the wireless connection fails to resume, please follow the steps

below to re-pair:

1. When there is no TWS connection, respectively double click the

multi-function button of the left and right earbuds to enter TWS

pairing state, the blue light will ﬂash rapidly;

2. After pairing is done, blue lights of both earbuds will ﬂash slowly.

● Bluetooth Connection

1. Two Earbuds Mode

•Open the charging case to take two earbuds out, they will automatically

turn on and make interconnection;

•Press and hold the multi-function button of the left earbud to enter

pairing state, the red and blue lights will ﬂash rapidly;

•Set mobile phone to search and connect to “EDIFIER TWS5”, after

pairing is successful, the blue light will ﬂash slowly.

2. One Earbud Mode

If uses one earbud only, please take the left or right earbud out of the

charging case, and refer to the procedures mentioned in

“Two Earbuds Mode”to pair it with mobile phone.

■ Functional Operation Instructions

● Music Playback

● Call

•Clear pairing records: when with no Bluetooth and TWS connection,

press and hold the multi-function button for 8 seconds.

•Disconnect from mobile phone: when the phone is connected, no

music is playing and no phone conversation, press and hold the

multi-function button for 3 seconds.

Previous track: double click the left earbud

(disabled for One Earbud Mode)

Next track: double click the right earbud

(disabled for One Earbud Mode)

Pause/play: single click

Accept a call: single click

End a call: single click

Decline a call: press and hold

Red light instead of blue light ashes.

•The earbuds are at low battery level, please recharge the earbuds.

Red light is o during charging.

•Ensure the earbuds are correctly placed in the charging case.

•When the earbuds have not been used for long periods of time, the

battery will enter sleep state, it needs to charge about 30 minutes

and then the red light will be lit.

No sound

•Check if the earbuds are operating.

•Check if the earbuds volume are at an appropriate level.

•Check if the earbuds are correctly connected with mobile phone.

•Check if the earbuds are operating within a normal working range.

The call quality of the earbuds are not good.

•Check if mobile phone is in an area with strong signal.

•Ensure the earbuds are within eﬀective distance (10m) and no

obstacle between the earbuds and mobile phone.

When playing music, cannot control pause/play/previous track/

next track via the earbuds.

•Ensure the paired device support AVRCP (Audio Video Remote

Control Proﬁle) proﬁle.

■ FAQs

•Keep the product away from humid places to avoid aﬀecting internal

circuit. Do not use the product during intense exercise or with much

sweat to prevent sweat from dropping into the product to make

damage.

•Do not put the product in places exposed to sun or with high

temperature. High temperature will shorten service life of electronic

components, damage battery and make plastic components deformed.

•Do not put the product in cold places to avoid damaging internal

circuit board.

•Do not dismantle the product. Non-professional personnel may

damage the product.

•Do not drop, strongly vibrate, strike the product with hard object to

avoid damaging internal circuit.

•Do not use drastic chemicals or cleaner to clean the product.

•Do not use sharp objects to scratch product surface to avoid

damaging shell and aﬀecting facade.

■ Maintenance
