Dish Network 129418 Manual de usuario

TABLE OF CONTENTS

Remote Control Basics....................................... 2

Models Supported by this Guide ......................... 2

UHF and IR Signals ............................................ 3

Installing Batteries............................................... 3

Converting the 6.0 Remote Control ................... 4

Setting Up to Control the Satellite Receiver ..... 5

Checking the Remote Address .......................... 8

Setting Up to Control Other Devices ................. 8

Combination Devices .......................................... 8

Limited Mode....................................................... 8

Setting Up Using Device Code Tables ................ 9

Setting Up Using Device Codes Scan............... 10

Checking the Device Codes...............................11

Switching Between TV and Device

Volume Control...................................................11

Remote Control Operation ............................... 13

Operating Modes............................................... 13

Controlling the Satellite Receiver ...................... 13

Controlling a TV (or a Second TV) .................... 23

Controlling a VCR

(Second VCR or a DVD Player) ........................ 25

Controlling a Tuner or Amplifier......................... 27

Device Codes .................................................... 29

TV Codes .......................................................... 29

VCR Codes ....................................................... 33

TV/VCR Combo Codes ..................................... 35

DVD Player Codes ............................................ 35

Tuner/Amplifier Codes....................................... 36

DVD/VCR Combo Codes .................................. 37

TV/DVD Combo Codes ..................................... 37

Troubleshooting ............................................... 38

Limited Warranty ............................................... 40

If You Need Help ................................................ 43

text_dishpvr.fm Page 1 Tuesday, March 2, 2004 12:35 PM

REMOTE CONTROL BASICS

This remote control gives you easy access to all the features of a DISH

Network satellite TV receiver. You can set up the remote to control the

satellite TV receiver and up to three other devices. These devices can

be a TV, a VCR or DVD player, and a third device.

MODELS SUPPORTED BY THIS GUIDE

This user’s guide supports the following remote control models as

shown on the label on the back of the remote:

•5.0 - Infrared (IR) only. For use with appropriate IR-controlled

DISH Network receivers.

•6.0 - Infrared/Ultra-High Frequency Pro (IR/UHF Pro). For use

with appropriate UHF Pro-controlled DISH Network receivers.

The 6.0 remote can be converted to one of three different remote

types used on a DISH Player-DVR 522 receiver:

With the blue 2 UHF Pro key installed, this remote

will operate the UHF Pro side of the DISH

Player-DVR 522 receiver. The remote comes with

this key already installed.

With the green 1 key installed (no UHF Pro

marking), this remote will operate the IR side

of the DISH Player-DVR 522 receiver. This remote

will look and work exactly like a 5.0 IR remote.

See instructions in Converting the 6.0 Remote.

With the green 1 UHF Pro key installed, this

remote will operate the side of the DISH

Player-DVR 522 receiver from a distance using

UHF Pro. See instructions in Converting the 6.0

Remote.

If you set up your DISH Player-DVR 522 to operate the

side using UHF Pro, the two UHF Pro remotes for

this receiver will interfere with each other when

operated at the same time. This may prevent the

remotes from operating the receiver momentarily.

•8.0 - Infrared/Ultra-High Frequency Pro (IR/UHF Pro). For use

with appropriate UHF Pro-controlled DISH Network receivers.

text_dishpvr.fm Page 2 Tuesday, March 2, 2004 12:35 PM

INSTALLING BATTERIES

The remote control requires AAA batteries. When

you replace old batteries, you should replace all of the

batteries. Use batteries of the same kind, for example,

alkaline or carbon zinc, and don’t mix batteries of

different kinds. Alkaline batteries last longer.

1. Press down on the battery cover and slide the

cover off.

2. If you are replacing batteries, take out all of

the old batteries.

3. Put the new batteries in. Make sure

you match the plus (“+”) ends with the

plus markings on the battery case.

4. Slide the cover back into place.

UHF AND IR SIGNALS

The remote control may use either UHF radio signals or IR light

signals to control the receiver but uses only IR signals to control other

devices.

•IR signals travel only short distances (up to 40 feet),

and cannot go through walls or other solid objects.

You must point the remote control right at the device

you want to control, with no objects to block the signal path.

•UHF signals travel long distances (up to 200 feet) and can

go through walls and other solid objects. Because UHF signals

travel so far, the receiver may respond to signals from other

nearby remote controls. To handle this problem, you may want to

change the remote and receiver addresses. See Setting Up to

Control the Satellite Receiver on page 4.

•Confirm that the UHF remote antenna is attached to the receiver’s

back panel UHF REMOTE ANTENNA input so you can use

your UHF Pro remote.

text_dishpvr.fm Page 3 Tuesday, March 2, 2004 12:35 PM

CONVERTING THE 6.0 REMOTE CONTROL

By replacing the key at the bottom of the 6.0 remote, this remote can be

converted to look and work like a 5.0 IR or to operate like a second

UHF Pro remote to control the side of the DISH Player-DVR 522

receiver. The instructions that follow show you how to replace this key.

After replacing the key, follow the instructions in Setting Up to Control

the Satellite Receiver.

Note: If you do not need to replace the key, you do not need to

complete the instructions that follow. Go to Setting Up to Control the

Satellite Receiver.

1. Slide the battery cover off.

2. Insert your thumbnail in the

seam between the remote

control and the blue 2 key to

separate the key from the

remote control.

3. Grasp the key at the bottom and pull down firmly to remove.

4. If you are converting the remote

to look and work like a 5.0 IR

remote, then turn the removed

key over with the green 1 side

up (this key should not have a

UHF Pro marking). Reinstall

the key with the green side

showing. Make sure the key

snaps in place.

Note: Key

has no UHF

Pro marking.

text_dishpvr.fm Page 4 Tuesday, March 2, 2004 12:35 PM

SETTING UPTO CONTROL THE SATELLITE

RECEIVER

The remote and the receiver must be set up on the same address so that

the remote can control the receiver. When you get the remote, it's

already set up to control the receiver on address 1. However, your

receiver may be set to a different address or, in the case of the DISH

Player-DVR 522, may need some additional setup. To set up the

remote and receiver to work together on the same address, use the

following instructions.

5. If you are converting the remote

to operate like a second UHF

Pro remote to control the

side of the DISH Player-DVR

522 receiver, then get the green

1 UHF Pro key provided

separately. Install this key in the

remote with the UHF Pro

marking showing.

If you set up your DISH Player-DVR 522 to

operate the side using UHF Pro, the two

UHF Pro remotes for this receiver will interfere

with each other when operated at the same time.

This may prevent the remotes from operating

the receiver momentarily.

6. If you have not already installed batteries, install them now.

See Installing Batteries for further details.

7. Slide the battery cover back into place.

Note: Key has the

UHF Pro marking.

text_dishpvr.fm Page 5 Tuesday, March 2, 2004 12:35 PM

1. For DISH Player-DVR 522 receivers only: If you are using a 6.0

remote control with the green 1 UHF Pro key installed, perform

the steps a. through e. below. If not, then go to step 2.

a. Open the TV1 UHF Pro Setup screen by pressing

MENU-6-1-6 on the remote control.

b. Select Enable from the TV1 UHF Pro Setup screen.

c. Press the SYS INFO button on the front panel to open the

System Information screen.

d. Move the highlight to the address for the Primary Remote

Address as shown below. This is important - if you do not

do this, your remote will change the receiver's Secondary

Remote Address and cause your Remote Control 1 to

control the side of your receiver.

Do not do this step if you are using 6.0

Remote with blue 2 key. This will cause your

Remote Control 2 to control side of your

receiver.

e. Go to step 3 below.

2. Open the System Information screen. Consult your receiver

user's guide for instructions on how to open this screen without

using the remote control. For most receiver models which use

this remote, press the SYS INFO button on the receiver front

panel. The System Information screen will show either one

Remote Address, or it may show a Primary Remote

Address and a Secondary Remote Address.

Note: On the DISH Player-DVR 522, leave Done highlighted.

3. Press and hold the SAT mode button about three

seconds, until all the mode buttons light up,

and then let go of the SAT button. The SAT mode

button will blink.

Note: Highlight

the Primary

Remote

Address if you

are using a 6.0

remote with a

green 1 UHF Pro

key.

text_dishpvr.fm Page 6 Tuesday, March 2, 2004 12:35 PM

4. Use the number buttons to enter any number

from 1 to 16. The SAT mode button goes out after you enter

each digit, and then lights up again.

Write down the number you entered:

5. Press the POUND (#) button.

If you entered the address correctly, the SAT mode

button will flash three times.

6. Press the RECORD button. If you are using a 6.0

remote with the green 1 key (no UHF Pro marking),

you must point the remote control at the receiver

while pressing the RECORD button.

7. Make sure the System Information screen shows the correct

remote address as follows:

•If only one Remote Address is shown, make sure this

address matches the number you entered in step 5.

•If you are using 6.0 remote with the green 1 UHF Pro key,

make sure that the Primary Remote Address shows

UHF Pro and IR and that this address matches the number

you entered in step 4.

•If you are using 6.0 remote with the green 1 key (with no

UHF Pro marking), make sure that the Primary Remote

Address shows IR and that this address matches the

number you entered in step 4.

•If you are using 6.0 remote with the blue 2 UHF Pro key,

make sure that the Secondary Remote Address matches

the number you entered in step 4.

8. Close the System Information screen. On most receivers,

this is done by selecting the Done button. See your receiver

user's guide for more information.

text_dishpvr.fm Page 7 Tuesday, March 2, 2004 12:35 PM

CHECKING THE REMOTE ADDRESS

To read out the remote control address setting:

1. Press and hold the SAT mode button for three seconds

until all mode buttons light. Then, let go.

2. Press the POUND (#) button twice while watching

the SAT mode button.

3. Count the number of times the SAT mode button

flashes. This number is the remote address. For

example, if the SAT mode button flashes 6 times, this

indicates the remote address is set to 6.

SETTING UPTO CONTROL OTHER DEVICES

To use the remote to control other devices (such as a TV, VCR, DVD

player, tuner, or amplifier), you must first program it to control these

other devices. You can do this by either following the instructions in

Setting Up Using Device Code Tables on page 9, or the Setting Up

Using Device Codes Scan procedure described on page 10.

COMBINATION DEVICES

If you are programming the remote to control a combination device,

such as a TV/VCR or a TV/DVD, program the remote control in one

mode, and then repeat the procedure in the other mode. For example, to

program the remote to control a TV/VCR using code 748, follow the

instructions to program the remote to control the TV using code 748,

and then repeat the instructions for the VCR using the same code.

LIMITED MODE

You can program your remote control in Limited Mode to keep from

accidentally changing the channel on your TV or VCR. When you use

the remote to control your TV in Limited Mode, you will only be able

to use the POWER, MUTE, and VOLUME buttons to control your TV.

Also, when you use the remote to control your VCR in Limited Mode,

you will only be able to use the POWER and VCR function buttons.

The section Setting Up Using Device Codes Tables has a step that tells

the remote control to go into Limited Mode.

Note: Limited Mode can not be used with audio amplifiers.

text_dishpvr.fm Page 8 Tuesday, March 2, 2004 12:35 PM

SETTING UPUSING DEVICE CODE TABLES

You can set up the remote to control other devices using the device

codes listed on page 29.

1. Use the device’s buttons or its remote control to turn on the

device.

2. Find the brand name of the device in the tables starting on

page 29.

If the brand isn’t listed, see Setting Up Using Device Codes

Scan on page 10.

3. Press and hold the mode button for the device you want

the remote to control, for about three seconds. When all the

other mode buttons light up, let go of the mode button - that

mode button should now be flashing.

For example, hold the TV mode button for a TV until all of the

other mode buttons light. When you let go, the TV mode light

will flash.

4. Only for the AUX mode, Use a number button to enter 0 for a

second TV, or 1for a second VCR or DVD player, or 2for a

tuner or amplifier.

5. Use the number buttons to enter one of the

device codes from the table.

6. Only for Limited Mode, Press 1.

Note: Skip this step if you do not want to use

Limited Mode.

7. Press the POUND (#) button. If you entered

the code correctly, the mode button flashes three times.

8. Press the blank POWER button to test if the code

works for the device. If it does, the device should

turn off.

9. Turn the device back on and try some other buttons

to make sure they work. Sometimes, the blank POWER button

works when other buttons don’t. If the code works for other

buttons, stop here.

text_dishpvr.fm Page 9 Tuesday, March 2, 2004 12:35 PM

10.If the code you entered doesn’t work, do steps 3 through 9 again

with another device code from the tables.

11.If you cannot find a code that works, try Setting Up Using

Device Code Scan.

SETTING UPUSING DEVICE CODE SCAN

If the code for your device is not listed in the tables on starting page 29,

use this procedure to scan the remote control’s memory for the device

code. Here’s what to do:

1. Use the device’s buttons or its remote control to turn the device

on.

2. Press and hold the mode button for the device you want the

remote to control, for about three seconds. When all the other

mode buttons light up, let go of the mode button - that mode

button should now be flashing.

For example, hold the TV mode button for a TV until all of the

other mode buttons light. When you let go, the TV mode light

will flash.

3. Only for the AUX mode, use the number buttons

to enter 0for a second TV, 1 for a second VCR or

DVD player, or 2 for a tuner or amplifier. Then press

the STAR (*) button.

4. Press the blank POWER button.

5. Press the up or down arrow button until the

device turns off. You will have to do this

repeatedly to scan through all codes.

Note: The mode button for the device will

flash rapidly eight times when you’ve

scanned all the codes for that device.

6. If the remote reaches the correct code, the device

turns off. When this happens, press the POUND (#)

button to store the code in the remote.

text_dishpvr.fm Page 10 Tuesday, March 2, 2004 12:35 PM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Mando a distancia de Dish Network

Dish Network

Dish Network 167820 Manual de usuario

Dish Network

Dish Network 159263 Manual de usuario

Dish Network

Dish Network 20.1 Manual de usuario

Dish Network

Dish Network Platinum Plus 121150 Manual de usuario

Dish Network

Dish Network 40.0 Manual de usuario

Dish Network

Dish Network 52.0 Manual de usuario

Dish Network

Dish Network 20.0 Manual de usuario

Dish Network

Dish Network Digital PVR Manual de usuario

Dish Network

Dish Network 6.3 Manual de usuario

Dish Network

Dish Network Duo ViP 222 Manual de uso y mantenimiento

Dish Network

Dish Network Platinum PVR Remote Control Manual de usuario

Dish Network

Dish Network 40.0 Manual de usuario

Dish Network

Dish Network BASIC REMOTE Manual de usuario

Dish Network

Dish Network Hopper with Sling Manual de usuario

Dish Network

Dish Network ViP 922 Slingloded DVR Manual de usuario

Dish Network

Dish Network 20.0 Manual de usuario

Dish Network

Dish Network 135331 Manual de usuario

Dish Network

Dish Network 54.0 Manual de usuario

Dish Network

Dish Network 11 Hoja de especificaciones

Dish Network

Dish Network DISHPlayer 500 Manual de usuario

Dish Network

Dish Network EZ Manual de usuario

Dish Network

Dish Network 176842 Manual de usuario

Dish Network

Dish Network EZ Manual de usuario

Dish Network

Dish Network 3.1 Manual de usuario

Manuales populares de Mando a distancia de otras marcas

Panasonic

Panasonic EUR7622KB0 Manual de usuario

Bang & Olufsen

Bang & Olufsen Beo4 Manual de usuario

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manual de usuario

Multiplex

Multiplex PROFI TX 9 Manual de usuario

One Remote

One Remote RMB4 Manual de usuario

FUTABA

FUTABA 9ZAP - PART2 Manual de usuario

HR Matic

HR Matic HR MULTI 3 Manual de usuario

Yamaha

Yamaha ACC-GNRST-30-20 Manual de usuario

EisSound

EisSound KBSOUND Manual de usuario

Marantz

Marantz RC101 Manual de usuario

Conrad

Conrad FS20 TC6 Manual de usuario

Anritsu

Anritsu MP1777A Manual de usuario

Niles

Niles WVC100 Guía de solución de problemas

RCA

RCA RCU1300 Manual de usuario

Bang & Olufsen

Bang & Olufsen BEO6 Manual de usuario

GE 94901 Manual de usuario

Onbon

Onbon YQ1-75 Manual de usuario

FUTABA

FUTABA R7108SB Instrucciones de instalación
